BAKERS PRIDE Y-DSP Display Ovens are ideal for display cooking
and exhibition kitchens. These ovens are designed and engineered
to be "built-in" behind brick, stone or tile applied directly to ovens
exterior or finished and trimmed in brass, copper, stainless or
powder-coated trim.
Ovens may be stacked two high. Oven exteriors are all heavy-
gauge steel and are fully insulated up to 5" (127mm) thick for
cooler outer temperatures and consistent interior temperatures.
Interior oven frame is constructed of 1/4" (6mm) heavy-duty angle
iron frame, completely welded to form a single, unitized section.
The oven body and lining are then welded to the framework.
Oven interiors are manufactured of high-heat resistant 16-gauge
aluminized steel. Doors are fully insulated, spring balanced with
natural black finish and custom wood handles.
Lintel plates support the masonry or tile for ease of installation.
Standard features include dome top plus front and side skirts.
All models feature independent, operator-controlled top & bottom
heat control dampers and micro slides for perfectly balanced
results.
Y Series features a 300°-650° F (149°-343°C) thermostat,
8" (203mm) interior deck height with
decks (steel decks optional) and are supported by a 1/4"
(6mm) angle iron frame.
Combination gas control incorporates a manual gas valve, pilot
safety and pressure regulator. Easily removable, slide-out, heavy-
duty flame diverters distribute the burner flame uniformly in the
burner chamber. A 3/4" (19mm) NPT gas connection is located on
the left side and left rear of oven - operator/installer may choose.
Heavy-duty, 7-gauge hot rolled steel legs are standard and finished
with durable Bakertone.
2 Year limited part and labor warranty standard.
throttling
1 1/2" (38mm) thick hearth
stone
q
q
q
q
q
q
q
q
q
q
q
q
q
q
q
q
Y Series @ 120,000 BTUH per deck, natural or LP gas
300°-650° F (149°-343°C) throttling thermostat
Top & bottom heat control dampers & micro-slides
Combination gas controls with valve, regulator & pilot safety
Heavy-duty, slide-out flame diverters
8" (203mm) interior deck heights with 1 1/2" (38mm) thick
hearth stone decks
Black powder coated doors with custom hardwood handles or
stainless doors with tubular steel handles
Front or side mounted controls with large, hinged access
cover door in black powder coat or stainless steel
Dome top - removable for field installations
Front & side skirts
Aluminized steel interiors
Spring balanced, fully insulated doors
Rear gas connections
7-Gauge legs
Fully insulated throughout
2 Year limited part and labor warranty
q
q
q
q
q
q
q
q
Side-mounted controls
Steel decks in lieu of hearth stone decks
150°-550° F (65°-288°C) thermostat
Automatic oven starter
Draft flue for direct vent (not available on CE units)
Fire brick hearth decks (Y-600/602 only)
Without dome and/or without skirts
Set of 4 casters - two with locks - not for use with skirts
BAKERS
PRIDE
qModel Y-600-DSP Single
qModel Y-800-DSP Single
qModel Y-602-DSP Double
qModel Y-802-DSP Double
SUPER DECK
Y-DSP SERIES
GAS DISPLAY OVENS
BAKERS
PRIDE
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
914/576-0200 • 1-800-431-2745 • fax [phone]
www.bakerspride.com
GAS DECK OVENS G
Model Y-602-DSP
with optional stone finish
CERTIFICATIONS
CANADIAN GAS ASSOCIATION
D
E
S
I
G
N
C
E
R
T
I FI
E
D
CERTIFIED
®
