Babelio Retractable Gate User manual

Retractable
Gate
USER MANUAL(GUIDE)
WARNING
Mounting hardware must be mounted into a stud in the wall.
If the door must be installed at the top of the stairs, the door should be at
least 6 inches from the leading edge of the top stairs.
Gate must swing away from stairs when opening.
Product and Accessories List
Your safety gate contains the following:
PLEASE CHECK TO MAKE SURE YOU HAVE THE FOLLOWING PARTS:
A
A
B
C
D
E
F
Wall Anchor
B
Mounting Screw
C Wall Hinge D
Lower Latch
E Upper Latch F
E-latch
G
G
Gate Frame H
H
Template
NOTE: The bottom of the template must be close to the ground and kept
perpendicular to the ground
Paste template
Installation Location
Hardware Installation
Bottom of stairs Top of stairs
lf the gate is used at the bottom of
the stairs, it must be placed on the
lowest stair to prevent children from
climbing upstairs.
lf the gate is used at the top of the
stairs, it must be placed 15 cm (6 in)
back from the top step to prevent
children from falling down the stairs.
Doorway & Opening
Front View
Top View
Side View
1
2
Use a tape measure to gure out
the opening width.
90°
x1
x1
x1
x1
x1
x2
(The latch is not in the hardware package,
the latch is installed on the door rail)
NOTE: The maximum spacing from the oor to bottom of gate is 2.5", the minimum
spacing is 1"
2022-10
10
1"~2.5"
15cm
6in

NOTE: Keep the door frame closed when tightening the Q1 screwNOTE: When installing the lower shaft, please keep the b end facing up and the a
end facing the ground
NOTE: Keep the door frame open while tightening the Q2 screw
Install the lower shaft
3 5
6
4
10
11
12
x
x
x
x
x
x
x
x
Install the upper shaft
a
a
b
b
Tighten the Q1 screw 7
Tighten the Q2 screw
Q2
Q1
Unscrew the E-latch
9
8Extend the door rail to the wall and determine the sticking position of D
and E
Tear o the sticker
E
Upper Latch
D
Lower Latch
Paste D and E to the wall
Adjust the width of the door frame again,so that the distance between the
handle and the upper latch is less than 0.078in, and then lock the E- latch
E Upper Latch
D Lower Latch
Open the door frame, install the upper latch and lower latches
(0.078in≈1mm)
E
Upper Latch
D
Lower Latch
