Banner A-GAGE MINI-ARRAY MACNXDN-1 User manual

A-GAGE MINI-ARRAY Features
• Measuringlightscreensystemfor
profilingandinspectionapplications
• Compactcontrolmoduleandsensors
• Controllerisprogrammable,using
DeviceNetconfigurationsoftwareand
suppliedEDSfilesfor:
– 8measurement(“ScanAnalysis”)
modes
– 4scanningmethods
– Beamblanking
– Selectablecontinuous,gatedorhost-
controlledscaninitiation
– Programmablehysteresisforhighand
lowlimits
• TwoDiscreteoutputs
• SeparateGateinputallowsexternal
controlofscaninitiation,forexample,by
apresencesensor
• Lowcost,comparedwithsimilarsystems
• Workingrangeupto17m(55'),
dependingonmodel
• Widefieldofview,easilyaligned
A-GAGE™MINI-ARRAY®Instruction Manual
(Control Modules MACNXDN-1 and MACPXDN-1 with DeviceNet™Interface)
PrintedinUSA P/N59437rev.A
WARNING . . .
Not To Be Used for Personnel Protection
ThesesensorsdoNOTincludetheself-checkingredundant
circuitrynecessarytoallowtheiruseinpersonnelsafetyapplications.A
sensorfailureormalfunctioncancauseeitheranenergizedorde-energized
outputcondition.ConsultyourcurrentBannerSafetyProductscatalogfor
safetyproductswhichmeetOSHA,ANSIandIECstandardsforpersonnel
protection.
!
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

2
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Table of Contents
3
1.System Description........................................... 4
1.1 SystemComponents ..............................................4
1.2 SystemFeatures.................................................6
1.3 DeviceNetFeatures...............................................7
1.4 TypicalApplications...............................................7
2.Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.1 EmitterandReceiverSpecifications..................................8
2.2 ControlModuleSpecifications......................................10
2.3 DeviceNetAttributeInformation....................................12
3.Installation and Mechanical Alignment ............................ 14
3.1 EmitterandReceiverMounting .....................................14
3.2 ControlModuleMounting........................................15
3.3 Hookups ......................................................16
3.3.1 EmitterandReceiverHookups..................................17
3.3.2 Inputs .....................................................17
3.3.3 Outputs....................................................17
3.3.4 DeviceNetCommunicationHookups.............................17
4.Control Module Configuration................................... 18
4.1 CommunicationsSetup ...........................................18
4.2 SystemAlignment..............................................18
4.3 Blanking.......................................................18
4.4 ControlModeSelection ...........................................19
4.5 ScanningMethods...............................................20
4.6 ScanAnalysisModeSelection......................................21
4.7 OutputConfiguration(AnalysisModeAssignment).....................22
5. System Diagnostics ......................................... 23
5.1 Diagnostics/StatusIndicators......................................23
Appendix: Glossary ........................................... 24
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

System Description
4
1. System Description
TheA-GAGE™MINI-ARRAY™measuringlightscreenisidealforapplicationssuchas
on-the-flyproductsizingandprofiling,edge-guiding,center-guiding,looptensioning
control,holedetection,partscounting,dieejectionverificationandsimilaruses.
ThissystemwasdesignedspecificallyforuseonDeviceNet™Busnetworks.
1.1 System Components
AtypicalA-GAGEMINI-ARRAYSystemhasfivecomponents:anemitter/receiverpair,
eachsensorhavingquick-disconnect(QD)connectors;oneoftwocompactcontrol
modules;andquick-disconnectcablestoconnectthem.
Sensorsareavailablewitharraylengthsfrom133mmto1819mm(5.25"to71.6"),in
152mm(6")increments(seethetableonpage5).Theemitterhasacolumnof
infraredLEDsspaced9.5or19mm(3/8"or3/4")apart,whichtranslatesto16or32
beamsperfoot.Thereceiverisconfiguredoppositetotheemitter,withtheidentical
lengthandbeamspacing.Sensorpairswith16beams/footarecapableofdetectinga
38-mmdiameter(1.5"dia.)cylindricalrod(heldperpendiculartothesensor)andhave
asensingrangeofupto17m(55').Sensorpairswith32beams/footarecapableof
detectinga19.1-mmdiameter(0.75"dia.)cylindricalrod(heldperpendiculartothe
sensor)andhaveasensingrangeofupto6m(20').(InInterlacedmode,thespecified
objectsensitivityincreases;seeSection4.5.)Thesensorshaveawidefieldofviewand
areeasilyaligned.
Themicrocontroller-basedcontrolmoduleisinterfacedwith,andcontrolledby,the
DeviceNetnetwork.EDSfilesaresuppliedtoworkwiththeuser’sDeviceNet
configurationtooltointerfaceandprogramthecontroller.CablesconnectingtheMINI-
ARRAYSystemwiththefacility’sBusnetworkareuser-supplied.ContactyourBanner
salesengineerorinterlinkBTforcableinformation.
Cablesconnectingthesensorswiththecontrolmoduleareavailableinthreelengths,
andhavequick-disconnectfittingsatthesensorend.SeeFigure1-1,page5.
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

System Description
5
Configure and monitor
the System with the
supplied EDS files and
the user’s DeviceNet
configuration tool.
DIN-
Rail Mountable
Control Module
Quick-Disconnect Cables
Figure 1-1. A-GAGE MINI-ARRAY System components
Housing
Length
3/4" Beam Spacing (16 Beams/Ft) 3/8" Beam Spacing (32 Beams/Ft)
201mm
(7.9")
BMEL616AEmitter 8
8
BMEL632AEmitter
BMRL632A Receiver
16
16
356mm
(14.0")
BMEL1216AEmitter
BMRL1216A Receiver
16
16
BMEL1232AEmitter
BMRL1232A Receiver
32
32
505mm
(19.9")
BMEL1816AEmitter
BMRL1816A Receiver
24
24
BMEL1832AEmitter
BMRL1832A Receiver
48
48
659mm
(26.0")
BMEL2416AEmitter
BMRL2416A Receiver
32
32
BMEL2432AEmitter
BMRL2432A Receiver
64
64
810mm
(31.9")
BMEL3016AEmitter
BMRL3016A Receiver
40
40
BMEL3032AEmitter
BMRL3032A Receiver
80
80
963mm
(37.9")
BMEL3616AEmitter
BMRL3616A Receiver
48
48
BMEL3632AEmitter
BMRL3632A Receiver
96
96
1115mm
(43.9")
BMEL4216AEmitter
BMRL4216A Receiver
56
56
BMEL4232AEmitter
BMRL4232A Receiver
112
112
1267mm
(49.9")
BMEL4816AEmitter
BMRL4816A Receiver
64
64
BMEL4832AEmitter
BMRL4832A Receiver
128
128
1572mm
(61.9")
BMEL6016AEmitter
BMRL6016A Receiver
80
80
BMEL6032AEmitter
BMRL6032A Receiver
160
160
1877mm
(73.9")
BMEL7216AEmitter
BMRL7216A Receiver
96
96
BMEL7232AEmitter
BMRL7232A Receiver
192
192
Models Total Beams Models Total Beams Receiver
Emitter
Emitter and Receiver Models
Cable
Model Description
QDC-515C 4.6m(15')cable,straightQDconnector
QDC-525C 7.6m(25')cable,straightQDconnector
QDC-550C 15.2m(50')cable,straightQDconnector
Cables
Controller
Model Description
MACNXDN-1 Twodiscrete,solid-stateNPNoutputs
MACPXDN-1 Twodiscrete,solid-statePNPoutputs
Control Module Models (with DeviceNet interface)
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

System Description
6
1.2 System Features
Built-infeaturessimplifytheoperationoftheA-GAGEMINI-ARRAYSystem.Emittersand
receivers,availableinachoiceoftworesolutionsand10lengths,providetherightsize
andprecisionneededformanyapplications.Programmablebeamblanking
accommodatesmachinecomponentsorotherfixturesthatmustremaininormove
throughthelightscreen.BlankingissetusingtheincludedEDSfileandtheuser’s
DeviceNetconfigurationtool.
Built-indiagnosticprogrammingandeasy-to-seeindicatorsonthesensorsandthe
controlmodulesimplifyalignmentandtroubleshooting(Figure1-2).Theemitterhasa
redLEDthatsignalsproperoperation.ThereceiverhasthreebrightLEDs:green
signalsthatthesensorsareproperlyaligned;yellowsignalsmarginalalignment;and
redsignalsmisalignmentorablockedcondition.Thecontrolmodulehasseven
SystemStatusLEDsthatindicateconditionssuchasoutput(s)conducting,Gatesignal
received,beamalignmentand/orblockedbeams.Inaddition,abi-color(red/green)
NetworkStatusLEDindicateswhetherthesystemisonlinewiththeDeviceNetnetwork
andwhetherthereareproblems.
TheA-GAGEMINI-ARRAYSystemprovidesawideselectionofsensingandoutput
options,including:measurement(“scananalysis”)modes;scanningmethodsthatcan
determinethetargetobject’slocation,overallsize,totalheightortotalwidth;and
numerousoutputoptions.Scanningmaybecontinuousorcontrolledbyahost
processcontrolleroragatesensor.
Blankingfeatureallowstheusertoconfigureanynumberofbeamstobe“blanked.”In
effect,blankingcausestheaffectedbeamstobemade“blind”toactivitywithinthe
array.
Figure 1-2. A-GAGE MINI-ARRAY with DeviceNet System features
DIN-Rail-Mountable Control Module
MINI-ARRAY CONTROLLER for DeviceNet
POWER
MACNXDN1
NETWORK
STATUS
1
1
V+
16 - 30V dc
1.2A MAX
EMTR RCVR
+12V
BR BU BK
5Wires
30V
150mA Max
OUT1
10-30V dc
GATE 30V
150mA Max
ALARM
WH
NC
+–
NC
COM DRN T/R
2345678910 11 12 13 14 15 D5 D4 D3 D2 D1
V-
F1
T/R V+
BR BU BK
5Wires
WH
CAN_HSHIELD V-CAN_L
DIAG1
DIAG2
DIAG3
OUT1 ALARM GATE ALIGN
2 3 4 5 6 7 8 9 10
11 12 13 14 15 16 17 18 19 20 
Red
Operational
LED
Network Status Indicator
Green Blocked LED
Red Marginal
Alignment LED
Yellow
Alignment LED
Diagnostic/Status Indicators
(see Section 5.1)
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

System Description
7
1.3 DeviceNet Features
TheA-GAGEMINI-ARRAYSystemconnectstotheDeviceNetBusnetworkusing
simplejunctionboxesor“T”connectors.AnElectronicDataSheet(EDS)issupplied
witheachcontrollertoassistindeviceconfiguration.TheMINI-ARRAYSystemmaybe
configuredbyanyofanumberofDeviceNetconfigurationtools;forspecific
configurationinformation,refertoyourDeviceNetdocumentation.ThefollowingMINI-
ARRAYcommunicationsareavailablethroughDeviceNet:
Device Information:manufacturer,productname,devicetype,modelandrevision
Configuration:analysismodeselections,scancontrolselection,outputsettings(set
point,hysteresisandinvert),andblankingselections
Sensor Alignment Information:totalnumberofsensorbeams,beamstatus,and
alignmentstatus
Status Information:measurementmodesresult,alignmentstatus,beamstatus,and
blankedbeamstatus
Diagnostic Information:numberofemitterbeams,numberofreceiverbeams,and
MINI-ARRAYSystemstatus
1.4 Typical Applications
TheA-GAGEMINI-ARRAYisusefulformanytypesofmeasurementandposition-
sensingapplications,someofwhichareshownbelow.
Figure 1-3. Typical applications for the A-GAGE MINI-ARRAY System
Box Profiling
Edge Guiding
Inspection Applications
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Speifications
8
2. Specifications
2.1 Emitter and Receiver Specifications
Emitter/Receiver Range
Specifiedatthepointwhere
3xexcessgainremains.
3/8" beam spacing
Minimum Object Sensitivity 3/8" beam spacing
Power Requirements
†
Maximumcurrentisfora6'
sensor.
3/8" beam spacing
Status Indicators Emitter: RedLEDlightstoindicateproperemitteroperation
Receiver: Greenindicatessensorsaligned(>3xexcessgain)
Yellowindicatesmarginalalignmentofoneormorebeams
Redindicatessensorsmisalignedoroneormorebeam(s)blocked
Sensor Scan Time 55microsecondsperbeam,pluspostprocesstimeperscan.Postprocesstimewillvary,basedonthe
numberofchannelsinterrogatedduringeachscan.Seepage20foradescriptionofscantimeforeach
scanningmethodandtheformulaforcalculatingpostprocesstime.
Connections Sensorsconnecttocontrollerusing5-conductorquick-disconnectcables(oneeachforemitterand
receiver),orderedseparately;seepage5foravailablelengths.UseonlyBannercables,whichincorporatea
“twistedpair”fornoiseimmunity.Cablesmeasure8.1mm(0.32")dia.andareshieldedandPVC-jacketed.
Conductorsare20gauge(0.9mm).Emitterandreceivercablesmaynotexceed75m(250')long,each.
Construction Aluminum,withblackanodizedfinish;acryliclenscover
3/4" beam spacing
3/4" beam spacing
Straight, Edge Modes:19.1mm(0.75")
Skip Mode:Multiplytheabovebythenumberof
skippedbeams,plus1
Interlaced Mode:12.7mm(0.5")*
Straight, Edge Modes:38.1mm(1.5")
Skip Mode:Multiplytheabovebythenumberof
skippedbeams,plus1
Interlaced Mode:25.4mm(1.0")*
Sensors < 4':0.6to6.1m(2'to20')
Sensors > 4':0.6to4.6m(2'to15')
Sensors < 4':0.9to17m(3'to55')
Sensors > 4':0.9to14m(3'to45')
3/4" beam spacing
12Vdc±2%,suppliedbycontroller
Emitter:0.10A@12Vdc
Receiver beam spacing:0.50A@12Vdc†
12Vdc±2%,suppliedbycontroller
Emitter:0.10A@12Vdc
Receiver beam spacing:0.75A@12Vdc†
Environmental Rating NEMA4,13(IP65)
Operating Conditions Temperature:-20°to+70°C(-4°to+158°F)
Maximum relative humidity:95%at50°C(non-condensing)
*Assumessensingisinthemiddle1/3ofsensingrange.
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Specifications
9
10.2 mm
(0.40")
L3
38.1 mm
Square
(1.50")
53.8 mm
(2.12")
2.5 mm
(0.10")
18.3 mm
(0.72")
*Distance X to
First Beam
L1
71 mm
(2.8")
R13 mm (0.5")
Minimum Bend
L2
Figure 2-1. Emitter and receiver dimensions
With mounting bracket flanges “in”With mounting bracket flanges “out”
*Distance X to First Beam
3/4" Beam Spacing: 42.9 mm (1.69")
3/8" Beam Spacing: 38.1 mm (1.50")
3/4" Beam Spacing (16 Beams/Foot)
Distance X: 42.9 mm (1.69")
3/8" Beam Spacing (32 Beams/Foot)
Distance X: 38.1 mm (1.50") Housing Length Distance Between Bracket Holes
Models Beams Models Beams L1 L2 L3
BMEL616AEmitter
BMRL616A Receiver
8
8
BMEL632AEmitter
BMRL632A Receiver
16
16
201mm
(7.9")
234mm
(9.2")
177mm
(7.0")
BMEL1216AEmitter
BMRL1216A Receiver
16
16
BMEL1232AEmitter
BMRL1232A Receiver
32
32
356mm
(14.0")
390mm
(15.4")
333mm
(13.1")
BMEL1816AEmitter
BMRL1816A Receiver
24
24
BMEL1832AEmitter
BMRL1832A Receiver
48
48
505mm
(19.9")
539mm
(21.2")
482mm
(19.0")
BMEL2416AEmitter
BMRL2416A Receiver
32
32
BMEL2432AEmitter
BMRL2432A Receiver
64
64
659mm
(26.0")
693mm
(27.3")
636mm
(25.1")
BMEL3016AEmitter
BMRL3016A Receiver
40
40
BMEL3032AEmitter
BMRL3032A Receiver
80
80
810mm
(31.9")
844mm
(33.2")
787mm
(31.0")
BMEL3616AEmitter
BMRL3616A Receiver
48
48
BMEL3632AEmitter
BMRL3632A Receiver
96
96
963mm
(37.9")
997mm
(39.3")
941mm
(37.0")
BMEL4216AEmitter
BMRL4216A Receiver
56
56
BMEL4232AEmitter
BMRL4232A Receiver
112
112
1115mm
(43.9")
1148mm
(45.2")
1091mm
(43.0")
BMEL4816AEmitter
BMRL4816A Receiver
64
64
BMEL4832AEmitter
BMRL4832A Receiver
128
128
1267mm
(49.9")
1301mm
(51.2")
1244mm
(49.0")
BMEL6016AEmitter
BMRL6016A Receiver
80
80
BMEL6032AEmitter
BMRL6032A Receiver
160
160
1572mm
(61.9")
1606mm
(63.2")
1549mm
(61.0")
BMEL7216AEmitter
BMRL7216A Receiver
96
96
BMEL7232AEmitter
BMRL7232A Receiver
192
192
1877mm
(73.9")
1910mm
(75.2")
1853mm
(73.0")
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Specifications
10
2.2 Control Module with DeviceNet Specifications
DeviceNet Configurations Vendor code: 12(BannerCorp.)
Device type: 110
Product code: 1(MACNXDN-1)
2(MACPXDN-1)
Connection types supported: ExplicitMessage,Poll,COS
Network address: 0-63(networkconfigured)
Baud rate supported: 125K,250K,500K(networkconfigured)
Output Configurations MACNXDN-1:TwoPNPdiscrete(switched)
MACPXDN-1:TwoNPNdiscrete(switched)
Power Requirements* Controller, emitter and receiver:16to30Vdc@1.2Amax.(typical:0.5A@16Vdc)
Inputs Sensor input: Emitterandreceiverwireinparalleltofiveterminals.
Gate input:Opticallyisolated,requires10to30Vdc(7.5kΩimpedance)forgatesignal
Discrete (Switched) Outputs NPN outputs: OpencollectorNPNtransistorratedat30Vdcmax.,150mAmax.
PNP outputs:OpencollectorPNPtransistorratedat30Vdcmax.,150mAmax.
All discrete outputs:
OFF-state leakage current:<10µA@30Vdc
ON-state saturation voltage:<1V@10mAand<1.5V@150mA
System Programming ViaDeviceNetinterfaceandsuppliedEDSfiles.
System Status Indicators Output (steady red):Output#1energized.
Alarm (flashing red):Output#2energized.
Gate (steady red):Gateinputstatus.
Alignment (steady green): Properemitter/receiveralignmentandaclear,unblockedlightscreen(ONwhen
greenorgreen/yellowreceiverLEDsareON.
Diag 1 (green), Diag 2 (red), Diag 3 (red): UsedincombinationtodisplaySystemstatus;seeChapter5,
SystemDiagnosticsformoreinformation.
Network Status Indicator Bi-colored(red/green)LEDvisibleonthecontrolmodulefrontpanelindicatesnetworkstatus:
Steady Green: On-line,connectedtomaster
Flashing Green: On-line,addressandbaudrateOK
Steady Red: Criticalnetworkfaultorduplicatenodeaddressdetected
Flashing Red: Connectiontimeout
OFF: Nonetworkpoweroroff-line
Construction Polycarbonatehousing;mountstoflatsurfaceordirectlyonto35-mmDINrail
Environmental Rating NEMA1(IP20)
Operating Conditions Temperature: -20°to+70°C(-4°to158°F)
Maximum relative humidity:95%@50°C(non-condensing)
DeviceNet Power* 11to25Vdc-suppliedbyDeviceNetBUSNetwork
*Application Note ThecontrollermustbepoweredupbeforetheDeviceNetconnectionineverypower-upsituation
forproperoperation
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Specifications
11
81.0 mm
(3.19")
115.0 mm
(4.53")
106.0 mm
(4.17")
35.0 mm
(1.38")
DIN mounting slot
Slot for M3.5 screws (2)
5.5 mm
(0.22")
69.0 mm
(2.72 ")
5.0 mm
(0.20")
96.0 mm
(3.78")
Figure 2-2. Control module dimensions
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Specifications
12
*Measurementmoderesults:
Beam numberifmeasurementmodeisFBB,FBM,LBB,orLBM
Number of beamsifmeasurementmodeisTBB,TBM,CBB,orCBM
2.3 DeviceNet Attribute Information
I/O Data Attribute Format, Poll and COS
I/O Data Mapping
BYTE BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
0XSystemStatus
Bit2
SystemStatus
Bit1
SystemStatus
Bit0 X X Alignment Blocked
Alignment
OK
1LSB–MeasurementMode1*
2MSB–MeasurementMode1*
3LSB–MeasurementMode2*
4MSB–MeasurementMode2*
5Reserved(always0)
I/O Message Types Polled COS
ProducedDataSize 8bytes 8bytes
ConsumedDataSize 0bytes 0bytes
SYSTEM STATUS: (BYTE 0, NIBBLE 2):
1 EEPROMerror
2Controllererror
3 ROMerror
4 Normal
5 Emittererror
6 Receivererror
7Emitter/receiver
mismatch
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Specifications
13
Analysis Mode 1 (FBB)
FBB: FirstBeamBlocked
FBM: FirstBeamMade
LBB: LastBeamMade
LBM: LastBeamMade
TBB: TotalBeamsBlocked
TBM: TotalBeamsMade
CBB: ContiguousBeamsBlocked
CBM: ContiguousBeamsMade
Disabled
Analysis Mode 2 (Disabled)
FBB: FirstBeamBlocked
FBM: FirstBeamMade
LBB: LastBeamMade
LBM: LastBeamMade
TBB: TotalBeamsBlocked
TBM: TotalBeamsMade
CBB: ContiguousBeamsBlocked
CBM: ContiguousBeamsMade
Disabled
Scan Control Modes (Continuous)
ContinuousScanning
GateMode
HostMode
Scanning Methods (Straight)
StraightScan
SkipScan1
SkipScan2
SkipScan3
SkipScan4
SkipScan5
SkipScan6
SkipScan7
Interlaced(Dither)Scan
EdgeScan
Output 1 Analysis Mode (Disabled)
Disabled
AnalysisMode1
AnalysisMode2
Output 1 Set Point – Low (1)
1-384
Output 1 Set Point – High (1)
1-384
Output 1 Hysteresis – Low (0)
0-385
Output 1 Hysteresis – High (2)
0-385
Output 1 Invert (No)
No
Yes
Output 2 Analysis Mode (Disabled)
Trigger
Alarm
Disabled
AnalysisMode1
AnalysisMode2
Single Scan (No)
No
Yes
Output 2 Set Point – Low (1)
1-384
Output 2 Set Point – High (1)
1-384
Output 2 Hysteresis – Low (0)
0-385
Output 2 Hysteresis – High (2)
0-385
Output 2 Invert (No)
No
Yes
Measurement Mode 1 Result (0)
Measurement Mode 2 Result (0)
Output 1 & 2 Scan Number (1)
1-9
Alignment Status (Unknown)
0: Made
1: Broken
Number of Beams (0)
0-384
Beam Status (0)
0: Brokenornotused
1: Made
Blanking Beams (0)
0: Notblanked
1: Blanked
Number of Emitter Beams (0)
0-192
Number of Receiver Beams (0)
0-192
Status of Controller (Unknown)
Unknown
EEPROMerror
Controllererror
ROMerror
Normal
Emittererror
Receivererror
Emitter/receivermismatch
(Items in parentheses are Factory Default Settings)
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Installation and Mechanical Alignment
14
3. Installation and Mechanical Alignment
3.1 Emitter and Receiver Mounting
BannerMINI-ARRAYemittersandreceiversaresmall,lightweight,andeasytomount;themountingbrackets(supplied)allow±30
degreesrotation.
Fromacommonpointofreference,makemeasurementstopositiontheemitterandreceiverinthesameplanewiththeirmidpoints
directlyoppositeeachother.MounttheemitterandreceiverbracketsusingtheM4x0.7x14mmboltsandassociatedmounting
hardware(allsupplied).SeeFigure3-1.
Althoughtheinternalcircuitryoftheemitterandreceivercanwithstandheavyimpulseforces,vibrationisolatorscanbeused
insteadoftheM4boltstodampenimpulseforcesandpreventpossibledamagefromresonantvibrationoftheemitterorreceiver
assembly.TwodifferentAnti-VibrationMountingKitsareavailablefromBannerasaccessories.
Figure 3-1. A-GAGE MINI-ARRAY emitter and receiver mounting hardware
Emitter
or
Receiver
Mounting
Mounting
Bracket
Surface
M4
Nut (4)
Washer (2)
with Compression
Slotted Hex Head
M4 x 10 mm
Bracket
Mounting
Nut
Washer
M4 x 14 mm
Screw with Flat
Washer
Compression
Washer (4)
Torque to
12 in. lbs.
(1.3 N-m)
3.0 Installation and Alignment
3.1 Emitter and Receiver Mounting
Banner MINI-ARRAY emitters and receivers are small, lightweight, and easy to mount; the mounting brackets (supplied) allow
±30 degrees rotation.
From a common point of reference, make measurements to position the emitter and receiver in the same plane with their
midpoints directly opposite each other. Mount the emitter and receiver brackets using the M4 x 0.7 x 14 mm bolts and
associated mounting hardware (all supplied). See Figure 3-1.
Although the internal circuitry of the emitter and receiver can withstand heavy impulse forces, vibration isolators can be used
instead of the M4 bolts to dampen impulse forces and prevent possible damage from resonant vibration of the emitter or
receiver assembly. Two different Anti-Vibration Mounting Kits are available from Banner as accessories.
P/N48955consistsof4anti-vibration
mounts(M4x0.7x9.5mm)and
8M4Kepsnuts.Thesemountsare
madefromBUNA-Nrubberandare
moreresistanttochemicalsandoils.
P/N12847consistsof4anti-vibration
mounts(M4x0.7x9.5mm)and
8M4Kepsnuts.Thesemountsare
madefromnaturalrubber,which
arelesschemicallyresistantthan
the48955mounts,buthavea
greatersheerforcespecathigher
temperature.
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Installation and Mechanical Alignment
15
Mounttheemitterandreceiverintheirbracketsandpositiontheredlensesofthetwo
unitssotheydirectlyfaceeachother.Theconnectorendsofbothsensorsmustpoint
inthesamedirection.Measurefromoneormorereferenceplanes(e.g.thebuilding
floor)tothesamepoint(s)ontheemitterandreceivertoverifytheirmechanical
alignment.Ifthesensorsarepositionedexactlyverticalorhorizontaltothefloor,a
carpenter’slevelisusefulforcheckingalignment.Astraightedgeorastringextended
betweenthesensorsalsohelpswithpositioning.Alsocheck“byeye”forline-of-sight
alignment.Makeanynecessaryfinalmechanicaladjustments,andhand-tightenthe
brackethardware.SeeSection4.2forfurtherinformationonalignment.
3.2 Control Module Mounting
ThecontrolmodulemustbeinstalledinsideanenclosurewhichhasaNEMA(orIEC)
ratingsuitablefortheoperatingenvironment.
MountingdimensionsforthecontrollerareshowninFigure2-2,onpage11.The
controlmoduleissuppliedwithM3.5hardwarefordirectmountingtoasurface,orit
maymountdirectlyontostandard35mmDINrail.
NON-QD EndQD End
Min. R.
Full R (4)
4.8 mm (2)
(0.19")
38.1 mm
(1.50")
6.4 mm R
(0.25")
44.5 mm
(1.75")
6.4 mm
(0.25")
57.2 mm
(2.25")
3.8 mm
(0.15")
10.2 mm (2)
(0.40")
ø30.5 mm
(1.20")
34.8 mm
(1.37")
11.9 mm
(0.47")
Slots have clearance
for M4 bolts (supplied)
and allow ±30°rotation
ø13.2 mm
(0.52")
ø6.8 mm (2)
(0.27")
3.0 mm
(0.12") 24.6 mm
(0.97")
53.8 mm
(2.12")
Material: Cold Rolled Steel
Finish: Black, Zinc Plated
Chromate Dip
Figure 3-2. A-GAGE MINI-ARRAY emitter and receiver mounting bracket dimensions
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Installation and Mechanical Alignment
16
3.3 Hookups
ConnectionsaremadetotheMACNXDN-1andMACPXDN-1controlmodulesvia20
wiringterminalslocatedalongthefrontsurfaceofthemodule.RefertoFigures3-3
and3-4fortheappropriatehookupinformation.
NOTE:ThecontrollermustbepoweredupbeforetheDeviceNetconnectioninevery
power-upsituation,forproperoperation.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 D5 D4 D3 D2 D1
F1
V+
16 - 30V dc
1.2A MAX
EMITTER and
RECEIVER CABLES 10-30V dc
GATE
SIGNAL
OUTPUT 1
BROWN
V-
NC NC
+-
BLUE DRAIN WIRE BLACK WHITE
DEVICENET
CONNECTIONS
RED WHITE DRAIN WIRE BLUE BLACK
150mA
max.
ALARM
150mA
max.
Figure 3-3. MACNXDN-1 hookup (2 NPN discrete outputs)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 D5 D4 D3 D2 D1
F1
V+
16 - 30V dc
1.2A max.
EMITTER and
RECEIVER CABLES 10-30V dc
GATE
SIGNAL
OUTPUT 1
BROWN
V-
NC NC
+-
BLUE DRAIN WIRE BLACK WHITE
DEVICENET
CONNECTIONS
RED WHITE SHIELD BLUE BLACK
150mA
max.
ALARM
150mA
max.
Figure 3-4. MACPXDN-1 hookup (2 PNP discrete outputs)
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Installation and Mechanical Alignment
17
3.3.1 Emitter and Receiver Hookups
Emittersandreceiversconnecttogetherinparalleltoterminals#4through#8ofthe
controlmodule(identicalforbothcontrolmodulemodels).SeeFigures3-3and
3-4forwirecolorinformation.
3.3.2 Inputs
System Power: Connectasourceof16to30Vdc,ratedat1amporgreater,tocontrol
moduleterminals#1(+)and#2(-).Connectagoodearthgroundtoterminal#3to
provideelectricalandRFnoiseimmunitytotheSystem.
NOTE:Removepowerbeforemakingotherconnectionstothecontroller.
Gate Signal: Connectaswitchedsourceof10to30Vdctoterminals#11(+)and
#12(-)toprovideagatinginput(ifrequired).Thegatingvoltagetypicallyisswitched
bytheopen-collectoroutputtransistorofadcsensingdevice.Thegatesignalcontrols
scanningwhentheGateoptionisselected(seeSection4.4).
3.3.3 Outputs
Eachcontrolmodulehastwosolid-statediscreteoutputs,labeledOutput#1and
Alarm.Bothareratedat30Vdcmax.,150mAmax.TheyareeitherbothNPNorboth
Trim braided shield flush
with cable
Trim foil shield flush
with cable
Uninsulated
drain wire
Figure 3-5. Emitter and receiver cable
preparation
NOTE:The“drainwire”istheuninsulated
strandedwirewhichrunsbetweenthe
braidedshieldandthefoilshield.Thefoil
shieldandthebraidedshieldshouldbe
removedatthepointwherethewiresexit
thecable.
Control
Module
Output #1
(Terminal #9)
Output #2 (“Alarm”)
(Terminal #15)
MACNXDN-1
Figure3-3
NPNopen-collector
30Vdcmax.
150mAmax.
NPNopen-collector
30Vdcmax.
150mAmax.
MACPXDN-1
Figure3-4
PNPopen-collector
150mAmax.
PNPopen-collector
150mAmax.
PNP,dependingonthemodel.
Terminal
Wire
Color Function
D3 – Shield
D5 Red BusPower(+V)
D1 Black BusPower(-V)
D4 White Communications+
D2 Blue Communications-
D5 D4 D3 D2 D1
DEVICENET
CONNECTIONS
V+ V-
CAN_H CAN_L
SHIELD
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Control Module Configuration
18
3.3.4 DeviceNet Communication Hookups
4. Control Module Configuration
TheA-GAGEMINI-ARRAYcontrolmoduleiseasilyconfiguredusingthesuppliedEDS
fileandtheuser’sDeviceNetconfigurationtool.
4.1 Communications Setup
SeeSection3.3.4,page17forinformationonconnectingtheMINI-ARRAYcontrol
moduletotheDeviceNetnetwork.
4.2 System Alignment
Theemitter/receiverpairshaveawidefieldofviewandareeasytoalign.The
recommendeddistancebetweentheemitterandreceiverrangesfrom15"to72".
(Shortersensorseparationcanbeachieved;pleaseconsultfactoryfordetails.)The
AlignmentprocessshouldbeperformedatSysteminstallationandrepeatedeverytime
oneorbothofthesensorsismoved.
AlignmentstatusiscontinuouslydisplayedbythegreenLEDindicatorsonthereceiver
andthecontroller.Whenallunblankedbeamsareclear,andexcessgainofallbeamsis
atleast3x,thegreenAlignmentindicatorswillbeON.Whentheexcessgainofoneor
morebeamsdropstobetween3xand1x,thegreenAlignLEDwillremainON,butthe
yellowLEDalsowillcomeONtoindicateawarningofmarginalalignment.Seesection
3.1formoreinformationaboutsensoralignment.
MakesurethesensorshavebeenwiredasshowninSection3.3.Applypowertothe
controlmoduleviaterminals#1and#2(16to30Vdc).
4.3 Blanking
Ifamachinefixtureorotherequipmentwillcontinuouslyblockoneormorebeams,
theaffectedbeamchannelsmaybeblanked.TheBlankingoptioncausesthecontrol
moduletoignorethestatusofblankedbeamsformeasurementmodecalculations.For
example,ifamachinefixtureblocksoneormorebeamsduringSystemoperation,the
outputdatawillbeincorrect;ifbeamsblockedbythefixtureareblanked,theoutput
datawillbecorrect.BlankingcannotbeusedwithEdgeScanmode.
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Control Module Configuration
19
4.4 Control Mode Selection
Thecontrolmodedeterminesthemethodusedtocontrolscanningofthelightscreen
array.Choosefromthreescancontrolmodes:
• ContinuousScanmode(theFactorydefaultsetting),
• HostCommandmode,and
• Gatemode
In Continuous Scan Mode,thecontrolmodulebeginsanewscanassoonasit
updatestheoutputsfromthepreviousscan.Thisisthefastestscancontrolmethod;it
isusedwhencontinuousupdatingoftheoutputsisacceptable.
Host Modeallowstheuser,withaDeviceNetconnection,todirecttheMINI-ARRAY
Systemtoscanoncommand.
Gate ModeactivatesanopticallyisolatedexternalGateinputbetweenterminals11(+)
and12(-)ofthecontrolmodule.TheGateinputhasimpedanceof7.5kΩandaccepts
a10to30Vdcsignal.Adcdevicesuchasaphotoelectricsensororopticalencoder
typicallysuppliestheGateinput.Gateinputsignalsmustbegreaterthan100
microsecondsinduration;thetimebetweensuccessiveGateinputsmustbegreater
thantheminimumscantimeforthelightscreenarray(seesection4.5forscantime
information).
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

Control Module Configuration
20
4.5 Scanning Methods
Thecontrolmoduleoffersthechoiceofoneoffourscanningmethods:
• Straightscan
• Interlacedscan
• Edgescan
• Skipscan
Straight Scanisthedefaultmodeinwhichallbeamsarescannedinsequencefromthe
bottomend(cableend)tothetopendofthearray.Thisscanningmethodrequiresthe
longestscantimesandprovidesthesmallestobjectdetectionsize.
TocalculatescantimeforStraightScan,multiplythenumberofbeamsby55
microseconds,andaddpostprocesstime.
Interlaced Scanalternatesastraightscanwithaslanted-beamscantoimproveoptical
resolutionwithinthemiddleone-thirdofthescanningrange(seeFigure4-1).Aslanted-
beamscanbeginswithabeambetweenemitterchannel1andreceiverchannel2,then
betweenemitterchannel2andreceiverchannel3,andsoon.Thelastemitterchannel
beamstothelastreceiverchanneltocompletethescan.Afterthissequence,theemitter/
receiverpairperformsastandardstraight-acrossscan(emitterchannel1–receiver
channel1,andsoon).
TocalculatescantimeforInterlacedScan,doublethenumberofbeamsinthearray,
multiplyby55microseconds,andaddpostprocesstime.
Edge Scanisdesignedtospeedsensingresponsetime,bymeasuringorlocatingonly
oneedgeofanobject.Edgescanactivatesonlythebeamslocatednearthetopedgeof
anobjectinthelightscreen.(NOTE:“Topedge”referstotheedgeoftheobjectpassing
farthestfromthecabledendofthesensors.)Whenthearrayisclear,thesystemwill
executestraightscans.Edgescanbeginswhenablockedchannelisdetected.Eachscan
beginssixbeamspriortothelastbeamblockedduringthepreviousscan.Thescan
continuesfromthispointandmovesupwardtothefirstunblockedbeam,wherethescan
iscompleted.UseofEdgeScanmodelimitstheScanAnalysismodeselectiontoonly
LBB(LastBeamBlocked).EdgeScanrequiresthefollowingconfiguration:AnalysisMode
1–LLB;AnaylsisMode2–None;andallbeamsactive(noblanking).
ScantimeforEdgeScanmodewillvary,dependingonwhatsizeobjectsareinthearray
atagiventime.
Skip Scanspeedssensingresponsetimeattheexpenseofdecreasedsensingresolution.
SkipScanmodeallowsfromonetosevenbeamstobeskippedduringeachscan.For
example,withonebeamskipped,onlybeams1,3,5,7,etc.willbeinterrogated;with
twobeamsskipped,onlybeams1,4,7,10,etc.willbeinterrogated.SkipScanalsohas
somerestrictions:theobjectshouldprovideasolidobstruction,andthesizeofthe
objectwilldeterminethemaximumstepsize(thetargetobjectcannotbesmallerthan
thedistancebetweentwoconsecutivebeams).
TocalculatescantimeforSkipScan,firstdeterminehowmanybeamsarebeingused.(For
example,ifthearrayhas16beams,anditisconfiguredtoskip1beam,thenhalfthe
beams–8–areinuse.Ifthearrayisconfiguredtoskip3beams,theneveryfourthbeam
– atotalof4forthisarray–isinuse.)Multiplythenumberofbeamsby55microseconds,
andaddpostprocesstime.
Post Process Time
Postprocesstimeisdeterminedbythenumberofbeams“fired”inagivenscan,and
measuredinmilliseconds.Tocomputepostprocesstime,usethefollowingformula:
PPT*(inmilliseconds)=(BeamChannelsFired+ 10)x0.12ms+1ms
8
* ApproximateValue
Resolution is
increased in
the center
third of
the range
Figure 4-1. Interlaced Scan Mode improves
optical resolution in the middle
third of the scanning range.
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]
