BaBylissMEN SUPER STUBBLE XTP User manual

SUPER STUBBLE XTP
7898DU
SAFETY CAUTIONS
• Original instructions. Read these safety precautions
carefully before using the unit! This appliance should
only be used as described within this instruction
booklet. Please retain for future reference.
IMPORTANT CHILD SAFETY
• ALWAYS keep out of the reach of very young children
(during and after use).
• This appliance should not be used, cleaned or
maintained by children.
• Always take extra care if used on children or near
children.
• Do not use on very young children.
IMPORTANT SAFETY
• WARNING! Do not use this appliance near
bathtubs, showers, basins or other vessels
containing water.
• Do not immerse the appliance in water or other liquids.
Keep the appliance dry.
• UK Only: Do not use this appliance in the bathroom.

• Outside the UK: If using the appliance in a bathroom,
unplug after use as the proximity of water can be
dangerous even if the appliance is switched off. For
additional protection the installation of a residual current
device (RCD) with a rated residual operating current not
exceeding 30mA is advisable in the electrical circuit
supplying the bathroom. Ask your installer for advice.
• The appliance’s charging stand and/or adaptor must
be kept away from sources of water so that they do not
fall into the water.
• CAUTION! Keep the power cord and the appliance
dry. For appliances with a removable power supply
unit, remove the power cord before cleaning or using
the appliance under running water.
• Always inspect the appliance before use for noticeable
signs of damage. Do not use if damaged or if the
appliance has been dropped. In the event of damage
contact the Conair Customer Care Line (refer to ‘UK
After Sales Service’ section for further information).
• Do not use the appliance if the charging adaptor or lead
is damaged. In the event of damage, discontinue use
immediately. If the charging adaptor or lead is damaged,
it must be replaced by the manufacturer. Return the
appliance to the Customer Care Centre (refer to ‘UK
After Sales Service’ section for further information). No
repair must be attempted by the consumer.
• Only use the attachments supplied with this appliance.
• WARNING! For the purposes of recharging the battery,

only use the detachable charging supply unit provided
with this appliance (CA81). This symbol indicates there
is a detachable power supply for means of charging.
• Do not leave the appliance unattended when switched
on.
• Do not leave the appliance plugged in for more than
24 hours.
• Unplug immediately if any problems occur during use.
• Do not place the appliance on any surface whilst in
operation.
• Special care is required when using the appliance close
to the ears, eyes and face.
• This appliance may be used by children aged from 8
and older and people with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction on the
safe use of the appliance and understand the hazards
involved. Children must not play with the appliance.
• Thisproductcontainsa(insertbatterytype)rechargeable
battery that is not to be removed from the appliance
for charging. The batteries in this appliance are non-
replaceable. Batteries must be disposed of safely at
the end of life. Please take to a recycling centre for
safe disposal. If the battery leaks, avoid touching it and
dispose of it at a recycling centre.
• The supply terminals are not to be short circuited.
• For domestic use only.
• This product complies fully with all appropriate EU

and UK Legislation and the standards relevant to this
type and class of appliance. We are an ISO9001:2015
certied company that continually evaluates our
Quality Management System performance. If you have
any queries regarding product safety and compliance,
please contact the Conair Customer Care Line (refer to
‘UK After Sales Service’ section).
WEEE - END-OF-LIFE ELECTRICAL AND
ELECTRONIC EQUIPMENTS
In everybody’s interest and to actively participate in
protecting the environment and human health:
• Do not discard your products with your unsorted
household wastes.
• The WEEE (Waste electrical and electronic equipment)
must be collected separately.
• Use the return and collection systems dedicated to
the WEEE available in your area. In this way, some
materials can be recycled, re-used or recovered.
• By ensuring this product is disposed of properly, you
will help prevent potential negative consequences for
the environment and human health due to possible
content of hazardous substances.
For more detailed information about the disposal of this
product, please contact your local household waste
disposal service.

INSTRUCTIONS FOR USE
IMPORTANT! Only use the adaptor and attachments supplied with
this appliance.
General
• Always inspect the appliance before use to ensure the trimmer blades
are free from hair, debris etc.
• Use on clean, dry hair that has been combed until
Oiling Instructions
• For optimum cutting performance, it is highly recommended to oil the
blades after every use.
• When using the oil for the rst time, unscrew the cap and cut off the
very end of the plastic tube with a pair of scissors.
• Switch the appliance on.
• Holding the trimmer at a 45 degree angle, gently squeeze the oil tube
and apply 2 drops directly onto the blades.
• Leave the unit on for a further few seconds to allow the oil to
thoroughly spread along the length of the blades.
• Switch off the unit and remove any excess oil by gently dabbing with
a cloth before using on hair.
Charging the appliance
• This trimmer is equipped with lithium ion batteries.
• Before using for the rst time, the appliance should be fully charged
continuously for 3 hours. This initial super-charge ensures optimum
power performance to ensure smooth fast trimming every time.
Maximum battery capacity will only be reached after 3 charging and
discharging cycles.
• Plug the power adapter into the socket on the underside of the
charging stand.
• Plug the power stand adaptor into a suitable bathroom shaver
socket. If you don’t have a bathroom shaver socket, use the 3-pin
plug adaptor supplied with the product. Place the 2-pin adaptor into
the back of the supplied 3-pin plug adaptor and plug into a mains

power socket and switch on at the wall.
Note: Always place the trimmer in the base with the ‘I/0’ switch in the
OFF position.
• When the unit is charging the display lights up indicating the running
time. The minutes will gradually increase until it reaches maximum
capacity of 70 minutes.
• A full charge will take 80 minutes and will supply enough power for
minimum 70 minutes continuous cordless use. The approximate
remaining using time is shown on the LED display.
• The Super Stubble XTP comes with a quick charge feature. A 5 minute
charge will provide enough power for approximately 3 minutes use.
• In order to maintain the optimum capacity of the rechargeable
batteries, the appliance should be recharged for 3 hours every 3
months approximately.
• When the LED display has less than 5 minutes left, the time symbol
indication will change to red.
Preserving the batteries
In order to maintain the optimum capacity of the rechargeable batteries,
the trimmer should be fully discharged and then recharged for 3 hours
every six months.
Preparation for Use
Always inspect the super stubble before use to ensure the cutting head
is free from hair and debris and is running smoothly.
Operation
To switch the Super Stubble XTP on, press the ‘0/I’ button. The LED
will show the selected cutting length and approximate usage time
remaining. After 10 seconds, the blue LED for the usage time will
switch off but the cutting length LED will be remain illuminated whilst
the motor runs. When there is approximately 5 minutes left shown on
the LED display, the time symbol will change colour to red and will
also start to ash. When the LED displays ‘00’, this indicates that the
unit needs to be recharged, however it may continue to run for a short
while after.

Using the comb guide
The comb guide allows you to change the cutting length of your
trimmer. You’ll need to experiment to nd your preferred length, but as
a guide, 0.4mm will give you very short stubble, whilst 1.6mm will give
you a longer stubble look. 2mm+ will give you a short beard.
• Ensure the comb guide is correctly positioned by pushing the comb
guide gently downwards to secure into place.
• Use the digital touch control ‘up’ or ‘down’ buttons to adjust the
telescopic comb guide to the required length.
• The cutting lengths are displayed on the LED screen in ‘mm’ – scroll
through the available length settings with the digital touch controls.
There are 24 length settings available: 0.4mm-5.0mm in 0.2mm
increments.
• Select your required length – the length setting will then remain
displayed on the LED screen.
• Press the power button to switch the super stubble on.
Memory Function
The stubble trimmer has a memory function that stores the last chosen
length setting. When the unit is switched off the comb guide returns
to 0.4mm position. When the trimmer is switched back on the comb
guide automatically moves up to the last chosen length setting.
Travel lock feature
• The BaBylissMEN Super Stubble XTP has a travel lock feature which
will lock all buttons from activating accidently.
• To activate the travel lock, press and hold the ‘I/0’ button for 2
seconds until the time display counts downs from 5 to 1. When the
countdown reaches 1, the lock signal is shown.
• To de-activate the travel lock press and hold the ‘I/0’ button for 2
seconds until the time display starts to count down from 5 to 1 and
the motor switches on and starts running. The travel lock is now
de-activated.
• When you place the unit in the charger, the travel lock is automatically
deactivated.

Using the trimmer without the comb guide
• Using without the comb guide is ideal for detailing/shaping and
general tidying of edges.
• To detach the comb guide, gently hold the trimmer in one hand and
with your thumb and index nger push up on each side of the comb
guide (Fig. 1). Flip the comb guide to the back of the unit, gently pull
down and secure under the latch to lock into place (Fig. 2). To release
the comb guide, pull down and move away from the latch (Fig. 3).
• Switch the Super Stubble XTP on by pressing the ‘power on’ button.
The LED will illuminate and the blades will start to move.
• If you are looking for an ultra-close nish, you can use the trimmer
without the comb guide. This will give you an extremely short cut.
IMPORTANT: When using the trimmer without the comb guide, the
cutting length will be below 0.4mm. The length setting shown on the
LED screen will no longer be relevant when the comb guide is detached.
Super Stubble Top Tips
• Use on clean, dry hair.
• If possible, when using for the rst time, try and grow your facial hair
for a few days before cutting so you can trim down to a level that is
best for you.
• Set the cutting length as required.
• It is always best to start cutting with a longer length rst, then trim
again if the length is longer than desired.
Fig. 1 Fig. 2 Fig. 3

• Hold the Super Stubble XTP against the hair, the teeth of the comb
guide should be pointing upwards and should be at against the face.
• Move the trimmer upwards through the hair, a little at a time, against
the direction of hair growth. The oating and contouring head will
follow the curves of your face to ensure both accuracy and comfort.
• The super stubble will work most effectively when cutting through
the hair at its own speed – never force through the hair. You may
experience a little resistance when trimming the neck area, where hair
is thicker and grows in many different directions. This is completely
normal.
• Just like shaving, extra time should be given when trimming under
the neck area, as again this is where hairs grow in many different
directions.
• Never switch the trimmer off whilst in the hair.
CLEANING & MAINTENANCE
• Regular cleaning will maintain the high performance of your Super
Stubble XTP.
• Switch off and remove the power cord if connected.
• Detach the comb guide by gently lifting the front of the comb guide
from both sides and ipping it over to the back of the unit and locking
it into position by clicking it securely onto the fastener on the back
of the handle.
• Use the cleaning brush supplied to brush away any hair and debris.
Do not use a sharp object to clean the trimmer blade.
• The blades can be removed to aid cleaning.
• To remove the blades hold the handle of the Super Stubble XTP with
one hand, place your thumb underneath the blades and push the
blades away from the handle.
• Gently blow away any hair trapped beneath the blades.
• The blades can be rinsed under the tap. After rinsing the blades they
may need to be oiled. See ‘Oiling Instructions’ above.
• Before re-attaching the blade to the trimmer, ensure the blades are
dry and moving blade is in the centre. See (Fig. 4).

Fig. 4
• Please do not use any chemical liquids when cleaning the trimmer.
• Ensure you clean the blades after each use and before storing away.
BATTERY DISPOSAL
This appliance contains Li ion batteries. To protect the
environment this appliance and its batteries must be disposed
of safely. At the end of its life, please take this appliance to
a recycling centre, where the internal rechargeable battery should
be removed by a professional and recycled separately. For more
information about the recycling of electrical and battery operated
appliances please contact your local council ofce or your household
waste disposal service. For specic enquiries regarding the replacement
of batteries in this product please contact our Conair Customer Care
Line (refer to ‘UK After Sales Service’ section).

UK GUARANTEE
This BaBylissMEN appliance is guaranteed for consumer use for 3
years and is only valid within the United Kingdom.
This guarantee covers consumer use only i.e. defects occurring under
normal use within the home from date of purchase or date of delivery,
whichever is later.
If the product develops a fault due to defects in materials or manufacture
within 12 months from the date of purchase, to avoid delays and
unnecessary inconvenience, where possible please return the product
to the point of purchase for an exchange.
If the product develops a fault due to defects in materials or manufacture
after 12 months from the date of purchase, and within the guarantee
period, Conair UK After Sales Service will repair or replace the product.
Exclusions
This guarantee will no longer be valid meaning that The Conair Group
Ltd will not be liable to repair or replace your product where:
1.) The appliance has been used on a voltage supply other than that
which is marked on the product, or advised within this instruction
booklet
2.) The appliance has been purchased from an unauthorised stockist*
3.) The appliance is used for professional / non domestic usage
4.) Repairs or alterations have been attempted by unauthorised persons
5.) The failure of the appliance is a direct result of misuse
6.) The failure is a result of not following the instructions for use
This guarantee does not cover any cosmetic damage due to misuse
of the product nor any damage to persons or property that occurs
because of product misuse.

*unauthorised stockists include, but are not limited to online auction
sites, private sellers and those selling second hand goods, refurbished
products etc.
Please contact the Conair Customer Care Line on 03705 133 191
(09:00 to 17:00 Monday to Friday) or e-mail [e-mail] for
further information on authorised stockists.
It is important to retain your proof of purchase. We recommend
attaching your receipt to this page.
Even where a refund may be applicable, no refund will be provided
without a valid receipt or proof of purchase, we will only be able
to offer a repair or replacement service. Please note this does
not apply if the product was purchased directly from The Conair
Group Ltd.
Guarantees on replacement products run from the original purchase
date or date of delivery, whichever is later, and not from the date of
replacement.
This guarantee is an additional benefit and does not affect your
statutory rights as a consumer.
If you have any queries regarding this guarantee please contact the
Conair Customer Care Line on 03705 133 191 (09:00 to 17:00 Monday
to Friday) or e-mail [e-mail]

UK AFTER SALES SERVICE
For further advice on using the appliance, contact the Conair Customer
Care Line on 03705 133191 (09:00 to 17:00 Monday to Friday) or email
your enquiry to [e-mail].
If you should need to return your appliance to us please send it to the
following address:
Customer Care Centre
Conair Logistics
Unit 4
Revolution Park
Buckshaw Avenue
Buckshaw Village
Chorley
PR7 7DW
Please enclose your name and address, together with a copy of proof
of purchase and details of the fault.
Please note this Instruction Booklet is not the guarantee.

IB-19/302A
