STANDARD FEATURES
CERTIFICATIONS
SPECIFICATIONS
The DP-2 electric counter top ovens feature two independent,
operator controlled baking chambers
and hearth stone decks making them ideal for baking and
roasting or pizza. Perfect for pan pizza.
The DP-2 features two sets of controls — one set for each bake
chamber. Each set consists of a 15-minute electric timer with
continuous ring audible alarms and manual shut-offs, ready-on
oven indicator light, and a 284-680° F (140-360°C) thermostat.
The exterior front, sides, top and door are fabricated of heavy
gauge type 430 stainless steel with a #4 finish. Door handle is
constructed of tubular stainless steel. Exteriors measures 26” wide
(660mm) by 28” deep (711mm) by 24” tall (610mm) overall.
The interiors are constructed of high heat aluminized steel, welded
to form a single unitized body. The entire oven is insulated with
1 1/2” thick (38mm) industrial grade insulation. Each hearth stone
deck measures 20 3/4” (527mm) by 20 3/4” (527mm) by 1/2"
thick (13mm).
Incoloy, tubular heating elements provide top and bottom heat
with up to 5050 watts in 208V or 220-240V, single or three phase.
International voltages available. Ovens are stackable.
Brick lining increases top heat intensity and speeds recovery.
1 Year limited parts and labor warranty included.
with 5 1/2” (140mm) deck
heights
q
q
q
q
q
q
q
q
DP-2 @ 5050 watts in 208V or 220-240V
Two independent, operator controlled cook/bake chambers
each with a separate set of controls
Two 15-minute electric timers with continuous ring, audible
alarms and manual shut-offs (one for each chamber)
Hearth stone decks
5 1/2" Deck height (140mm)
All stainless steel exterior
Unitized, welded, aluminized steel interior
Fully insulated
q
q
q
q
300°-650°F (149°-343°C) Thermostats (one for each
chamber)
4” (102 mm) adjustable legs
Interior lights
Limited one year parts & labor warranty
OPTIONS & ACCESSORIES
q
q
q
q
q
q
q
Stainless steel stand with or without casters
Stacking kit
Steel decks in lieu of hearth stone
International voltages
Infinite controls for independent top and bottom heat control
4" adjustable legs
Brick lined
BAKERS
PRIDE
qModel DP-2
qModel DP-2BL
COUNTER TOP
ELECTRIC
PIZZA & BAKE OVENS
BAKERS
PRIDE
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
914/576-0200 • 1-800-431-2745 • fax [phone]
CANADIAN GAS ASSOCIATION
Job ____________ Item # ___________
ELECTRIC COUNTER TOP OVENS
®
Model DP2
with optional top & bottom heat controls
C
L
A
S
S
I
F
I
E
D
UL
®CUS
UL
®

BAKERS
PRIDE
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
TSW:10/06
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
914/576-0200 • 1-800-431-2745 • fax [phone]
SHIPPING INFORMATION
Model
DP-2 278 17.736 32 1/2 32
126 .51 914 826 813
Shipping Weight Crate SizeCarton Dimensions
Lbs. Cubic
Feet
Inches
Width Depth Height
Inches Inches
Kilos Cubic
Meter
mm mm mm
POWER SUPPLY
Model VOLTAGEWATTS PHASE AMPS
Under 500 lbs = Shipping Class # 70
SIDE VIEW / SECTION
REAR VIEW
FRONT VIEW
Each oven requires a separate electrical connection.
1 Phase and Canada include cord and plug
3 Phase and International voltages has no line cord
MINIMUM CLEARANCES
Left Side
Right Side
Rear
0
0
0
1
1
1
0
0
0
25
25
25
* In European Community Countries and North America. In NON-COMBUSTABLE locations only.
** In European Community Countries only in COMBUSTIBLE locations. NOT for North America.
* Height without legs
Inches Inches
Non-Combustible Construction* Combustible Construction**
mm mm
NEMA Plug #
USA Canada UK Europe
ALL DIMENSIONS NOMINAL
SPECIFICATIONS
Model
DP-2 20 3/4 x 20 3/4 527x527 2 2
Deck Size #
Decks
# Cook
Chambers
Overall Dimensions
Inches mm Inches
Width Depth Height*
Inches Inchesmm mm mm
28 2426 711 610660
DP2
DP2
5050
5050
208
220-240
1&3
1&3
24.5 & 14.0
22.0 & 12.7
6-30P
6-30P
6-30P
6-30P
26"
(660mm)
24"
(610mm)
TOP VIEW
Bake Chamber
22 1/4"
(565mm)
21 3/4"
(552mm)
28"
(711mm)
1 1/2"
(38mm)
1”
[25mm]
LINE CORD 5-1/2"
[140mm]
400 350
300
300
250
200
150
450
500
550
°F
°C
80
100
120
140
160
180
180
200
220
240
260
280
400 350
300
250
200
150
450
500
550
°F
°C
80
100
120
140
160
180
200
220
240
260
280
280
MINUTESMINUTES 01
12
15
14
13
11
10 98
7
6
5
4
3
2
MINUTESMINUTES 01
12
15
14
13
11
10 98
7
6
5
4
3
2
BAKERS PRIDE
BAKERS PRIDE
9-1/2"
[241mm]
6-3/4"
[171mm]
21"
[533mm]
7-1/2"
[191mm]
7-1/2"
[191mm]
5-1/2"
[140mm]
5-1/2"
[140mm]
6-30P US & Canada
