TCNM-AD/EX/SP Scanner Family –
Setup Procedure Using Programming
Barcodes

TCNM-AD/EX/SP Setup Procedure Using Programming Barcodes
2 p/n 174900 Rev. A
Stand-Alone Layout Barcode
To re-program a network scanner for a stand-alone configuration, use the following barcode.
Stand-Alone Layout
Step 1. Press and hold the SMART-TEACH button to enter the “AutoLearn Mode”. Once button is
pressed, the LED cycle appears as follows:
Just pressed. After 2 seconds. After 4 seconds. Release
the button to enter the
AutoLearn Mode.
The laser beam turns ON
and the yellow LEARN
LED blinks: the AutoLearn
Mode is working.
Step 2. Put the barcode related to the planned function in front of the scanner. The picture below
shows, as example, the Restore Default Values barcode1.
Step 3. After the scanner has successfully read the code, the LEDs stay on steady for 2 seconds.
1The barcodes shown are examples, only. Use the barcodes in the Stand-Alone Layout Barcodes section for the
actual programming.

TCNM-AD/EX/SP Setup Procedure Using Programming Barcodes
3 p/n 174900 Rev. A
Successful Reading
Step 4. The scanner is programmed and the AutoLearn Mode ends. The green “ready” LED is on.
Programming Done
The Stand-Alone configuration can also be programmed using
GeniusPlus. Refer to the Help On Line documentation for further details.

TCNM-AD/EX/SP Setup Procedure Using Programming Barcodes
4 p/n 174900 Rev. A
Smart-Teach Key Lock – Unlock Barcode
The SMART-TEACH key can be locked and unlocked through two different methods:
•GeniusPlus parameter
•Programming barcode
The programming barcode procedure uses the AutoLearn Mode described earlier. The code below is a
toggle-code:
•if the key is locked, the programming code unlocks the key
•if the key is unlocked, the programming code locks the key
Restore Default Parameters Barcode
The programming barcode procedure uses the AutoLearn Mode. Use this code to set the scanner to its
factory default values, configuration and environmental parameters:
