Baicells ATOM OD15 User manual

1
ATOM OD15 CPE
Installation &
Configuration Guide
Model EG8015G-M11
April 2020
Version 1.2

2
About This Document
This document is for operators who will be installing and configuring the Baicells ATOM OD15 CPEs, model
EG8015G-M11.
Related Documents
All technical specifications and documents are on the Baicells website under Resources > Documentation.
Baicells SNAP PoE+ Router Data Sheet
Baicells SNAP PoE+ Router User Manual
Baicells ATOM OD06H/L Data Sheet
Copyright Notice
Baicells Technologies, Inc., copyrights the information in this document. No part of this document may be reproduced
in any form or means without the prior written consent of Baicells Technologies, Inc. The Baicells logo is a proprietary
trademark of Baicells Technologies, Inc. Other trademarks mentioned in this document belong to their owners.
Revision Record
Date
Version
Description
SMEs/Contributors
Author/Editor
18-Nov-2020
v1.0
-
Tang Houcheng
Support Resources
Documentation - Baicells product data sheets, this document, and other technical manuals may be found at
Baicells > Resources > Documentation.
Support - Open a support ticket, process an RMA, and the Support Forum are at Baicells > Support.
Contact Us
Baicells Technologies Co., Ltd.
Baicells Technologies North America, Inc.
China
North America
Address:
9-10F,1stBldg.,No.81BeiqingRoad,Haidian
District,Beijing,China
555 Republic Dr., #200, Plano, TX 75074, USA
Phone:
[phone]
[phone]
Email:
[e-mail]
[e-mail] or [e-mail]36T
Website:
www.Baicells.com
https://na.Baicells.com

3
Table of Contents
1. Introduction....................................................................................................................................................... 5
1.1. Description .................................................................................................................................................... 5
1.2. ODU Modes................................................................................................................................................... 5
1.3. Features......................................................................................................................................................... 7
2. Installation......................................................................................................................................................... 7
2.1. Part & Materials............................................................................................................................................. 7
2.2. LEDs & Interfaces........................................................................................................................................... 8
2.3. CPE Software ................................................................................................................................................. 9
2.4. Login.............................................................................................................................................................. 9
2.5. Status Menu .................................................................................................................................................. 9
2.5.1. Overview................................................................................................................................................... 9
2.6. Network Menu..............................................................................................................................................13
2.6.1. LAN Settings .............................................................................................................................................13
2.6.2. WAN Settings................................................................................................................................................14
2.6.2.1. NAT Mode.................................................................................................................................................14
2.6.2.2. Router Mode ............................................................................................................................................14
2.6.2.3. Tunnel Mode ............................................................................................................................................14
2.6.2.4. Bridge Mode.............................................................................................................................................15
2.6.2.5. Mixed Mode .............................................................................................................................................15
2.6.3. WLAN Settings..................................................................................................................错误!未定义书签。
2.6.4. Static Routes.............................................................................................................................................16
2.6.5. DMZ .........................................................................................................................................................17
2.6.6. UPnP ........................................................................................................................................................17
2.7. LTE Menu......................................................................................................................................................18
2.7.1. Connection Settings..................................................................................................................................18
2.7.1.1. Roaming setting........................................................................................................................................18
2.7.1.2. Default connection....................................................................................................................................18
2.7.1.3. Power Scan Option....................................................................................................................................18
2.7.2. Edit APN Profile.........................................................................................................................................19
2.7.3. PIN Management......................................................................................................................................19
2.7.4. Cell selection ............................................................................................................................................20
2.7.5. SIM Lock Settings......................................................................................................................................22
2.7.6. MTU .........................................................................................................................................................22
2.8. Security Menu ..............................................................................................................................................23
2.8.1. IP Filtering ................................................................................................................................................23
2.8.2. IPv6 Filtering.............................................................................................................................................23
2.8.3. MAC Filtering............................................................................................................................................24
2.8.4. URL Filtering .............................................................................................................................................25
2.8.5. System Security.........................................................................................................................................26
2.8.6. Connect Limit ...........................................................................................................................................26
2.8.7. Schedule...................................................................................................................................................27
2.9. NAT Menu.....................................................................................................................................................28
2.9.1. Port Forwarding........................................................................................................................................28
2.9.2. Port Triggering ..........................................................................................................................................28

4
2.9.3. ALG...........................................................................................................................................................29
2.10. System Menu................................................................................................................................................29
2.10.1. Account ....................................................................................................................................................29
2.10.2. WEB Settings ............................................................................................................................................30
2.10.3. NTP ..........................................................................................................................................................30
2.10.4. TR-069......................................................................................................................................................30
2.10.5. TR-069 Certificate .....................................................................................................................................31
2.10.6. Restore / Update.......................................................................................................................................31
2.10.6.1. Firmware Update..................................................................................................................................31
2.10.6.2. Restore Factory Settings........................................................................................................................32
2.10.7. Diagnosis..................................................................................................................................................32
2.10.7.1. TCPDump .............................................................................................................................................32
2.10.7.2. Ping......................................................................................................................................................32
2.10.7.3. Trace ....................................................................................................................................................33
2.10.7.4. Result...................................................................................................................................................33
2.10.8. Backup Settings.........................................................................................................................................34
2.10.9. System Log................................................................................................................................................34
2.10.10. System Messages......................................................................................................................................34
2.10.11. SAS Settings..............................................................................................................................................35
2.11. Reboot..........................................................................................................................................................36
2.12. Logout..........................................................................................................................................................36
Appendix: Regulatory Compliance .............................................................................................................................37
FCC Compliance.........................................................................................................................................................37
ISEDC Compliance..........................................................................................................................错误!未定义书签。

5
1. Introduction
1.1. Description
The Baicells Atom OD15 Outdoor Low-Gain and Outdoor High-Gain User Equipment (UE) is part of a
broadband wireless access system that integrates with Long-Term Evolution (LTE) backhaul networks to
provide subscribers with Internet access. The UE, also referred to as Customer Premise Equipment (CPE),
communicates through a wireless connection to the operator’s eNodeB’s (eNB) at cell sites located in the
region. The eNBs communicate with the backhaul network (错误!未找到引用源。).
Figure 1: LTE Network Architecture
The outdoor low-gain or high-gain UE may be selected because of the distance between the user's location
and the closest eNB or for environments where there may be blockage or partial blockage in the wireless
signal path between the UE and eNBs in the area - e.g., dense trees or buildings.
As an LTE standards-based product, the Baicells equipment provides higher near-line-of-sight (nLOS) and
non-line-of-sight (NLOS) signal penetration than other wireless technologies. The high-gain UE has a higher
antenna gain than the low-gain UE, making it possible to get the strongest possible signal reception for
subscribers.
The LTE standards organization that defines certain characteristics of user equipment across manufacturers
labels each progression of the standards as releases, such as Release 9, Release 10, etc., and categories,
such as Category 4 (CAT4) and Category 6/7 (CAT6/7).
Typically the difference from one release/category to the next is in capacity, i.e., higher throughput. There
is no physical difference between the CAT4 and CAT6/7 UE, but the low-gain UE and the high-gain UE do
look different from one another. A physical comparison is provided in section 4.
1.2. ODU Modes
This device can work at two modes, ODU standalone or IDU+ODU mode.
(1) ODU standalone Mode
Standalone mode, ODU can worked at NAT/TUNNEL/BRIDGE mode

6
a) NAT Mode, the ODU work as a LTE and Ethernet Gateway, it converts LTE network data to local
Ethernet data.
b) Tunnel Mode, the ODU can build a L2 or L3 VPN tunnel with a designated VPN server.
c) Bridge Mode, the ODU can bridge it LTE IP address to LAN port devices, when configured as the
bridge, the CPE’s LAN port will work as trunk mode, so it can’t assign IP address to any no-trunk
devices (like PC), so you have to Manual Configure the PC’s IP address in the same broadcast
domain (e.g. 192.168.150.88).
(2) IDU+ODU Mode
When the ODU connect to a IDU device (Baicells PoE router), it will automatic be configured as Bridge
mode, and assign all its LTE IP to IDU, at that mode, the IDU will take the place of ODU to control all the CPE
functions.
CAUTION:
Before contacting Baicells FAE or your distributor, please DO NOT mixed use the two
modes.

7
1.3. Features
The Baicells Atom UEs provide robust throughput and are designed for growth and expansion as
technology evolves. Some of the key features and attributes of the Atom outdoor UEs are listed below.
Exact specifications vary by model. For the latest information, please refer to the Baicells website for your
specific UE model.
Standardized LTE TDD bands 42, 43, 48. Customization may be requested.
Complies with 3GPP Release 11 (CAT12/15)
1000 Mbps Ethernet interface
Built-in bipolar directional LTE antenna
Power supply using Power Over Ethernet (PoE)
Cell lock, SIM lock, and Pin lock
Pole or wall mount options
TR-069 management protocol support
Local and remote GUI management
2. Installation
2.1. Part & Materials
Refer to Table 1 for a list of the components that you should receive with the Baicells outdoor UE.
Table 1: Parts
Item
Qty
Atom OD15 unit
1
Power Cable
1
PoE Power Adaptor
1

8
Atom OD15 Mounting
Bracket
1 each
You will need standard tools, Ethernet cable, ground wire, and RJ-45 connectors for installing and
connecting the outdoor unit (Table 2).
Table 2: Materials
Item
Description
Ethernet Cable
Outdoor shield CAT5E, shorter than 330 feet
Ground Wire
16mm2yellow-green wire
2.2. LEDs & Interfaces
On the low-gain UE the LEDs are on the side of the unit, and the connection interfaces are on the bottom of
the unit. On the high-gain UE both the LEDs and the interfaces are on the side of the unit. Refer to 错误!未
找到引用源。 for a description of the LEDs and 错误!未找到引用源。 for a description of the interfaces.
Table 3: LEDs
LEDs vary by model –not all models will have all of the LEDs listed below.
Identity
Description
Color
Status
Description
L&S
LTE network and USIM
status
Blue
Off
The UE is not connected to the network
Steady On
The UE is connected to the LTE network
PWR
Power status
Yellow
Off
No power supply to the UE
Steady On
Power to the UE is on
LTE Signal
L/M/H 3 bars to indicate
wireless connection
status. The more bars,
the stronger the signal
between the UE and a
network cell (eNB).
Green
All Off
The signal is too weak for the UE to connect to
the network
Steady On
Bars will light steadily according to signal
strength
Blinking
The UE is scanning the network
The UE is authenticating with the network
The UE is getting an IP address from the
network
Table 4: Interfaces
Interfaces vary by model –not all models will have all of the interfaces listed below.
Interfaces
Description
PoE
Power over Ethernet (PoE) power adaptor

9
Interfaces
Description
SIM/USIM Slot
Universal Subscriber Identity Module card slot, 1.8V/3.0V USIM 2FF
RESET
Reset/restore button
GND
Ground lug. The unit is connected to Earth by conductor.
2.3. CPE Software
The firmware of the CPE should be BaiCE_BG_1.5.4 or above, if the CPE is not running this version, please
download it from the Baicells website > Resources > Firmware or contact Baicells support.
2.4. Login
The CPE comes preloaded with a GUI to configure the device. With the CPE turned on and connected to the
router, access the GUI login page by opening a Web browser and entering http://192.168.150.1.
Figure 2: Login
Initially, use the default Username = admin/Password = admin (Figure 21).
Once you are in the GUI, you will want to change the password; please refer
to section 3.9.1 Account.
2.5. Status Menu
2.5.1. Overview
After logging in, the GUI opens to the Status > Overview page (错误!未找到引用源。). This page is a
dashboard of key information regarding the CPE. The top row, Current State, shows the network connection
status, signal intensity, LAN link status, and the number of smart devices (cell phones, pc's, laptops)
connected to the Internet through the CPE.

10
The Device Info pane displays the product name, software version, serial number, etc. The LTE Status pane
shows important operational information, such as the CPE's SIM card status and its IMSI and IMEI numbers,
wireless frequency being used, eNB connection status, and current signal strength and quality.
Under Throughput Statistics you will see downlink (DL) and uplink (UL) data rates for current throughput
(kbps), average rates, peak rates, and total throughput. The data is measured during a 3-second interval
every 5 minutes. The APN Status pane displays any gateway connections. The bottom pane, Devices List,
will show details about all smart devices currently connected through the CPE. Refer to Table 5 for a
description of the Status fields.
Figure 3: Status
Figure 4: Throughput Statistics
Figure 5: Internet Statistics

11
Figure 6: LAN Status
Figure 7: Device List
Table 3: Status
Field Name
Description
Connection State
Connection status between the CPE and the network –either Checking SIM, Scanning,
Registering, Acquiring IP, Connected, or Disconnected
Signal Intensity
Indicates the strength of the signal between this CPE and the serving eNB, either
excellent, good, general, bad, or severe. The ODU CPE hardware typically displays 1 to 5
LEDs to indicate this level (Figure 3&4).
Devices Connected
The number of smart devices connected to the Internet through this CPE via a LAN or
Wireless LAN (WLAN)/Wi-Fi connection
Device Info
Product Name
LTE ROUTER indicates the CPE is operating as a router
Product Model
ODU CPE model number
Hardware Version
ODU CPE hardware version
LTE Module FW Name
LTE Module FW’s version
LTE Connection Time
The timer will be reset after every LTE connections
Software Version
ODU CPE operating software version
Software Build Time
Date and time the software was built
SN
Serial Number
IMEI
International Mobile Equipment Identity is like a serial number for the SIM card
System Up Time
The timer will be reset after reboot
LTE Status
USIM
The Universal Subscriber Identity Module, or SIM, card status is either available or not
ready in the ODU CPE
IMSI
The unique International Mobile Subscriber Identity (IMSI) number associated with the
SIM card in the subscriber's ODU CPE. The IMSI must be identifiable by the operator's LTE
network in order to access it.
PLMN
The Public Land Mobile Number (PLMN), or operator network ID, to which the CPE is
connected
PCI
The Physical Cell Identifier (PCI) unique to each eNB. PCI indicates to which eNB the
ODU CPE is connected. An operator can have multiple eNBs serving the same cell.
eNB ID
The operator's cell site ID to which the CPE is connected. A cell site may comprise more
than one eNB. Each eNB is given a PCI to identify it.

12
EARFCN
The E-UTRA Absolute Radio Frequency Channel Number (band and frequency) within
which the CPE operates
Bandwidth
The range of frequencies within the band the CPE may use for wireless communications
with an eNB, expressed in MHz
CINR
The Channel Signal-to-Interference-plus-Noise Ratio reflects the signal strength of the
signal received from the two antennas in the eNB, expressed in decibels (dB)
NOTE: Additional SINR values are reported when a transmitting device is using more than
two antennas.
DL Frequency
The frequency, in MHz, being used in the downlink (eNB to CPE). In LTE, the carrier
frequency in the uplink and downlink is designated by the EARFCN, which identifies the
LTE band and carrier frequency.
UL Frequency
The frequency, in MHz, that the CPE is using in the uplink (CPE to eNB). In LTE, the carrier
frequency in the uplink and downlink is designated by the EARFCN, which identifies the
LTE band and carrier frequency.
RSSI (dBm)
RSRQ (dBm)
Reference Signal Receiving Quality indicates the quality of the wireless signal
CQI
Channel Quality indication
TXPWR (dBm)
Real time UE TX power
Roam
Roam status
Throughput Statistics
DL
The current downlink data throughput rate, in Kbps
UL
The current uplink data throughput rate, in Kbps
Average
The average DL and UL data throughput rates, in Kbps, for this CPE in the last 3 minutes
Peak
The peak DL and UL data throughput rates, in Kbps, for this CPE in the last 3 minutes
Sum
The total (sum) DL and UL data throughput rates, in Kbps
Internet Status
APN Number
Access Point Name (gateway) connection to other network devices. At least one APN
must be configured to establish the TR-069 connection to the CloudCore or other NMS
Enable
Indicates if the APN is enabled or disabled
MAC Address
MAC address of the APN gateway
Connection Type
Type of network connection
IP Address
IPv4, IPv6, or IPv4v6 address of the APN gateway
DNS server
Domain Name Server IP address
LAN Status
MAC Address
MAC address of the LAN device, e.g., router, to which the CPE is connected
IP Address
The IP address of the LAN device
Netmask
The subnet mask of the LAN device
Devices List
Index
Numerical ID assigned to each smart device connected through the ODU CPE
Device Name
The name of each smart device connected through the CPE
MAC Address
The MAC address of each smart device connected through the CPE
IP Address
The IP address of each device connected through the CPE
Lease Time
Amount of time a smart device’s IP address has been leased
Type
Type of smart device connection

13
2.6. Network Menu
2.6.1. LAN Settings
Enter the Network > LAN DHCP Server enable, IP address, subnet mask, DHCP range, lease time, UPNP
enable.
Figure 8: DHCP Settings
DHCP Static Leases settings can set by the host’s MAC address.
Figure 9: DHCP Static Leases

14
2.6.2. WAN Settings
2.6.2.1. NAT Mode
The CPE will be worked at NAT mode, and all 8 APNs can be configured by Default router/Data/Mgmt/Voip
bear types.
Figure 10: WAN Settings
2.6.2.2. Router Mode
When selected Router mode, the CPE will worked at router mode, it can dynamic update router tables.
Figure 11: Router Mode
2.6.2.3. Tunnel Mode
This CPE can support L2TP and GER VPN mode.

15
Figure 12: Tunnel Mode
2.6.2.4. Bridge Mode
When the CPE worked at Bridge mode, the WAN ports address will bridge to LAN port, and the LAN port
will worked at trunk mode.
Figure 13: Bridge Mode
2.6.2.5. Mixed Mode
Mixed mode can configured every APN with different mode (e.g. Bridge), this is a professional mode.

16
Figure 14: Mixed Mode
2.6.3. Static Routes
Set Static routes of the CPE, it can configure LAN or WAN port routes, Gateway, Destination Network and
Route Subnet Mask, in Current Settings, show all activated static routes.
Figure 15: Static routes

17
2.6.4. DMZ
In technology, the DMZ refers to a firewall between incoming WAN traffic and the LAN to which the CPE is
connected. Two basic DMZ methods are (a) using a single firewall, also known as the three-legged model,
and (b) using dual firewalls (Figure 36). These architectures can be expanded to create complex
architectures depending on the network requirements.
Figure 16: DMZ
When the LAN has a DMZ/firewall server, you can enable DMZ on the CPE so that packets from the WAN
are forwarded to the firewall (Figure 37). Alternatively, you can enable Internet Control Message Protocol
(ICMP) redirect error messages to support Layer 2 multicast features.
Figure 17: DMZ Settings
2.6.5. UPnP
The Universal Plug & Play (UPnP) function provides a set of networking protocols that allows
device-to-device networking on a local network. When UPnP is enabled, devices seamlessly and
dynamically discover each other’s presence on the network and attach to one another and to network
services. Often, UPnP is used for streaming media between devices on the network.
Go to Security > UPnP to enable the CPE to be searched by other devices (Figure 38). Once enabled, any
redirects of traffic will display in the Active UPnP Redirects section of the window.
Figure 18: UPnP Settings

18
2.7. LTE Menu
2.7.1. Connection Settings
LTE connection settings includes Roaming settings, Default connection settings and Power Scan Option.
Figure 19: Connection Settings
2.7.1.1. Roaming setting
If set Roam enable, the CPE can access to other PLMN network, else the CPE just can access the network
PLMN same with the SIM card.
2.7.1.2. Default connection
If set always on, the CPE will automatic access the LTE network after booting, if set manual, the CPE need
manual connection to the LTE network.
Figure 20: Default Connection Settings
2.7.1.3. Power Scan Option
The CPE support two power scan options, the first is First Detected Cell, and the second is the Strongest
Cell.

19
Figure 21: Scan mode Settings
2.7.2. Edit APN Profile
An Access Point Name (APN) is the name of a gateway between a 3G/4G mobile network and another
computer network, frequently the public Internet. Generally, multiple APNs are used for different business
flows such as TR-069 management, voice, data, etc., and may support different services and QoS levels for
different subscribers.
Figure 22: APN Profiles
The CPE supports 8 APN configurations. At least one APN (TR-069) must be configured when the CPE/eNB
connect to the Baicells CloudCore. In the window (Figure 42) you will select the APN number (1-8), enable it,
enter an APN Name, select the type of IP addressing (IPv4, IPv6, or IPv4v6), identify if it is the default
gateway, and choose which type of protocol will be supported on it.
2.7.3. PIN Management
Use the PIN Management feature if you want to require users to enter a PIN code before they can use the
CPE to access the network (Figure 43). Once the PIN is enabled, you will need to remember it if you want to
later modify the number. You are limited to 3 tries to enter the correct PIN code before getting locked out.
If this happens, contact your service provider (end-users) or Baicells support (service providers).

20
Figure 23: PIN Management
2.7.4. Cell selection
The Cell selection determines which frequencies the CPE’s routine scan of available frequencies will cover.
Scanning is a process of tuning to a specific frequency and measuring the simplest signal quality [e.g.,
Received Signal Strength Indication (RSSI)].
As part of the cell selection and re-selection process, the CPE performs the scan first and then selects a
small number of candidate cells to go through the next step of measuring and evaluating signals to select
the best eNB that can serve it. The CPE frequently (milliseconds) performs the scan to ensure it has the best
possible connection to the network. Refer Figure 44.
Figure 24: Cell selections
Select one of the following options:
Full Band (default) –All channels in the band.
−The CPE will routinely scan all channels in the band and all EARFCNs, increasing the time it
takes to connect compared to the other modes. The band is dependent on the CPE model.
Dedicated EARFCN –Specific EARFCNs or frequencies. (Figure 45)
−The CPE will scan the dedicated EARFCN or frequency list first when it is powered on.
−If the CPE cannot connect to the LTE network after scanning the list, it will scan other
supported bands and frequencies. You can add up to 10 EARFCNs or frequencies.
Cell Lock –A combination of PCI + EARFCN or frequency. (Figure 46)
−The CPE is limited to scanning a specific list of eNBs based on both their Physical Cell
Identifier (PCI) and EARFCN or frequency. The CPE will scan the list of eNBs with the
EARFCN and PCI combination. Using this mode can accelerate network access time.
PCI Lock –Specific PCIs only. Locks the CPE to a designated PCI or PCI range. (Figure 47)
After selecting an option, enter the required information and select ADD.
