INSTALLATIONANDOPERATINGINSTRUCTIONS
CycloneSERIES
GASCONVECTIONOVENS
Models:BCO-GandGDCO-G
INTENDEDFOROTHERTHANHOUSEHOLDUSE.RETAINTHISMANUALFORFUTURE
REFERENCE.OVENMUSTBEKEPTCLEAROFCOMBUSTIBLESATALLTIMES.
Thisequipmenthasbeenengineeredtoprovideyouwithyearrounddependableservicewhenused
accordingtotheinstructionsinthismanualandstandardcommercialkitchenpractices.
Form#88985004/05
! !
WARNING
Improperinstallation,adjustment,alteration,serviceormaintenance
cancausepropertydamage,injuryordeath.ReadtheInstallation,
OperatingandMaintenanceInstructionsthoroughlybeforeinstallingor
servicingthisequipment.
! !
FORYOURSAFETY
Donotstoreorusegasolineorotherflammablevaporsandliquidsin
thevicinityofthisoranyotherappliance.
! !
WARNING
Initialheatingofovenmaygeneratesmokeorfumesandmustbedonein
awell-ventilatedarea.Overexposuretosmokeorfumesmaycause
nauseaordizziness.
IMPORTANTINSTRUCTIONS: Afterthegassupplyhasbeenconnectedtoyourunit,itisextremelyimportantto
checkpipingforpossibleleaks.Todothis,usesoapandwatersolutionorsolutionsthatareexpresslymadeforthis
purpose.DONOTUSEmatches,candles,flames,orothersourcesofignitionsincethesemethodsareextremely
dangerous.Instructionstobefollowedintheeventyousmellgasshouldbepostedinaprominentlocation.Obtain
theseinstructionsfromyourlocalgassupplier.
BAKERSPRIDEOVENCO.,INC.
30PineStreet
NewRochelle,NY10801
[phone]Phone[email protected]mE-Mail
[phone]Faxwww.bakerspride.comWebAddress
[phone]US&Canada
1

TableofContents
AReceiving2
BSetUp/Mounting3
CInstallationwithCasters(Optional)4
DLocationandMinimumClearances4
EGasConnections4
FElectricalConnection5
GFlueConnectionVentilation5
HBurnerOperation6
ISystemCheckRotaryControl6
JProgrammingMenus6
AGeneralInstructions7
BOperationSequenceRotaryControl7
Cookonlyrotarycontrol7
Timedcookingrotarycontrol7
Cookandhold-rotarycontrol7
Optionalsteaminjectionrotarycontrol8
Tocooldowntheovenquickly8
CCleaning8
DServicing8
StackingInstructions9
LegAssemblyInstructions10
WiringDiagrams11,12
PartsList&ExplodedView13
I.INSTALLATIONINSTRUCTIONS
II.OPERATINGINSTRUCTIONS
SECTIONITEMPAGE
Warranty16
2
I.INSTALLATIONINSTRUCTIONS
A.RECEIVING
B.SETUP/MOUNTING:
NOTE:
Readthenoticeontheoutsidecartonregardingdamageintransit.Damagediscoveredafteropening
thecartonis“CONCEALEDDAMAGE.”Carriermustbenotifiedimmediatelytosendaninspectorand
tofurnishformsforclaimsagainstthecarrier.
Whentheovenarrives,itshouldconsistof:
Acrateorcartoncontainingyournewoven(twoforastackedunit).
Acartoncontainingfour31”legswithmountinghardware(setoffour6”legsissuppliedforstacked
installations).
AcartoncontainingaFlueAdapterandaDraftHood.Optional:forDirectVenting(Notavailablefor
EuropeanCommunityCountries).
Thisappliancemustbeinstalledbycompetentpersonnelinaccordancewiththerulesinforce.
IntheU.K.,Corgiregisteredinstallers(includingtheregionsofBritishGas)undertaketoworktosafe
andsatisfactorystandards.ThisappliancemustbeinstalledinaccordancewiththecurrentGasSafety
(InstallationandUse)RegulationsandtherelevantBuildingRegulations/IEERegulations.Detailed
recommendationsarecontainedintheBritishStandardCodesofPracticeB.S.6172,B.S.5440:Part2
andB.S.6891.

3
Yourovenwillbepackedsittingonitsbottom.Theskidmaybeleftundertheovenforconveniencein
furtherhandling.Unpackcarefully,avoidingdamagetotheStainlessSteelfrontand/ortrim.If
concealeddamageisfound,followtheinstructionsdetailedinSectionA(Receiving).Keepthearea
aroundtheovensfreeandclearofcombustiblematerials.Donotstoreanymaterialsontopoforunder
anyoven.Theprovisionforadequateairsupplytoyourovenforventilationandpropergascombustion
isessential.Asaminimum,observetheclearancesdetailedinSectionD(Location).Provideadequate
ventilationandmakeupairinaccordancewithlocalcodes.Servicingyourovenisdonethroughthe
frontcontrolpanelandrightsideaccesscover.Ensurethattheseareasarekeptunobstructedforeasy
access.
(1)TiltOvenovertoleft-handsideandattachtwo31”legsontheright-handsidewiththree½”bolts
andwashers.Tightenfirmly.
(2)Usingproperliftingequipment,liftuptheleft-handsideandattachtwo31”legsontheleft-hand
sidethesameway.
(2)Tiltlowerunitovertotheleft-handsideandpositiontwo6”legsontherightside(oneforfrontand
oneforback),secureinplacebyusing4bolts(3/8”-16)perleg.Tightenfirmly.
(3)Usingproperliftingequipment,liftuptheleftsideoftheunitandattachtheothertwolegsinthe
sameway.
(4)Usingtheliftingequipment,raisethetopoventoproperheightandslideontopofthebottom
oven.Lineupsidesandfrontandfastentoeachotherattherearoftheunitsbyusingamounting
bracketsuppliedinthestackingkit.
(1)Loosen12bolts(attaching31”legs)slightly.
(2)Remove4innerbolts,1fromeachofthe4legs,placetoprightangleandtopleftangle
underneathandtightenthese4bolts.
(3)Insert“OpenRackShelf”andtightenintoplacewitheight3/8-16screws,washersandnuts.
(4)Position“RackSupports”andtighteninplaceusing4eachofflatwashersand5/16-18HexNuts.
Forasingleunit:RefertoFigure4
Forastackoftwoovens:RefertoFigure3
Toassembleanopenrackstand:RefertoFigure1
(1)Removefluefrombottomovenpriortostacking.Whentopovenisproperlypositionedonbottom
oven,re-installthefluebackonthebottomoven.
! !
CAUTION
Donotstorecombustibleitemsormaterialsonracks.
2
3
4
5
6
7
8
9
10
Figure1 OPENRACKSTANDASSEMBLYINSTRUCTIONS:BCO-E&GDCO-E
STEP1)
STEP2)
STEP3)
STEP4)
Attach4eachItem2with16
each3/8-16boltstothe
threadedholeslocatedin
thebottomoftheovenor
suppliedwithlegkit.
PlaceItem4betweenthe
legsandoverItem9then
attachItem9toItem4with
16each10-32screws.
AttachItem5toItem10
using2each¼-20screws
(Bothsides)
PlaceItem5intoItem6and
intotheholesinItem4.
(Bothsides)

FittheStandardFlueDivertersuppliedintotheholeinthetopoftheovenforunderventilationhood
installationandsecurewithscrews.Fordirectventing,FlueAdapterandDraftHoodmustbeplacedinto
theholeontopoftheoven.
Fourcasters(twowithwheelbrakes)andthemountinghardwarearepackedandincludedinthe
shipmentifordered.Installcasterswithwheelbrakesonthefrontoftheunit.Installationoftheunit
shouldbemadewithaconnectorthatcomplieswiththelatesteditionoftheStandardforConnectorsfor
MovableGasAppliancesANSIZ21.69intheUSA(CANCSA-6.16in Canada)andaquick-disconnect
devicethatcomplieswiththelatesteditionofthestandardforquickdisconnectdevicesforusewithgas
fuelANSIZ21.41intheUSA(CSA6.9inCanada).Adequatemeansmustbeprovidedtolimitthe
movementoftheappliancewithoutdependingontheconnectorandanyquickdisconnectdeviceorits
associatedpipingtolimitappliancemovement.
Therestraintshouldbeattachedtotherearlegsoftheovenonwhichcastersaremounted.If
disconnectoftherestraintisnecessary,therestraintshouldbeimmediatelyreconnectedafterthe
appliancehasbeenreturnedtoitsoriginallyinstalledposition.
Movetheoventoitsfinallocationkeepingtheminimumclearancefromthebackoftheoventothewall.
Thisclearanceisnecessaryforsafeoperationandtoprovideproperairflowtotheburnerchamber.
C.INSTALLATIONWITHCASTERS(OPTIONAL):RefertoFigure4
D.LOCATIONANDMINIMUMCLEARANCES:
MINIMUMCLEARANCESFROMCOMBUSTIBLEANDNONCOMBUSTIBLECONSTRUCTION
UnderVentilation Hood DirectVenting
RIGHTWALL 1” 1”
LEFTWALL 1” 3”
REARWALL 3” 3”
SUITABLEFORINSTALLATIONONCOMBUSTIBLEFLOORWHEN
INSTALLEDWITHLEGSORCASTERSPROVIDED.
! !
CAUTION:DONOTSETTHEOVENWITHITSBACKFLATAGAINSTTHE
WALL.ITWILLNOTOPERATEPROPERLYUNLESSTHEREISATLEAST
THREEINCHESBREATHINGSPACEBEHINDTHEOVEN
!!
E.GASCONNECTION:
Theovensshouldnotbeinstalledonthesamegassupplylinewithspaceheaters,boilersorothergas
equipmentwithhighintermittentdemand.
Theinstallationoftheovenmustconformtothelatestlocalcodesor
Theappliancemustbeisolatedfromthegassupplypipingsystembyclosingitsmanualshut-offvalve
duringanypressuretestingofthegassupplypipingsystemattestpressuresequaltoorlessthan½
psig(3.45kpa).Theapplianceanditsshut-offvalvemustbedisconnectedfromthegassupplypiping
systemduringanypressuretestingofthatsystemattestpressuresinexcessof½psig(3.45kpa).
Useapipejointcompoundthatisresistanttotheactionofliquefiedpetroleumgaseswhenmakinggas
connections.ForPropanegas,useatleast½”(13mm)pipeortubingwitha5/8”(16mm)inside
diameter.ForNaturalgas,use¾”(19mm)pipe.
NationalFuelGasCode,ANSI
Z223.1,NaturalGasInstallationCode,CAN/CGA-B149.1,orthePropaneInstallationCode,
CAN/CGA-B149.2.
4

Thegaspressureregulatorispartofthecombinationvalveandisadjustedtoyieldapressureof3.5”
watercolumn(9mbar)forNaturalGas.IftheovenisorderedforuseonPropaneGasorButane,the
pressureregulatorinthecombinationvalveispresetatthefactorytoyieldapressureof10”water
column(25mbar).
GassupplypressureintheEuropeanCommunitycountriesshouldbeasbelow.
GasTypeSupplyPressure
G2020mbar
G2525mbar
G20/2520/25mbar
G3030or50mbardependingoncountry
G3130,37,or50mbardependingoncountry
Aseparateshut-offvalveforeachovenmustbeprovided.Itshouldbeascloseaspossibletotheplace
wherethegaslinegoesintotheoven.Itmustbelocatedsuchthatitiseasilyaccessible.Whenstacking
withanotheroven,twoshut-offvalves,oneforeachofthetwoovens,mustbeprovided.
Theoven,wheninstalled,mustbeelectricallygroundedinaccordancewithlocalcodesand/orthe
latesteditionoftheNationalElectricalCodeANSI/NFPANo.70intheUSA(CanadianElectricalCode
CSAStandardC22.1,Part1inCanada).
InEurope,theappliancemustbeconnectedbyanearthencabletoallotherunitsinthecomplete
installationand,thence,toan independentearthconnectionincompliancewithEN60335-1and/or
localcodes.
Theelectricmotor,alltherelatedswitches,interiorlights,andthetimer/buzzerareallconnected
throughthe6-foot(1829mm)powersupplycordlocatedattherearoftheoven.Thesupplycordmust
bepluggedintoaproperlygrounded,three-prongreceptacle.DONOTCUTORREMOVETHE
GROUNDINGPRONGFROMTHEPLUG.
Normalfactoryconnectionsaremadefor120voltsA.C.,60hz,ServiceinUSAandCanadaor240volts
A.C.,50hzserviceinEuropeancommunitycountries.Othervoltagescanbesupplieduponrequest.
Electricalcharacteristicsofthisunitcanbefoundontheratingplatelocatedontherightsideoftheunit.
Thisunitisprovidedwithapermanentlylubricatedelectricmotor.Awiringdiagrammaybefoundonthe
backoftheservicepanelontheright-handsideandinthismanual.
Iftheovenisnotventeddirectlyandisinstalledunderaventilationhood,theunitisreadytobeinstalled
asis.Localinspectorsandventilationspecialistsshouldbeconsultedsothatthedesignandthe
installationofthehoodconformtolocal/municipalcodes.IntheU.K.,followventilationrequirementsas
detailedinB.S.5440.
NOTE:
AftertheGasSupplyhasbeenconnected,itisextremelyimportanttocheckallthepipingfor
leaks.Useasoapandwatersolutionoraproductexpresslymadeforthispurpose.Donotuse
matches,candlesoraflameandsoforthtocheckleakssincethesemethodsareextremely
dangerous.
Noexternalregulatorisrequired.
F.ELECTRICALCONNECTION:
G.FLUECONNECTIONVENTILATION:
Installationunderventilationhood(standard):
5

Optionaldirectventing(notavailableforEuropeancommunitycountries):
NOTE:DONOTPUTADAMPERINTHEFLUEANDDONOTCONNECTABLOWERDIRECTLY
TOTHEFLUE.
H.BURNEROPERATION:
I.SYSTEMCHECK-ROTARYCONTROL:
NOTE:OVENSTARTSHEATINGASSOONASTHESETTEMPERATUREISHIGHERTHANTHE
OVENTEMPERATUREWITHTHEOVENDOORSCLOSEDANDTHESELECTORSWITCHNOT
IN“0”POSITION.
THERMOSTATINDICATORLIGHTGOESOUTWHENOVENREACHESSETTEMPERATURE
ANDCOMESONWHENOVENISHEATINGUP.
INTHEEVENTOFPOWERFAILURE,THEOVENWILLNOTOPERATE.RESTORATIONOF
POWERAFTERANYDURATION,WILLRETURNUNITTONORMALOPERATION.
J.PROGRAMMINGMENUS(forunitswithdigitalcontrols):
Ifdirectventing,aflueadapterandadrafthoodarerequiredtobeinstalled.Theypreventthefluegases
leavingtheoventobeaffectedbytheairpressurechangesontheoutsideofthefluestackextending
outofthebuilding.Thefluepipefromthedrafthoodmustnotrundownwardsatanypointfromtheoven
tothefinaloutlet.Itshouldalwaysslantslightlyupwards.Forbestresults,isshouldrisestraightup.The
ventingsystemshallbeinaccordancewiththeNationalFuelGasCode,ANSIZ223.1/NFPA54andor
theCSAB149.1,NaturalGasandCSAB149.2,PropaneInstallationCodes,andlocalcodes.
Ifthefluerunsdirectlytothefreeairoutsidethebuilding,useawinddeflectororaULlistedventcapat
theendofthepipe.Terminationoftheventmustbeatleasttwofeetabovethehighestpartoftheroof
withintenfeet.REF:AGACATALOGNO.XH0474.
Theovenburnerflameshouldalwayshaveablueappearance.Thisindicatesagoodmixtureofairand
gas.WhenusingLPgas,theflamewillhaveablue-yellowappearance.Theremaybeintermittent
yellow-orangeflamenoticed.Thisiscausedbydustparticlesburningintheflame.
(1)Opentheovendoor.
(2)TurnSelectorSwitchto“HI.”TheindicatorlightnearSelectorSwitchandovenlightwill
illuminate.
(3)Closethedoor.Ovenlightswillgooffandfanwillrun.Makesurefanisrotatingclockwise
lookingfromfront.
(4)PressOvenLightswitch.Ovenlightwillgoonandwillgooffwhenswitchisreleased.
(5)TurnGasCockDialto“ON”position(onlyforUSAandCanada).
(6)Turnthethermostatknob.Theindicatorlightnearthethermostatwillilluminateandthe
burnerswillcomeon.
(7)TurntheTimerKnobandsetatimeof2minutes.Attheendof2minutes,youshouldhear
thebuzzer.Turnthetimerknobto“0”,tostopthebuzzer.
(8)Opentheovendoors.Ovenlightswillgoonandburnersandfanwillgooff.
(9)TurnSelectorSwitchto“CoolDown”position.Thefanwillruntocooldowntheoven.
(10)TurnSelectorSwitchto“0”position.
(11)Closetheovendoors.
RefertoC&H-3PlusControllerOperating/ProgrammingInstructionsManual.
6

II.OPERATINGINSTRUCTIONS
A.GENERALINSTRUCTIONS:
B.OPERATIONSEQUENCEROTARYCONTROL:
Cookonlyrotarycontrol:
Timedcookingrotarycontrol:
NOTE:TIMERISASIGNALDEVICEONLYANDDOESNOTCONTROLTHEOVEN.
CookandHoldRotaryControl:
(1)ThisequipmenthasanElectronicTemperatureControlandElectronicHotSurfaceDirect
IgnitionSystem.
(2)Duetoincreasedefficiencyofthisoven,thetemperatureofstandardrecipesmaybereduced
50°F(30°C).
(3)Alwaysloadeachshelfevenly.Spacepansawayfromeachotherandfromsidesandbackof
oventoallowmaximumairflowbetweenthem.
(4)Largetemperedglasswindowsandinteriorlightsallowaclosecheckontheproduct,makingit
unnecessarytofrequentlyopenthedoors.Productscookfasterinaconvectionovenas
comparedtoaconventionaloven.Dependingontheproductandthetypeofpansused,time
savingmayrunfrom20percenttoashighas50percent.
(1)Closetheovendoors.
(2)TurnSelectorSwitchto“HI”or“LO”position.TheindicatorlightneartheSelectorSwitchwillbe
illuminated.
(3)Turnthethermostatknobtothedesiredcookingtemperature.
(4)Uponreachingthesettemperature,theindicatorlightnearthethermostatwillgoout.
(5)Loadtheovenwithproducttobecooked.
(6)Removetheproductfromtheovenwhendone.
(1)Closetheovendoors.
(2)TurnSelectorSwitchto“HI”or“LO”position.TheindicatorlightneartheSelectorSwitchwillbe
illuminated.
(3)Turnthethermostatknobtothedesiredcookingtemperature.
(4)Uponreachingthesettemperature,theindicatorlightnearthethermostatwillgoout.
(5)Loadtheovenwithproducttobecooked.
(6)Turnthetimerknobtothedesiredbaketimeandtimerwillstartcountingdown.
(7)Whentimerreacheszero,abuzzerwillsound.
(8)Turnthetimerknobto“O”position.
(9)Removetheproductfromtheoven.
(1)Closetheovendoors.
(2)TurnSelectorSwitchto“HI”or“LO”position.TheindicatorlightneartheSelectorSwitchwillbe
illuminated.
(3)Turnthethermostatknobtothedesiredcookingtemperature.
(4)Uponreachingthesettemperature,theindicatorlightnearthethermostatwillgoout.
(5)Loadtheovenwithproducttobecooked.
(6)Turnthetimerknobtothedesiredbaketimeandtimerwillstartcountingdown.
(7)Whentimerreacheszero,abuzzerwillsound.
(8)TurntheTimerknobto“O”position.
(9)Turnthethermostatknobtothedesiredholdtemperature.
(10)Removetheproductfromtheovenwhenneeded.
7

8
Optionalsteaminjection:Rotarycontrol:
NOTE:DONOTUSESTEAMINJECTIONATTEMPERATURESBELOW275°F(135°C).
OvencooldownRotarycontrol:
C.CLEANING:
CLEANONLYWHENOVENISCOLD
KEEPCLEANINGFLUIDSAWAYFROMELECTRICAL
WIRES,LIGHTSOCKETS,SWITCHESANDCONTROLPANEL.
NOTE:ALWAYSRUBTHESTAINLESSSTEELALONGTHEGRAINS.
Thesolenoidvalveforsteaminjectionismountedbehindtheservicepanelontheright-handsideofthe
unit.Theelectronictimerispresetatthefactory.A¼”coppertubingisprovidedontheSolenoidValve
forwaterhookupwithacompressionfitting.Afterthewaterhookupismade,makesurethatthereareno
leaks.Forsteaminjection,presstheSteamswitchmomentarily.
Tocooldowntheoventoalowerdesiredtemperature,followthestepsdetailedbelow.
(1)Opentheovendoors.
(2)TurnSelectorSwitchto“ovencooldown”position.Fanwillnowoperateandcooldowntheoven.
(3)Whentheovenhascooleddowntothedesiredtemperature,turntheSelectorSwitchto“O”
position.Closeovendoors.
(1)Withporcelainenamelinteriors,thisovenisdesignedtobeasmaintenancefreeaspossible.
However,forbestresults,theovenshouldbecleanedregularly.Enameledinteriorscanbe
easilycleanedwithovencleaners.
(2)Bakedonsplatter,oil,greaseordiscolorationonthestainlesssteelfrontorinsideoftheoven
mayberemovedwiththestainlesssteelcleanersuppliedoranyothersimilarcleaningagent.
(3)Tocleantheblowerwheel,removeandimmerseinammoniatedwaterfor20to25minutes.
Then,scrubitoffwithasmall,stiffbrush.Thesameprocedurecanbefollowedforwireracksand
racksupports.Toremovetheblowerwheel,loosenthesetscrews(2)onthehuboftheblower
wheelandtightenthe3/8”wheelpullerbolt(supplied)incenterofthehub(SeeFigure2).
D.SERVICING:
NOTE:THISAPPLIANCEMUSTBESERVICED
BYANAUTHORIZEDSERVICEAGENT.
(1)Powersupplytotheunitmustbe
disconnectedbeforeanyserviceis
performed.
(2)Mostoftheserviceontheunitcanbe
performedfromthefrontand/orcontrol
panelside.
(3)Forproperservicing,accesstothecontrol
panelsideoftheunitwillberequired.
(4)Itwillbenecessarytohaveaccesstothe
backoftheovenforserviceneedsrelated
tothegassupplyandelectricpowersupply.
(5)Asystemwiringdiagramisprovidedinthis
manualandonthebackoftheservice
panelontherightsideoftheoven.
(6)Thisunitisprovidedwithapermanently
lubricatedelectricmotor.
(7)Allservicingshouldbeperformedbya
factory-authorizedtechnicianonly.
(8)Forpropermaintenanceandrepairs,call
thefactorytollfree(800-431-2745)foranauthorizedserviceagencyinyourarea.
NOTE:THEVENTILATIONSYSTEMMUSTBEINSPECTEDATLEASTEVERYSIXMONTHSAND
MAINTAINEDCLEANANDFREEOFOBSTRUCTIONS.
CleaningTheBlowerWheel
Figure2
WheelPullerBolt3/8”-Hex
BlowerWheel
SetScrews(2)
Motor

2
1
3
Attachpart#21818062with
6each8-32stainlessscrews
Removetheouterandinnerfluefromthe
bottomovenbeforeplacingthetopoven(to
preventdamagingthebottomoven’sflue).
Re-installaftertopovenispositioned.
Material:14ga
201Stainless
Figure3 STACKINGINSTRUCTIONSFOR:BCO-G&GDCO-GCONVECTIONOVENS
Item1 Item2 Item3
E3770A E3771A 3/8”-16Bolt
9

WITHPLATECASTER
WITHOUTPLATECASTER
LEGASSEMBLYINSTRUCTIONS-MODEL:BCO-G&GDCO-GFigure4
1.Attachtwoitem2totwoitem1usingitem3,4and5.
2.Usingproperliftingequipmentattachitem1tothe4
correspondingholepatternslocatedinthebottom
oftheovenwithitem6.
1
2
3
4
5
6121818095Leg,25"WeldmentAssy
28633515FootInsert,Adjustable
38227700HexHd5/16-18X3/4Bolt#5Zn
48509300Washer,Flat,SAE,5/16
58435000Hex-Nut5/16-18
682447-00HexHd.3/8-16X.750#5
Item P/N Description
1.Attachtwoitem2totwoitem1usingitem3,4and5.
2.Attachtwoitem7totwoitem1usingitem3,4and5.
3.Usingproperliftingequipmentattachitem1tothe4
correspondingholepatternslocatedinthebottom
oftheovenwithitem6.
121818092Leg,25"SSWeldmentAssy
28633102Caster,5”SwivelW/TopPlate
38227700HexHd5/16-18X¾Bolt#5Zn
48509300Washer,FlatSAE,5/16
58435000Hex-nut5/16-18
682447-00HexHd.3/8-16X.750#5
78633101Caster,5"SwivelW/Plate&Brake
Item P/N Description
1
2
3
4
5
6
7
10
