Bali SRGF11450 User manual

Questions, problems, missing / replacement parts? Before returning to your retailer,
call our customer service department at 1-866-814-0585, 8 a.m. - 8 p.m., EST
Monday-Friday.
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
DANGER
WARNING
WARNING: For Outdoor Use
Only.
CAUTION:
Installer: Leave the instruction manual
to the user for future use.
Consumer: Please keep this manual
for future reference.
Read the instructions before use. This
appliance must be installed in accordance
with such regulations as are in force.
Owner’s Manual
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
52" RECTANGLE GAS
FIRE PIT
Model#SRGF11450
TM

This appliance can produce carbon monoxide which has
no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such
as a camper, tent, car or home.
DANGER CARBON MONOXIDE HAZARD
SPECIFICATION
Certification CSA
Rated Heat Input 60000 BTU/HR
Fuel LP
Gas Supply 20 lb (9 kg) LP gas cylinder
Manifold Pressure 11” W.C.
Injector Size(diameter) 2.7mm
Gas Supply Pressure
M
Battery Size AA, 1 piece
ax. 250PSI, Min. 5PSI
tDo not try to light the appliance.
tDo not touch any electrical switch; do not use any phone in the vicinity of this product.
tImmediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s
instructions.
tIf you cannot reach your gas supplier, call the fire department.
WARNING : Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Read the installation, operation and maintenance
instructions thoroughly before installing or servicing this equipment.
WHAT TO DO IF YOU SMELL GAS?
Installation and service must be performed by a qualified installer, service agency or gas
supplier.

WARNINGS AND CAUTIONS
2

IMPORTANT SAFETY INFORMATION
tThe installation must comform with local codes or, in the absence of local codes, with
the CAN/CGA-B 149.2, Propane Installation Code.
tAlways place the appliance on a firm and level surface.
tDo not burn solid fuels in this gas appliance.
tUse the appliance outdoors in a well-ventilated space only, not in a building, garage, or any other
enclosed area.
tWhen using the appliance, keep the appliance area clear and at least 50 inches from combustible
materials, gasoline and other flammable liquid and vapors. Certain items or materials, when stored
under the appliance or nearby, will be subjected to radiant heat and could be seriously damaged.
t Inspect the gas connections of appliance prior to each use. Do not operate the unit if there is gas leak.
A qualified service person should inspect the appliance annually.
tAlert children and adults to the hazards of high surface temperatures and keep them away
to avoid burns or clothing ignition.
tCarefully supervise children and pets when they are near the appliance.
tReplace and guard or other protective device removed for servicing.
tDo not hang clothing or other flammable materials on or near the appliance.
tDo not use the appliance if any part has been under water. Immediately call a qualified service
technician to inspect the appliance and to replace any part of the control system and any gas
control which has been under water.
t
t
Use only a cylinder supply system arranged for vapor withdrawal, and the cylinder must include a
tThe LP-gas supply cylinder to be used must be: Constructed and marked in accordance with the
Specifications for LP-gas cylinders of the U.S. Department of Transportation (DOT); or the Standard
for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission,
CAN/CSA-B339, as applicable;
The LP-gas supply cylinder to be used must be provided with a listed overfilling prevention device;
and provided with a cylinder connection device compatible with the connection for the appliance.
collar to protect the cylinder valve.
tThis appliance requires 20 lb (9 kg) LP gas supply cylinder.
tThe burner must be replaced prior to the appliance being put into operation if it is evident that the
burner is damaged. The replacement burner shall be that specified by the manufacturer.
tInstallation and repair should be done by a qualified service person. The appliance should
be inspected before use and at least annually by a qualified service person. More frequent
cleaning may be required as necessary. It is imperative that control compartment, burners,
and circulating air passageways of the appliance be kept clean.
WARNINGS AND CAUTIONS
3

This appliance is designed to operate with a standard 20 Ib propane cylinder with Approved
Cylinder Connection.
WARNING:
This product can expose you to chemicals including lead, which is known to the State of
California to cause cancer, and carbon monoxide, which is known to the State of California to
cause birth defects or other reproductive harm. For more information, go to:
www.P65Warnings.ca.gov.
NOTE: PLEASE READ THE FOLLOWING SAFETY RULES:
Before beginning assembly of product, make sure all parts are present. If any part is missing or
damaged, do not attempt to assemble the product. Contact customer service for replacement parts.
Perform a leak test with a soapy solution:
1. To check gas connections.
2. After connecting a new cylinder.
3. Upon re-assembly after disassembly.
WARNINGS AND CAUTIONS
PREPARATION
TOOLS NEEDED: (NOT INCLUDED)
Philips screwdriver
Adjustable open end wrench
Estimated time for assembly: 10 minutes.

4

Exploded View
1
2
3
4
56
7
8
9
10
11
12
13
14
16
17
18
19
20
21
15
5

Parts List
NOITPIRCSEDTRAP QUANTITY
Lid
Lava rock
Burner assembly
Control knob
Tabletop
Right side panel
Right hind leg
Front panel
Left foreleg
Back panel
Right foreleg
Foot pad
Connecting tube assembly
Rail mounting plate
Cylinder holder
Caster
Cylinder locking bolt
Sliding track
Left hind leg
Cylinder holder reinforced rib
Door
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1pc
1bag
1pc
1pc
1pc
1pc
1pc
1pc
1pc
1pc
4pcs
1pc
2pcs
1pc
2pcs
1pc
2pcs
1pc
1pc
2pcs
1pc
6

AA
ASSEMBLY INSTRUCTIONS
1. Place the lava rocks (2) onto the burner assembly (3). Put the lid (1) onto the tabletop(5)
Note: Please remove the lid (1) when using fire pit.
2. Unscrew the battery compartment cap on the control panel, install one AA 1.5 V battery
(not included) with anode end of battery located towards the battery compartment cap.
Replace the battery compartment cap into position.
1
2
35
7

ASSEMBLY INSTRUCTIONS
3. Slide out the door, and place cylinder in the cylinder holder, then attach regulator to cylinder
and turn clockwise by hand. Check your fire pit for leaks, see Check for leaks section. After
that, push the door back to position.
8

Check for leaks
uqiltrap1gniximybnoitulosegakaeleka M)1 uid dish
soap and 3parts water.
2) Spoon or brush several drops (or use squirt
bottle)
of the solution onto hose/regulator/cylinder
connection.
3)
alve. Inspect the connections
and look for bubbles.
4) If no bubbles appear, the connection is safe.
5) If bubble appear dnanesool,egakaelsiereht, ,kaelallitssierehtfI.noitcennocsihtnethgit-er
please call customer service: 1- 866 -814 - 0585.
Turn on gas cylinder v
SAFETY CHECK
Note:
1) The cylinder supply system must be arranged for
vapor withdrawal;
2) The cylinder used must include a collar to protect
the cylinder valve.
The hose assembly must be replaced prior to the
appliance being put into operation if there is evidence
of excessive abrasion or wear, or if the hose is
damaged.
At least once a year, a complete inspection of the
entire gas path components should be performed.
If there is need to replace parts, proceed to leak test
after reassembly (These procedures should be
performed by a professional technician).
9
Your gas fire pit has been checked at all connections
at the factory for leakage.
In transportation and handling some connections may
have loosened. Follow these steps to check the hose/
regulator/cylinder connections:

WARNING: DO NOT ATTEMPT TO OPERATE THE APPLIANCE UNTIL YOU HAVE READ AND
UNDERSTAND ALL PRECAUTIONS . FAILURE TO DO SO CAN RESULT IN PROPERTY
DAMAGE, SERIOUS INJURY, OR DEATH.
WARNING
WARNING
WARNING
FOR YOUR SAFETY:
DO NOT touch or move gas appliance
for at least 45 minutes after use.
Lighting operations should comply
with Lighting Instruction section.
Improper lighting operations will
cause serious injury and explosion.
Before turning gas supply ON
Your
fire pit was designed and approved for OUTDOOR
USE ONLY. DO NOT use it inside a building or any other
enclosed area.
Make sure surrounding areas are free of combustible
materials, gasoline, and other flammable vapors or liquids.
Ensure that there is no obstruction to air ventilation.
Be sure all gas connections are tight and there are no leaks.
Be sure the access panel is clear of debris.
Be sure any component removed during assembly or
servicing is replaced and fastened prior to starting.
FOR YOUR SAFETY:
WARNING!!!
Do not use an open flame to check for leakage.
Do not smoke during testing.
Do not test indoors.
A leak check must be performed whenever the gas
cylinder is replaced.
NOTE:
U
se only the pressure regulator supplied with this fire pit.
Replace them with those specified by the manufacturer
only.
OPERATION
10
If at any time you are unable to
light burner and smell gas, wait 5
minutes to allow gas to dissipate
before attempting to light gas
appliance. If after . 1 minute, you
are unable to light burner, wait 5
minutes and allow flammable
vapors to dissipate before
attempting to light gas appliance.

ATION
Before Lighting
The gas fire pit should be thoroughly inspected before each
use, and by a qualified service person at least annually.
If relighting a hot gas fire pit, always wait at least 5 minutes.
Lighting instructions
1. Make sure control knob is in the
"OFF" position.
2. Turn LP cylinder gas valve to fully
open position.
3. Press down control knob and turn it
counter clockwise to "LOW"
position.
4. If the burner is lit, keep pressing down
the control knob for 1 minute before
releasing it.
5. If the burner is not lit, press down the
control knob and turn clockwise to "OFF" position, repeat from step 3 after 5 minutes.
6. When burner is lit, press down the control knob and turn it to desired heat output position
between "LOW" and "HIGH".
7. Press down and turn the control knob clockwise to "OFF" position to shut down the appliance.
Turn off cylinder gas valve.
Flame Characteristic
Normally the burner flame is yellow.
If the burner flame is blue and very small, please check theerehtfI.ytpmeroerusserpsagwolebyamtisa,rednilycsag
is enough gas in the cylinder, please contact customer service
to change the burner of the gas fire pit.
If flames lift away from burner or backfire happens,or produce
thick black smoke, the fire pit should be turned off immediately.
The fire pit should not be operated again until the unit is serviced
and/or repaired by a qualified service technician.
WARNING:DO NOT ATTEMPT TO OPERATE THIS HEATER UNTIL YOU HAVE READ
AND UNDERSTAND ALL PRECAUTIONS. FAILURE TO DO SO CAN RESULT IN
PROPERTY DAMAGE,SERIOUS INJURY,OR DEATH.
OPERATION
Battery Compartment
O
F
F
P
u
s
h
t
o
t
u
r
n
L
O
W
H
I
G
H
11

CAUTION:AVOID INHALING FUMES EMITTED FROM THE GAS APPLIANCE'S FIRST USE.
SMOKE AND ODOR FROM THE BURNING OF OILS USED IN MANUFACTURING WILL
APPEAR. BOTH SMOKE AND ODOR WILL DISSIPATE AFTER APPROXIMATELY 30
MINUTES.THE GAS APPLIANCE SHOULD NOT PRODUCE THICK BLACK SMOKE.
NOTE:
The burner may be noisy when initially turned on. To eliminate
excessive noise from the burner, turn the control knob to the
LOW position.Then, turn the knob to the level of heat desired.
Operation pressure checked:
If the flame is very small, this is because the supply pressure is
not enough. Please refill gas cylinder.
Re-light: .noitisop"FFO"otbonklortnocehtnruT)1
2)
3) Repeat steps beginning with step 3 of the lighting instruction.
Shut down instructions:
1) Push in and turn control knob clockwise to "OFF"position.
2)
2) Turn LP cylinder valve to "OFF" position.
The Event of Gas Leakage:
1) Turn the control knob to "OFF" position.
3) Wait 5 minutes to allow gas to dissipate.
4) If odor continues, immediately call gas supplier.
WARNING : Gas appliance will be hot after use.
Handle with extreme care.
Wait five (5) minutes before attempting to relight appliance.
Turn LP cylinder gas valve clockwise to OFF position when
appliance is not in use.
OPERATION
O
F
F
P
u
s
h
t
o
t
u
r
n
L
O
W
H
I
G
H
P
u
s
h
t
o
t
u
r
L
O
W
H
I
G
H
O
F
F
n
12

CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT ABOVE, BESIDE OR UNDER
THIS HEATER WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE
SERIOUSLY DAMAGED.
This gas fire pit is primarily used for the heating
of outdoor patios, decks, spas, pools and open
working areas.
Always make sure that adequate fresh air
ventilation is provided. Follow the spacing
tolerances shown in Figure 1 at all times.
This gas fire pit must be placed on level, firm
ground.
Never operate in an explosive atmosphere.
Keep away from areas where gasoline or other
flammable liquids or vapors are stored or used.
LOCATING HEATER FOR USE
13

T
DO NOT touch or move gas appliance
for at least 45 minutes after use.
Allow all burner elements to cool
before touching.
FOR YOUR SAFETY ;
WARNING:
NOTE:
In a salt-air environment (such as
near an ocean). corrosion occurs
more quickly than normal.
Frequently check for corroded
areas and repair them promptly.
NOTE:
Wait until gas appliance is cool before
covering.
CLEANING AND MAINTENANCE :
To enjoy years of outstanding performance from your
gas fire pit, make sure you perform the following
maintenance activities on a regular basis:
Keep exterior surfaces clean.
Use warm soapy water for cleaning. Never use
flammable of corrosive cleaning agents.
While washing your unit, be sure to keep the area
around the burner dry at all times. If the gas control is
exposed to water in any way, do NOT try to use it. It
must be replaced.
Keep the appliance area free and clean from combustible
Check if there are cracks or worn sections on hose. If
yes, please call our customer service to replace hose.
materials, gasoline and other flammable vapors and
liquids; not obstructing the flow of combustion and
ventilation air; keeping the ventilation opening(s) of the
cylinder enclosure free and clear from debris.
Gas fire pit does NOT reach the desired temperature.
Gas fire pit glow is excessively uneven.
Gas fire pit makes popping noises.
At least once a year, the unit should be inspected for
the presence of spiders, spider webs or other insects.
Air flow must be unobstructed. Keep controls, burner,
and circulating air passageways clean. Signs of possible
blockage include:
Spiders and insects can nest in burner or orifices. This
dangerous condition can damage gas fire pit and render
it unsafe for use. Clean burner holes by using a heavy-duty
pipe cleaner. Compressed air may help clear away
smaller particles.
MAINTENANCE/STORAGE
14

NOTE:
Wait until the appliance is
cool before covering.
Store the fire pit indoors during the winter if it will be subjected to
freezing temperatures.
Disconnect and remove the cylinder from the appliance before the
appliance can be stored indoors.
STORAGE
Turn the control knob to "OFF" position.
,esuretfanwodloocotfire pitehtrofsetunim54tsaeltawollA
Turn LP cylinder to OFF position.
Take out the battery from the battery compartment during
periods of extended inactivity or when transporting.
and then disconnect and remove the cylinder.
Cylinder must be stored outdoors in a well-ventilated area out of
the reach of children. When the cylinder is disconnected,tightly
,gnidliubanitierotstono
ddna,sgulpevlavdedaerhtehtllatsni
garage or any other closed area.
You may store product indoors ONLY if the cylinder is
disconnected and removed.
,slairetamelbitsubmocmorfeerfdnaraelcaerafire pitehtpeeK
gasoline and other flammable vapors and liquids.
secafrusroiretxetcetorpottirevocfire pitehtgnisutonerauoyfI
and to help prevent build up in air passages.
Store gas fire pit in an area sheltered from direct contact with
sleet, hail, snow, dust and debris).n,iarsahcus(rehtaewtnemelcn
i
A qualified service person should install and repair the fire pit and
inspect it annually.
It might be necessary to clean this fire pit frequently. You must
passageways clean.
MAINTENANCE AND STORAGE
keep the control compartment, burner and circulating air
15

WARRANTY INFORMATION
The appliance has been manufactured under the highest standards of quality and workmanship. We
warrant to the original consumer/purchaser that all aspects of this product will be free of defects in
material and workmanship for one (1) year from the date of purchase. A replacement for any defec-
tive part will be supplied free of charge for installation by the consumer. Defects or damage caused
by the use of other than genuine parts are not covered by this warranty. This warranty shall be effec-
tive from the date of purchase as shown in the purchaser’s receipt.
This warranty is valid for the original consumer/purchaser only and excludes industrial, commercial
or business use of the product, product damage due to shipment or failure which results from altera-
tion, product abuse, or product misuse, whether performed by a contractor, service company, or con-
sumer. We will not be responsible for labor charges and/or damage incurred in installation, repair or
replacement, nor for incidental or consequential damage.
Gas leak
Low gas pressure
Clogged or dirty burner ports
Spent battery
Gas odor
Delayed ignition
Incorrect burner
flame
PROBLEM
OBSERVED POSSIBLE CAUSE
Incorrect gas supply or pressure
Clogged or dirty burner ports
CORRECTIVE MEASURES
Check all gas connections
Check gas supply pressure
Clean burner parts--see manual
"CLEANING AND MAINTENANCE" section
Change battery
Check gas supply pressure
Clean burner parts
TROUBLESHOOTING

