BABY DELIGHT AJEY-402R User manual

Please read the following instructions and warnigns carefully.
Keep this instruction manual for future reference.
Tools required: Screwdriver and Drill (not included)
For technical support see back page.
Adult use only.
Adult assembly required. Keep small parts
away from children when assembling.
WARNING:
Warnings & Guidelines:
INSTRUCTION MANUAL
Mom Applauded Features:
• 5” video monitor screen
• Wireless camera with night vision
• Movement and position monitor with an alert for inactivity
• User friendly interface
®
STRANGULATION HAZARD - Keep cord
out of baby’s reach. NEVER place camera
or cords within 3 feet of the crib. Use enclosed Security Clips to help secure
cord away from baby’s reach. Never use extension cords with AC Adapters.
Only use the AC adapters provided.
WARNING:
1

Warnings & Guidelines • Continued
THIS PRODUCT CANNOT REPLACE RESPONSIBLE ADULT SUPERVISION.
• STRANGULATION HAZARD - Keep cord out of baby’s reach.
NEVER place camera or cords within 3 feet of the crib. Use enclosed Security
Clips to help secure cord away from baby’s reach. Never use extension cords
with AC adapters. Only use the AC adapters provided.
• When an AC adapter is plugged into an electrical outlet, do not touch the
exposed end.
• Test monitor before first use, periodically, and when changing location of
the Camera.
• Do not use monitor near water (such as bathtub, sink, etc.)
• Keep monitor away from heat sources (such as stoves, radiators, etc.).
• Make sure there is proper ventilation around all monitor components. Do
not place on sofas, cushions, beds, etc. which may block ventilation.
• Nursery monitors use public airwaves to transmit signals. This monitor may
pick up signals from other monitors or similar devices and signals broadcast
by this monitor may be pickd up by other receivers.
• This product is not a toy. Do not allow children to play with it.
• This product contains small parts. Adult assembly required. Exercise care
when unpacking and assembling the product.
WARNING:
• Use only the original rechargeable batteries provided. Please contact
Summer Infant, Inc. for replacement batteries. Contact information can be
found on bottom of these instructions or on the battery itself.
• Do not mix old and new batteries.
• Do not mix alkaline, standard, or rechargeable batteries.
• Batteries are to be inserted with correct polarity.
• Clean battery and product contacts prior to battery installation.
• Do not short-circuit supply terminals.
• Only the recommended batteries or equivalent are to be used, volts
and size.
• Remove the batteries when product is stored for long periods of time or
when batteries are exhausted.
• Dispose of exhausted batteries properly.
• Do not recharge non-rechargeable batteries.
• Rechargeable batteries are only to be charged under adult supervision.
• Keep all batteries away from children.
BATTERY WARNING:
2

500mA
DC-7.5V
• 6 Cable Clips
• 1 Actor and Wall Mount Screw
• 1 camera, 1 monitor, 1 movement unit
• 2 AC Adaptors
Features • Camera
®
®
3
X6X1X1
Hardware
Camera
AC Adapters
Monitor
LensMicrophone
Movement Unit Charging Station AC Adapter Jack
Power On LED Power On/Off
Movement
Unit
All Components

DC-7.5V
500mA
/ OK
ZZ
MENU /
VIDEO /
VOL
®
Features • Monitor
4
Sound/Lights
Video On/Off
Adjustable
Kickstand
Battery
Compartment
AC Adapter
Plugin
(Underneath)
Magnetic Clip for
Clothing
Volume
Ok/SelectAlarm?
Toggle Up/Down
Speaker Power on LED
Menu
®
NOTE: There is no need to pair any of the components. The Camera, Monitor and
Movement Unit have all been synched at the factory.

5
Camera Setup • Adult Assembly Required
1
2 3
5
4
WALL MOUNT: Place camera in desired location
Place camera in desired location
Tighten screw until only 1/4”
(6.3mm) of the scre is exposed.
(screwdriver not included)
Determine a location for the
Camera that will provide the
best view of your baby in the
crib. Place the Camera on a
flat surface, such as a dresser,
bureau or shelf. NEVER place
Camera or cords within 3 feet
of the crib
There is no need to pair any of the components. The Camera, Monitor and
Movement Unit have all been synched at the factory.

Be sure to
test reception
and Camera
positioning.
6
6
6
7
Secure the cord to the wall using the 6 Security
Clips included to keep cord away from baby’s reach.
TABLE TOP: Place camera in desired location, secure cord, and turn on.
Be sure to
test reception
and Camera
positioning
Be sure to test your Monitor’s reception before initial use. We also recommend
testing your Monitor’s reception periodically.
PLEASE KEEP IN MIND THAT THE 5” AUDIO, VIDEO, & MOVEMENT MONITOR
WILL NOT PROVIDE THE SAME LEVEL OF PICTURE QUALITY AS YOUR
TELEVISION WITH CABLE, SATELLITE DISH, OR DIGITAL SERVICE.

®
®
Movement Unit Setup • Adult Assembly Required
Movement Unit Icon Status
1
2
ATTACHING MOVEMENT UNIT: Place the top of The Movement Unit with
logo facing UP and the slip the magnetic bottom unit behind the clothing
with the magnets away from baby.
Press the power button on the front of the Movement Unit for 3 seconds
to power on. You should see movement info and orientation of the
baby (side, back, stomach) on the screen.
The two pieces
should connect
together with
the clothing in
the middle.
Research shows that sleeping on their back
is the safest position for babies.
The Movement Unit will transmit movement info and baby’s orientation (side,
stomach and back) to the Camera. The Camera will transit this information to the
Monitor and display that information on the screen. For best results, make sure
the Movement Unit is within 30 feet of the Camera.
LoBatt Movement Icon – This means the Movement Unit needs
to be charged. The Movement Unit will flash an amber light
and you will hear a single beep on the Monitor. The Movement
Unit can be re–charged on the camera (takes apaproximately
3 hours) in the dock. The Movement Unit has a battery life of
approximvately 24 hours of continuous use.
SIDE
STOMACH
BACK
Low
Battery
®
7

To Disable the Movement & Orientation Information
Charging Icon – This means the Movement Unit is currently in
the recharging dock in the Camera and is charging.
Screen will display (show screen) TURN
MOVEMENT INFO AND ALARM OFF
(YES OR NO). Use the side button to
move to YES or NO and hit OK.
Press the Menu button on the Monitor
Locate the Monitor icon and use the
Up button to move to the DISPLAY
ICON and press OK.
No signal icon – This means the Movement Unit is out of range
or powered off while not charging in the dock. Please locate
the movement unit and place it in the charging dock on the
Camera or move the Movement unit closer to the Camera. You
will hear a single beep on the Monitor as well.
Disabled Icon – This means the user has disabled the
Movement unit. You can choose NOT to show the movement
info and position info on the Monitor screen. This also disables
all alarms on the Monitor. The Movement Unit will still alarm if
no movement is detected for 15 seconds.
Charging
No
Signal
No
Signal
menu up/down select
8
To disable the movement and orientation information from being displayed on
the screen, use the following steps. PLEASE NOTE: This also disables all alarms on
the Monitor.

®
9
Pause Icon – Pressing the Pause
button on the Monitor when the Alarm
Icon is on the screen and the Monitor
is alarming will silence the Alarm for
15 seconds. After 15 seconds, if there is
still no movement detected, the alarm
will resume.
Alarm Icon – After no movement has
been detected for 15 seconds, the
Monitor will begin to beep. After 20
seconds of no movement detected, the
Alarm icon will appear on the Monitor
screen and the Monitor will
beep rapidly.
alarm select
beep
ON
OFF
Trouble Shooting
The Camera, Monithor and Movement Unit have all been paired. If any of the
components need to be paired, please see below:
To Pair the Camera and Monitor:
®
12
Place the Monitor and Camera within 3 feet of
each other.
Press the Menu
button on the
Monitor and use
the side button
to move to the
CAMERA icon.
Power off the
Camera and
power on the
Monitor.
3ft
menu
3
up/
down

500mA
DC-7.5V
®
10
ON
OFF
To Pair the Movement Unit and Camera:
4
6
1
5
7
2
Use the Up button to move to
the PAIRING button and press
the OK button.
Power the Camera on.
Place Monitor and
Movement Unit within
3 feet of each other.
Power off the Movement
Unit (hold the power
button for 3 seconds)
and power on the
Camera.
Press the Menu button on the Monitor and
use the side button to move to the Movement
Unit icon.
You should see the PAIRING
SCREEN.
You should see live video on
the Monitor.
menu
up/
down
select

®
11
3 4
Use the Up button to move to
the PAIRING button and press
the OK button. You should see the
PAIRING SCREEN.
Power the Movement Unit
on (hold the power button
for 3 seconds). You should see
movement and orientation
information on the Monitor.
ON

Cleaning Information
Limited Warranty
Care & Cleaning
Caring for your new 5” Audio, Video, Monitor is very easy...
• Simply use a mild soap and damp cloth to wipe down the chair. You may also
rinse off the chair outside with a garden hose and allow to air dry. The tray may
be rinsed off in the sink and dried prior to use.
• Do not allow the chair to remain outside and exposed to the elements of the
sun, wind, and rain for long periods of time. Do not fold up a damp chair or put
the chair back into the bag until it is completely dry.
At Baby Delight, Inc. we make innovative and high quality products for babies,
children and their parents. We warrant this product to be free from defects in
material and workmanship existing at the time of manufacture for a period of
90-days from the date of initial purchase (sales receipt is required for proof of
purchase). If such a defect is discovered during the limited warranty period, we
will, at our sole option, repair or replace your product at no cost to you.
This limited warranty does not cover claims resulting from misuse, failure to
follow the instructions on installation, maintenance and use, abuse, alteration,
involvement in an accident, and normal wear and tear.
For warranty service or replacement part information:
USA: Please call 1-401-597-6868, or write to Consumer Services, 30 Martin St.
Cumberland, RI 02864
Some replacement parts may be available for purchase after this limited warranty
expires. Please visit us at www.babydelight.com or call us at 1-401-597-6868
for details.
Macari Baby, Inc. 401-333-6800
30 Martin Street, Cumberland, RI 02864
www.babydelight.com
[e-mail]
MADE IN CHINA
BD04020, BD0401012

FCC Caution:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment .This equipment should be installed and operated with
minimum distance 20cm between the radiator& your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
IC Warning
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le fonctionnement
The device is compliance with RF exposure guidelines, users can obtain Canadian information on RF
exposure and compliance.The minimum distance from body to use the device is 20cm.
Le présent appareil est conforme
Après examen de ce matériel aux conformité ou aux limites d’intensité de champ RF,
les utilisateurs peuvent sur l’exposition aux radiofréquences et la conformité and compliance d’acquérir
les informations correspondantes. La distance minimale du corps à utiliser le dispositif est de 20cm.
