Bacharach CO2 Monitor 2800 User manual

          
CO2Monitor 2800
Instruction 19-9220
Operation & Maintenance
Rev. 6 – June 2004
Product Leadership • Training • Service • Reliability

CO2Monitor 2800
Instruction 19-9220
WARRANTY
Bacharach, Inc. warrants to Buyer that at the time of delivery this Product
will be free from defects in material and manufacture and will conform
substatially to Bacharach Ic.’s alicable secicatios. Bacharach’s li-
ability and Buyer’s remedy under this warranty are limited to the repair or
replacement, at Bacharach’s option, of this Product or parts thereof returned
to Seller at the factory of manufacture and shown to Bacharach Inc.’s reason-
able satisfaction to have been defective; provided that written notice of the
defect shall have been given by Buyer to Bacharach Inc. within one (1) year
after the date of delivery of this Product by Bacharach, Inc.
Bacharach, Inc. warrants to Buyer that it will convey good title to this Product.
Bacharach’s liability and Buyer’s remedy under this warranty of title are
limited to the removal of any title defects or, at the election of Bacharach, to
the replacement of this Product or parts thereof that are defective in title.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND ARE GIVEN
AND ACCEPTED IN LIEU OF (I) ANY AND ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE: AND (II) ANY OBLIGATION, LIABILITY,
RIGHT, CLAIM OR REMEDY IN CONTRACT OR TORT, WHETHER OR
NOT ARISING FROM BACHARACH’S NEGLIGENCE, ACTUAL OR IM-
PLIED. The remedies of the Buyer shall be limited to those provided herein
to the exclusion of any and all other remedies including, without limitation
incidental or consequential damages. No agreement varying or extending
the foregoing warranties, remedies or this limitation will be binding upon
Bacharach, Ic. uless i writig, siged by a duly authorized ofcer of
Bacharach.
Register Your Warranty by Visiting
www.bacharach-inc.com
BACHARACH®is a registered trademark of Bacharach, Inc.
© Copyright 1998, Bacharach, Inc., all rights reserved.
Printed in U.S.A.
A

Instruction 19-9220
CO2Monitor 2800
i
CONTENTS
SPECIFICATIONS.............................................................................. ii
1.0 INTRODUCTION .................................................................................1
1.1 General.............................................................................................1
1.2 Main Features..................................................................................1
1.3 Battery .............................................................................................1
1.4 Units of Measurement.....................................................................1
1.5 Important Note ................................................................................2
1.6 Cleaning ...........................................................................................2
1.7 Sunlight............................................................................................2
1.8 Servicing...........................................................................................2
2.0 OPERATION .........................................................................................3
2.1 Reading Mode ..................................................................................3
3.0 MAINTENANCE ...................................................................................4
3.1 Battery Low .....................................................................................4
3.2 Air Calibration.................................................................................4
3.3 Calibration Using Higher Gas Concentration ...............................5
3.4 Test Mode.........................................................................................5
3.5 Fault Condition Warning ................................................................6
3.6 Data Logging....................................................................................6
3.7 Software Version/Serial Number.................................................... 6
3.8 Factory Authorized Reset Mode......................................................6
4.0 PARTS & SERVICE .............................................................................7
4.1 Parts and Accessories......................................................................7
4.2 Bacharach Service Centers .............................................................7

CO2Monitor 2800
Instruction 19-9220ii
SPECIFICATIONS
Range: 0 - 50,000 ppm* or 0 - 5%
Resolution: 0.01% or 100 ppm
Accuracy: ±5000 ppm CO2
Temperature: 0 - 40° C
Relative Humidity: 10 - 95% non-condensing
Response Time: <10 seconds to 90% of reading
Size: 140 (L) x 65 (W) x 20 (D) mm
(5.5 x 2.6 x 0.8 in.)
Weight: 200 grams (0.44 lbs.)
Case: ABS Plastic
IP55 (NEMA 3R)
Available Models: Standard Instrument .............................19-3319
Instrument with 110 VAC Charger .......19-7101
Instrument with 230 VAC Charger .......19-7102
* Note that ppm is the standard as supplied. With the optional

Instruction 19-9220
CO2Monitor 2800
1.0 INTRODUCTION
1.1 General
The Bacharach CO2Monitor Model 2800 is easy to use, but it is essen-
tial that these Operating Instructions are read prior to use.
The CO2Monitor is designed to warn the user of increasing Carbon Diox-
ide levels in the range of 0 to 50,000 ppm. The unit is based on the Infra-
red absorption principle and has two preset alarm levels - normally 5,000
ppm and 10,000 ppm. When either of these levels is reached, a combina-
tion of audible and visual alarm signals will be activated until the CO2
level returns below the lowest preset level. It is a compact, easy-to-use
unit and can be hand-held or attached to a belt.
1.2 Main Features
• Audible and visual warnings if CO2exceeds preset levels.
• Easy to operate with user-friendly screen display.
• Easy calibration in clean air.
• Functional test mode.
• Fault condition warning.
The unit is normally supplied complete with a battery charger and oper-
ating instructions.
1.3 Battery
The battery should provide 8 to 10 hours of continuous use when fully
charged. When the BATTERY LOW indicator is activated, the unit must
be recharged as soon as possible using the battery charger (supplied)
which connects to the socket on the side of the unit.
1.4 Units of Measurement
Models are available with readout of CO2concentration in either parts
er millio (m) or % (uit must be recogured usig the otioal
BACH-COM Software). Please note that 1 % = 10,000 ppm and 0.01 % =
100 ppm.
1

CO2Monitor 2800
Instruction 19-9220
1.5 Important Note
Always ensure that the sensor grille located on the front of the unit is un-
obstructed and open to the atmosphere. A quick instrument check can be
performed by breathing directly into the sensor grille. This will cause the
indicated CO2level to increase and may cause the instrument to alarm.
A - Digital Display
B - Gas diffusion grille
C - Alarm light
D - IrDA communication link
E - Alarm light
F - Audible alarm location
G - Test button (fl)
H - Battery charging and
ear phone socket
I - Air calibration button (f2)
J - On/Off Button
1.6 Cleaning
Keep the unit clean by wiping with a soft cloth dampened with a mild
detergent solution.
1.7 Sunlight
The unit should not be left out in direct sunlight, or in other areas where
excessive heat exists, for long periods since component damage due to
overheating may result.
1.8 Servicing
There are no user-serviceable parts inside the CO2Monitor.
Unauthorized disassembly of the unit will invalidate the warranty.
2

Instruction 19-9220
CO2Monitor 2800
2.0 OPERATION
2.1 Reading Mode
When the instrument is switched on, there will be a 20 second (approxi-
mately) warm up time before the CO2level present in the atmosphere
surrounding the user is displayed. The ON/OFF button should be pressed
quickly when switching the unit on and held down for approximately 2
seconds when switching the unit off.
CO2 PPM CO2
MONITOR 300
Whe the uit has bee tured o, a “codece bee” will soud for
0.25 seconds every 30 seconds. This should NOT be interpreted as an
alarm condition. The unit has two preset alarm levels which are normal-
ly set to indicate the presence of Carbon Dioxide in concentrations above
5,000 ppm or 10,000 ppm (factory preset levels). The levels can be factory
set at customer secied levels, or ca be reset usig the BACH-COM
Software (See Section 4.1).
When the CO2level rises above the low alarm level:
• The dislay will show the cocetratio ad ash oce er secod.
• The Alarm LEDs will ash oce er secod.
•The beeper will sound intermittently once per second.
When the CO2level rises above the high alarm level:
• The dislay will show the cocetratio ad ash oce er secod.
•The Alarm LEDs will be lit continuously.
•The beeper will sound continuously.
3

CO2Monitor 2800
Instruction 19-9220
3.0 MAINTENANCE
3.1 Battery Low
When the battery voltage falls below a predetermined level, the screens
will alternate between the following:
Low Batt and PPM CO2
300 300
In addition, the alarm will emit three rapid tones every 30 seconds. The
unit must be given a full charge as soon as possible. Charging time is
between 1 and 1.5 hours. Once the unit is fully recharged, it will emit a
constant beeping tone for 30 seconds and display:
CHARGING then CHARGED
>>>>>
3.2 Air Calibration
The unit can be calibrated, approximately, in clean outside air (assumed
to be 340 ppm CO2) by pressing and holding down the f2button for a
minimum of 3 seconds. It is essential to ensure that the unit is in clean
air before attempting an air calibration. If this condition is not ensured,
incorrect readings will be obtained. Be careful that your breath does not
affect this air calibration procedure. A 340 ppm calibration gas cylinder
can be used (See Section 4.1 for a list of Calibration accessories).
Hold the f2button down and the following sequence of displays will ap-
pear.
A i r C a I
A i r C a I
0 K
The gas display screen will reappear after the f2button has been re-
leased. If the calibration was unsuccessful, or if the f2button was re-
leased prematurely, then the display will show the following:
A i r C a I
Failed
4

Instruction 19-9220
CO2Monitor 2800
If this happens, retry the Air Calibration procedure, ensuring that the
unit is only exposed to clean outside air. If the procedure is still unsuc-
cessful then the unit must be returned to a Bacharach Service Center
(see Section 4.2) for evaluation. This procedure will provide a good low
end CO2calibration.
3.3 Calibration Using Higher Gas Concentration
The unit should be checked periodically with a higher concentration of
CO2gas, depending on usage (every 3-6 months). Check the unit with a
gas typically in the 1.5 to 3.0% CO2range using the optional Calibration
Accessories (Section 4.1). Accuracy should be ±10% of reading.
If during the calibration check, the instrument reading is outside of the
tolerance of the check gas used, the instrument can be returned to a
Bacharach Service Center (see Section 4.2) for recalibration.
3.4 Test Mode
To activate the TEST MODE, switch the unit on, and then press and
hold down the f1button. Both LEDs will illuminate and the alarm will
sound. The following screen will be displayed:
TestMode
Power
Provided that both alarm LEDs illuminate, the alarm sounds and the
display is as shown, the unit is ready for operation. If any of these func-
tions are NOT operating correctly, the unit must be returned immedi-
ately to Bacharach for service.
In the lower part of the Test Mode screen is a bar graph showing the ap-
proximate amount of battery power available. As the power in the unit
reduces, the bar graph decreases in size.
Full Empty
5

CO2Monitor 2800
Instruction 19-9220
3.5 Fault Condition Warning
The unit can warn the user of an internal fault, i.e. a source failure or
blockage in the Infrared path. When a fault occurs, both LEDs will illu-
minate and the alarm will sound continuously. The following screen will
display until the unit is switched off.
FAULT
If the fault condition warning is activated at any time, then the unit
must be returned to Bacharach for service.
3.6 Data Logging
When the CO2Monitor is switched on, it will automatically begin storing
time, date and CO2levels at 30 second intervals. Optional BACH-COM
Software allows this interval to be changed (Section 4.1).
Readings are stored with their real time to the nearest second. There is
storage capacity for more than 1,500 sets of readings. Once the storage
capacity has been exceeded, the latest readings will overwrite the oldest
stored data - i.e. rst i, rst out.
NOTE: Optional BACH-COM Software is available to pro-
duce tables and plots of real time CO2exposure (See Section
4.1 for part numbers).
3.7 Software Version/Serial Number
While holding the f1button down, turn the unit ‘on’ in order to retrieve
the instrument software version and issue date. Releasing the f1button
will dislay the istrumet serial umber for ve secods.
3.8 Factory Authorized Reset Mode
This function should only be activated when advised by a Bacha-
rach service representative as it may alter calibration.
While holding down f2 butto, tur uit “o”. The dislay will show...
FACTORY
SETTINGS
Keep f2button depressed for 5 more seconds until the display shows...
FACTORY
RESET OK
6

Instruction 19-9220
CO2Monitor 2800
4.0 PARTS & SERVICE
4.1 Parts and Accessories
Accessories
IrDA Interface Kit & BACH-COM Software ..............................19-3301
12 VDC Charger w/Cigarette Lighter Adapter .......................... 19-3302
Earphone ......................................................................................19-3303
Protective Boot .............................................................................19-3304
Stand.............................................................................................19-3307
Carrying Case ..............................................................................19-3311
Replacement Parts
Battery Pack.................................................................................19-3306
110 VAC USA Plug Charger........................................................19-3312
230 VAC European Plug Charger ...............................................19-3313
Calibration Accessories
Calibration Kit .............................................................................19-8027
Calibration Cup............................................................................19-3305
Calibration Gas:
340 ppm CO2 ...........................................................................24-1125
2500 ppm CO2 .........................................................................24-1130
7

CO2Monitor 2800
Instruction 19-9220
4.2 Bacharach Service Centers
México
Bacharach de México
Playa Regatas No. 473 Tercer Piso
Col. Militar Marte
Delegación Iztacalco, 08830
México D.F. México
Phones: [phone]
[phone]
FAX: [phone]
Email: [e-mail]
Europe
European Headquarters
Bacharach Instruments
Sovereign House, Queensway
Leamington Spa
Warwickshire CV31 3JR
United Kingdom
Phone: [phone]
Fax: [phone]
Email: [email protected]
Sales / Service Center - Denmark
Bacharach Instruments Int'l
P.O. Box 44
39 Lindegade
DK 6070 Christiansfeld Denmark
Phone: [phone]
Fax: [phone]
Email: [email protected]
8
United States
California
7281 Garden Grove Blvd.,
Suite H
Garden Grove, CA 92841
Phone: [phone]
Fax: [phone]
Email: [email protected]
New Jersey
7300 Industrial Park
Rte. 130, Bldg. 22
Pennsauken, NJ 08110
Phone: [phone]
Fax: [phone]
Email: [email protected]
Pennsylvania
621 Hunt Valley Circle
New Kensington, PA 15068
Phone: [phone]
Fax: [phone]
Email: [email protected]
Canada
Bacharach of Canada, Inc.
250 Shields Court Unit #3
Markham, Ontario L3R 9W7 Canada
Phone: [phone]
Fax: [phone]
Email: [email protected]

Instruction 19-9220
CO2Monitor 2800

Headquarters:
621 Hunt Valley Circle, New Kensington, PA 15068
Ph: 724-334-5000 • Fax: [phone] • Toll Free: 800-736-4666
Website: www.bacharach-inc.com • E-mail: [email protected]
Printed in U.S.A.
