BainUltra MIA Series User manual

OWNER’S MANUAL
IMPORTANT INFORMATION FOR THE INSTALLER
AND THE OWNER
INCLUDED: THERMOMASSEURTM INSTALLATION
USING THE MIATM SERIES CONTROLS
USING THE EUPHONIATM SYSTEM
IMPORTANT: TO BE KEPT FOR THE OWNER
The quest for your wellness™

OWNER’S MANUAL
3
www.bainultra.com
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
TABLE OF CONTENTS
SAFETY INSTRUCTIONS 4
THERMOMASSEUR®
PARTS AND TOOLS 5
SITE PREPARATION 6
THERMOMASSEUR®INSTALLATION 7 - 9
PLUMBING INSTALLATION 10 - 12
TEKURATM NEW INSTALLING/CHANGING ACCESSORIES 13 - 16
BALNEO®, AYOURA®AND AMMA®FREESTANDING
PARTS AND TOOLS 17
SITE PREPARATION 18 - 19
INSTALLATION 20 - 25
TURBINE
TECHNICAL SPECIFICATIONS 26
ELECTRICAL INSTALLATION 27 - 29
REMOTE MOUNTING 30 - 34
SKIRTS
GENERAL INSTRUCTIONS 35
PARTS AND TOOLS 36
INSTALLATION 37 - 53
THE MIATM SERIES CONTROLS
INSTALLATION 54
USER GUIDE 55 - 69
EUPHONIATM SYSTEM
INSTALLATON 70 - 72
USER GUIDE 73 - 75
MAINTENANCE 76 - 78
TROUBLESHOOTING 79 - 80
WARRANTY 81 - 82
DRILLING TEMPLATES 83 - 85
956, chemin Olivier
Saint-Nicolas (Québec)
G7A 2N1
T 418.831.7701 1.800.463.2187
F 418.831.6623 1.800.382.8587 [email protected]

4
OWNER’S MANUAL |SAFETY INSTRUCTIONS
1 800 463.2187 From 8 a.m. to 8 p.m. Monday to Thursday (EST) .From 8 a.m. to 5 p.m. on Friday (EST)
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR®
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTROCUTION, OR PERSONAL INJURY
• Risk of hyperthermia; people using medication and/or having an adverse medical history should
consult a physician before using a hydro-thermo massage bathtub equipped with a heater.
• Risk of hyperthermia and possible drowning: do not use a hydro-thermo massage bathtub
equipped with heater immediately following strenuous exercise.
• Risk of fetal injury; pregnant or possibly pregnant women should consult a physician before using
a hydro-thermo massage bathtub equipped with a heater.
• Risk of accidental injury or drowning; do not use drugs or alcohol before or during the use of a
hydro-thermo massage bathtub equipped with a heater.
• Use this unit only for its intended purposes or as described in this manual. Use only attachments
recommended by the manufacturer.
• Risk of hyperthermia and possible drowning. water temperature in excess of 100ºF (38ºC) may
be injurious to your health. Check and adjust temperature before use.
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
DANGER
• To reduce the risk of injury, as with any other conventional bath, do not allow children or physically impaired people to use
this unit unless they are closely supervised at all times.
• To avoid injury, exercise care when entering or exiting the Thermomasseur®.
ELECTRICAL CONNECTIONS:
• Never drop or insert objects into any openings.
• The Thermomasseur®must be connected only to a supply circuit that is protected by A 15 amp class A ground fault circuit
interrupter (GFCI) for baths with 1heated backrest and A 20 amp (GFCI) for baths with 2 heated backrests of the Amma®
series. This interrupter is supplied by a certified electrician and must be tested on a regular basis in accordance with manufac-
turer’s instructions. The GFCI ground must be connected. If defective, do not use the Thermomasseur®. Disconnect
immediately and call a certified electrician.
• Use 12 AWG (or greater) copper conductors that resist temperatures of at least 194ºF (90ºC).
• Canada only: for permanently connected units. A green-colored terminal (or a wire connector marked g, gr, ground or
grounding) is provided within the terminal compartment (not applicable if unit supplied with an electric plug). To reduce the
risk of electrocution, connect this terminal or connector to the grounding terminal of your electric service or supply panel
with conductor equivalent in size to the circuit conductors supplying the equipment and be 12 AWG or more.
• All electrical connections must be carried out by a certified electrician and must respect federal, provincial/state, and local
building codes and regulations.
• Before using the Thermomasseur®, its exterior construction (podium or skirting) should be finished so that a bather cannot
accidentally come in contact with electrical components (turbine and power module).
• For indoor use only.
• Install in accordance with manufacturer’s installation instructions.
• The use of alcohol, drugs, or medication can greatly increase the risk of fatal hyperthermia.
CAUTION: RISK OF ELECTRICAL SHOCK
• Disconnect electric power before servicing.
• Do not permit electrical appliances (hair dryer, lamp, telephone, radio, television, etc.) within 5’ (1.5 m) of the Thermomasseur®.
WARNING

THERMOMASSEUR®|OWNER’S MANUAL
5
www.bainultra.com
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR®
5
THERMOMASSEUR®
IMPORTANT •Before starting installation, ensure that parts received match your order. For all questions, call
BainUltra®at 1 800 463-2187.
A-10 Drill
A-11 11/64” drill bit
A-12 82° routing bit
A-13 Screws
A-14 Appropriate screwdriver
A. PARTS AND TOOLS
TILE FLANGE INSTALLATION
MOLDED TILE FLANGE INSTALLATION
A-1 24” Level
A-2 24” Square
A-3 Caulking gun
A-4 Pencil
A-5 Hole saw
A-6 1/16” drill bit
SKIRT INSTALLATION
OTHER NECESSARY ITEMS
See skirt section.
• Wood shims
• Silicone
A-3
A-2
A-1
A-4 A-5
A-10 A-11 A-12 A-13
A-7 A-8
A-9
A-14
A-6
A-7 Miter box (angle cutter)
A-8 Fine tooth saw
A-9 Double-face tape
THERMOMASSEUR®- PARTS AND TOOLS
THERMOMASSEUR®
PARTS AND TOOL

6
OWNER’S MANUAL |THERMOMASSEUR®
1 800 463.2187 From 8 a.m. to 8 p.m. Monday to Thursday (EST) .From 8 a.m. to 5 p.m. on Friday (EST)
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR®
THERMOMASSEUR®
SITE PREPARATION
There is a technical specification sheet for each
BainUltra®ThermoMasseur®which includes
information such as necessary dimensions of site
before installation. If you do not already have
the technical specifications, download from
the BainUltra site at: www.bainultra.com or
call us at: 1 800 463-2187.
• See faucet manufacturer’s technical specifications
for zoning and plan water supply accordingly.
• Position drain according to manufacturer’s
specifications.
FAUCET INSTALLATION
Before installing, ensure that the floor underneath
the bath can support 1,500 lbs (680 kg). The bath
may sit directly on the floor. However, the bath may
also be installed on a bed of concrete. For this type
of installation, it is recommended that you insulate
the concrete between two sheets of plastic, one on
floor and the other underneath bath.
• A service access is necessary. Minimum dimensions
are: 22” x 18” (55 cm x 46 cm) to properly reach all
electrical components of the system.
• An air vent is also necessary. Minimum dimensions
are: 2” x 4” (5 cm x 10 cm) to ensure proper
functioning of the turbine. The service access panel
is often the best place to install the air vent.
All ThermoMasseur®components are factory-installed.
If for practical or accessibility reasons, the turbine and
the InMix (Chromatherapy) module must be moved,
follow recommendations outlined in TURBINE -
REMOTE MOUNTING section of this manual.
BEDDING
SERVICE ACCESS AND VENTILATION
REMOTE MOUNTING
IMPORTANT • Ensure that the base of the bath is supported at least every 16” (40.6 cm).
• The space surrounding the turbine air intake must be large enough and free of debris for proper
airflow and be at a temperature between 72ºF (20ºC) and 86ºF (30ºC) for optimal performance.
WARNING
THERMOMASSEUR®- SITE PREPARATION

THERMOMASSEUR®|OWNER’S MANUAL
7
www.bainultra.com
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR® THERMOMASSEUR® THERMOMASSEUR®
The BainUltra®ThermoMasseur®is almost as easy
to install as a conventional bath. The following
instructions outline steps to follow for the main
types of installation.
THERMOMASSEUR®
INSTALLATION
IMPORTANT • The Thermomasseur®must sit entirely on its base with the lip supported by a wooden structure.
• The Thermomasseur®must be level.
• The Thermomasseur®is molded with an integrated slope towards the drain. If decking around
the Thermomasseur®is level, the bath will drain accordingly.
1. ALCOVE INSTALLATION (BETWEEN
2 OR 3 WALLS)
The following instructions apply to both rectangular
and corner baths.
1-2
1-1
1-3
1-4
1-5
1-1 Place level lengthwise on decking of the
ThermoMasseur®and adjust by placing
shims under ThermoMasseur®where
necessary. Repeat exercise width wise on
the bath. Glue shims in place with a drop
of silicone.
1-2 Mark position of wooden supports to be
attached to the wall by tracing a line
underneath the deck of the ThermoMasseur®.
1-3 Pull the ThermoMasseur®out.
1-4 Align the wooden supports [at least 1 1/2”
(3.8 cm) thick] with markings and nail into
place on the wall studs.
1-5 Reposition ThermoMasseur®and verify that
it is level.
THERMOMASSEUR®- INSTALLATION

8
OWNER’S MANUAL |THERMOMASSEUR®
1 800 463.2187 From 8 a.m. to 8 p.m. Monday to Thursday (EST) .From 8 a.m. to 5 p.m. on Friday (EST)
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR®
1. ALCOVE INSTALLATION (BETWEEN
2 OR 3 WALLS)(NEXT)
IMPORTANT • If the Thermomasseur®and the skirt were not ordered together, the retainer blocks will not be
on the bath. As such, leave a 1/4” (0.6 cm) between the 2” x 3” (5 cm x 7.6 cm) support
structure and the lip of the bath so that the top of the skirt may be inserted under the deck.
1-6 To finish the front of the bath (with ceramic
tile or other materials), a 2” x 3” (5 cm x
7.6 cm) structure is necessary to support
the ThermoMasseur®. Place underneath
the deck (A) or the edge of the bath (B)
depending on the desired finish.
1-7 BainUltra®skirt installation requires a single
2” x 3” (5 cm x 7.6 cm) support in the
front of the ThermoMasseur®. Tilt the base
of the support 3” (7.6 cm) inwards and
upwards. Place the top of the support
behind the two retainer blocks (D) of the
skirt placed underneath the lip of the
ThermoMasseur®(C).
Instructions for installing skirts and retainer blocks
not factory-installed may be found in this manual
in the SKIRT section.
Structure
2" x 3"
[5 cm x 7.6 cm]
Bath Deck
Bath Lip
Structure
2" x 3"
[5 cm x 7.6 cm]
1-6
1-7
2-5
Structure
2" x 3"
[5 cm x 7.6 cm]
Bath Deck
3 ” [7.6 cm]
THERMOMASSEUR®- INSTALLATION

THERMOMASSEUR®|OWNER’S MANUAL
9
www.bainultra.com
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR® THERMOMASSEUR®
A tile flange is recommended for alcove installations
(between 2 or 3 walls). Some bath models may
include a molded tile flange. Tile flanges for other
models are not installed or may be factory-installed.
Molded tile flange (secure the flange to the wall
while supporting from beneath).
Factory or customer-installed tile flange.
No tile flange.
TILE FLANGE
2. TILE FLANGE INSTALLATION
4-2 4-3
2-1 2-2
IMPORTANT • A factory-installed tile flange does not replace a silicone joint between tiling and the Thermomasseur®.
• The surfaces that come into contact with double-sided tape must be clean.
2-1 Using a miter box (angle cutter) and a
fine-tooth saw, cut 3 pieces of tile flange
to desired lengths. Cut 45° angles where
necessary.
2-2 Apply double-sided tape along the entire
length of the flange. Stick the tile flange
to the deck.
2-3 Apply silicone.
4-2 4-3
Angle de 45°
2-1 2-2
4-2 4-3
45°Angle
2-1 2-2
THERMOMASSEUR®- INSTALLATION

10
OWNER’S MANUAL |THERMOMASSEUR®
1 800 463.2187 From 8 a.m. to 8 p.m. Monday to Thursday (EST) .From 8 a.m. to 5 p.m. on Friday (EST)
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR®
THERMOMASSEUR®
PLUMBING INSTALLATION
All plumbing installations must be carried out by a
certified plumber. Installation of a ThermoMasseur®
is the same as for regular acrylic baths. Pay close
attention to the following when installing the
ThermoMasseur®:
All BainUltra®ThermoMasseurs®require a 20” drain
and overflow set, except for the following models :
• The Amma 7242, Amma Oval 7242, Thermal CN2K,
and Thermal CR2K which require a 27” set.
• The Ayoura drop-in model which requires with set
of adjustable length.
• The Ayoura freestanding model which has a factory
pre-installed set.
DRAIN, OVERFLOW, AND PLUMBING
Once the plumbing installation is complete and
before tile or any other related work begins, fill the
bath to the overflow and wait thirty minutes. Check
all plumbing hook-ups and bath for leaks.
BainUltra®is not responsible for any water damage
caused by leaks due to improper installation (see
WARRANTY section).
LEAK TEST
The drain and overflow openings are factory-drilled.
However, drilling may be necessary to install faucets.
This drilling of acrylic or wood is a very delicate
operation, especially for UCS (BainUltra Coloration
System) ThermoMasseurs®and for the acrylic or
Lyptus wood insert on the Ayoura freestanding
model.
DRILLING ACRYLIC OR LYPTUS WOOD FOR
FAUCETS
1. DRILLING
1-1 Drill a 1/16” guide hole before using the
hole saw.
1-2 Use a hole saw in good condition to avoid
accidental scratches. The center guide
bit should extend 1/4” (0.6 cm) for correct
drill positioning.
1/4”
[0.6 cm]
1-2
1-1
1/16”
IMPORTANT • Do not remove the protective plastic film (peel coat) on the bath and place a drop-cloth in the
Thermomasseur®during installation to protect acrylic.
• To avoid drilling in an air intake zone or, an electric component, always check under deck
before drilling.
• Drill openings slightly larger than actual faucet size. This is to avoid any possible cracking or
other damage to the acrylic or UCS finish.
• When installing faucets, do not over-tighten fittings, as this may damage the acrylic or UCS finish.
• This type of damage is not covered by the warranty.
• Drill at medium speed and do not apply pressure to drill; let the drill do the work.
THERMOMASSEUR®- PLUMBING INSTALLATION

THERMOMASSEUR®|OWNER’S MANUAL
11
www.bainultra.com
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR® THERMOMASSEUR® THERMOMASSEUR®
BATH ON DECK
PLUMBING INSTALLATION
IMPORTANT • Bath must be completely supported by the floor making sure the edge rests entirely on the structure.
• Bath must be levelled.
• Bath is molded with a slope toward drain. If bath is levelled in respect to the deck, the water will
drain completely.
1. INSTALLATION
* See specification sheet of bath for exceptions.
1-1 Prepare the site to connect the plumbing
and turbine.
1-2 Build the (2” x 3”) wooden structure taking
into account the thickness of the ceramic
tiles and the plywood as well as the height
of the bath.
NOTE: Plan air intake for turbine.
1-3 Secure plywood into place with screws
around and above structure.
1-4 Cut inside 1 1/2” of the outside dimensions
of the tub.
1-5 Ensure bath is levelled and that it fits properly
in cutout.
NOTE: Protect turbine as you insert bath.
1-6 Install desired finishing materials (ceramic
tiles, granit, marble or other) and top
surface and siding of the deck.
1-7 Set bath back into place and conduct
plumbing and turbine connection.
Edge of bath
Ceramic, marble,
granit or other
Plywood
2” x 3”
structure
1 1/2" [3.8 cm]
BATH ON DECK - PLUMBING INSTALLATION

12
OWNER’S MANUAL |THERMOMASSEUR®
1 800 463.2187 From 8 a.m. to 8 p.m. Monday to Thursday (EST) .From 8 a.m. to 5 p.m. on Friday (EST)
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR®
UNDERMOUNTED BATH
PLUMBING INSTALLATION
1. INSTALLATION
1-1 Prepare the site to connect the plumbing
and turbine.
1-2 Build the (2” x 3”) levelled wooden struc-
ture with plywood as in Detail A, taking
into account the thickness of the ceramic
tiles and the plywood as well as the height
of the bath.
NOTE: Plan air intake for turbine.
1-3 Ensure bath is levelled.
NOTE: Protect turbine as you insert bath.
1-4 Conduct plumbing and turbine connection.
1-5 Enclose contour of podium using plywood.
NOTE: Plan air intake for turbine.
1-6 Install desired finishing materials (ceramic
tiles, granit, marble or other) and top
surface and siding of podium.
1-7 Apply seal to junction of ceramic tiles with
ceramic grout and/or silicone.
IMPORTANT • Bath must be completely supported by podium making sure the edge rests entirely on the structure.
• Bath must be levelled.
• Bath is molded with a slope toward drain. If bath is levelled in respect to the deck, the water will
drain completely.
Edge of bath
Ceramic, marble,
granit or other
Plywood
1" [2.5 cm]
2” x 3”
structure
Detail A
UNDERMOUNTED BATH - PLUMBING INSTALLATION

THERMOMASSEUR®|OWNER’S MANUAL
13
www.bainultra.com
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR® THERMOMASSEUR® THERMOMASSEUR®
TEKURATM
ARMRESTS
NOTE • The MyBodyRestTM accessory kit is comprised of armrests, headrests and legrests.
1. INSTALLATION
1-1 To change the armrests, loosen the
2 armrest screws that are in place
with a 3/16” Allen key.
1-2 Place new armrest and secure into place
using the 3/16” Allen key.
TEKURATM - ARMRESTS

14
OWNER’S MANUAL |THERMOMASSEUR®
1 800 463.2187 From 8 a.m. to 8 p.m. Monday to Thursday (EST) .From 8 a.m. to 5 p.m. on Friday (EST)
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR®
1. INSTALLATION
1-1 Set headrest on upper part of backrest.
NOTE • Installation of the headrest is possible on an undermounted bath that was installed according
to instructions (see page 12 of this manual).
TEKURATM
HEADRESTS
TEKURATM - HEADRESTS

THERMOMASSEUR®|OWNER’S MANUAL
15
www.bainultra.com
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR® THERMOMASSEUR® THERMOMASSEUR®
TEKURATM
LEGREST FOR 6636 1-PERSON MODEL
1. INSTALLATION
1-1 Loosen the 2 legrest suction cups by
approximately 0 to 1 ½ “ (0 to 3.8 cm),
according to desired height of legrest.
The two suction cups must be at the
same height.
1-2 Set legrest on bottom of bath in order for
it to rest securely on the specially designed
notches.
1-3 Press down on the uppermost part to
make suction cup adhere to surface.
TEKURATM - LEGREST FOR 6636 1-PERSON MODEL
0 to 1
1/2
"
[0 to 3.8 cm]

16
OWNER’S MANUAL |THERMOMASSEUR®
1 800 463.2187 From 8 a.m. to 8 p.m. Monday to Thursday (EST) .From 8 a.m. to 5 p.m. on Friday (EST)
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR®
TEKURATM
LEGRESTS FOR 7242 2-PERSON MODEL
1. INSTALLATION
1-1 Loosen the 2 suction cups of each legrest
by approximately 0 to 1 ½” (0 to 3.8 cm),
according to desired height of legrests. All
4 suction cups must be at the same height.
1-2 Set the first legrest on bottom of bath in
order for it to rest securely on edge of one
of the seats.
1-3 Press down on the uppermost part to
make suction cup adhere to surface.
1-4 Set the second legrest opposite the first so
they rest against one another.
1-5 Press down on top part to make suction
cups adhere to surface.
TEKURATM - LEGRESTS FOR 7242 2-PERSON MODEL
0 to 1
1/2
"
[0 to 3.8 cm]

THERMOMASSEUR®|OWNER’S MANUAL
17
www.bainultra.com
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR® THERMOMASSEUR®
IMPORTANT • Before starting installation, ensure that parts received match your order. For all questions, call
BainUltra®at 1 800 463-2187.
• Instructions in this section apply to the Ayoura®and Amma®freestanding models. Refer to
Thermomasseur®instructions for the installation of Ayoura®and Amma®drop-in models.
BALNEO®,AYOURA®& AMMA®FREESTANDING
PARTS AND TOOLS
BALNEO®, AYOURA®& AMMA® FREESTANDING - PARTS AND TOOLS
A. PARTS INCLUDED
A-1 Pipe concealer (Cella model)
A-2 Screws and washers
(Cella and Amma models)
A-3 Floor anchoring
(Ayoura, Naos and Sanos)
A-4 Template (Ayoura and Amma models)
B. TOOLS REQUIRED
B-1 24” level
B-2 Caulking gun
B-3 Pencil
B-4 Erasable marker
B-5 Drill
B-6 3/16” drill bit
B-7 2” hole saw
B-8 7/16” wrench (Cella and Amma models)
7/8” wrench (Ayoura model)
B-9 Phillips #2 screwdriver
B-10 Silicone
A-1
A-1
A-2
A-2
A-4
A-4
A-3
A-3
2
2
B-2
B-2
B-1
B-1
B-3
B-3
B-5
B-5
B-7
B-7
B-6
B-6
B-8
B-8
B-4
B-4
B-10
B-10
B-9
B-9

18
OWNER’S MANUAL |THERMOMASSEUR®
1 800 463.2187 From 8 a.m. to 8 p.m. Monday to Thursday (EST) .From 8 a.m. to 5 p.m. on Friday (EST)
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR®
BALNEO®, AYOURA®& AMMA® FREESTANDING
SITE PREPARATION
If the massage table will be used on the Ayoura
model, BainUltra®recommends leaving at least
3’ (0.92 m) of free space around the bath to give
the massage therapist enough room to work.
If you cannot install the turbine or provide an air
passage under the floor for the Cella, Naos, or
Sanos models, an optional surface installation kit
is available and must be ordered through your
retailer.
• Before finishing your bathroom floor (ceramic,
wood or other) ensure that the floor is level. No
subsequent adjustments may be made to these
baths except for the Amma model, where shims
may be installed under the bath.
• Thermomasseurs®are molded with an integrated
slope towards the drain. If floor is level, the bath
will drain accordingly.
• The Ayoura model requires a 12’’ x 20’’ (30.5 cm
x 50.8 cm) recess where drain, water and electric
supplies, control cable and if needed, remote air
supply have been installed. See bath’s template for
correct positions.
• The Amma model requires a 12” x 9” (30.5 cm
x 22.9 cm) recess for the drain. Refer to the bath
template for the locations of water supply, electrical
connection, and control cable and remote air supply,
if applicable.
For models in the Balneo series, the turbine is
not installed on the ThermoMasseur®. Determine
a suitable place close to the bath (must be less than
15’ [4.6 m] away), either under the floor, in a closet,
or any other location that will conceal the power
module and turbine. Chosen location must be easily
accessible for servicing while allowing sufficient air
circulation for the turbine (see TURBINE - REMOTE
MOUNTING section).
The turbine of the Ayoura and Amma models is
installed beneath the bath. To allow access to
the turbine and other components, foresee a 24”
x 18” (61 cm x 46 cm) space facing the Ayoura access
panel. For the Amma model, foresee an 11” (28 cm)
space around the bath in order to be able to take
out the removable base. Refer to the template. The
turbine may also be installed remotely. If necessary,
please contact BainUltra®at 1 800 463-2187 for
additional information.
BEDDING
SERVICE ACCESS AND VENTILATION
BALNEO®, AYOURA®& AMMA® FREESTANDING - SITE PREPARATION

THERMOMASSEUR®|OWNER’S MANUAL
19
www.bainultra.com
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR® THERMOMASSEUR®
• Use flexible pipes for Ayoura and Amma water
connections.
• On the Ayoura model, the faucet may be installed
on the acrylic or wood lip. On the Amma model,
the faucet may be installed on the bath ledge.
In both cases, follow faucet location recommenda-
tions in drawings.
NOTE: Before drilling the wood or acrylic, read the
instructions in the THERMOMASSEUR®-
PLUMBING INSTALLATION section.
• On the Ayoura model, BainUltra®recommends
installing faucets no higher than 4 5/8” (11.7 cm).
This is the height clearance under the massage
table when it is installed. If the faucet exceeds this
height, you will not be able to install the massage
table.
NOTE: The length of pipe (A) under the lip must
not impede reinstallation of the access panel.
This measure varies depending on faucet
models and location on the acrylic or wood lip.
PLUMBING
•Balneo series baths cannot be drilled for faucet installation. Faucets must be freestanding or
wall-mounted models.
WARNING
3 7/8 "
[9.8 cm]
32"
[81.3 cm]
Faucet area Amma
Faucet area Ayoura
4 5/8" (11,7cm)
(A)
2" (5,1cm)
MASSAGE table
Diagonal view Ayoura
BALNEO®, AYOURA®& AMMA® FREESTANDING - SITE PREPARATION

20
OWNER’S MANUAL |THERMOMASSEUR®
1 800 463.2187 From 8 a.m. to 8 p.m. Monday to Thursday (EST) .From 8 a.m. to 5 p.m. on Friday (EST)
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR®
AYOURA®FREESTANDING
INSTALLATION
1. BATH SITE
2. INSTALLATION
1-1 Once floor is prepared and level and
recess is cleared around the drain, place
installation template on floor in the
chosen location.
1-2 Align template overflow drain hole with
floor drain and make sure recess around
drain matches required measurements.
1-3 Mark anchor screw entry points on the
floor.
1-4 Remove template and screw anchors
where specified.
2-1 Unscrew both screws on access panel
under the lip and gently remove panel.
2-2 Complete installation of bath drain. Make
sure it is watertight.
2-3 Install bath on anchors.
2-4 Connect drain and water supply and
finish wiring.
2-5 Reinstall access panel.
TEMPLATE:
AYOU RA
Dimensions: ±1/4" [±6mm]
12"
20"
1-1
1-2
2-3
AYOURA®FREESTANDING - INSTALLATION

THERMOMASSEUR®|OWNER’S MANUAL
21
www.bainultra.com
Printed in Canada. Copyright © May 2008 BainUltra Inc. All rights reserved. 45220001
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
THERMOMASSEUR® THERMOMASSEUR®
AYOURA®FREESTANDING
MASSAGE TABLE (OPTIONAL)
• Before using, always follow installation instructions to fasten safety anchors. Improper
installation can cause injury or damage the bath and massage table.
• Do not sit or lean on headrest.
• Do not plunge cushions in water and do not use massage table as Vichy shower.
WARNING
3. MOUNTING
4. UNMOUNTING
3-1 Place first cushion on bath.
3-2 Make sure supports are well seated on
bath edges.
3-3 Place the second cushion on bath.
3-4 Adjust cushions then press firmly in the
center. Both cushions should be the
same height.
3-5 Check that all supports fit snugly on bath
edges.
3-6 Before using, always fasten the two safety
anchors by hooking them on the metal
pieces under the lip and pulling down on
strap to tighten.
4-1 Loosen safety anchors by pulling up on
the plastic clasp.
4-2 Place straps inside bath by passing them
under the massage table.
4-3 Remove cushions in reverse mounting
order.
4-4 Store cushions with supports up as shown
to avoid damage to the supports.
3-3
3-1
3-6
4-4
AYOURA®FREESTANDING - MASSAGE TABLE (OPTIONAL)
