badbacks AXIS User manual

STEP 5c: Fasten cross beam E with bolt I and washer J.STEP 5b: Fasten top rail C using bolt H.
STEP 5a: Short end of gear bar D must be fitted into the drive socket in leg B.STEP 5: Attach top rail C and cross beam E, with leg A fitted to leg B.
AXIS HEIGHT ADJUSTABLE DESK
Installation Guide
E
A
B
D
C
B
D
C
B
E
K
I
J
B
H
C
L

* To prevent possible scratches or damage,
assemble the Desk upside down on a soft surface
such as a blanket, carpet or packaging.
* Attach Leg to the Top assembly by using Bolts,
spring washer, flat washer. Tighten using the
Allen Wrench provided.
Recommended
2-person Step
AXIS HEIGHT ADJUSTABLE DESK
Installation Guide
Any top supplied for this unit will be a universal top and will require the installer to correctly position & pre-drill before fixing it to the frame.
A
x 1 x 1 x 1
x 1
x 1
x 2
x 4
x 2
x 2
x 2
x 1
x 1
B C
D
E
F
G
H
I
J
K
L
PARTS

STEP 1: Fit adjustable feet to all legs. STEP 2: Attach top rail C to leg A through support arm using bolt H.
AXIS HEIGHT ADJUSTABLE DESK
Installation Guide
G
G
B
A
C
H
A
C
H
A
L

STEP 3: Attach cross beam E to lower mount on leg A using bolt I and washer J.STEP 4: Insert long hex end of gear bar D to leg A.
AXIS HEIGHT ADJUSTABLE DESK
Installation Guide
E
K
I
J
C
E
A
A
D
C
D
C
E
A

STEP 5c: Fasten cross beam E with bolt I and washer J.STEP 5b: Fasten top rail C using bolt H.
STEP 5a: Short end of gear bar D must be fitted into the drive socket in leg B.STEP 5: Attach top rail C and cross beam E, with leg A fitted to leg B.
AXIS HEIGHT ADJUSTABLE DESK
Installation Guide
E
A
B
D
C
B
D
C
B
E
K
I
J
B
H
C
L

STEP 6: Insert caps G into cross beam E.COMPLETED
AXIS HEIGHT ADJUSTABLE DESK
Installation Guide
EG
E
A
B
D
C

STEP 2: Fold handle away parallel to desk top.STEP 1: Pull handle lever. Tilt handle lever upward and klick into crank handle.
HOW TO OPERATE HANDLE
1
2
3

CHANGING CRANK HANDLE FROM LEFT TO RIGHT OPERATION
STEP 1: Loosen grub screws from locking collar on leg B.STEP 5: Fit the hex drive assembly into the drive socket on leg A.
STEP 2: Slide out crank handle and shaft.
STEP 6: Fit hanger bracket screws and tighten.
STEP 3: Remove hanger bracket screws to release the assembly.
STEP 7: Slide in crank handle assembly.
STEP 4: Slide the hex drive assembly out of the leg.
STEP 8: With crank handle fully retracted, push the locking collar
hard against the furthest bearing on the hanger bracket and
tighten grub screws.
STEP 9: Test operation.
BA
A
A
B
B
