BÜHLMANN Quantum Blue User manual

Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
Quantum Blue® Reader
QBSoft User Manual

Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
2
Notice:
It is the policy of BÜHLMANN Laboratories AG to improve products as new techniques and components become
available. BÜHLMANN Laboratories AG reserves the right to change specications at any time. In an effort to
produce useful and appropriate documentation, we appreciate your comments on this user manual. Please contact
BÜHLMANN Laboratories AG.
Trademarks
Trademarks and labels used in this document are property of their respective owners. [2021].
Copyright Information
[© Copyright 2021 by BÜHLMANN Laboratories AG]
Reproduction or republication of this document in any form or format is prohibited without the prior written consent of
BÜHLMANN Laboratories AG.

3
Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
TABLE OF CONTENT
CHAPTER 1: Introduction..............................................................................................................................4
1.1 Preface ....................................................................................................................................................4
1.2 General product description ....................................................................................................................4
1.3 System requirements...............................................................................................................................4
CHAPTER 2: Installation ...............................................................................................................................5
2.1 Installation of the QBSoft Software..........................................................................................................5
2.2 Installation process in two steps..............................................................................................................6
CHAPTER 3: Running Quantum Blue®Reader with QBSoft ........................................................................ 8
3.1 Connecting the Quantum Blue®Reader..................................................................................................8
3.2 Starting Quantum Blue®Reader..............................................................................................................8
3.3 Menu Bar.................................................................................................................................................9
3.4 Measurement.........................................................................................................................................10
3.5 Result Display........................................................................................................................................13
3.6 Results on device (Quantum Blue®Reader) .........................................................................................14
3.7 Results in the PC Backup......................................................................................................................15
3.8 Manage Test Methods ...........................................................................................................................16
3.9 Manage User IDs...................................................................................................................................17
CHAPTER 4: Uninstallation.........................................................................................................................18
4.1 Uninstall QBSoft Software.....................................................................................................................18
Table of Content

Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
4
CHAPTER 2: INSTALLATION
1.1 Preface
The instruction manual is intended for people who will be using the software described here. Errors in the
application can be avoided and trouble-free operation can be ensured only in knowledge of these operating
instructions. It is therefore necessary that the present operating instruction is known to the responsible
persons. For any damage or malfunction resulting from non-observance of the QBSoft Software Manual, we
assume no liability.
Please note the importance of the following symbol, classied according to ISO 3864-2:
Note symbol: Indicates general notes, useful operator tips and operating recom-
mendations which however do not affect the safety and health of the personnel.
1.2 General product description
Easy to use, comprehensive software for the user of the BÜHLMANN Quantum Blue® Reader, offering:
• Control of the Quantum Blue®Reader via PC
• Multi-language user interface
• Status display of important Quantum Blue®Reader functions
• Archiving of test data stored in the Quantum Blue®Reader or the QBSoft Software
• Management of test data stored in the Quantum Blue®Reader or the QBSoft Software
• Printing of all measured (and stored) test data
• Administration of Test Methods and Users in the Quantum Blue®Reader.
The QBSoft Software is designed for a typical workow in a diagnostic laboratory, including maintenance,
administration, archiving and printing of test data of the Quantum Blue®Reader. The installation of the QBSoft
Software should be performed by qualied persons with knowledge of software installations.
Manufacturer:
BÜHLMANN Laboratories AG
Baselstrasse 55
4124 Schönenbuch
www.buhlmannlabs.ch
1.3 System requirements
The installation of the software is very simple, straightforward and can be carried out on:
• Windows®7, 8, 10
• Installed current .NET Framework of your Windows®version
• Intel compatible PC with 1 GHz processor and a minimum of 512 MB RAM
• 100 MB available memory on the hard disc
• CD-ROM drive (optional)
• Monitor with a minimum resolution of 1024 x 768
CHAPTER 1: INTRODUCTION

5
Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
CHAPTER 2: INSTALLATION
2.1 Installation of the QBSoft Software
Insert the CD-ROM.
Open the CD-ROM in the File Explorer.
Start “Software Installer.exe” from the “Software\QBSoft” directory.
Execute installation process.
The software offers the possibility to install QBSoft and drivers simultaneaously or independently.
• Remote control of the Quantum Blue
®
Reader by
your computer requires the installation of QBSoft
and its driver. Select “Install Driver & QBSoft” to
install both Driver and QBSoft Software
(recommended).
•
Manually select “Install Driver”, if QBSoft Soft-
ware is already installed.
•
Manually select “Install QBSoft”, if Driver is
already installed.
• To cancel the installation process select “Exit”.
CHAPTER 1: INTRODUCTION

Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
6
CHAPTER 2: INSTALLATIONCHAPTER 2: INSTALLATION
2.2 Installation process in two steps
If choosing “Install Driver and QBSoft”, a Setup Wizard will appear, guiding through the
installation process:
Note: When installation of Driver and QBSoft is chosen, the installation process is devided
into two steps:
• Step 1: Installation of Lateral Flow Reader (driver)
• Step 2: Installation of QBSoft Software
Step 1: Installation of Lateral Flow Reader
• Select “Next” to proceed the installation of the rst
installation step: The installation of the Lateral
Flow Reader.
• Select “Cancel” to stop the installation.
• Select “Next” to start the installation of the
Lateral Flow Reader.
• Select “Back” to return to the previous step.
• Select “Cancel” to stop the installation.
• To change the location, where to install the
Lateral Flow Reader, click “Browse” to select a
folder.
•
If Lateral Flow Reader should be installed for
everyone using the computer, select “Everyone”,
otherwise leave the pre-selected eld “Just me”.
•
After choosing the folder of installation, select
“Next” to proceed with the installation of the
Lateral Flow Reader.
• Select “Back” to return to the previous step.
• Select “Cancel” to stop the installation.

7
Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
CHAPTER 2: INSTALLATION
• By selecting “Next” Lateral Flow Reader is being
installed. Wait until the installation is completed
and conrm installation.
• Select “Back” to return to the previous step.
• Select “Cancel” to stop the installation.
• After successful installation, the window on the
left appears.
• Select “Close” to nish the rst step of the instal-
lation process and proceed with the second step
of the installation: The installation of the QBSoft
Software.
Step 2: Installation of the QBSoft Software
The installation of QBSoft Software is necessary for
measurement.
•
Select “Next” to start the second installation step.
Installation of QBSoft Software will start automat-
ically. Repeat the same installation steps also
with the QBSoft Software Setup Wizard to
complete the installation process.
• Select “Close” to stop the installation of the
QBSoft Software.

Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
8
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFTCHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT
3.1 Connecting the Quantum Blue®Reader
Connect the Quantum Blue®Reader to the PC via USB cable.
3.2 Starting Quantum Blue®Reader
• Press the ENTER (on Fig. 1, No. 5) button of Quantum Blue®Reader for three seconds to start the
reader. Wait for completion of automatic self-test and self-calibration.
• Start QBSoft Software by double-clicking the QBSoft icon.
BÜHLMANN Laboratorites AG, CH-4124 Schönenbuch / Switzerland
Quantum Blue® Infliximab
REF
B-LFTLIF-RCC15
RFID
RFID Chip Card
Prod. Datum: DD.MM.YYYY
LOT
XXXX
H
YYYY-MM-DD
BÜHLMANN Laboratorites AG, CH-4124 Schönenbuch / Switzerland
Quantum Blue® Infliximab
REF
B-LFTLIF-RCC
RFID
RFID Chip Card
Prod. Datum: DD.MM.YYYY
LOT
XXXX
H
YYYY-MM-DD
1
2
3
4 5
Fig. 1: Quantum Blue®Reader

9
Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT
3.3 Menu Bar
The menu bar contains three menu groups, “File”, “Tools” and “Info”.
File
• Choose “Connect” to establish connection with
the Quantum Blue®Reader.
•
Choose “Select Port” if the QBSoft does not auto-
matically choose the correct port.
•
Choose “Disconnect” to close the connection
between QBSoft and the Quantum Blue®
Reader.
Tools
• Choose “Language” to select the language
setting for the entire user interface of the QBSoft.
After having chosen the required language, the
QBSoft Software must be closed by clicking on
the symbol and re-started again.
Info
• Choose “System Info” to display informations
about the QBSoft Software and the Quantum
Blue®Reader. Note that clicking on “Copy”
copies the information to the Windows®
Clipboard.
• Choose “About” to display information about the
QBSoft Software ID, software version and
manufacturer.

Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
10
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFTCHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT
3.4 Measurement
Click on “Measurement” (Fig. 2, No. 1) to perform a test run using the QBSoft Software. This function allows
the user to select a Test Method stored on the Quantum Blue®Reader and to scan a test cassette.
The system is ready for measurement, if the status bar at the bottom of the screen shows “Connected”
(Fig. 2, No. 2), “Drawer Closed” (Fig. 2, No. 3) and “Ready” (Fig. 2, No. 4). Also displayed in the status bar is
the memory status of the Quantum Blue®Reader. This example shows that 79 test results are currently stored
in the memory of the reader (Fig.2, No.5).
Fig. 2: Measurement screen
1
2345

11
Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT
3.4 Measurement
This section describes the use of Quantum Blue®Reader in combination with QBSoft Software. If Quantum
Blue®Reader is operated without a computer, please refer to the Quantum Blue®Reader User Manual.
A
In order to start measuring, make sure the connection is
established, indicated by the green square in the lower left
corner of the window (Fig. 4, No. 1).
Place the RFID card on top of the reader (Fig. 3) until the
device has read the information on the RFID card. If the
RFID chip card is not read correctly after some seconds,
please hold the card a little further down the back of the unit.
The precise position of “A” can vary slightly between differ-
ent Quantum Blue® Readers. The “Info” display will conrm
the successful reading of the RFID card (Fig. 4, No. 2).The
Test Method (Fig. 4, No. 3) will be automatically selected
based on the information on the RFID card.
Fig. 3: Quantum Blue®Reader + RFID Card
1
2
3
Fig. 4: Measurement screen

Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
12
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT
3.4 Measurement
The user has to enter a Patient ID and select a User ID before scanning of the Test Cassette can be started.
Additionally, the user can enter Expiry Date information of the test (cassette) and add some comments.
The user-accessible and / or –editable functions are:
The drop-down list box “Method” displays the Test
Methods which are stored on the Quantum Blue®
Reader. Select the Test Method to be run.
Reading of RFID card automatically selects the
respective test method (see respective instruction for
use of the tests).
The user-editable text box “Patient ID” is used to add
a Patient ID to the results.
The drop-down list box “User” displays the Users who
are registered on the Quantum Blue®Reader. Select
the corresponding User ID. Manage User IDs under
section 3.9.
The user-editable text box “Exp. Date” allows to add
the Expiration Date of the Test Cassette to the results.
The user-editable text box “Comment” is used to add
comments to the results.
Start the test measurement (scanning process) on
Quantum Blue®Reader with the QBSoft Software.
During the measurement the function of the “Start’
button changes to a “Stop” function, so that the
scanning (and incubation) process can be interrupted
at any time. Note that the “Start” button is enabled
only when all of the user entry items (at least the
Method, Patient ID and User ID) are selected.
The grey “Info” box describes the current status of the
Quantum Blue®Reader while a test run (measure-
ment) is performed.
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT

13
Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
3.5 Result Display
After completion of the measurement detailed results, the instrument settings including the test lot, the
operator (user), etc are displayed in a printable test report as shown in Fig. 5:
1) Clicking the “Print” button allows the printing of the detailed results on the default Windows®printer.
2) If you would like to continue with the measurement repeat steps according to the chapter 3.4.
3) The detailed test results are listed in result tables as shown in Fig. 6 and 7. These result tables are used to
view, store, up/download, print and manage test results saved either on the Quantum Blue®Reader or
in the PC Backup (see chapters 3.6 and 3.7).
4) Manage User IDs and Test Methods (see chapters 3.8 and 3.9).
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT
Fig. 5: Test report
1
2 3 4

Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
14
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT
3.6 Results on device (Quantum Blue®Reader)
The table in Fig. 6 displays the results which are stored on the Quantum Blue®Reader. By choosing the item
“On Device”(Fig. 6) and clicking the button “Load Results from Device” (Fig. 6, No. 1) the results are displayed
in the table (Fig. 6):
1) Load all results from the Quantum Blue®Reader
2) Unselect all results in the table / Select all results in the table
3) Delete selected results from the Quantum Blue®Reader
4) Save selected results in the PC Backup* / Save selected results into a folder of choice
5) Print selected results with the default Windows®printer
6) Save selected results as a CSV le
* Selected results will be saved into “C:\Dokuments and Settings\All Users\Application Data\LFSuite\ Backup” or “C:\Pro-
gramData\ LFSuite\Backup” or into “C:\...\LFSuite\ Backup” (the exact location depends on the Windows®operating sytem
version and your personal computer settings).
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT
2
45 6
1
3
Fig. 6: Result screen

15
Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
3.7 Results in the PC Backup
The table shown in Fig. 7 displays the results which are stored in the PC Backup folder. By choosing the item
“In PC Backup” the results stored in the backup folder are automatically displayed. As long as the result les
are not deleted from the PC Backup, they remain stored and will be displayed each time the item “In PC
Backup” is selected:
1) Load results from PC Backup
2) Unselect all results in the table / Select all results in the table
3) Delete selected results in the PC Backup folder*
4) Save selected results into a folder of choice
5) Print selected results with the default Windows®printer
6) Save selected results as a CSV le
* Selected results will be saved into “C:\Dokuments and Settings\All Users\Application Data\LFSuite\ Backup” or “C:\Pro-
gramData\ LFSuite\Backup” or into “C:\...\LFSuite\ Backup” (the exact location depends on the Windows
®
operating sys-
tem version and your personal computer settings).
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT
1
2
345 6
Fig. 7: Result screen

Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
16
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT
3.8 Manage Test Methods
The function “Manage Test Methods” is used for the administration of the Test Methods stored on the
Quantum Blue®Reader. These methods can be transferred to and uploaded from the Quantum Blue®
Reader.
See Fig. 8:
1) Move the selected method upwards / downwards in the list
2) Delete the selected method from the list
3) Add a method le to the list from a PC folder
4) Save a method from the list as a le in a folder on the PC
5) Save methods to device / Load methods from device
Note: All currently stored methods will be overwritten while saving a fresh list of methods! If you
want to add just ONE new method to the existing methods on the Quantum Blue
®
Reader, rst
load all methods from the device then add the new method to a free space (line) in the method
list, and nally save the method list containing all methods to the device again.
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT
1 2 3
5
4
Fig. 8: Manage Test Methods

17
Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
3.9 Manage User IDs
The User IDs can be transferred to and uploaded from the Quantum Blue®Reader.
See Fig. 9:
1) Editable User ID table. Each User ID can hold up to 10 characters.
2) Move the selected User ID up / downwards in the list
3) Delete the selected User ID from the list
4) Save the entire list of all User IDs to the device
5) Load the entire list of all User IDs from the device
Note: All currently stored User IDs will be overwritten while saving a fresh list of User IDs! If you
want to add just ONE new User ID to the existing Users on the Quantum Blue® Reader, rst
load all User IDs from the device then add the new User ID to a free space (line) in the users
list, and nally save the users list containing all User IDs to the device again.
CHAPTER 3: RUNNING QUANTUM BLUE®READER WITH QBSOFT
1
54
2 3
Fig. 9: Manage User IDs

Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
18
4.1 Uninstall QBSoft Software
The uninstallation of the QBSoft Software is very simple. The software can be uninstalled in a usual manner
via the system control of the Windows®.
These procedure depends on your Windows® version. Please refer to the respective instructions.
CHAPTER 4: UNINSTALLATION

19
Quantum Blue®Reader Soware User Manual, Version 4.0
Release Date: 01-02-2021
BÜHLMANN products are subject to the quality standards within the quality management system
according to ISO 13485.

BÜHLMANN Laboratories AG Phone [phone]
Baselstrasse 55 Fax orders [phone]
4124 Schönenbuch [email protected]
Switzerland www.buhlmannlabs.ch
For more information please contact:
BÜHLMANN Laboratories AG
Phone: [phone]
Email: [email protected]
www.buhlmannlabs.ch
