Backyard TF2089904-KK-00 User manual

TF2089904-KK-00 Eng Page 1 of 22 20150422 V.1
30 QT. Aluminum
Turkey Fryer Set For Outdoor Use Only
Model# TF2089904-KK-00
Assembly, Use and Care Manual
Tools required:
Phillips screwdriver / Adjustable wrench
Thanks you for purchasing this outdoor cooking appliance.
Please read Safety and Precaution statements, Grill Maintenance, Leak Testing
Regulator / Cylinder connection and Lighting Grill before using grill for first time.
This instruction manual contains important information necessary for the proper
assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling and using the
appliance.
Follow all warnings and instructions when using the appliance.
Keep this manual for future reference.

TF2089904-KK-00 Eng Page 2 of 22 20150422 V.1
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and immediately call your fire
department.
Failure to follow these instructions could result in fire or explosion which could
cause property damage, personal injury or death.
DANGER
1. Never operate this appliance unattended.
2. Never operate this appliance within 10 ft (3.0 m) of any structure, combustible
material or other gas cylinder.
3. Never operate this appliance within 25 ft (7.5 m) of any flammable liquid.
4. Do not fill cooking vessel beyond maximum fill-line.
5. Never allow oil or grease to get hotter than 400°F or 200°C. If the temperature
exceeds 400°F (200°C) or if oil begins to smoke, immediately turn the burner or
gas supply OFF.
6. Heated liquids remain at scalding temperatures long after the cooking process.
Never touch cooking appliance until liquids have cooled to 115°F (45 °C) or less.
7. If a fire should occur, keep away from the appliance and immediately call your fire
department. Do not attempt to extinguish an oil or grease fire with water.
Failure to follow these instructions could result in fire, explosion or burn hazard
which could cause property damage, personal injury or death.
WARNING
Combustion by-products when using this product contain chemicals known to the State of
California to cause cancer, birth defects, or other reproductive harm.
WARNING
This Appliance is not intended for commercial use.
Safety Symbols
The symbols and boxes shown below explain what each heading means. Read and follow all
of the messages found throughout the manual.
DANGER
Danger: Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
Warning: Indicates a potentially hazardous situation which, if not avoided, will result in death
or serious injury.

TF2089904-KK-00 Eng Page 3 of 22 20150422 V.1
CAUTION
CAUTION: Indicates a potentially hazardous situation or unsafe practice which, if not
avoided, may result in minor or moderate injury.
WARNING
1. Never leave the appliance unattended. Keep children and pets away from the
appliance at all times.
2. The use of alcohol, prescription or non-prescription drugs may impair the
consumer‟s ability to properly assemble or safely operate the appliance.
3. This appliance is for OUTDOOR USE ONLY. DO NOT use in building, garage or
any other enclosed area.
4. This appliance is not intended to be installed in or on a boat. This appliance is not
intended to be installed in or on recreational vehicles.
5. This appliance is not intended for and should never be used as a heater.
6. When cooking, the fryer / boiler must be on a level, stable noncombustible
surface in an area clear of combustible material. As asphalt surface (blacktop)
may not be acceptable for this purpose.
7. Keep the fuel supply hose away from any heated surface.
8. When cooking with oil or grease, the thermometer provided MUST be used. Follow
instructions in this manual for proper installation and use of the thermometer. If the
thermometer supplied with this fryer has been lost or damaged. A replacement
thermometer must be one specified by the appliance manufacturer.
9. If the temperature exceeds 400°F (200°C) or if oil begins to smoke, immediately
turn the burner or gas supply OFF and wait for the temperature to decrease to
less than 350°F (176°C) before relighting burner according to the manufacturer‟s
instructions. If there is a lid (cover), do not remove the lid.
10. When cooking with oil or grease, have a type BC or ABC fire extinguisher readily
available. In the event of an oil or grease fire do not attempt to extinguish with
water. Immediately call the fire department. A Type BC or ABC fire extinguisher
may, in some circumstances contain the fire.
11. Never overfill the cooking vessel with oil, grease or water. Follow instructions in
this manual for establishing proper oil, grease or water levels.
12. Introduction of water or ice from any source into the oil/grease may cause
overflow and severe burns from hot oil and water splatter. When frying with
oil/grease, all food products MUST be completely thawed and towel dried before
being immersed in the fryer.
13. Do not place empty cooking vessel on the appliance while in operation. Use
caution when placing anything in cooking vessel while the appliance is in
operation. Placing an empty cooking vessel on the appliance while in operation
will result in melting the cooking vessel. Use caution when placing anything in
cooking vessel while the appliance is in operation
14. In the event of rain, snow, hail, sleet or other forms of precipitation while cooking
with oil or grease, cover the cooking vessel immediately and turn off appliance
burners and gas supply. Do not attempt to move the appliance or cooking vessel.
15. Do not move the appliance when in use. Allow the cooking vessel to cool to
115°F (45°C) before moving or storing.
16. Do not leave the appliance unattended, keep children and pets away from the
appliance at all times.

TF2089904-KK-00 Eng Page 4 of 22 20150422 V.1
WARNING
Installation Safety Precautions.
Use appliance only with LP (propane) gas and the regulator/ valve assembly supplied.
Installation must conform with local codes or, in the absence of local codes, with the
National Fuel Gas Code, ANSI Z223.1/NFPA 54, Storage and Handling of Liquefied
Petroleum Gases, ANSI/NFPA 58; or Natural Gas and Propane Installation Code, CSA
B1 49.1.
This appliance shall be used only
outdoors, and shall not be used in a
building, garage or any other
enclosed area.
Use appliance at least 10 ft. from
any wall or surface. Maintain 10 ft
clearance to objects that can catch
fire or source of ignition such as
pilot lights on water heaters, live
electrical appliances, etc. Never
use under balconies made of wood
or ANY overhead construction.
Apartment Dwellers: Check with management to learn the requirements and fire codes
for using an LP Gas appliance at an apartment. If allowed use outside at an apartment.
If allowed, use outside on the ground floor with a ten(10) foot clearance form walls or
rails.
Before opening LP tank valve, check the coupling nut for tightness. When appliance is
not in use, turn off control knob and LP tank valve.
Never move appliance while in operation or still hot.
If you notice grease or other hot material dripping from appliance onto valve, hose or
regulator, turn off gas supply at once. Determine the cause, correct, clean and inspect
valve, hose and regulator before continuing. Perform a leak test.
The regulator may make a humming or whistling noise during operation. This will not
affect safety or use of appliance.
Clean and inspect the hose before each use of the appliance. If there is evidence of
abrasion, wear, cuts or leaks, the hose must be replaced prior to the appliance being
put into operation.

TF2089904-KK-00 Eng Page 5 of 22 20150422 V.1
WARNING
Never use a cooking vessel larger than 30 qts. Diameter greater than 11-3/4 inches
and taller than 15-1/2 inches.
Never fill pot above upper fill line. Oil can splatter causing staining or discoloration to
ground surface.
Never place empty cooking vessel on the appliance while in operation. Use caution
when placing anything in the cooking vessel while the appliance is in operation.
Never move the appliance when in use. Allow the cooking vessel to cool before moving
or storing.
Never leave the appliance unattended. Keep children and pet away from the appliance
at all times.
This appliance is not intended for and should never be used as a heater.
WARNING: Hose is a trip hazard.
Never operate appliance with LP tanks out of correct position specified in assembly
instructions.
Always close LP tank valve and remove coupling nut before moving LP tank from
specified operating position.
Appliance shall not be used for commercial cooking.
This appliance will be hot during and after use. Use insulated oven mitts or gloves for
protection from hot surfaces or splatter from cooking liquids.
Avoid bumping of or impact with the appliance to prevent spillage or splashing of hot
cooking liquid.
Never drop food or accessories into hot cooking liquid. Lower food and accessories
slowly into the cooking liquid in order to prevent splashing or overflow. When removing
food from the appliance care should be taken to avoid burns from hot cooking liquids.
DANGER
The safety relief valve on the LP tank could activate releasing gas and cause an
intense fire with risk of death or serious injury. Therefore, follow instructions bulleted
below exactly.
A. Do not store a spare LP-gas cylinder under or near this appliance.
B. Never fill the cylinder beyond 80 percent full; and
C. If the instructions in (a) and (b) are not followed exactly, a fire causing death or
serious injury any occur.
If you see, smell, or hear escaping gas, immediately get away from the LP
tank/appliance and call your fire department.
All spare LP tanks must have safety caps installed on the LP tank outlet.
Keep the fuel supply hose away from any heated surface
24”

TF2089904-KK-00 Eng Page 6 of 22 20150422 V.1
LP Tank Removal, Transport and Storage
Turn OFF all control knobs and LP tank valve. Turn coupling nut counterclockwise by hand
only –do not use tools to disconnect. Place dust cap on cylinder
valve outlet whenever the cylinder is not in use. Only install the
type of dust cap on the cylinder valve outlet that is provided with
the cylinder valve. Other types of caps or plugs may result in
leakage of propane.
A disconnected LP tank in storage or being transported must
have a safety cap installed (as shown). Do not store an LP tank
in enclosed spaces such as a carport, garage, porch, covered
patio or other building. Never leave an LP tank inside a vehicle which may become
overheated by the sun.
Do not store LP tanks in an area where children play.
LP Tank
The LP tank used with your appliance must meet the following requirements:
Purchase LP tanks only with these required measurements: 12” (30.5cm) (diameter) x 18”
(45.7cm) (tall) with 20lb. (9kg). Capacity maximum.
The LP-gas supply cylinder to be used must be constructed and marked in accordance
with the specifications for LP-gas cylinders of the US Department of Transportation (DOT)
or the National Standard of Canada, CAN/CSA-B339, Cylinders, Spheres and Tubes for
the Transportation of Dangerous Goods.
LP tank valve must have:
Type 1 outlet compatible with regulator or appliance.
Safety relief valve.
UL listed Overfill Protection Device (OPD). This OPD safety feature is
identified by a unique triangular hand wheel. Use only tanks equipped
with this type of valve.
LP tank must be arranged for vapor withdrawal and include collar to protect
LP tank valve.
LP (Liquefied Petroleum Gas)
LP gas is non toxic, odorless and colorless when produced. For your safety, LP gas has
been an odor (similar to rotten cabbage) so that it can be smelled.
LP gas is highly flammable and may ignite unexpectedly when mixed with air.
LP Tank Filling
Use only licensed and experienced dealers.
LP dealer must purge tanks before filling.
Dealer should NEVER fill LP tank more than 80% of LP tank volume. Volume of propane in
tanks will vary by temperature.
A frosty regulator indicates gas overfill. Immediately close LP tank valve and call LP gas
dealer for assistance.
Do not release liquid propane (LP) gas into the atmosphere. This is a hazardous practice.
To remove gas from LP tank, contact an LP dealer or call a local fire department for
assistance. Check the telephone directory under” GAS Companies” for nearest certified PL
dealers.
LP Tank Exchange
Many retailers that sell appliances offer you the option of replacing your empty LP tanks
through an exchange service, Use only those reputable exchange companies that inspect,
precision fill, test and certify their cylinders. Exchange your tank only for an OPD safety
feature-equipped tanks as described in the “LP Tank” section of this manual.
Always keep new and exchanged LP tanks in upright position during use, transit or

TF2089904-KK-00 Eng Page 7 of 22 20150422 V.1
storage.
Leak test new and exchanged LP tanks BEFORE connecting to appliance.
LP Tank Leak Test
For your safety
Leak test must be repeated each time LP tank is exchanged or refilled.
Do not smoke during leak test.
Do not use an open flame to check for gas leaks.
Appliance must be leak checked outdoors in well-ventilated area, away
from open flames or sparks.
Use a clean paint brush and 50/50 soap and water solution.
Use mild soap and water. Do not use household cleaning agents. Damage to gas train
components can result.
Brush soapy solution onto all weld seams and entire valve area.
WARNING
If “growing” bubbles appear, do not use or move the LP tank. Contact an LP gas supplier or
your file department.
Connecting Regulator to the LP Tank
1. Place LP tank on a secure, level, and stable surface.
2. Turn control knob to the OFF position.
3. Turn LP tank OFF by turning hand wheel clockwise to a
full stop.
4. Remove the protective cap from the LP tank valve.Always
use cap and strap supplied with valve.
5. Hold regulator, insert nipple (B) into LP tank valve. Hand tighten coupling nut, holding
regulator in a straight line (C) with LP tank valve so as not to cross thread the
connection.
6. Turn the coupling nut clockwise to tighten to a full
solid stop. The regulator will seal on the back-check
feature in the LP tank valve, resulting in some
resistance. An additional one-half to three quarters
turn is required to complete connection. Tighten by
hand only –do not use tools.
NOTE: If you cannot complete connection, disconnect regulator and repeat step 5 and 6. If
you are still unable to complete the connection, do not use this regulator!
Do not use a POL transport
plug (A) (plastic part with
external threads)! It will
defeat the safety feature of
the valve.

TF2089904-KK-00 Eng Page 8 of 22 20150422 V.1
Disconnecting Regulator to the LP Tank
1. Turn control knob of regulator to the OFF position.
2. Turn LP tank OFF by turning hand wheel clockwise to a full stop.
3. Turn the coupling nut counterclockwise to loosen the connector. Loose by hand only –
do not use tools.
4. When disconnected, the regulator should be hung on the hook attached to the
appliance.
WARNING
Do not insert any tool or foreign object into the valve outlet or safety relief valve. You
may damage the valve and cause a leak. Leaking propane may result in explosion, fire,
severe personal injury, or death.
Never attempt to attach this appliance to the self-contained LP gas system of a camper
or trailer or motor home.
The pressure regulator and hose assembly supplied with the appliance must be used.
Replacement pressure regulator and hose assemblies must be those specified by the
appliance manufacturer.
WARNING
Do not use appliance until leak checked.
If leak is detected at any time, STOP.
If you cannot stop a gas leak, immediately close LP tank valve, leave area of appliance,
and call LP gas supplier or your fire department!
Leak Testing Valves, Hoses and Regulator
1. Turn all control knob(s) to OFF.
2. Be sure regulator is tightly connected to LP tanks.
3. Completely open LP tank valve by turning hand wheel
counterclockwise. If you hear a rushing sound, turn gas off
immediately. There is a major leak at the connection. Correct
before proceeding.
4. Brush soapy solution onto indicated connections shown at
right in Aand B.
5. If „growing” bubbles appear, there is a leak. Close LP tank
valve immediately and retighten connections. If leaks cannot
be stopped, do not try to repair. Call for replacement parts.
Order new parts by giving the serial number, model number
and name of items needed to the Customer Service Center
at 1 –888 –837 –1380. Use only replacement parts
specified by manufacturer.
6. Always close LP tank valve after performing tank leak test by
turning hand wheel clockwise.
B

TF2089904-KK-00 Eng Page 9 of 22 20150422 V.1
Lighting Instruction
Step
Procedure
Illustration
1.
Read all instructions before lighting.
2.
Turn regulator control valve to OFF position.
3.
Fully turn timer control knob clockwise.
4.
Fully open LP tank valve.
5.
Light match and place it over burner.
Tip: Wooden kitchen match works best.
6.
PRESS and continually HOLD down push button of
safety valve while slowly turning ON the regulator
control valve. Continually hold down the push button
of the safety valve. DO NOT stand with head or arms
over cooker.
7.
After burner is lit, continue to HOLD the push button
for 10 seconds and then release. Holding push
button of safety valve for less than 10 seconds will
cause burner flame to go out.
8.
If ignition does not occur in 5 seconds, turn the regulator and LP tank valve off, wait 5 minutes, and
repeat the lighting procedure.
9.
Check the position of thermocouple, make sure the
flame has full contact with the thermocouple
Note: If thermocouple does not have full contact with
flame, unit will not stay lit.
10.
Cycle time for timer is around 15 minutes. If the timer is not reset within around 15 minutes, the burner
will shut OFF automatically. If this occurs, please follow lighting instructions and continue to cook.
HOLD the Push
button of safety
valve

TF2089904-KK-00 Eng Page 10 of 22 20150422 V.1
CAUTION
If burner does not light OR if burner flame is accidentally extinguished, turn knob to OFF,
wait 5 minutes, try again. If the burner does not ignite with valve open OR if burner flame is
accidentally extinguished after lighting, gas will continue to flow out of the burner and could
accidentally ignite with risk of injury.
Burner Flame Check
Light burner, rotate knob from HIGH to LOW. You should
see a smaller flame in LOW position than seen on HIGH.
Always check flame prior to each use. The air damper (D)
mounted on the back of your burner helps to control the
amount of primary air that mixes with the LP gas. A blue
flame with little or no yellow flame provides the best heat.
Adjust the air damper by turning it clockwise or
counterclockwise until the desired flame is achieved.
Turning LP Cooker Off
Turn all knobs to OFF position, Turn LP tank OFF by turning
hand-wheel clockwise to a full stop.
Regulator and Hose Assembly Check
Before each use, check to see if there is evidence of
abrasion, wear, cuts or leaks, the hose assembly and
regulator must be replaced prior to the appliance being put
into operation. The replacement hose assembly and regulator shall be that specified
by the manufacturer.
Cleaning the Burner
CAUTION
Checking and cleaning burner / venture tubes for insect nests. A clogged tube can lead to
fire beneath the appliances.
Spiders‟ nests or wasps‟ mud inside the burner may cause fire at the air damper. If a fire
occurs, immediately turn off gas supply at LP tank valve.
Note:
Spiders and small insects can spin webs and build nests inside the burner. This especially
occurs in late summer and fall before frost when spiders are most active. These nests can
obstruct gas flow and cause a fire in and around the burner and orifice. Such a fire can
cause operator injury and serious damage to the appliance.
To help prevent a blockage and ensure full heat output, clean and inspect burner tube often
(once or twice a month). NOTE: Water or air pressure will not normally clear a spider web.

TF2089904-KK-00 Eng Page 11 of 22 20150422 V.1
Steps for Cleaning the Burner:
1. Remove orifice/hose from the burner.
2. Look inside the burner tube for nests, webs, or mud.
3. To remove the above obstructions, use an accessory
flexible venture brush or bend a small hook on one end
of a long flexible wire such as the one in small picture.
4. Inspect and clean the burner if needed.
5. Reattach orifice/hose to burner.
Cleaning and Maintenance
Keep appliance area clear and free from combustible materials, gasoline and other
flammable vapors and liquids.
Do not block holes in bottom or sides of appliance.
Check burner flames regularly.
Use appliance only in well-ventilated space. NEVER use in enclosed space such as
carport, garage, porch, covered patio, or underANY overhead construction.
Completely thaw meat and poultry prior to placing in hot oil.
To minimize splattering, dry surfaces of meat and poultry prior to placing in hot oil.
When LP tanks is connected to appliance, store outdoors in well-ventilated space and
out of reach of children.
Store appliance indoors ONLY if LP tanks turned off and disconnected, removed form
appliance and stored outdoors.
To keep the appliance clear and free from gasoline and other flammable vapors and
liquids.
Not obstructing the flow of combustion and ventilation air.
Keeping the ventilation opening(s) of the cylinder enclosed free and clear from debris.
Clean all cooking surfaces of vessels, aluminum pots and pan with warm, soapy water
and a nylon cleaning pad to avoid oxidation, corrosion and rusting.
CAUTION
All cleaning and maintenance should only be done when the appliance is cool and with the
fuel supply turned off at the LP tank. DO NOT clean any part in a self-cleaning oven. The
extreme heat will damage the finish.
Correct care and maintenance will keep your appliance operating smoothly. Clean regularly
as determined by the amount of use. NOTE: Clean the entire appliance each year and
tighten all hardware on a regular basis (1-2 times a year or more depending on usage).
Cleaning should be done where detergents won‟t harm patio, lawn or the like.

TF2089904-KK-00 Eng Page 12 of 22 20150422 V.1
Suggested Cleaning Materials:
Mild dish washing liquid detergent
Hot water
Wire brush
Paper clip
Nylon Cleaning pad
Soft brass bristled brush
Component Cleaning:
Burner: Wire brush loose corrosion from burner exterior. Clean clogged gas port holes
with an opened paper clip. Replace corroded or damaged burners that would emit
excess gas.
Cooking surfaces, pots and pans: Clean the cooking surface with soapy water and a
nylon cleaning pad.

TF2089904-KK-00 Eng Page 13 of 22 20150422 V.1
Product Diagram
9
8
5
7
6
1
3
13
12
11
14
4
10
15
16
2

TF2089904-KK-00 Eng Page 14 of 22 20150422 V.1
Component List
1. Weld Stand
……1pc
2. Legs……3pcs
3. Stand Ring
……1pc
4. Small T-Support
Leg……2pcs
5. Small T-Support
Leg (With Support
Bar For Timer)
……1pc
6. Adjustable Pot
Tip Guard…….2pcs
7. Heat Shield
……1pc
8. Auto-Shut Off Valve,
Timer Control Box, Gas
Hose & Regulator
Assembly……1pc
9. Burner
………….…1pc
10. 30QT Turkey
Fryer……1pc
11.Pot Lid ……1pc
12. Turkey Stand
……1pc
13. Turkey Hook
……1pc
14. Regulator Hook
……1pc
15. Thermometer
……1pc

TF2089904-KK-00 Eng Page 15 of 22 20150422 V.1
Hardware List
Item No.
Item name
Diagram
Qty
A
BOLT M6 x 12
18
B
NUT M6 FLANGE LOCK
16
Assembly Instructions:
1. Attach Burner (9) toAutomatic Shut Off Valve in the
Timer Control Box (8) by turning the burner clockwise.
Do not fully tighten burner to the valve, tighten until 3
threads remain visible on the valve. Attach
thermocouple to thermocouple bracket which has
been fixed to the burner.
2. Attach Thermocouple (9) as shown on the right
illustration and tighten the nut.
Note: If thermocouple does not have full contact with flame, unit will
not stay lit.
Leave 2 visible thread
3. Assemble the Legs (2) to Welded Stand (1) by using
6pcs M6 x 12 bolts (A) and 6pcs M6 nuts (B).
Proper connection is critical for correct operation of unit.
Timer Control Box
Three Visible
Threads
Thermocouple
Thermocouple
Bracket
Automatic shut
Off valve
nut
9
8
2
A
1
2
3
B
4

TF2089904-KK-00 Eng Page 16 of 22 20150422 V.1
4. Assemble the Legs (2) to Stand Ring (3) by using
3pcs M6 x 12 bolts (A) and 3pcs M6 nuts (B). Install the
Small T-Support Legs (4) and (5) onto the
Stand Ring (3) with 3pcs M6 x 12 bolts (A) and 3pcs
M6 nuts (B).
5. Unscrew the pre-assembled nut from the threaded pin
of the Burner (9). Then insert the threaded pin at the
bottom of burner into the center hole of burner
supporting bar. Make sure the alignment pin on the
burner seat in the notch on the edge of burner
supporting bar. Align the holes on Heat Shield (7) with
threaded pin and alignment pin of Burner (9) and hole
on burner supporting bar, then fix the Heat Shield (7)
outside the burner supporting bar and tighten with hex
nut (on the threaded pin) onto the bolt of Burner (9).
6. Align Timer Control Box (8) to the timer box supporting
bar on Small T-Support Leg (5) and fix it with
2pcs M6 x 12 bolts (A) by going through the supporting
bar and then to the timer box.
Timer box
supporting bar
A
3
B
5
Burner Supporting Bar
7
Threaded Pin
8
Timer Box Support Bar (5)
2
9

TF2089904-KK-00 Eng Page 17 of 22 20150422 V.1
7. Mount the Adjustable Pot Tip Guard (6) on to Welded
Stand (1) by 2pcs M6 x 12 bolts (A) and
2pcs M6 nuts (B).
8. Thread Regulator Hook (14) through hole on side of
regulator.
9. When transporting or storing LP cooker without tank
attached, hook regulator onto burner or cooker stand
to prevent damage to regulator.
Using Your Thermometer
Check the thermometer before each use by inserting into a pot
of boiling water and ensuring that it registers approximately
212°F +/- 20°F (100°C +/- 10°C). If it does not function properly,
obtain a replacement thermometer specified by the
manufacturer before using the appliance. Prior to lighting,
position thermometer clip so that at least 2.75” of thermometer
tip is submerged in oil. Reposition thermometer as necessary
to cook. Continue to use thermometer until burner is turned off.
6
A
14
1

TF2089904-KK-00 Eng Page 18 of 22 20150422 V.1
The following safety measures are recommended when using your fry set.
LOCATION MATTERS
Select a safe place to fry your turkey. It should be in an open area, outside, and on a
cement or brick surface. Place the liquid propane gas tank and fryer so that any wind blows
the heat of the fryer away from the gas tank. Never use your fryer in an enclosed area, near
a wall or on a wooden deck. Keep a minimum clearance of 10 feet from the sides, front and
back of the fryer to any construction.
PREPARE PROPERLY
Remove and discard any thermometer buttons, leg holders
and giblet packs contained inside the completely thawed turkey.
Do not attempt to fry a frozen or partially frozen turkey. Ensure
your turkey is completely thawed prior to proceeding. NOTES:
Bass Pro Turkey Fryer can cook a turkey weight up to 18
pounds. The USDA recommends thawing 24 hours (1 day) for
every 4-5 pounds in refrigerator.
Insert the T-Star stand up through the cavity of turkey so
that the legs are at the top.
Determining the maximum fill level when using a vessel without a maximum fill line:
Place the turkey (or other food product) on the lifter.
Place the turkey and lifter into the empty vessel.
Fill the vessel with water just until the turkey is completely
submerged. There must be a minimum of 3 inches or 8 cm
between the water level and top of the vessel.
Remove the turkey from the pot and either mark the water
level on the side of the vessel or measure the amount of
water in the vessel.
Remove the water and completely dry the vessel and the
turkey.
This is the amount of cotton seed oil, peanut oil or other
cooking oilthe vessel is to be filled with to cook the turkey.
Use marinade by injecting it into the thicker areas of the
turkey breasts and thighs.
To use, load the injector with marinade and insert the
needle into the turkey. Withdraw the needle slowly while
pushing the plunger, minimizing large pockets of marinade
and spreading it more evenly. Discard any unused
marinade.

TF2089904-KK-00 Eng Page 19 of 22 20150422 V.1
Completely pat dry the inside and outside surfaces of the
turkey. This is very important as it reduces the splattering of
oil. After patting the bird dry, add herb rubs or seasonings
to the skin.
Fry with Care
Check your hose at both ends for proper connection.
Also, place the tank and hose so that they are not
located directly next to the fryer (see photo). Center
the pot over the burner on the cooker.
Fill the pot to the mark with peanut oil. Do not place
an empty cooking vessel on the appliance while in
operation. Placing an empty cooking vessel on the
appliance while in operation will result in melting the
cooking vessel. Use caution when placing anything
in cooking vessel while the appliance is in operation.
Light the burner unit and heat the oil to 325°F. Never
leave the fryer unattended at any time.
Check the oil using a deep fry temperature gauge. If
it has reached 325°F, you are ready to start deep
frying. Monitor the temperature throughout the frying
process to maintain 325°F –never let the oil
temperature get hotter than 325°F.
If the oil exceeds 400°F or if the oil begins to smoke,
immediately turn the burner off.
Wear long, insulated, flame-retardant gloves to
protect your hands and arms. Use the lift handle to
slowly lower the turkey into the oil. Pause at several
points before reaching the bottom of the pot.
Never drop food or accessories into hot cooking
liquid. Lower food and accessories slowly into the
cooking liquid in order to prevent splashing or
overflow. When removing food from the appliance,
care shall be taken to avoid burns from hot cooking
liquids.
Adjust the burner to maintain 325°F. Monitor the
fryer during the entire process to assure a safe
frying experience. Do not leave fryer unattended.
Cook until a golden brown color is achieved. Normal
cooking time is 3 1/2 minutes per pound.

TF2089904-KK-00 Eng Page 20 of 22 20150422 V.1
DANGER
Do not fill past the maximum fill line marked on the utensil.
An oil overflow may occur resulting in a fire which could cause property damage,
personal injury or death. Follow directions above to prevent this.
Do not place an empty cooking vessel on the appliance while in operation. Placing an
empty cooking vessel on the appliance while in operation will result in melting the
cooking vessel. Use caution when placing anything in cooking vessel while the
appliance is in operation
WARNING
Avoid bumping of or impact with the appliance to prevent spillage or splashing of hot
cooking liquid. Introduction of water or ice from any source into the oil/grease may cause
overflow and serve burns from hot oil and water splatter. When frying with oil/grease, all
food products MUST be completely thawed and towel dried before being immersed in the
fryer.
Remove the turkey from the oil and place it on paper towels in an aluminum pan.
Using a meat thermometer, check for an internal meat temperature of 180°F.
Remove turkey fry accessory and allow the turkey to “rest” for 15 minutes to allow the
juices to settle into the turkey. Slice and serve!
If you need additional parts to replace missing parts, please call Customer Service at
1 –888 –837 –1380.
