Banda EXPERT D 802 User manual

Version: 01/ 2017
COSTUMER SERVICE:
55 (19) 3844-7173 - (19) 3844-7465 - (19) 3844-4923 •
[e-mail]
WARRANTY
Banda Audioparts warrants this equipment to be free of all defects in material and workmanship for
a period of 12 months from the date of purchase
Within the period of this warranty, Banda Audioparts will repair or replace, free of charge, any part
proving defective in material or workmanship.
Warranty Exclusions:
1. Damage resulting from misuse, abuse, accident, alterations or improper installation;
2. Damage resulting from installation in surfaces subjected to high levels of vibration;
3. Any source of repairs made by anyone other than a Banda Audioparts authorized service
technician;
This warranty does not cover shipping costs.
The defective equipment must be shipped to the factory or to an authorized service center
Street: Manoel Joaquim Filho, number 353 - Jardim Santa Terezinha II - Paulínia - SP - Brazil
- Zipcode: 13148-115
Banda Audioparts reserves the right to change the product and its specifications at any time
without prior notice.
Note:Permanent Technical Support
After the warranty expires, Banda Audioparts will continue to provide extensive technical
assistance directly or through its network of authorized service, charging, however, the repair
services and replacement of components
Warning: Continuous expose to sound pressure levels over 85dB may cause permenent hearing loss.
REGISTRATION DATA
Name:
Invoice: Date: Phone:
Address:
Shop: Phone:
I N S T R U C T I O N M A N U A L
EXPERT D 802EXPERT D
INDEX
02
02 .......... Technical Specification
03 ..........Active Crossover
03 .......... Front Panel
Power Supply, Signal input and Power Output Sections04 ..........
Clip Indicator04 ..........
05 .......... • EXPERT D 802Connection Example
06 .......... • EXPERT D 1202 • EXPERT D 1602 Connection Example
07 .......... Protection System and Troubleshooting
08 .......... Warranty
TECHNICAL SPECIFICATION
• Operation Topology: Half-Bridge Class D
• Selectable Active Crossover:
• Linkwitz-Riley 12dB/octave:
Low Pass 18Hz - 80Hz
High Pass 18Hz - 40kHz
Band Pass (flat)
• Frequency Response 18Hz - 40kHz (-3dB)
• Subsonic Filter (18dB/octave)
• Clip Indicator
• THD < 0.047%
• SNR > 93.5dB
• Damping Factor > 100
• Input Sensitivity: 150mV ~ 2,3V
• Input Impedance: 22kohms
• MONO/STEREO switch
• Individual Gain Control
• Differential Input Circuit
• Dimensões:
• EXPERT D 802 - 1202 - 1602:
9,64"L x 2.08"H x 8,97"W
Peso: 6,39lb
*Equivalent to current draw with resistive load and sinusoidal signal at half power.
**These values are typical and may present some minor variation.
• Output EXPERT D 802:
2 channels (400Wrms 2ohms / 12.6Vdc) or
1 channel (800Wrms 4ohms / 12.6Vdc)
Current draw at full power (average music
program): 43A*
• Output EXPERT D 1202:
2 channels (600Wrms 2ohms / 12.6Vdc) or
1 channel (1200Wrms 4ohms / 12.6Vdc)
Current draw at full power (average music
program): 61A*
• Output EXPERT D 1602:
2 channels (800Wrms 2ohms / 12.6Vdc) or
1 channel (1600Wrms 4ohms / 12.6Vdc)
Current draw at full power (average music
program): 79A*
03
TECHNICAL SPECIFICATION - EXPERT D 802-1202-1602
• 12dB/octave selectable active crossoveross
Low Pass: 18Hz-80Hz
High Pass: 80Hz - 40kHz
Band Pass - (Flat)
Nota: To access the crossover switch, remove the plastic
cover under the amplifier.
LOW FLAT HIGH
Front panel view
1. • Red Led : Blinking - Output clipping (distortion)
Constant - Output short circuit •
2. • Blue Led : On
3. •Yellow Led : Constant - Fuse blown or missing
• Blinking - Low voltage battery
4. MONO/STEREO switch
5. Gain control - right channel (Channel 2)
6. Gain control - left channel (Channel 1)
6. MONO gain control (Bridged)
2 3 4 5 6 1
ACTIVE CROSSOVER - EXPERT D 802 - 1202 - 1602
EXPERT D 1202
EXPERT D 1602

04
TECHNICAL SPECIFICATION CONNECTION EXAMPLES EXPERT D 802
Canal 1
1. Positive speaker output
2. Negative speaker output
RCA 1. Signal input
Note: For bridge connection, select MONO in MONO/STEREO switch.
1 2 RCA 1 RCA 2 3 4
05
Canal 2
3. Positive speaker output
4. Negative speaker output
RCA 2. Signal input
Bridged
2. Negative speaker output
3. Positive speaker output
RCA 1. Signal input
CONNECTION EXAMPLES EXPERT D 1202 - 1602
06 07
PROTECTION SYSTEM AND
TROUBLESHOOTING
21 34
8 ohms 100Wrms woofer x 4
wired in parallel
8 ohms 100Wrms woofer x 4
wired in parallel
4 ohms 800Wrms subwoofer / woofer
EXPERT D 1202
EXPERT D 1602
2x 4 ohms 600W subwoofer / woofer
wired in parallel
1- 4+4 ohms 800Wrms subwoofer
wired in parallel
for each channel
Note: these are basic projects, just given as examples.
Short Circuit protection:
If short circuit is detected in output terminals, the output is disabled and the red LED lights up until the short circuit is
removed. If the load impedance is lower than the amplifier specification, the equipment may trigger the short circuit
protection.
Low Voltage Protection:
When battery voltage is lower than 9Vdc, the amplifier will shut down and the yellow LED will blink until the
equipment is restarted.
Power Supply Inverted Cable Protection:
If the power supply cables are connected inverted, the internal fuse will blow.
Troubleshooting:
Protection triggered
1. Check if the internal fuse is blown. If so, replace it with a same current rate fuse (50A - EXPERTD D 800Wrms,
,50A - EXPERTD D 800Wrms, 80A EXPERT D 1600Wrms).
2. Check if there is short circuit in the output terminals. To do it, turn o ffthe amplifier, disconnect all speakers and the
input RCA cable and wait about 20 seconds. Turn the amplifier again and if the blue LED lights up, the amplifier is
operating normally.
3. Check if any speaker is presenting short circuit or the total impedance load is lower than the amplifier specification.
4. Check if there is enough current in battery to supply the amplifier and if the cables are capable of conduct that
current.
Output Noise
1. Check if there is loose connection in signal input or in the RCA cable.
2. Check if there is ground connection in the radio/cd RCA output.
3. Check if RCA cables are wired separated from the power cables.
4. Check if the +12Vdc that powers the amplifier is coming directly from the battery.
5. Check if ground cable is connected in car chassis as near as possible of the amplifier.
6. Both radio/cd and amplifier must be firmly connected to car chassis ground to avoid noises and voltage fluctuations
at amplifier output.
Important Notes:
• Use 5 AWG (EXPERT D 802), 4AWG (EXPERT D1202) and 4AWG (EXPERT D1602) power cables for both GND and +12Vdc.
• Do not use impedance load lower than the amplifier specification. This can damage the equipment.
• Use wire solder for tinning the cable end for better electrical contact. Loose electrical connection can cause malfunction,
heating and even fire
• The GND connection must be as short as possible, using adequate wire terminal firmly connected to a clean, paint free
spot at the car chassis.
• If more than one amplifier is used, provide adequate individual wiring for each one.
• If using power supply to power the amplifier, it must be capable of supply between 12.6 – 14.4Vdc with at
least the amplifier maximum current value and maximum output variation (Vripple) of 10%.
Note: these are basic projects, just given as examples.
1. Negative power input (ground): connect to car chassis.
2. Protection fuse: • 50A (EXPERT D 802) • 50A (EXPERT
D1202)• 80A (EXPERT D 1602).
3. Remote input: connect to radio/cd remote output.
4. Positive power input (+12Vdc): connect to baterry positive
terminal.
Signal input and power output section.
CLIP INDICATOR
The red LED lights up when the amplifier output is distorting. As long as the speakers used are capable of
handle the total output power this LED can eventually blink but if it holds still it means too much distortion in
the output and this can damage the speakers and the amplifier. In this case, turn down the head unit volume.
8 ohms 150Wrms woofer x 4
wired in parallel 8 ohms 150Wrms woofer x 4
wired in parallel
8 ohms 200Wrms woofer x 4
wired in parallel
8 ohms 200Wrms woofer x 4
wired in parallel
