Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 21d
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2021 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly an d se rv ic e may n ot b e in cl uded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 58395 58448
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
IMPORTANT SAFETY INFORMATION
Read all safety warnings and instructions.
Save all warnings and instructions for future reference.
Failure to heed these markings may result in personal injury and/or property damage:
1. Study, understand, and follow all instructions
before operating this device.
2. Do not exceed rated capacity.
3. Use only on hard, flat, level surfaces.
4. Immediately after lifting, support the
vehicle with appropriate means.
5. Wear ANSI-approved safety goggles and
heavy-duty work gloves during use.
6. Keep clear of load while lifting and lowering.
7. Keep head and body clear of the
jack handle path during use.
8. Do not use on curved or sloping vehicle
surfaces. Use properly rated lifting strap
when flat lifting surfaces do not exist.
9. When the jack is under load, the handle must be in
the upright position and clipped to the main rail.
10. When changing jack from lifting to lowering, handle
must be in upright position and clipped to main rail.
11. When lowering load, keep head, body,
and hands clear of handle path and hold
jack handle firmly with both hands.
12. When lowering the load, the jack handle will
have and upward force that must be resisted
by the user’s hands in a controlled manner.
13. The jack must have a load of 150 lb or more to lower
with the handle movement. At loads below 150 lb, the
lifting mechanism will slide down the rail to the base.
14. Do not lift the vehicle more than necessary.
Lifting more than necessary may cause
unexpected movement or tipping.
15. Lower load slowly in controlled fashion.
Do not allow load to drop quickly.
16. Apply parking break and chock tires before using.
17. Inspect before every use;
do not use if parts are bent, loose, or damaged.
18. Do not alter the jack or use attachments and/
or adapters that are not supplied by the
manufacturer. Any alterations or modifications
to this tool may result in dangerous conditions.
19. Be aware of dynamic loading!
Sudden load movement may briefly create
excess load causing product failure.
20. Maintain labels and nameplates on tool.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for replacement.
21. This product is not a toy.
Keep it out of reach of children.
22. The warnings, precautions, and instructions
discussed in this manual cannot cover all
possible conditions and situations that may occur.
The operator must understand that common sense
and caution are factors which cannot be built into
this product but must be supplied by the operator.
SAVE THESE INSTRUCTIONS.

Page 3For technical questions, please call 1-888-866-5797.Item 58395 58448
Specifications
Model 58395 58448
Height 48″ 60″
Rated Load 5000 lb. 5000lb.(4.5″-41″)
3300lb.(41″-53″)
Base Dimensions 5″x9-3/4″ 5″x9-1/2″
Maximum Lift Height 41″ 53″
Minimum Lift Height 4.5″ 4.5″
Setup - Before Use
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Note: For additional information regarding the parts listed in the following pages,
refer to Parts List and Diagram on page 7.
Components
Figure A: Jack Layout

Page 4 For technical questions, please call 1-888-866-5797. Item 58395 58448
Operation
Read ENTIRE IMPORTANT SAFETY INFORMATION section at beginning of this manual
including all text under subheadings therein before set up or use of this product.
Note: For additional information regarding the parts listed in the following pages,
refer to Parts List and Diagram on page 7.
Warning! Keep hand securely on Handle. During lifting and lowering, the weight of the
load pushes up against the Jack Handle. If your hands slip off handle, or if handle is
horizontal when moving the Reversing Latch, Handle may move very rapidly.
Raising Stationary Load
WARNING! Dynamic loading may under certain
circumstances create a situation where the actual
weight being held or lifted is far in excess of Jack or
bolt capacity. DO NOT drop weight onto the Lifting
Arm, or allow sudden motion of the Lifting Arm, as this
mayshearthe1/2″boltorcausetheJacktofail.
WARNING! Do not use the Jack to support
or stabilize load. Always securely chock
and block (stabilize) load to be lifted.
1. Securely chock and stabilize load to prevent
rolling or shifting during lifting process.
2. Place Jack’s base plate securely on a firm,
level, and dry surface with Steel Standard
Bar pointing straight up. See Figure B.
3. Lift the Reversing Latch until it
locks in the up position.
4. Pull the handle away from the Steel Standard
Bar, releasing the Handle Clip Spring.
5. Grasp the Handle and raise the Lifting
Mechanism until the Large Runner is
completely and securely under the load.
Note: Keep Handle against Steel Standard
Bar with the Handle Clip Spring holding it
when not actively lifting or lowering.
6. Grasp the Handle firmly with both hands.
Carefully pump Handle up and down to raise
load. Do not use an extension on Handle.
Note: The load will be raised on each down stroke of
the handle. Watch the load and the Jack carefully. Stop
lifting if either one starts to move. Do not continue until it
safe to do so. When safe, stabilize and block the load.
7. When the load is raised to desired height,
place the Handle in the upright position
clipped to the Steel Standard Bar.
8. Block load securely. Lower load onto
proper blocks or supports.
WARNING! Do not use Jack for long-
term support of a load.
9. Remove Jack from stabilized load.
Figure B: Lifting Steps 2 - 6

Page 5For technical questions, please call 1-888-866-5797.Item 58395 58448
Lowering a Stationary Load
Note: Jack must have a load of at least 150 lb. If
load is less than 150 lb., the Lifting Mechanism will
slide down to the Base Plate, dropping your load.
1. Position Jack under raised load and raise
the stationary load high enough to remove
blocks from under load. See Figure C.
Note: Make sure load is stabilized
before removing blocks.
2. Place Handle in upright position clipped to
Steel Standard Bar before lowering the load.
3. Move Reversing Latch to down position.
4. Grasp Handle firmly with both hands.
Carefully pump Handle to lower load.
Note: The load will be lowered on
each up stroke of the Handle.
Figure C: Lowering Steps 1 - 4
Clamping
1. Loosen the standard top Clamp-Clevis Bolt.
2. Turn the top Clamp-Clevis 90 degrees to the Steel
Standard Bar, and re-tighten Bolt. See Figure D.
Note: You can connect Clamp-Clevis Anywhere along
the Steel Standard Bar to use the jack as a clamp.
3. Operate Jack as you would for raising a load.
See Raising Stationary Load on page 4.
Figure D: Clamping Steps 1 - 3
Winching
1. Make sure top Clamp-Clevis is in
line with Steel Standard Bar.
2. Install one end of chain or tow strap (sold
separately) securely to the object to be winched.
Securely attach the other end of the chain or
tow strap to the top Clamp-Clevis of the Jack.
3. Take another chain or tow strap and secure one end
to a fixed, stable object. Attach the other end of the
chain or tow strap to the large Runner on the Jack.
WARNING! Do not attach chain or strap to
bottom hole of the large runner on the Jack.
4. Operate Jack as you would for raising a load.
See Raising Stationary Load on page 4. Figure E: Winching Steps 1 - 4

Page 6 For technical questions, please call 1-888-866-5797. Item 58395 58448
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available individually
as replacement parts. Parts may not be interchangeable. Specify item number when ordering:
 48″TrailJack(58395):193175438621
 60″TrailJack(58448):193175439239
User-Maintenance Instructions
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If abnormal noise occurs, have the problem corrected before further use.
TO PREVENT SERIOUS INJURY:
Remove load from the jack before any procedure on this page.
1. BEFORE EACH USE, inspect the general
condition of the equipment. Check for:
• loose hardware
• misalignment or binding of moving parts
• cracked or broken parts
• any other condition that may
affect its safe operation.
• lubricate moving parts of the
Jack with lubricating oil.
Note: Using Jack without proper lubrication can result
in poor performance and damage to Jack. The front
and back of the Steel Rail must be kept rust free.
Note: Do not use motor oil or grease to lubricate Jack.
2. Before each use and after the inspection,
thoroughly test the Jack for proper
operation prior to its actual use.
3. AFTER USE, clean the tool with clean cloth.
4. Store the Jack in a safe, dry location out of reach
of children and other non-authorized people.
a. Place Handle in upright clipped position
against Steel Standard Bar.
b. Raise the Reversing Latch until
it locks in the up position.
c. Store in the upright clipped
position in a dry location.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Page 7For technical questions, please call 1-888-866-5797.Item 58395 58448
Part Description Qty
1 Top Clamp-Clevis 1
2 Top Clamp-Clevis Bolt and Nut 1
3 Steel Standard Bar 1
4 Reversing Lever 1
5 Handle Clip Spring 1
6 Cap Screw with Washer 1
7 Handle with Cotter Pin 1
8 Handle Socket 1
9 Connecting Rod Pin 1
10 Connecting Rod 1
Part Description Qty
11 Hex Bolt and Nut 1
12 Lifting Arm/Large Runner 1
13 Reversing Switch Spring 1
14 Reversing Latch 1
15 Reverse Rod Pin 2
16 Climbing Pin 2
17 Climbing Pin Spring 2
18 Small Runner 1
19 Hex Bolt and Nut 1
20 Base with Cotter Pin 1
Parts List and Diagram

26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
