Backyard GBC1449W Series User manual

Outdoor LP Gas Barbecue Grill
Model No. GBC1449W Series
Manufactured in China for: Blue Rhino Global Sourcing, Inc.
Winston-Salem, NC 27105 USA • 1.800.762.1142 • BlueRhino.com
© Blue Rhino Global Sourcing, Inc.
Backyard Grill™ is a trademark of Wal-Mart Stores, Inc. Used with permission. GBC1449W_s-OM-105 ES
Table of Contents
Important Safeguards ...........................................Page 2
Expanded View & Hardware .......................................... 3
Assembly Instructions............................................... 4
Installing LP Gas Tank............................................... 9
Inserting LP Gas Tank ............................................. 9
Securing LP Gas Tank ............................................. 9
Connecting LP Gas Tank ........................................... 9
Disconnecting LP Gas Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installing Natural Gas Line .......................................... 10
Connecting Natural Gas Line ....................................... 10
Disconnecting Natural Gas Line..................................... 10
Operating Instructions.............................................. 10
Checking for Leaks .............................................. 10
Operating Main Burners .......................................... 10
Operating Side Burner............................................ 11
Cleaning and Care ................................................ 11
Product Registration ............................................... 12
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Limited Warranty ................................................. 12
Troubleshooting .................................................. 13
The use and installation must conform with local codes or, in the absence of local
codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas
and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code,
B149.2, or the Standard for Recreational Vehicles, ANSI A 119.2/NFPA 1192, and CSA
Z240 RV Series, Recreational Vehicle Code, as applicable.
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
If you are assembling this unit for someone else, give this manual to him or her to
read and save for future reference.
California Proposition 65: Combustion by-products produced when using this product
contain chemicals known to the State of California to cause cancer, birth defects, and
other reproductive harm.
California Proposition 65: Wash your hands after handling this product.
OWNER’S MANUAL
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
WARNING
FOR YOUR SAFETY:
1. Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage.
2. Read the installation, operation, and
maintenance instructions thoroughly before
installing or servicing this equipment.
3. Failure to follow these instructions could
result in fire or explosion, which could cause
property damage, personal injury, or death.
4. This instruction manual contains important
information necessary for the proper
assembly and safe use of the appliance.
5. Read and follow all warnings and
instructions before assembling and using
the appliance.
6. Follow all warnings and instructions when
using the appliance.
7. Keep this manual for future reference.
DANGER
If you smell gas -
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
WARNING
FOR YOUR SAFETY:
1. Do not store or use gasoline or other
flammable liquids or vapors in the vicinity of
this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
DANGER
Never operate this appliance unattended.
Made from 75% Bagasse
(environmentally friendly sugar
cane pulp by-product)
Natural gas conversion kit
(model no. VFK1001W1)
available at Walmart.com

Outdoor LP Gas Barbecue Grill
Model No. GBC1449W Series
2
WThis grill is for outdoor use only, and should not be used in a building,
garage or any other enclosed area.
WDo NOT operate, light or use this appliance within ten feet (3.05 m) of
walls, structures or buildings.
WFor residential use only. This grill is NOT for commercial use.
WThis grill is not intended for and should never be used as a heater. TOXIC
fumes can accumulate and cause asphyxiation.
WThis grill is safety certified for use in the United States and/or Canada
only. Do NOT modify for use in any other location. Modification will
result in a safety hazard and will void your warranty.
WThis grill is for use with liquid propane (LP) gas only. The conversion to
or attempted use of natural gas in this LP gas grill is dangerous, may
cause bodily harm and will void your warranty.
WThis grill, from the factory, is for use with liquid propane (LP) gas. The
natural gas conversion kit model number VFK1001W1 may be used to
convert your grill to natural gas. The use of any other conversion kit is
dangerous, may cause bodily harm and will void your warranty.
WLP gas characteristics:
a. LP gas is flammable and hazardous if handled improperly. Become
aware of the characteristics before using any LP gas product.
b. LP gas is explosive under pressure, heavier than air, and settles/
pools in low areas.
c. LP gas in its natural state has no odor. For your safety, an odorant is
added that smells like rotten cabbage.
d. Contact with LP gas can cause freeze burns to skin.
WNatural gas (NG) characteristics:
a. NG is flammable and hazardous if handled improperly. Become
aware of the characteristics before using any NG product.
b. NG is explosive under pressure, heavier than air, and settles/pools in
low areas.
c. NG in its natural state has no odor. For your safety, an odorant is
added that smells like rotten cabbage.
d. Contact with NG can cause freeze burns to skin.
WApartment dwellers: Check with management to learn the requirements
and fire codes for using a LP gas grill in your apartment complex.
If allowed, use outside on the ground floor with a ten foot (3.05 m)
clearance from any structure. Do NOT use on or under balconies.
WLP gas cylinder needed to operate. Only cylinders marked “propane”
may be used.
WThe LP gas cylinder must be constructed and marked in accordance
with the Specifications for LP-gas Cylinders of the U.S. Department
of Transportation (D.O.T.) or the National Standard of Canada, CAN/
CSA-B339, Cylinders, Spheres and Tubes for the Transportation of
Dangerous Goods; and Commission.
WLP gas cylinder must be arranged for vapor withdrawal.
WThe LP gas cylinder must have a listed overfilling prevention device
(OPD).
WOnly use LP gas cylinders equipped with a cylinder connection device
compatible with the connection for outdoor cooking appliances.
WThe LP gas cylinder must have a cylinder collar to protect the cylinder
valve.
WNever use a LP gas cylinder with a damaged body, valve, collar or
footing.
WDented or rusted LP gas cylinders may be hazardous and should be
checked by your LP gas supplier prior to use.
WThe LP gas cylinder should not be dropped or handled roughly.
WLP gas cylinders must be stored outdoors out of the reach of children
and must not be stored in a building, garage or any other enclosed area.
Your cylinder must never be stored where temperatures can reach over
125°F.
WDo NOT insert any tool or foreign object into the valve outlet or safety
relief valve. You may damage the valve and cause a leak. Leaking
propane may result in an explosion, fire, severe personal injury or death.
WDo NOT block holes in sides or back of grill.
WNever keep an LP gas cylinder in a hot car or trunk. Heat will cause the
gas pressure to increase, which may open the relief valve and allow gas
to escape.
WPlace dust cap on cylinder valve outlet whenever the cylinder is not in
use. Only install the type of dust cap on the cylinder valve outlet that is
provided with the cylinder valve. Other types of caps or plugs may result
in leakage of propane.
WIf grill is not in use, the gas must be turned off at the supply cylinder
and disconnected.
WDo NOT store a spare LP gas cylinder under or near this appliance.
WNever fill the cylinder beyond 80 percent full.
WA fire causing serious injury or damage to property may occur if the
above is not followed exactly.
WNever attempt to attach this grill to the self-contained LP gas system of
a camper trailer, motor home or house.
WNever use charcoal, lighter fluid, lava rocks, gasoline, kerosene or
alcohol with this product.
WYour grill has been checked at all factory connections for leaks.
Recheck all connections as described in the “Operating Instructions”
section, as shipping can loosen connections.
WCheck for leaks even if your unit was assembled for you by someone
else.
WDo NOT operate if a gas leak is present. Gas leaks may cause a fire or
explosion.
WYou must follow all instructions in “Checking for Leaks” section before
operating. To prevent fire or explosion hazard when testing for a leak:
a. Always perform a leak test before lighting the grill and each time
the cylinder is connected for use.
b. No smoking. Do NOT use or permit sources of ignition in the area
while conducting a leak test.
c. Conduct the leak test outdoors in a well-ventilated area.
d. Do NOT use matches, lighters, or a flame to check for leaks.
e. The use of alcohol, prescription or non-prescription drugs may
impair the consumer’s ability to properly assemble or safely operate
the appliance.
f. Strong odors, colds, sinus congestion, etc. may prevent the
detection of propane. Use caution and common sense when testing
for leaks.
g. Do NOT use grill until any and all leaks are corrected.
LP: If you are unable to stop a leak, disconnect the LP gas supply.
Call a gas appliance serviceman or your local LP gas supplier.
NG: If you are unable to stop a leak, turn off the main valve on the
NG supply line. Call a gas appliance serviceman or your local NG
supplier.
WNG: The appliance and its individual shutoff valve must be disconnected
from the gas supply piping system during any pressure testing of that
system at pressure in excess of 1/2 psig (3.5 kpa).
WNG: The appliance must be isolated from the gas supply piping system
by closing its individual manual shutoff valve during any pressure
testing of the gas supply piping system at test pressures equal to or
less than 1/2 psig (3.5 kpa).
WThis grill is designed to operate at an inlet pressure of: LP gas: 11
inches water column; NG: 7 inches water column.
WDo NOT store or use gasoline or other flammable liquids or vapors
within 25 feet (7.62 m) of this appliance.
WDo NOT use in an explosive atmosphere. Keep grill area clear and free
from combustible materials, gasoline and other flammable vapors and
liquids.
WMinimum clearance from sides and back of unit to combustible
construction is 36 inches (91.4 cm). Do NOT use this appliance under
any type of overhang or roof.
WIt is essential to keep the grill’s valve compartment, burners and
circulating air passages clean.
WInspect grill before each use.
WDo NOT alter grill in any manner. Any alteration will void your warranty.
WDANGER: Failure to follow the dangers, warnings and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion causing damage
to property.
WWARNINGS:
Important Safeguards

Need help? 1.800.762.1142
Do not return to place of purchase.
Recipes
BlueRhino.com/recipes
Replacement Parts
parts.BlueRhino.com /
1.800.762.1142 3
WDo NOT use the grill unless it is COMPLETELY assembled and all parts
are securely fastened and tightened.
WDo NOT build this model of grill in any built-in or slide-in construction.
Ignoring this warning could cause a fire or an explosion that can
damage property and cause serious bodily injury or death.
WThis grill should be thoroughly cleaned and inspected on a regular
basis.
WClean and inspect the hose before each use of the appliance. If there
is evidence of abrasion, wear, cuts or leaks, the hose must be replaced
prior to operation.
WUse only the regulator and hose assembly provided. Use only the
replacement regulator and hose assembly specified by Blue Rhino
Global Sourcing, Inc.
WUse only Blue Rhino Global Sourcing, Inc. factory-authorized parts. The
use of any part that is not factory-authorized can be dangerous and will
void your warranty.
WDo NOT operate this appliance without reading “Operating Instructions”
in this manual.
WDo NOT touch metal parts of grill until they have completely cooled
(about 45 min.) to avoid burns, unless you are wearing protective gear
(pot holders, gloves, BBQ mittens, etc.).
WDo NOT install or use in or on boats or recreational vehicles.
WWhen cooking, fire extinguishing materials should be readily accessible.
In the event of an oil/grease fire, do NOT attempt to extinguish with
water. Use type BC dry chemical fire extinguisher or smother with dirt,
sand or baking soda.
WDo NOT use grill in high winds.
WNever lean over the grill when lighting.
WDo NOT leave a lit grill unattended. Keep children and pets away from
grill at all times.
WDo NOT leave grill unattended while preheating or burning off food
residue on high. If grill has not been cleaned, a grease fire can occur
that may damage the product.
WDo NOT place empty cooking vessels on the appliance while in
operation.
WUse caution when placing anything on the grill while the appliance is in
operation.
WDo NOT attempt to move grill when in use. Allow the grill to cool before
moving or storing.
WLP gas cylinder must be properly disconnected and removed prior to
moving this grill.
WStorage of grill indoors is permissible only if the cylinder is
disconnected, removed from the grill and properly stored outdoors.
WAlways open grill lid carefully and slowly as heat and steam trapped
within grill can cause severe burns.
WDo NOT attempt to disconnect the gas regulator from the cylinder or any
gas fitting while the grill is in use.
WAlways place your grill on a hard, non-combustible, level surface. An
asphalt or blacktop surface may not be acceptable for this purpose.
WMove gas hoses as far away as possible from hot surfaces and dripping
hot grease.
WKeep all electrical cords away from a hot grill.
WAfter a period of storage and/or nonuse, check for leaks, burner
obstructions and inspect for any abrasion, wear or cuts to the hose.
WFailure to open lid while igniting the grill’s burners, or not waiting 5
minutes to allow the gas to clear if the grill does not light, may result in
an explosive flame-up.
WNever operate grill without its heat plates installed.
WAlways use a meat thermometer to ensure food is cooked to a safe
temperature.
WUse protective gloves when assembling this product.
WDo NOT force parts together as this can result in personal injury or
damage to the product.
WNever cover entire cooking area with aluminum foil.
WDeaths, serious injury or damage to property may occur if the above is
not followed exactly.
Important Safeguards

Outdoor LP Gas Barbecue Grill
Model No. GBC1449W Series
4
1
15
23
Parts List
1Lid Handle 55-22-326
2Temperature Gauge 55-24-043
3Warming Rack 55-23-026
4Cooking Grid (3) 55-23-027
5Lid*
55-24-089 (W)
55-24-099 (WBS)
55-24-094 (WRS)
6Side Burner Grid 55-10-047
7Side Burner 55-23-029
8Right Side Shelf 55-24-271
9Heat Plate (4) 55-10-156
10 Burner (4)* 55-23-031
11 Grill Body
Assembly*
55-24-272 (W)
55-24-275 (WBS)
55-24-277 (WRS)
12 Control Knob
Bezel (5)* 55-09-006
13 Control Knob (5) 55-09-007
14 Regulator/Hose
Assembly* 55-23-033
15 Left Side Shelf 55-23-034
16 Right Cart Frame 55-23-035
17 Grease Cup 55-11-018
18 Grease Tray 55-23-036
19 Bottle Opener* 55-23-037
20 Left Cart Frame 55-23-038
21 Wheel (2) 55-07-363
22 Axle 55-23-039
23 LP Gas Tank
Retainer Wire 55-23-040
24 Rear Cart Frame
Support 55-23-041
25 Cart Frame Support
Wire (2) 55-23-041
26 Foot (2) 55-23-043
27 Upper Front Panel
55-24-273 (W)
55-24-276 (WBS)
55-24-278 (WRS)
28 Lower Front Panel
55-23-045 (W)
55-24-101 (WBS)
55-23-510 (WRS)
29 Lighting Hook 55-07-331
* Pre-assembled
Expanded View
27
16
19 14
3
6
4
4
4
5
7
11
20
24
21
21
25
8
28
2
17
18
26
10
12
13
Tools Required for Assembly (Included)
#2 Phillips Head Screwdriver 1 pc
M10-M6 Wrench 2 pcs
Hardware
AScrew ST4.8x10 Nickel Plated Phillips Truss Head 2 pcs
BScrew M4x10 Nickel Plated Phillips Truss Head 4 pcs
CBolt M6x16 Nickel Plated Phillips Hex Head 26 pcs
DWing Bolt M6x10 Nickel Plated 1 pc
ENut M10 Nickel Plated 2 pcs
FWing Nut M5 Nickel Plated 2 pcs
GWing Nut M6 Nickel Plated 2 pcs
HWasher ø6.4 Nickel Plated 6 pcs
ILock Washer ø6.5 Nickel Plated 6 pcs
9
29
22

Need help? 1.800.762.1142
Do not return to place of purchase.
Recipes
BlueRhino.com/recipes
Replacement Parts
parts.BlueRhino.com /
1.800.762.1142 5
1
DO NOT RETURN TO PLACE OF PURCHASE.
For assistance, call 1.800.762.1142 toll-free. Please have
your Owner’s Manual and model number available for
reference.
Note: The model number is printed on a label which can be found on
the inside door, back or side of the cart assembly.
Assembly Tips:
1. Select an area where you will assemble this product. To
protect components, choose a smooth surface that’s free of
cracks or openings.
2. Spread out all parts.
3. Tighten all hardware connections by hand first. Then, before
completing each step, go back and fully tighten all hardware.
Be careful not to over-tighten. That could damage surfaces or
strip threads.
4. For best results, complete each step in the order presented.
To complete assembly you will need:
• (1) Leak detection solution (instructions on how to make the
solution are included in the “Operating Instructions” section of
this manual).
• LP: (1) Precision-filled LP gas grill tank with Acme Type 1
external threaded valve connection (standard grill size).
• NG: (1) Natural gas conversion kit, model number VFK1001W1
(not included).
Typical assembly is approximately one hour.
Assembly Instructions
3
Attach Axle and Wheels
Ex 2
4
Attach Front Panels
Cx 8
2
Attach Feet
Ax 2

Outdoor LP Gas Barbecue Grill
Model No. GBC1449W Series
6
Assembly Instructions (continued)
5
Attach Cart Frame Support Wires and Rear Cart Frame
Support
Cx 4 Fx 2
6
Attach LP Gas Tank Retainer Wire and Lighting Hook
Dx 1
8
Attach Grill Body Assembly
Cx 4
Hx 4
Ix 4
7
Attach Thermometer

Need help? 1.800.762.1142
Do not return to place of purchase.
Recipes
BlueRhino.com/recipes
Replacement Parts
parts.BlueRhino.com /
1.800.762.1142 7
Assembly Instructions (continued)
9
Attach Left Side Shelf
Note: Leave 5 mm of bolt threads exposed.
Cx 5
10
Attach Right Side Shelf
Note: Leave 5 mm of bolt threads exposed.
Cx 5
11
Attach Side Burner Valve and Control Knob Bezel
Bx 2
12
Insert Side Burner, Side Burner Grid and Igniter Wire
Bx 2

Outdoor LP Gas Barbecue Grill
Model No. GBC1449W Series
8
Assembly Instructions (continued)
14
Attach Lid Handle
Gx 2 Hx 2
Ix 2
13
Attach Control Knobs
15
Insert Heat Plates and Cooking Grids
16
Insert Warming Rack

Need help? 1.800.762.1142
Do not return to place of purchase.
Recipes
BlueRhino.com/recipes
Replacement Parts
parts.BlueRhino.com /
1.800.762.1142 9
Assembly Instructions (continued)
17
Insert Grease Tray and Grease Cup
Natural gas conversion kit (model no.
VFK1001W1) available at Walmart.com.
Installing LP Gas Tank
To operate, you will need one precision-filled standard grill LP gas
tank with external valve threads.
WCAUTION: LP gas tank must be properly
disconnected and removed prior to moving this
grill.
Inserting LP Gas Tank
Place precision-filled LP gas tank upright into the notches in the right cart frame so the tank
valve is facing the gas line connection.
Securing LP Gas Tank
Secure tank by sliding the tank retainer wire over shoulder of LP gas tank.
Connecting LP Gas Tank
1. Before connecting, be sure there is no debris caught
in the head of the LP gas tank, head of the regulator
valve or in the head of the burner or burner ports.
2. Connect regulator/hose assembly to tank by turning
knob clockwise until it stops.
Disconnecting LP Gas Tank
1. Before disconnecting, make sure the LP gas tank valve
is “CLOSED.”
2. Disconnect regulator/hose assembly from LP gas tank
by turning knob counterclockwise until it is loose.
WCAUTION: LP gas tank must be properly
disconnected and removed prior to
moving this grill.
3. Place the protective cap cover on the LP tank and
store the tank outdoors in a well ventilated area out of
direct sunlight.
Getting More Propane
Need a tank of gas? One option is to try propane exchange. It’s easy, fast,
safe, and available at tens of thousands of conveniently located retail
outlets nationwide, which are typically open nights and weekends. You
can purchase a fresh, precision-filled tank or exchange your empty for a
fresh, precision-filled tank. Another option is to have your tank refilled at a
refill station. Be sure to check the hours of operation for the refill station.
20 lb
9 Kg
17.9 in. / 45.5 cm
12.2 in. / 31 cm

Outdoor LP Gas Barbecue Grill
Model No. GBC1449W Series
10
Operating Instructions
Checking for Leaks
Burner Connections
1. Make sure the regulator valve and hose
connections are securely fastened to the burner
and the tank.
2. Visually check the connection between the
burner/venturi tube and orifice.
3. Make sure the burner/venturi tube fits over the
orifice.
WWARNING: Failure to inspect this
connection or follow these instructions
could cause a fire or an explosion
which can cause death, serious bodily
injury or damage to property.
4. Please refer to diagram for proper installation
(Figures 1 and 2).
5. If the burner/venturi tubedoes not rest flush to the
orifice, as shown, please contact 1.800.762.1142
for assistance.
Tank/Gas Line Connection
1. Make 2-3 oz. of leak detection solution by mixing
one part liquid dishwashing soap with three parts
water.
2. Make sure control knobs are in the “ OFF”
position (Figure 3).
3. LP: Connect LP gas tank per “Installing LP Gas
Tank” section.
NG: Connect NG main line per “Installing Natural
Gas Line” section.
4. LP: Turn LP gas tank valve to “OPEN.”
NG: Turn “ON” natural gas main valve.
5. Spoon several drops of solution, or use a squirt
bottle, at all “X” locations (Figures 1, 2, 4a and
4b).
a. LP: If any bubbles appear, turn LP gas tank
valve to “CLOSED,” reconnect and re-test.
NG: If any bubbles appear, turn natural gas
main valve “OFF,” reconnect and re-test.
b. LP: If you continue to see bubbles after several
attempts, turn LP gas tank valve to “CLOSED”
and disconnect LP gas tank, per “Disconnect LP
Gas Tank” section. Contact 1.800.762.1142 for
assistance.
NG: If you continue to see bubbles after several
attempts, turn natural gas main valve to
“OFF.” Disconnect natural gas line and contact
1.800.762.1142 for assistance.
c. LP: If no bubbles appear after one minute, turn
LP gas tank valve to “CLOSED,” wipe away
solution and proceed.
NG: If no bubbles appear after one minute, turn
natural gas main valve to “OFF,” wipe away
solution and proceed.
Installing Natural Gas Line
Installation should be done by a qualified service person.
WCAUTION: If young children are in the area, a locking valve should be
considered.
Connecting Natural Gas Line
1. Before connecting, be sure there is no debris caught in
the head of the natural gas line, head of the grill natural
gas line or in the head of the burner or burner ports.
2. Connect grill natural gas line to natural main gas line.
Disconnecting Natural Gas Line
1. Before disconnecting, make sure the natural gas main
line valve is “OFF.”
2. Disconnect grill natural gas line from natural gas main line.
X
X
Operating Main Burners
First Use
1. Make sure all labels, packaging and protective
films have been removed from the grill.
2. Remove manufacturing oils before cooking on this
grill for the first time by operating the grill for at
least 15 minutes on (HIGH) with the lid closed.
This will “heat clean” the internal parts and
dissipate odors.
Lighting
WCAUTION: Keep outdoor gas cooking
appliance area clear and free from
combustible materials, gasoline and
other flammable vapors and liquids.
WCAUTION: Do NOT obstruct the flow of
combustion and ventilation air.
WCAUTION: Check and clean burner/
venturi tubes for insects and insect
nests. A clogged tube can lead to a
fire.
WCAUTION: Attempting to light the
burner with the lid closed may cause
an explosion.
1. Open lid.
2. Check for obstructions of airflow to the burners. Spiders, insects and webs can clog the
burner/venturi tube. A clogged burner tube can lead to a fire.
3. All control knobs must be in the “ OFF” position (Figure 3).
4. LP: Connect LP gas tank per “Installing LP Gas Tank” section.
NG: Connect NG main line per “Installing Natural Gas Line” section.
5. LP: Turn LP gas tank valve to “OPEN.”
NG: Turn natural gas main valve to “ON.”
6. Push and turn any control knob to (HIGH). The burner should light. If it does not, repeat
up to three times.
7. If ignition does not occur in 5 seconds, turn burner control knob “ OFF,” wait 5 minutes,
and repeat lighting procedure.
8. If igniter does not light burner, use a lit match secured with the lighting rod (included with
grill) to light burners. Access the burners through the cooking grid and heat plates. Position
lit match near side of burner (Figure 5).
Important: Always use the lighting rod (included) when lighting burners with a match.
9. After lighting, observe the burner flame. Make sure all burner ports are lit and flame height
matches illustration (Figure 6).
Note: Each burner lights independently - repeat steps 5-9 for the other burners.
WCAUTION: If burner flame goes out during operation, immediately turn
the control knobs to the “ OFF” position
(a) LP gas tank valve “CLOSED” or
(b) NG main valve “OFF”
and open lid to let the gas clear for 5 minutes before re-lighting.
Turning Off
1. LP: Turn LP gas tank valve to “CLOSED.”
NG: Turn natural gas main valve to “OFF.”
2. Turn all control knobs clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the LP gas is burned.
3. LP: Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
NG: Keep NG main gas line connected.
Controlling Flare-ups
WCAUTION: Putting out grease fires by only closing the lid is not
possible.
1. If a grease fire develops, turn control knobs to the “ OFF” position
(a) LP gas tank valve “CLOSED” or
(b) NG main valve “OFF”
Do NOT use water on a grease fire. This can cause the grease to
splatter and could result in serious burns, bodily harm or other
damage.
2. Do NOT leave grill unattended while preheating or burning off food
residue on (HIGH). If grill has not been cleaned, a grease fire can
occur.
WWARNING: When cooking, fire extinguishing materials should be
readily accessible. In the event of an oil/grease fire, use type BC dry
chemical fire extinguisher or smother with dirt, sand or baking soda.
Do NOT attempt to extinguish with water.
Flare-ups are a part of cooking meats on a grill and add to the unique flavor of grilling.
Excessive flare-ups can over-cook your food and be dangerous.
Important: Excessive flare-ups result from the build-up of grease in the bottom of your grill.
Figure 5
Lighting
hook
Match
Figure 6
Burner
Flame Slight
Yellow
Slight
Blue
Dark
Blue
Operating Instructions (continued)
Figure 1: Main Burners
Burner/
venturi tube
LP Gas
Valve with
Orifice
LP Gas
Connection
Figure 2: Side Burner
LP Gas
Connection
Valve Soft Pipe
Connection
LP Gas
Valve with
Orifice
Burner/
venturi
tube
Figure 3
OFF
APAGADO
Figure 4a
X
XX
XX
Figure 4b
X
X

Need help? 1.800.762.1142
Do not return to place of purchase.
Recipes
BlueRhino.com/recipes
Replacement Parts
parts.BlueRhino.com /
1.800.762.1142 11
If a grease fire occurs, close the lid AND turn the control knob(s) to “ OFF” until the grease
burns out. Be careful when opening the lid as sudden flare-ups may occur.
If excessive flare-ups occur, do NOT pour water onto the flames.
Minimize Flare-ups:
1. Trim excess fat from meats prior to cooking.
2. Cook high fat content meats on (LOW) setting or indirectly.
3. Ensure that your grill is on a hard, level, non-combustible surface and the grease is
allowed to drain into grease receptacle.
Operating Side Burner
NOTE: Side burner can be used while main burners are operating.
Never use side burner as a grill.
WCAUTION: Maximum weight for side burner and side shelf is 33 lbs.
WCAUTION: Using pots larger than 6 quarts in capacity could exceed
weight limit of the side burner shelf, resulting in failure of grill cart
components.
WCAUTION: Do NOT lean on the side burner shelf.
WCAUTION: Attempting to light the burner with the lid closed may cause
an explosion.
Lighting
1. Open lid.
2. Check for obstructions of airflow to the burners.
Spiders, insects and webs can clog the burner/
venturi tube. A clogged burner tube can lead to
a fire.
3. Control knob must be in the “ OFF” position
(Figure 3).
4. LP: Connect LP gas tank per “Installing LP Gas
Tank” section.
NG: Connect NG main line per “Installing Natural
Gas Line” section.
5. LP: Turn LP gas tank valve to “OPEN.”
NG: Turn natural gas main valve to “ON.”
6. Push and turn control knob to (HIGH). The
burner should light. If not, repeat up to three
times.
7. If ignition does not occur in 5 seconds, turn burner control knob “ OFF,” wait 5 minutes
and repeat lighting procedure.
8. If igniter does not light burner, use a lit match secured with the lighting rod (included with
grill) to light burners. Position the lit match near side of the burner (Figure 7).
Important: Always use the lighting rod (included) when lighting burner with a match.
9. After lighting, observe the burner flame. Make sure all burner ports are lit and flame height
matches illustration (Figure 6).
WCAUTION: If burner flame goes out during operation, immediately turn
the control knob to the “ OFF” position
(a) LP gas tank valve “CLOSED” or
(b) NG main valve “OFF”
and open lid to let the gas clear for 5 minutes before re-lighting.
Turning Off
1. LP: Turn LP gas tank valve to “CLOSED.”
NG: Turn natural gas main valve to “OFF.”
2. Turn control knob clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the LP gas is burned.
3. LP: Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
NG: Keep NG main gas line connected.
Cooking
1. Open lid and ignite the side burner per “Lighting” instructions.
2. Adjust control knob to desired flame height.
3. Place pan on center of grid.
4. Cook and adjust temperature as needed.
5. Turn grill off per “Turning Off” instructions.
Figure 7
Lighting
Hook
Match
Operating Instructions (continued) Cleaning and Care
WCAUTION:
1. All cleaning and maintenance should be done when grill is cool
and with the fuel supply disconnected.
2. Do NOT clean any grill part in a self-cleaning oven. The extreme
heat will damage the finish.
3. Do NOT enlarge valve orifices or burner ports when cleaning the
valves or burners.
WCAUTION: Unplug rotisserie motor from the outlet when not in use and
before cleaning. Allow to cool before putting on or taking off parts.
Notices
1. This grill should be thoroughly cleaned and inspected on a regular basis.
2. Abrasive cleaners will damage this product.
3. Never use oven cleaner to clean any part of grill.
Before Each Use:
1. Keep the grill area clean and free from any
combustible materials, gasoline, and other
flammable vapors and liquids.
2. Do NOT obstruct the flow of the combustion of LP
gas and the ventilation of air.
3. Keep the ventilation opening(s) of the LP gas tank
area free and clear from debris.
4. Visually check the burner flames to make sure
your grill is working properly (Figure 8).
5. See sections below for proper cleaning
instructions.
6. Check for obstructions of airflow to the burners.
Spiders, insects and webs can clog the burner/
venturi tube. A clogged burner tube can lead to
a fire.
Cleaning Surfaces
1. Wipe surfaces clean with mild dishwashing
detergent or baking soda mixed with water.
2. For stubborn surfaces, use a citrus-based
degreaser and a nylon scrubbing brush.
3. Rinse clean with water.
4. Allow to air dry.
Cleaning Main Burners
1. LP: Turn LP gas tank valve to “CLOSED.”
NG: Turn natural gas main valve to “OFF.”
2. Turn all control knobs clockwise to the “ OFF”
position.
Note: A “poof” sound is normal as the last of the
gas is burned.
3. LP: Disconnect LP gas tank per “Disconnecting
LP Gas Tank” section.
NG: Disconnect main gas line per “Disconnecting Natural Gas Line” section.
4. Remove cooking grids and heat plates.
5. Remove burners by removing the fasteners, which secure the burners to the grill bottom.
6. Lift burners up and away from gas valve orifice.
7. Disconnect wire from spark electrode.
8. Clean venturi of each burner with small bottle brush or compressed air.
9. Remove all food residue and dirt on burner surfaces.
10. Clean any clogged ports with a stiff wire (such as an opened paper clip).
11. Inspect burners for any damage (cracks or holes). If damage is found, replace with new
burner(s) from manufacturer.
12. Reinstall burners, checking to insure that gas valve orifice is correctly positioned inside
each burner/venturi tube. Also, check position of spark electrode.
13. Replace heat plate(s) and cooking grid(s).
14. LP: Connect LP gas tank per “Installing LP Gas Tank” section.
NG: Connect NG main line per “Installing Natural Gas Line” section.
15. Perform leak test per “Checking for Leaks” section.
Cleaning Side Burner
1. LP: Turn LP gas tank valve to “CLOSED.”
NG: Turn natural gas main valve to “OFF.”
2. Turn all control knobs clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the gas is burned.
3. LP: Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
NG: Disconnect main gas line per “Disconnecting Natural Gas Line” section.
4. Remove side burner grid.
5. Remove burner by removing the screws that secure the burner to the side shelf.
6. Lift burner up and away from gas valve orifice.
Figure 8
Burner Flame Conditions
Use this chart to see if your burners
need to be cleaned.
1-2 in. /
25.4 - 50.8 mm
Normal: Soft blue flames with yellow
tips between 1 in. - 2 in. height.
Needs cleaning: Noisy with hard
blue flames.
Has to be replaced: Wavy with
yellow flames.

Outdoor LP Gas Barbecue Grill
Model No. GBC1449W Series
12
7. Clean venturi of burner with small bottle brush or compressed air.
8. Remove all food residue and dirt on burner surface.
9. Clean any clogged ports with a stiff wire (such as an opened paper clip).
10. Inspect burner for any damage (cracks or holes). If damage is found, replace with new
burner from manufacturer.
11. Reinstall burner, check to insure that gas valve orifice is correctly positioned inside burner/
venturi tube, also check position of the spark electrode.
12. Replace cooking grid(s).
13. LP: Connect LP gas tank per “Installing LP Gas Tank” section.
NG: Connect NG main line per “Installing Natural Gas Line” section.
14. Perform leak test per “Checking for Leaks” section.
Before Storing
1. LP: Turn LP gas tank valve to “CLOSED.”
NG: Turn natural gas main valve to “OFF.”
2. Turn all control knobs clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the gas is burned.
3. LP: Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
NG: Disconnect main gas line per “Disconnecting Natural Gas Line” section.
4. Clean all surfaces.
5. Lightly coat the burner(s) and cooking grid(s) with cooking oil to prevent excess rusting.
6. If storing the grill indoors, disconnect the LP tank per “Disconnect LP Gas Tank” section.
7. Place the protective cap cover on the LP tank and store the tank outdoors in a well-
ventilated area out of direct sunlight.
8. If storing the grill outdoors, cover the grill with a grill cover for protection from the weather.
Product Registration
For faster warranty service, register your product immediately at BlueRhino.com/warranty or by
calling 1.800.762.1142.
Replacement Parts
Replacement parts can be found at parts.BlueRhino.com or by calling 1.800.762.1142.
Limited Warranty
Blue Rhino Global Sourcing, Inc (“Blue Rhino”) warrants to the original retail purchaser of this
product, and to no other person, that if this product is assembled, maintained, and operated
in accordance with the printed instructions accompanying it, then for a period of five (5) years
for the burners and one (1) year for all remaining parts from the date of purchase, all parts in
such product shall be free from defects in material and workmanship. Blue Rhino may require
reasonable proof of your date of purchase. Therefore, you should retain your sales slip or
invoice. This Limited Warranty shall be limited to the repair or replacement of parts, which prove
defective under normal use and service and which Blue Rhino shall determine in its reasonable
discretion upon examination to be defective. Before returning any parts, you should contact
Blue Rhino’s Customer Care Department using the contact information listed below. If Blue
Rhino confirms, after examination, a defect covered by this Limited Warranty in any returned
part, and if Blue Rhino approves the claim, Blue Rhino will replace such defective part without
charge. If you return defective parts, transportation charges must be prepaid by you. Blue Rhino
will return replacement parts to the original retail purchaser, freight or postage prepaid.
This Limited Warranty does not cover any failures or operating difficulties due to accident,
abuse, misuse, alteration, misapplication, improper installation or improper maintenance or
service by you or any third party, or failure to perform normal and routine maintenance on
the product as set out in this owner’s manual. In addition, the Limited Warranty does not cover
damage to the finish, such as scratches, dents, discoloration, rust or other weather damage,
after purchase.
This Limited Warranty is in lieu of all other express warranties. Blue Rhino disclaims all
warranties for products that are purchased from sellers other than authorized retailers or
distributors, including the warranty of merchantability or the warranty of fitness for a particular
purpose. Blue Rhino ALSO DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING
WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. Blue Rhino SHALL HAVE NO LIABILITY TO PURCHASER OR ANY THIRD
PARTY FOR ANY SPECIAL, INDIRECT, PUNITIVE, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
Blue Rhino further disclaims any implied or express warranty of, and assumes no responsibility
for, defects in workmanship caused by third parties.
This Limited Warranty gives the purchaser specific legal rights; a purchaser may have other
rights depending upon where he or she lives. Some jurisdictions do not allow the exclusion or
limitation of special, incidental or consequential damages, or limitations on how long a warranty
lasts, so the above exclusion and limitations may not apply to everyone.
Blue Rhino does not authorize any person or company to assume for it any other obligation
or liability in connection with the sale, installation, use, removal, return, or replacement of its
equipment, and no such representations are binding on Blue Rhino.
Blue Rhino Global Sourcing, Inc.
Winston-Salem, North Carolina 27105 USA
1.800.762.1142
Cleaning and Care (continued)

Need help? 1.800.762.1142
Do not return to place of purchase.
Recipes
BlueRhino.com/recipes
Replacement Parts
parts.BlueRhino.com /
1.800.762.1142 13
Troubleshooting
Problem Possible Cause Prevention/Cure
Burner will not light using ignitor
LP gas tank valve is closed
NG main valve is closed
LP: Make sure regulator is securely attached to the LP gas tank per “Installing
LP Gas Tank,” then turn LP gas tank valve to “OPEN”
NG: Make sure regulator and NG main line are securely attached per “Installing
Natural Gas Line,” then turn NG main valve to “ON”
LP gas tank is low or empty Exchange, refill or replace LP gas tank
LP gas / NG leak
1. LP: Turn LP gas tank valve to “CLOSED”
NG: Turn natural gas main valve to “OFF”
2. Wait 5 minutes for gas to clear
3. Follow “Checking for Leaks” section
Battery needs to be changed Replace the “AA” battery (follow assembly step for inserting battery)
Wires or electrode covered with cooking residue Clean wire and/or electrode with rubbing alcohol
Electrode and burners are wet Wipe dry with cloth
Electrode cracked/broken - sparks at crack Replace electrode
Wire loose or disconnected Reconnect wire or replace electrode/wire assembly
Wire is shorting (sparking) between ignitor and electrode Replace ignitor wire/electrode assembly
Bad ignitor Replace ignitor
Burner will not light with match
No gas flow
LP: Check if LP gas tank is empty
A. If empty, exchange, refill or replace LP gas tank
B. If LP gas tank is not empty, refer to “Sudden drop in gas flow or reduced
flame height” (see below)
NG: Check if NG main valve is connected
A. Make sure regulator and NG main line are securely attached, then turn NG
main valve to “OPEN”
B. If NG main valve is “ON,” then refer to “Sudden drop in gas flow or reduced
flame height” (see below)
LP gas tank is low or empty Exchange, refill or replace LP gas tank
LP gas / NG leak
1. LP: Turn LP gas tank valve to “CLOSED”
NG: Turn natural gas main valve to “OFF”
2. Wait 5 minutes for gas to clear
3. Follow “Checking for Leaks” section
Coupling nut and regulator not fully connected Turn the coupling nut about one-half to three quarters additional turn until solid
stop. Tighten by hand only - do NOT use tools.
Obstruction of gas flow 1. Clear burner/venturi tube
2. Check for bent or kinked hose
Disengagement of burner to valve Reengage burner and valve
Spider webs or insect nest in burner/venturi tube Clean burner/venturi tube
Burner ports clogged or blocked Clean burner ports
Sudden drop in gas flow or reduced flame height
LP: Out of gas Exchange, refill or replace LP gas tank
NG: No main line pressure Call your natural gas provider to inspect natural gas line
LP: Overfilling prevention device may have been
activated
1. Turn control knobs to “ OFF”
2. Wait 30 seconds and light grill
3. If flames are still too low, reset the overfilling prevention device:
a. Turn control knob(s) “ OFF”
b. Turn LP gas tank valve to “CLOSED”
c. Disconnect regulator
d. Turn control knobs to (HIGH)
e. Wait 1 minute
f. Turn control knobs to “ OFF”
g. Reconnect regulator and leak check connections, being careful not to
fully open valve.
h. Light grill per “Lighting” section
Irregular flame pattern, flame does not run the
full length of burner Burner ports are clogged or blocked Clean burner ports
Flame is yellow or orange
New burner may have residual manufacturing oils Burn grill for 15 minutes on (HIGH) with the lid closed
Spider webs or insect nest in burner/venturi tube Clean burner/venturi tube
Food residue, grease, etc. on burners Clean burner
Poor alignment of valve to burner/venturi tube Ensure burner venturi is properly engaged with valve
Flame goes out
High or gusting winds Do NOT use grill in high winds
Low on LP Gas Exchange, refill or replace LP gas tank
Overfilling prevention device may have been activated Refer to “Sudden drop in gas flow or reduced flame height” (see above)
Flare-up
Grease buildup Remove and clean all grill parts per “Cleaning and Care” section
Excess fat in meat Trim fat from meat before grilling
Excessive cooking temperature Adjust to lower cooking temperature
Persistent grease fire Grease trapped by food buildup around burner system
1. Turn control knobs to “ OFF”
2. LP: Turn LP gas tank valve to “CLOSED”
NG: Turn natural gas main valve to “OFF”
3. Leave lid in closed position and let fire burn out
4. After grill cools, remove and clean all parts per “Cleaning and Care” section
Flashback (fire in burner tube(s)) burner/venturi tube are blocked Clean burner/venturi tube(s)
Inside of lid is peeling (like paint peeling)
The lid is stainless steel, not painted Grease buildup has turned to carbon and is flaking off – clean thoroughly per
“Cleaning and Care” section
The lid is coated/painted
• This can be from baked on grease buildup that has turned into carbon and is
flaking off
• Clean thoroughly per “Cleaning and Care” section
For more assistance, please visit us at BlueRhino.com or call 1.800.762.1142.

MANUAL DEL USUARIO
Está disponible el kit de
conversión a gas natural (nº
de modelo VFK1001W1) en
las tiendasWalmart.com
Parrilla de gas propano
para exteriores
Modelo de la serie GBC1449W
Fabricado en China para: Blue Rhino Global Sourcing, Inc
Winston-Salem, NC EE.UU. • 1.800.762.1142 • BlueRhino.com
© Blue Rhino Global Sourcing, Inc.
Backyard Grill™ es registradas de Wal-Mart Stores, Inc. Usado con el permiso. GBC1449W_s-OM-105 ES
Índice
Salvaguardias importantes ..................................... Página 2
Despiece y elementos de ferretería..................................... 4
Instrucciones de armado ............................................ 5
Instalación del tanque de gas propano líquido (PL) ......................... 9
Insertar el tanque de gas propano líquido .............................. 9
Asegurar el tanque de gas propano líquido ............................. 9
Conectar el tanque de gas propano líquido ............................. 9
Desconectar el tanque de gas propano líquido........................... 9
Instalación de la línea de gas natural .................................. 10
Conectar la línea de gas natural .................................... 10
Desconectar la línea de gas natural.................................. 10
Instrucciones de operación.......................................... 10
Detección de fugas .............................................. 10
Operación de los quemadores principales ............................. 10
Operación del quemador lateral..................................... 11
Limpieza y cuidado................................................ 11
Registro del producto .............................................. 13
Piezas de repuesto ................................................ 13
Garantia limitada ................................................. 13
Resolución de problemas ........................................... 14
El uso e instalación de este producto ha de realizarse de acuerdo con los códigos
locales. Si no existen códigos locales, use las normas siguientes: Código Nacional
de Gas Combustible, ANSI Z223.1/NFPA 54, Código de Instalación de Propano y Gas
Natural CAN/CGA-B149.1, o el Código de Manipulación y Almacenaje de Propano
B149.2, o la Norma sobre Vehículos Recreativos, ANSI A 119.2/NFPA 1192, y CSA
Z240 Serie VR, y el Código sobre Vehículos Recreativos, según aplique.
ESTE MANUAL DE INSTRUCCIONES CONTIENE INFORMACIÓN IMPORTANTE SOBRE LA
SEGURIDAD. POR FAVOR, LÉALO Y CONSÉRVELO PARA FUTURAS CONSULTAS.
Si está montando esta unidad para otra persona, entréguele este manual para futuras
consultas.
Propuesta 65 de California: La combustión del propano al usar esta unidad crea
productos químicos considerados por el Estado de California como causantes de
cáncer, malformaciones congénitas u otros daños reproductivos.
Propuesta 65 de California: Lavarse las manos después de manipular este producto.
Hecho con 75% de bagazo de caña
(subproducto de la caña de azúcar
respetuoso del medio ambiente)
ADVERTENCIA
PARA SU SEGURIDAD:
Solamente para uso en exteriores
(fuera de cualquier recinto)
ADVERTENCIA
PARA SU SEGURIDAD:
1. Una instalación, ajuste, alteración, reparación
o mantenimiento inadecuados pueden causar
lesiones o daños a la propiedad.
2. Lea atentamente las instrucciones de
instalación, funcionamiento y mantenimiento
del equipo antes de instalarlo, ponerlo en
marcha o darle servicio.
3. El no seguir estas instrucciones puede
ocasionar un incendio o una explosión, con sus
consecuentes daños a la propiedad, lesiones
personales y hasta accidentes fatales.
4. Este manual de instrucciones contiene
información importante necesaria para un
correcto ensamblaje y uso seguro del aparato.
5. Lea y siga todas las instrucciones y
advertencias antes de ensamblar y usar el
producto.
6. Obedezca todas las advertencias e
instrucciones cuando use el equipo.
7. Guarde este manual para referencia futura.
PELIGRO
Si huele a gas -
1. Cierre la entrada de gas al aparato.
2. Apague cualquier llama activa.
3. Abra la tapa.
4. Si el olor persiste, manténgase alejado del
aparato y llame inmediamente a su proveedor
de gas o al departamento de bomberos.
ADVERTENCIA
PARA SU SEGURIDAD:
1. No guarde o use gasolina u otros líquidos o
vapores inflamables cerca de esta unidad o de
cualquier otro aparato.
2. Un tanque de propano líquido que no esté
conectado para su uso no se debe almacenar
cerca de éste o cualquier otro aparato.
PELIGRO
Nunca deje este artefacto encendido sin vigilancia.

Parrilla de gas propano para exteriores,
modelo de la serie GBC1449W
2
WEsta parrilla es para ser usada al aire libre únicamente y no debe usarse
en un edificio, garaje o cualquier otra área cerrada.
WNO opere, encienda o use esta unidad a menos de diez (10) pies
(3,05 m) de paredes, estructuras o edificaciones.
WPara uso residencial únicamente. Esta parrilla NO ha sido diseñada para
uso comercial.
WEsta parrilla no ha sido diseñada como calentador y nunca se la debe
utilizar como tal. Gases TÓXICOS pueden acumularse y provocar la
asfixia.
WEsta parrilla tiene certificación de seguridad para uso en los Estados
Unidos y/o Canadá solamente. No debe modificarse para uso en ningún
otro lugar. Cualquier modificación resultará en un riesgo de seguridad e
invalidará su garantía.
WEsta parrilla utiliza únicamente gas de propano líquido como
combustible. El convertir o tratar de convertir esta parrilla de gas
propano líquido para ser usada con gas natural es peligroso e invalida
la garantía de la unidad.
WEsta parrilla, tal como llega de la fábrica, es para uso con gas propano
líquido (PL). Puede usarse el kit de conversión a gas natural número
de modelo VFK1001W1 para convertir su parrilla a gas natural. El uso
de cualquier otro kit de conversión es peligroso, puede causar lesiones
personales y anulará la garantía.
WCaracterísticas del propano líquido (PL):
a. El propano es inflamable y resulta peligroso si se manipula
inadecuadamente. Antes de utilizar cualquier producto que emplee
propano líquido, estudie detenidamente sus características.
b. El gas de propano líquido es explosivo bajo presión, más denso que
el aire, se asienta y se acumula a poca altura.
c. En su estado natural, el propano no tiene ningún olor. Para su
seguridad, se añade una esencia odorífera que huele a col podrida.
d. El contacto directo con el propano líquido puede causar
quemaduras frías en la piel.
WCaracterísticas del gas natural (GN):
a. El gas natural es inflamable y resulta peligroso si se manipula
inadecuadamente. Antes de utilizar cualquier producto que emplee
gas natural, estudie detenidamente sus características.
b. El gas natural es explosivo bajo presión, más denso que el aire, se
asienta y se acumula a poca altura.
c. En su estado natural, el gas natural no tiene ningún olor. Para su
seguridad, se añade una esencia odorífera que huele a col podrida.
d. El contacto directo con el gas natural puede causar quemaduras
frías en la piel.
WHabitantes de apartamentos: Comuníquese con la administración
para obtener los requisitos y los códigos de incendio para uso de una
parrilla a gas propano líquido en su complejo de apartamentos. Si está
permitido su uso, coloque la unidad en exteriores, sobre el suelo con
una distancia de diez (10) pies (3 m) de paredes o barandas. No debe
usarse en balcones ni debajo de estos.
WSe requiere un tanque de gas propano para hacer funcionar este
aparato. Únicamente tanques marcados “Propano” pueden usarse en
esta unidad.
WEl tanque de gas propano líquido (PL) debe estar fabricado y
comercializado según las Especificaciones para tanques de gas
propano líquido del Departamento de Transporte (DOT) de EE.UU. o del
Estándar nacional de Canadá, CAN/CSAB339 sobre tanques, esferas y
tubos para el transporte de mercancías peligrosas; y la comisión.
WVerifique que el tanque de gas propano líquido esté en una posición
adecuada para la extracción de vapor.
WEl tanque de gas propano líquido debe tener un dispositivo que evite el
sobrellenado del tanque (OPD).
WUtilice únicamente tanques de propano que tienen un dispositivo de
conexión compatible con aparatos de cocción al aire libre.
WNO utilice nunca un tanque de propano líquido si el cuerpo no tiene
collar para proteger la válvula.
WNO utilice nunca un tanque de propano líquido si el cuerpo, la válvula, el
collar o el anillo inferior presentan algún daño.
WLos tanques de propano líquido abollados u oxidados pueden ser
peligrosos y deberían ser revisados por su proveedor de gas PL antes
de utilizarlos.
WNO deje caer el tanque de gas propano líquido ni lo maneje
bruscamente.
WLos tanques deben almacenarse en exteriores, en un lugar al aire libre
siempre fuera del alcance de los niños y nunca en un garaje, edificio o
espacio cerrado. Nunca almacene tanques de gas en un lugar en el que
la temperatura supere los 125˚F (51,5˚C).
WNO inserte ninguna herramienta u objeto extraño en la salida de la
válvula ni en la válvula de seguridad. Puede dañar la válvula y causar
una fuga. Una fuga de gas propano puede causar una explosión, un
incendio, lesiones personales graves o la muerte.
WNO obstruya los agujeros situados a los lados y en la parte trasera de la
parrilla.
WNO ponga nunca un tanque de gas propano lleno en un carro o
camioneta calientes. El calor podría hacer que la presión del gas
aumentase, lo que abriría la válvula de seguridad y haría que se
escapase el gas.
WPonga la tapa contra el polvo en la válvula de salida del tanque cuando
no lo esté usando. Únicamente use la tapa contra el polvo que viene con
la válvula del tanque. Otros tipos de tapones o tapas pueden crear fugas
del propano.
WSi la parrilla no se está usando, el gas debe cerrarse en el tanque de
suministro y se debe desconectar el tanque.
WNunca guarde un tanque adicional de propano debajo o cerca de esta
parrilla.
WNunca llene el tanque más allá de 80% de su capacidad.
WEl no seguir exactamente las instrucciones dadas arriba puede producir
un incendio con daños a la propiedad, lesiones serias y hasta fatales.
WNO intente nunca acoplar esta parrilla al sistema de propano de un
campero, de una casa móvil o de su propia casa.
WNO use nunca carbón de leña, líquido para encendedor, rocas de lava,
gasolina, queroseno o alcohol con este aparato.
WTodas las conexiones de gas de su parrilla han sido verificadas en
fábrica en cuanto a fugas de gas. Sin embargo, vuelva a probar la
integridad de todas las conexiones como se indica en las “Instrucciones
de operación” ya que el movimiento en transporte puede aflojar algunas
de ellas.
WVerifique que no haya fugas aún si el aparato ha sido armado por otra
persona.
WNO opere la unidad si hay una fuga de gas. Las fugas de gas pueden
provocar un fuego o una explosión.
WAntes de operar esta unidad, debe observar todos los procedimientos
para verificar que no hay fugas de gas. Para evitar cualquier riesgo de
fuego o de explosión al comprobar si hay fugas:
a. Compruebe siempre si hay fugas antes de encender la parrilla, cada
vez que el tanque de gas está conectado.
b. No fume. No use o permita fuentes de ignición en el área al
comprobar si hay fugas.
c. Siempre compruebe si hay fugas en exteriores donde hay una buena
ventilación.
d. No use cerillas, encendedores o una llama para comprobar si hay
fugas.
e. El uso de bebidas alcohólicas, medicamentos o drogas de farmacia
puede afectar la habilidad del usuario para armar debidamente u
operar en forma segura este aparato.
f. Los olores fuertes, los resfríos, la congestión de los senos nasales,
etc. pueden evitar la detección del gas propano. Tome medidas de
precaución y sentido común al realizar pruebas para determinar la
presencia de fugas.
g. No use la parrilla hasta que todas las fugas hayan sido reparadas.
PROPANO: Si no puede parar una fuga, desconecte el tanque de
propano. Llame a un técnico de servicio de artefactos a gas o a su
proveedor de propano local.
PELIGRO: El no seguir los avisos de peligro, las advertencias y las precauciones, puede ocasionar un incendio o una explosión, con sus consecuentes
daños a la propiedad, lesiones personales y hasta accidentes fatales.
ADVERTENCIAS :
Salvaguardias importantes

¿Necesita ayuda?
Llame al 1.800.762.1142.
No vuelva al lugar de compra.
Para recetas, visite
BlueRhino.com/recipes
Para piezas de repuesto, visite
parts.BlueRhino.com /
1.800.762.1142 3
GAS NATURAL: Si no puede detener una fuga, cierre la válvula
principal que se encuentra en la línea de suministro de gas natural.
Llame a un técnico de servicio de artefactos a gas o a su proveedor
local de gas natural.
WGAS NATURAL: El artefacto y su válvula de cierre individual deben
desconectarse del sistema de tuberías del suministro de gas durante
una prueba de presión de dicho sistema a presiones que excedan 1/2
psig (3.5 kpa).
WGAS NATURAL: El artefacto debe aislarse del sistema de tuberías de
suministro de gas cerrando su válvula de cierre manual individual
durante una prueba de presión del sistema de tuberías de suministro de
gas a presiones de prueba de 1/2 psig (3.5 kpa) o menores.
WEsta parrilla está diseñada para funcionar con las presiones de entrada
siguientes: Gas propano líquido (PL): 11 pulgadas (28 cm) de columna
de agua. Gas natural (GN): 7 pulgadas (18 cm) de columna de agua.
WNO guarde o use gasolina u otros líquidos o vapores inflamables a
menos de 7,6 m (25 pies) de esta unidad.
WNO utilice el equipo en una atmósfera explosiva. Mantenga la zona de
la parrilla libre de materiales combustibles, gasolina y cualquier otro
vapor o líquido inflamable.
WEl espacio mínimo entre los laterales y la parte posterior de la unidad
y la construcción combustible es de 36 pulgadas (92 cm). NO use esta
parrilla debajo de aleros o bajo techo.
WEs fundamental mantener limpio el compartimiento de la válvula de la
parrilla, los quemadores y los conductos de aire circulante.
WInspeccione la parrilla antes de cada uso.
WNO altere la parrilla de ninguna forma. Toda alteración anulará la
garantía.
WNO utilice la parrilla a menos que esté COMPLETAMENTE montada y que
todas las piezas estén bien fijadas y apretadas.
WNO instale este modelo de parrilla en ninguna construcción empotrada
o que requiera deslizamiento interior. Ignorar esta advertencia podría
provocar un incendio o una explosión y causar daños materiales así
como lesiones corporales graves o la muerte.
WEsta parrilla de gas debe limpiarse y verificarse completamente de
manera regular.
WLimpie y revise la manguera antes de cada uso del aparato. Si detecta
alguna señal de abrasión, desgaste, cortes o fugas, deberá sustituir la
manguera antes poner en marcha el aparato.
WUtilice únicamente el regulador y el conjunto de manguera incluido. El
regulador de repuesto y el conjunto de manguera de repuesto serán los
especificados por Rhino Global Sourcing, Inc.
WUse únicamente piezas autorizadas de fábrica de Blue Rhino Global
Sourcing, Inc. El uso de cualquier pieza no autorizada de fábrica puede
ser peligroso. Su uso invalida su garantía.
WNO encienda esta unidad sin haber leído las “Instrucciones de
operación” que se encuentran en este manual.
WNO toque las piezas de metal de la parrilla hasta que no se haya
enfriado completamente (alrededor de 45 minutos) para evitar
quemaduras, a menos que usted tenga puestos elementos de protección
tales como guantes o almohadilla para las ollas, guantes de barbacoa,
etc.
WNO instalar o utilizar en embarcaciones o vehículos recreativos.
WCuando esté cocinando, tenga fácilmente accesibles los elementos para
extinguir un incendio. En caso de que la sustancia de freír se incendie
no trate de extinguir el fuego con agua. Use un extinguidor de material
químico seco tipo BC o ahogue el fuego con tierra, arena o soda de
hornear.
WNO utilice la parrilla si hace mucho viento.
WNunca se apoye sobre la parrilla cuando la está encendiendo.
WNO deje una parrilla encendida sin vigilancia, especialmente, mantenga
los niños y las mascotas lejos de la parrilla en todo momento.
WNO deje la parrilla sin supervisión al precalentar o quemar residuos de
alimentos con la perilla en la graduación más alta. Si la parrilla no ha
sido limpiada, puede incendiarse la grasa y dañar el producto.
WNO coloque los recipientes de cocción sobre el artefacto mientras está
en funcionamiento.
WTenga cuidado al colocar cosas sobre la parrilla cuando ésta se
encuentre en funcionamiento.
WNO intente mover la parrilla mientras esté encendida. Deje que la
parrilla se enfríe antes de moverla o guardarla.
WEl tanque de gas propano líquido debe desconectarse correctamente y
retirarse antes de mover esta parrilla.
WEl almacenamiento del aparato en un espacio cerrado sólo está
permitido si el tanque está desconectado, desmontado del aparato y
guardado al aire libre.
WAbra siempre la tapa de la parrilla en forma cuidadosa y lentamente,
pues el calor y el vapor que hay dentro de la parrilla pueden ocasionarle
severas quemaduras.
WNO trate de desconectar el regulador de gas del tanque, o cualquier otro
accesorio de la línea de gas, mientras esté usando la parrilla.
WColoque siempre la parrilla sobre una superficie firme y nivelada,
alejada de productos combustibles. Una superficie de asfalto o de
pavimento puede que no sea adecuada para este propósito.
WRetire las mangueras de gas lo más lejos posible de las superficies
calientes y de las zonas donde gotee grasa caliente.
WMantenga todos los cables eléctricos lejos de una parrilla caliente.
WDespués de un período de almacenamiento o de falta de uso de la
unidad, verifique que no haya fugas u obstrucciones en el quemador e
inspeccione la manguera para detectar zonas gastadas o cortes en ella.
WEl no abrir la tapa cuando se están encendiendo los quemadores de la
parrilla, o el no esperar cinco minutos para permitir que el gas salga
de la parrilla cuando el gas no se ha encendido, puede provocar una
llamarada explosiva.
WNunca opere la parrilla antes de haber instalado las placas de
distribución de calor.
WUse siempre un termómetro para carne para asegurar que la comida ha
quedado cocida a la temperatura apropiada.
WPor favor, use guantes de protección cuando esté armando este
producto.
WNO trate de forzar las piezas juntas pues esto puede ocasionar lesiones
o dañar el producto.
WNunca cubra la totalidad del área de cocción con papel de aluminio.
WEl no seguir exactamente las instrucciones dadas arriba puede producir
daños a la propiedad, lesiones serias y hasta fatales.
Salvaguardias importantes

Parrilla de gas propano para exteriores,
modelo de la serie GBC1449W
4
1
15
23
Lista de piezas
1Manija de la tapa 55-22-326
2Indicador de
temperatura 55-24-043
3Rejilla de
calentamiento 55-23-026
4Rejilla de
cocción (3) 55-23-027
5Tapa*
55-24-089 (W)
55-24-099 (WBS)
55-24-094 (WRS)
6Rejilla del
quemador lateral 55-10-047
7Quemador lateral 55-23-029
8Repisa derecha 55-24-271
9
Placa de
distribución de
calor (4)
55-10-156
10 Quemador (4)* 55-23-031
11 Carcasa de la
parrilla*
55-24-272 (W)
55-24-275 (WBS)
55-24-277 (WRS)
12
Soporte de la
perilla de
control (5)*
55-09-006
13 Perilla de
control (5) 55-09-007
14 Regulador y
manguera* 55-23-033
15 Repisa izquierda 55-23-034
16 Marco derecho del
carro 55-23-035
17 Recogedor de
grasa 55-11-018
18 Bandeja para la
grasa 55-23-036
19 Destapador* 55-23-037
20 Marco izquierdo del
carro 55-23-038
21 Rueda (2) 55-07-363
22 Eje 55-23-039
23
Alambre de
retención del
tanque de propano
55-23-040
24 Soporte trasero del
carro 55-23-041
25 Vara de soporte del
carro (2) 55-23-041
26 Pie (2) 55-23-043
27 Panel frontal
superior
55-24-273 (W)
55-24-276 (WBS)
55-24-278 (WRS)
28 Panel frontal
inferior
55-23-045 (W)
55-24-101 (WBS)
55-23-510 (WRS)
29 Varilla de
encendido 55-07-331
*Viene ensamblado
Despiece
27
16
19 14
3
6
4
4
4
5
7
11
20
24
21
21
25
28
2
17
18
26
10
12
13
Herramientas necesarias para el armado (incluidas)
Destornillador en cruz (Phillips) no. 2 1 pz
Llave inglesa M10-M6 2 pzs
Elementos de ferretería
ATornillo Niquelado, de cabeza Phillllips abombada,
ST4,8x10 2 pzs
BTornillo Niquelado, de cabeza Phillllips abombada, M4x10 4 pzs
CPerno Niquelado, de cabeza Phillllips hexagonal, M6x16 26 pzs
DPerno de
mariposa Niquelado, M6x16 1 pz
ETuerca Niquelada, M10 2 pzs
FTuerca de
mariposa Niquelada, M5 2 pzs
GTuerca de
mariposa Niquelada, M6 2 pzs
HArandela Niquelada, ø6,4 6 pzs
IArandela de cierre Niquelada, ø6,5 6 pzs
9
29
22

¿Necesita ayuda?
Llame al 1.800.762.1142.
No vuelva al lugar de compra.
Para recetas, visite
BlueRhino.com/recipes
Para piezas de repuesto, visite
parts.BlueRhino.com /
1.800.762.1142 5
Instrucciones de armado
1
NO DEVUELVA EL PRODUCTO AL LUGAR DE
COMPRA.
Si necesita ayuda llame, sin cargo, al 1.800.762.1142. Por
favor tenga a mano su manual y el modelo número de la
unidad, para referencia.
Nota: El número o lateral del modelo se encuentra en la parte trasera
o lateral el carro.
Para facilitar el armado:
1. Elija el lugar en el que armará este producto. Para proteger los
componentes, elija una superficie lisa, sin fisuras ni hendijas.
2. Presente todas las piezas.
3. Ajuste todas las conexiones de los elementos de ferretería,
primero en forma manual. Luego, después de completar cada
paso, ajústelos por completo. Tenga cuidado de no ajustar
demasiado. Se podrían dañar las superficies o forzar las
roscas.
4. Para obtener mejores resultados, siga todos los pasos en el
orden indicado.
Para terminar el armado de la unidad necesitará:
• una (1) solución para detección de fugas. Las instrucciones
sobre cómo preparar esta solución se encuentran en la
sección “Instrucciones de operación”.
• GAS PROPANO (PL): un (1) un tanque de gas propano líquido,
para parrilla, llenado con precisión y con rosca externa Acme
Tipo 1 para conexión de válvula.
• GAS NATURAL (GN): kit de conversión a gas natural, nº de
modelo VFK1001W1 (no incluido).
Tiempo de armado estimado: una hora
3
Acople el eje y las ruedas
Ex 2
4
Acople los paneles frontales
Cx 8
2
Acople los pies
Ax 2

Parrilla de gas propano para exteriores,
modelo de la serie GBC1449W
6
Instrucciones de armado (continuación)
5
Acople las varas de soporte del carro y el soporte
trasero del carro
Cx 4 Fx 2
6
Acople el alambre de retención del tanque de propano y
la varilla de encendido
Dx 1
8
Acople la carcasa de la parrilla
Cx 4
Hx 4
Ix 4
7
Acople el indicador de temperatura

¿Necesita ayuda?
Llame al 1.800.762.1142.
No vuelva al lugar de compra.
Para recetas, visite
BlueRhino.com/recipes
Para piezas de repuesto, visite
parts.BlueRhino.com /
1.800.762.1142 7
Instrucciones de armado (continuación)
9
Acople la repisa izquierda
Nota: Deje expuesto un segmento de la rosca del perno de unos 5 mm.
Cx 5
10
Acople la repisa derecha
Nota: Deje expuesto un segmento de la rosca del perno de unos 5 mm.
Cx 5
11
Acople la válvula del quemador lateral y el soporte de la
perilla de control
Bx 2
12
Acople el quemador lateral, la rejilla del quemador
lateral y el alambre del encendedor
Bx 2
