Babytone BM-1T User manual

Baby Monitor
User Manual
Contact us: [email protected]
Website: www.getbabytone.com

Contents
1. Introduction ..............................................1
2. Warnings ...................................................1
3. Packing List.............................................. 2
4. Guide to Parts.......................................... 3
4.1. Overview of the Camera Unit.....3
4.2. Overview of the Baby Monitor ...4
5. Activate the Device ................................ 6
5.1. Camera Unit ..................................6
5.2. Baby Monitor.................................6
5.3. Pairing ............................................6
6. Using the Device ..................................... 7
6.1. Setting up ......................................7
6.2. Pan, tilt, and zoom .......................8
6.3. Screenshot (TF card required) ...8
6.4. Night vision mode.........................9
6.5. Talk Mode.......................................9
6.6. Video on/off...................................9
6.7. Volume............................................9
7. Baby Monitor Menu Options ................. 9
7.1. Playback (TF card required) ..... 10
7.2. Vox Monitoring............................ 10
7.3. Music ............................................ 10
7.4. Feeding Clock............................... 11
7.5. Camera.......................................... 11
7.6. Bluetooth ..................................... 12
7.7. General settings ......................... 14
8. Maintenance.........................................15
9. Troubleshooting....................................16
10.Specifications .......................................18
11. Symbols.................................................19
12.FCC Statement .................................... 20

1
1. Introduction
It is intended to monitor infants or children
when they are alone through real-time
images captured by the camera and audio
communication. Also, paired with the
optional device Baby Sleep Monitor, data of
oxygen level and heart rate can be tracked
and displayed through the integrated
communication module of the camera,
ensuring your acknowledgement of the
child’s conditions.
2. Warnings
This device is compliant with all relevant
standards regarding electromagnetic
fields and is, when handled as described in
the User's Guide, safe to use. Therefore,
always read the instructions in this User's
Guide carefully before using the device.
⚫Adult assembly is required. Keep small
parts away from children when
assembling.
⚫This product is not a toy. Do not allow
children to play with it.
⚫This product is not a substitute for
responsible adult supervision.
⚫Keep this user's guide for future
reference.
⚫Keep the cords out of the reach of
children.

2
⚫Do not cover the product with a towel
or blanket.
⚫Test this monitor and all its functions
so that you are familiar with it prior to
actual use.
⚫Do not use the product in damp areas
or close to water.
⚫Do not install the product in extreme
cold or heat, direct sunlight, or close
to a heat source.
⚫Only use the chargers and power
adapters provided. Do not use other
chargers or power adapters as this
may damage the device and battery
pack.
⚫Do not touch the plug contacts with
sharp or metal objects.
⚫Connect the power adapters to easily
accessible electrical outlets.
3. Packing List
⚫Baby Monitor (Display screen, Model:BM-1R)
⚫Camera Unit ( Model:BM-1T)
⚫Charging Plug and Power Cable for Baby
Monitor
⚫Charging Plug and Power Cable for
Camera Unit
⚫Bracket
⚫User Manual

3
4. Guide to Parts
4.1. Overview of the Camera Unit
1. Camera Lens
2. Indicator LED
3. Temperature & Humidity Sensor
4. Speaker
5. Reset Key
6. Power Adapter Socket
7. Bracket
8. Screw Holes
9. Connection Hole
Note: You can either fix the
camera to anywhere you
need by adjusting the bracket
or to the wall after inserting
screws.
1
2
3
4
5
6
7
98

4
4.2. Overview of the Baby Monitor
1. LCD Screen
2. Joystick
Camera mode: Tilt up or down, pan left or
right.
Menu mode: Up, down, left, right.
3. OK Key
4. Menu/Exit Key
Press to open the Menu options or exit.
5. Indicator LED
Blue light: talking.
Green light: charging, it turns off when
charging is complete.
6. Talk Key
Press to speak to your baby.
7. Microphone
8. TF Card Slot
9. Power Adapter Socket
10. Power Key
Long press to power on/off.
Short press to turn off/wake up screen.
11. Volume Key
12. Speaker
13. Antenna
Lift the antenna for optimal signal reception.
6
2
3
4
8
5
9
1
13
12
10
11
7

5
Baby Monitor menu icons
Icon
Description
Talk mode ON
Recording
Volume
Ambient humidity
Ambient temperature
TF card full
Vox monitor state
Signal intensity
Oxygen level (if paired with
‘Baby Sleep Monitor’)
Heart rate(if paired with
‘Baby Sleep Monitor’)
* The Baby Sleep Monitor is an optional
device.
* When the TF card is full, it will loop
recording, please export the needed
data (MENU>Camera>Record>Export)
from the TF card before it is overwritten.

6
5. Activate the Device
5.1. Camera Unit
a) Connect the micro USB interface of the
power adapter to the Camera Unit, and
the other end to the electrical outlet.
Note:
⚫Compatible power adapter output:
DC 5V, 1A.
5.2. Baby Monitor
a) Connect the Type C interface of the
power adapter to the Baby Monitor
and the other end to the electrical
outlet for charging.
b) Once the charging is finished. Press
and hold the Power key for 3
seconds to turn on the Baby Monitor.
c) When the Camera Unit and Baby
Monitor are all switched on, the
pairing process will begin
automatically.
Note:
⚫Compatible power adapter output:
DC 5V, 2A.
5.3. Pairing
The Camera Unit has been paired with
your Baby Monitor before delivery.
a) Switch on the two units, the Baby
Monitor will show a “No Camera”
symbol .

7
b) Wait patiently for automatic pairing,
you can monitor the pairing process
through the LED light on the camera.
Indicator
Status
Description
Purple, red,
and blue
light
30s
alternating
flashing
Power on,
waiting for
configuration
Red light
30s quick
flashing
Unpaired,
disconnected
Blue light
30s on then
off
Paired,
connected
30s flashing
then off
Paired,
disconnected
30s quick
flashing
then off
Configuring
wireless
network
If the Camera Unit lose its link with Baby
Monitor or you need to pair with a new
camera, follow the procedures below:
a) Press the Menu Key on the Baby
Monitor.
b) Control the joystick to select
Camera>Unbind to disconnect the
current camera.
6. Using the Device
6.1. Setting up
a) Place the Camera Unit in a convenient

8
location (e.g. on a table) and point the
camera lens towards the area you
want to monitor.
b) Adjust the Camera Unit's angle by
controlling the joystick to rotate the
camera up, down, left and right until
you are satisfied with the image in the
Baby Monitor.
Note:
⚫Do not place the Camera Unit within
baby's reach.
⚫If there is interference with the
picture or sound, try moving the units
to different locations, and ensure that
they are not close to other electrical
equipment.
6.2. Pan, tilt, and zoom
The camera can be remotely controlled
from the Baby Monitor.
a) Manipulate the joystick to tilt upward
or downward, or pan left or right.
b) Double click the OK button to enter
zoom mode, then press the volume -/+
button to select among 1X to 4X
zoom.
c) Press the Menu key to exit zoom
mode.
6.3. Screenshot (TF card required)
a) Click the OK key during the monitoring
to take a screenshot.

9
b) Remove the TF card and check the
pictures in your computer.
6.4. Night vision mode
The Camera Unit has high-intensity
infrared LEDs for picking up clear images
in the dark. When the built-in photo sensor
detects a low level of ambient light, the
LEDs will automatically activate and the
screen on the Baby Monitor will display in
black and white.
6.5. Talk Mode
Press the TALK button on the Baby
Monitor, and the icon will be displayed
at the top of the screen while the light is
on. Then you can talk to your baby
through the camera's loudspeaker.
6.6. Video on/off
Press the Power key to turn the LCD
display on or off. The monitor will enter
sleep mode with audio on.
6.7. Volume
Press the + or – button to select the
desired volume level from Level 0-4. (The
default Volume level setting is Level 1.)
7. Baby Monitor Menu Options
More functions can be accessed to by
pressing the Menu key. Please control the
joystick to select, press the OK key to

10
confirm, and press the Menu key to exit.
7.1. Playback (TF card required)
This function is turned on by default
(prompt the user to install TF card), you
can activate it after inserting the TF card,
please follow the procedures below:
a) Press Menu>Playback, and select the
record of a specific date.
b) Press the OK key to stop or play the
video.
c) Control the joystick up or down to
choose the desired speed.
d) Control the joystick left or right to fast
forward/backward with a step-size of
5 min (default)/30min/1h/2h.
7.2. Vox Monitoring
a) Press Menu>Vox.
b) Select from options off, low, medium
and high, and the icon will be
lightened at the top of the screen.
c) Having set the sensitivity, the screen
can be aroused from the sleep mode
whenever the corresponding sound is
detected.
7.3. Music
a) Press Menu>Music.
b) Select your desired song from the 8
lullabies available, or turn on the loop
option to play a single song

11
continuously or 8 songs in turn.
Note: The device cannot be muted in this
page, the default volume is level 1. The
volume can be changed in camera setting
page, Menu>Setting>Camera.
7.4. Feeding Clock
a) Press Menu>Setting>Feeding Clock.
b) Choose the desired duration and
repeat or not. You will then be
reminded by the clock.
c) You can turn off the reminder in the
message box.
7.5. Camera
Press Menu>Setting>Camera to manage
the camera.
⚫Volume
Choose the desired camera volume
from the options.
⚫Record
➢Export: export the needed video
recordings to the TF card, then
remove the card and check them
in the computer.
➢Format: clear the record data.
➢Record: start/stop recording after
inserting a TF card.
Note:
⚫The device features loop
recording, please export the
needed data from the TF card

12
before it is overwritten.
⚫One-eighth of the storage space
is reserved for storing the
exported video. It may need to be
exported in stages when the
video file is too large.
⚫Exporting will take more time
when too many files are selected.
⚫No other operations are possible
while the video is being exported.
⚫Taking out the TF card while
recording will cause damage to it.
⚫Upgrade
1) Download the latest firmware (if
any) in the TF card.
2) Choose Upgrade and press OK
key to confirm.
3) Wait few minutes to enjoy an
updated camera, and restart the
Baby monitor for the updated
version.
⚫Unbind
Choose Unbind and press OK key to
confirm.
7.6. Bluetooth
Baby sleep monitor is an optional device for
monitoring the baby’s heart rate and
oxygen level.

13
Pair with Baby Sleep Monitor (BBSM)
a) If the monitor has never been paired
with an BBSM, please press
Menu>Setting>Bluetooth>Add device
to start searching.
b) Press and hold the Power key of
BBSM to turn it on, and select its right
name (BBSM S1+the last four number
of SN) on the Monitor screen.
c) If the devices are not successfully
paired in 2 minutes, you can either
return to last page or select ‘Rescan'.
If paired successfully, the device
management page will be displayed.
Note:
⚫The Baby Sleep Monitor will be
automatically paired next time if
it is not unbound. You could
manage the BBSM in the
Bluetooth page.
⚫The icon“ --”and “ --”will
appear at the top of the screen
when the BBSM is paired but no
value is displayed yet.

14
Manage the bluetooth device
a) Press MENU>Setting>Bluetooth to
start managing Reminder and Unbind.
b) Modify reminder thresholds.
Available
Range
Step-
size
Default
value
Avg O2 level
80-99
1
90
Heart rate
(High)
110-200
10
130
Heart rate
(Low)
40-100
10
70
Note:
⚫The reminders are off by default.
⚫The reminder may pop up at any
time accompanied by a notice
when detecting a value out of
the setting range. The notice will
stop in 2 minutes after you press
OK key.
c) You can press Unbind to remove the
current device.
7.7. General settings
Press Menu>Setting>General for the
following settings.
⚫Display
Select the desired display duration
from the four options (1 minute, 10
minutes, 30 minutes, always).
⚫Brightness
Select the desired brightness from the
four options (40%,60%,80%,100%).

15
⚫Date & Time
Select 12 Hour mode or 24 Hour mode.
You can also press date or time to
calibrate.
⚫Language
Select the desired language from
provided options.
⚫Temperature
You can switch the temperature unit
here.
⚫System
Descriptions of both units are
displayed. You can restore the default
setting of the device by pressing the
Default button, or unbind or upgrade
(TF card required) the camera.
8. Maintenance
Clean the device with a slightly damp cloth
or with an anti-static cloth. Never use
cleaning agents or abrasive solvents.
⚫Do not clean any part of the device
with thinners or other solvents and
chemicals - this may cause
permanent damage to the product
which is not covered by the warranty.
⚫Keep the device away from hot,
humid areas or strong sunlight, and
do not let it get wet.

16
⚫Every effort has been made to ensure
high standards of reliability of the
device. However, if something does
go wrong, please do not try to repair
it yourself - contact Customer Service
for assistance.
Note:
Always power off and disconnect the
power adapter before cleaning the device.
9. Troubleshooting
If you experience difficulties in operating
your device, refer to the troubleshooting
guide below.
No display
⚫Charge the device.
⚫Press and hold Power key on the
Baby Monitor to turn it on.
⚫Press the reset on camera if no
video in 30 seconds.
If the Camera Unit has lost its link with
the Baby Monitor
⚫Charge the device.
⚫Move the Camera Unit closer to the
Baby Monitor.
⚫Reset the units by disconnecting
them from the power supply. Wait

17
for about 15 seconds before
reconnecting.
⚫See 5.3 Pairing, if there is a need to
re-register the units.
⚫The reset key may be mistakenly
pressed. Please unbind the Camera
Unit from Baby Monitor, then wait
for the automatic pairing with
Camera Unit powered on.
Noise interference on your Baby Monitor
⚫Make sure that there is at least 3 to
6 feet between the 2 units to avoid
audio feedback.
⚫The Camera Unit may go out of
range if it is too far away. Move the
Camera Unit closer to the Baby
Monitor.
⚫Make sure that the Baby and Baby
Monitors are not near other
electrical equipment, such as a
television, computer or
cordless/mobile telephone.
⚫Keep the device at least 5ft (1.5m)
away from 2.4 GHz products or turn
them off.
⚫If the signal is weak, try moving the
Baby Monitor and/or Camera Unit
to different positions in the rooms.

18
10. Specifications
Baby Monitor
Frequency
2.4 GHz
Brightness
control
4 steps
Volume control
4 steps
Resolution ratio
720P
Temperature
–10°C～45°C (Operating)
–30°C～70°C (Storage)
Humidity
20%～85% (Operating)
20%～85% (Storage)
Battery
4400mAh rechargeable
lithium-polymer battery
Adapter
5V/2A
Interface
Type-C
Camera Unit
Frequency
2.4 GHz
Image sensor
GC2053（1/2.9）
Resolution ratio
1080P
Lens
f 3.92mm
IR LED
940nm4
Viewing angle
94.9°(D)/79.1°（H）
Temperature
–10°C～45°C (Operating)
–30°C～70°C (Storage)
Humidity
20%～85% (Operating)
20%～85% (Storage)
Adapter
5V/1A
Interface
Type C
