b-mMla PSA User manual

Deodorizing System
OPERATION MANUAL
Model No.:
PSA
Please read and retain this manual prior to usage

1
CONTENTS
SAFETY INSTRUCTIONS 2
PARTS AND COMPONENTS 3
INSTALLATION GUIDE 4
OPERATION INSTRUCTION 5
FILTER CARE AND REPLACEMENT 6
CLEANING AND MAINTENANCE 7
TROUBLE SHOOTING 8
PRODUCT SPECIFICATION 9
DEAR VALUED CUSTOMER,
Thank you for your purchase of the Deodorizing System PSA. For your safety and to optimize the capabilities of
this appliance, please read and retain this manual prior to operating the appliance; please keep it in a convenient
and safe location for future reference.

2
SAFETY INSTRUCTIONS
Please read the following instructions before use.
The appliance is designed for domestic use and may only be operated in accordance with the following
instructions.
WARNING
1. Do not expose the product to water and do not unplug the product with wet hands.
2. Do not clean or spray the appliance with water, liquid, detergent, or any flammable liquids.
3. Do not obstruct the air inlet and outlet.
4. Always use the supplied AC power adapter.
5. To help ensure safe operation, regularly inspect the AC power adapter and AC power cord. If damaged, stop use
immediately and call service centre for assistance.
6. Do not use the appliance when it is damaged.
7. Do not disassemble, repair, or modify the appliance.
8. Do not use the appliance in the presence of burning incense and chemical fumes.
9. Do not use the appliance near heat generating devices such as stove, oven, fireplace, heater etc. or direct sunlight.
10. Unplug the appliance if it is not being used.
11. Do not use the appliance in a location subject to significant changes in temperature changes.
12. Do not use the appliance in hot and humid environments such as bathrooms or kitchens.
13. If the appliance produces a strange noise, burning smell or smoke, immediately remove the power plug from the electric
socket and call the service center.
14. To reduce the risk of electric shock, this equipment has a polarized plug (one blade is wider than the other). This plug will
only fit in a polarized outlet in one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit,
contact qualified personnel to install the proper outlet. Do not alter the plug in any way.
SAFETY PRECAUTIONS
1. Ensure that the power plug is connected to a correctly designated electric socket as specified on the rating plate.
2. If the power cord is damaged, it must be replaced by the manufacturer or a qualified service agent.
3. The appliance is not intended for use by persons with reduced physical, sensory or mental capabilities unless they are
under the supervision of or have been given instruction by a person who is responsible for their safety.
4. When in the presence of the appliance, children should be supervised.
5. The appliance is not a substitute for proper ventilation or regular vacuuming and should not be used in place of an
extractor hood or stove top range hood.
6. Ensure the power socket is in good condition and properly connected. Ensure that the appliance is properly connected
and that the plug is not over-loaded or over-heated.
7. Only use the appliance on a dry, stable and level surface.
8. Ensure that the appliance operates at a minimum distance of 10 cm from adjacent walls or objects.
9. Do not push, lean against or exert excessive force on any part of the appliance. Do not stick sharp objects into any part of
the appliance.
10. If the Filter assembly is not properly installed, the appliance would not operate.
11. Maintain good air circulation when using the appliance.
12. Prior to cleaning and maintenance, the appliance must be disconnected from the power supply.
13. When the appliance is turned on for the first time, warm air may be released from the air outlet. This is normal due to
catalytic oxidation taking place inside the NCCO Reactor.

3
PARTS AND COMPONENTS
Illustration Diagram
A
B
C
J
D
F
E
G
K
H
I
L
Front Rear
Bottom
A – Main body
B – Power button/ Mode indicator
C – Top cover
D – Air outlet
E – Filter assembly
F – HEPA filter
G – NCCO Reactor
H – AC power adapter
I – Power connector
J – Air inlet
K – Power jack
L – Rating label

4
INSTALLATION GUIDE
Using the appliance for the first time:
1. Read the instruction manual and retain for future reference.
2. Remove all packaging, use a soft dry cloth to clean all the removable parts, the product cavity, and then re-
assemble parts.
3. Position the appliance on a dry, solid, level surface and ensure the appliance is provided with reasonable
space of at least 10 cm to operate effectively.
4. Check power sockets and any extension cords to confirm compliance with product requirements. Ensure
that the appliance is plugged in prior to use.
5. The appliance is equipped with sensors for detecting filter assembly’s position. The appliance will not
operate with if filter assembly is not properly placed.
6. When the appliance is turned on for the first time, warm air may be released from the air outlet. This is
normal due to catalytic oxidation taking place inside the NCCO Reactor.
1. Open the top cover
Lift up and remove top cover.
2. Detach filter assembly
Pull out filter assembly from main body.
3. Remove plastic packaging materials of filters
Remove all packaging materials before using the appliance.
4. Fit the Filter assembly to original position
Fit the Filter assembly back to the appliance and finally mount the top cover.
Attention:
Please make sure the filter assembly is fitted in right direction, the arrows
should be matched.

5
OPERATION INSTRUCTION
Connect the appliance to a suitable power source, the power button will flash to indicate it is ready for use.
1. Connect the appliance to the power adaptor.
2. Power On/Off and Mode Selection
Power on: Press the Power Button/ Mode Indicator to turn on the
appliance. When the power is on, the system would start operate at
Silence Mode and Mode Indicator shows the colour of green.
High Performance Mode: Press the Power Button/ Mode Indicator again
(second time) after turning on the appliance, the Mode indicator shows
the colour of blue.
Power off: Press the Power Button/ Mode Indicator again (third time) to
turn off the appliance.

6
FILTER CARE AND REPLACEMENT
1. Filter lifetime may vary depending on the environment, usage and location of the appliance.
2. To maintain optimal performance of the appliance, only use the recommended filters.
3. Always disconnect appliance from the power supply prior to disassembly.
4. When the NCCO Reactor needs to be replaced, it is recommended that the HEPA Filter be replaced at the
same time.
Suggested Filter Cleaning and Replacement Cycles
Filter Cycle Method
HEPA Filter Every 6 months
*
Replacement
NCCO Reactor Every 2 years
*
Replacement
*The suggested filter cleaning and replacement cycle may differ depending on the operating environment.
1. Open the top cover
Lift up and remove top cover.
2. Change HEPA Filter or NCCO Reactor
Take out the filter assembly from the
appliance, and take out the HEPA Filter by
pulling the belt from filter assembly.
Replace the new HEPA Filter or NCCO
Reactor. Fit the Filter assembly back to
the appliance.
Tips:
When the NCCO Reactor is needed to be
replaced, HEPA Filter is recommended to
be changed at the same time.
3. Mount the top cover
Make sure the front cover is firmly locked.

7
CLEANING AND MAINTENANCE
1. Always disconnect the appliance prior to disassembly for cleaning or replacing filters.
2. Do not clean or wash HEPA Filter or NCCO Reactor with water.
1. Cleaning Exterior Body
Use dry and soft cloth to clean the appliance.
Tips:
Use a damp cloth warranted but do not use abrasive materials.
2. Cleaning Air Inlet and Outlet
Clean the air inlet and outlet with a soft brush or vacuum cleaner.
Warning:
Never rinse or soak HEPA Filter and NCCO Reactor with water.

8
TROUBLE SHOOTING
Problems
Solutions
The appliance does not operate.
Check if the appliance is connected to a power source.
Switch on the appliance.
No air is blowing through air outlet.
Check if the appliance is connected to a power source.
Switch on the appliance.
When the appliance is used in a more polluted area, the
treatment will takes a longer time. Use more units or use the
appliance for longer period if necessary.
After a long period of operation, the air
quality has still not improved.
The filter may require cleaning and replacement.
Clean and replace the filters.
HEPA filter may be clogged.
Change the HEPA filter. (Please refer to “FILTER CARE AND
REPLACEMENT”).
Airflow speed from air outlet becomes slow.
Make sure all packaging materials are removed.
Make sure all packaging materials are removed.
Make sure the air inlet and outlet are not blocked by external
objects.
Remove all adjacent objects that block the air inlet and outlet.
The appliance produces unusual noise.
The appliance may be malfunctioning.
Seek advice from call service center or qualified service
agent.
The appliance emits unusual smell or smoke
(e.g. smoke, flame, burning)
Turn off the appliance and disconnect from power source.
Contact service center or qualified service agent immediately.

9
PRODUCT SPECIFICATION
Country US / CANADA China / Hong Kong
Power Supply
110-240V 50/60Hz Power
Adaptor with DC 12V @ 1A
110-240V 50/60Hz Power
Adaptor with DC 12V @ 1A
Silent 2.7W 2.7W
Power
Consumption
(W)
Mode
High Performance
5.5W 5.5W
Silent 5.1 m
3
/hr
Air Flow Volume
(m
3
/hr)
Mode
High Performance
10.2 m
3
/hr
Silent 26 dB
Noise Level
(dB)
Mode
High Performance
45 dB
Applicable Room Size (m
2
) 107.6~215.3 ft
2
/10~20 m
2
Product Dimensions (W x D x H)
6.1”x6.2”x6.9” ( Inch )
15.6 x 15.8 x 17.6 ( CM )
Weight (kg) 2.6 lb / 1.2kg
Stage 1 Stage 2 Stage 3
Treatment System
Active Oxygen Generator HEPA Filter NCCO Reactor
Function Sterilization
Remove dust, hair and
airborne particles such as
allergens and pollen,
bacteria, viruses and fungi.
Remove odor, decompose
and oxidize harmful
pollutants such as
formaldehyde and VOCs.
