Introduction
ImagePRO-II’s Dual Channel Output mode, available in the ImagePRO-II Dual Output unit,
allows for any selected input or Logo to be presented at two different output resolutions
simultaneously. For example, say your main presentation output is a projector running at
1920x1080p. With this mode enabled you could also send the output to a record deck
expecting NTSC. By assigning output connections to either Channel A or Channel B, the
channels can be independently configured for Output Resolution / Frame Rate, Area of
Interest, Effects or even Pan / Zoom settings, giving the operator maximum flexibility for a
given show configuration.
1. Getting Started
To get started, make sure you have an ImagePRO-II Dual Output unit (R900 683) or obtain
a Dual Channel Option Card kit (R900 68 ) to upgrade an existing ImagePRO-II unit If you
are not certain what type of unit you have contact your local Barco Sales Representative for
more information.
Next, confirm that Software Release 2.00 or higher is installed to enable and make use of
the Dual Channel feature.
2. Initial Setup
To enable Dual Channel Mode
1) Press the SETUP button on the front panel.
2) Select the SYSTEM menu.
3) Scroll to SYSTEM MODE and change the field to DUAL2K.
) Wait for the system to configure itself to use this mode.

26-0904001-00 Rev 00.00 8
Setting up the Output Connector Map
Now that Dual Channel mode is enable, select which output connectors will map to Output A
and which will map to Output B.
1) Within the SYSTEM menu, scroll to and select the OUTPUT CONNECTOR MAP
submenu
2) By default, all seven outputs of the ImagePRO-II will be mapped to Output A.
3) Scroll to the various connectors as required and change the field from A to B to
map that connector to Output B.
O U T C O N N E C T O R M A P
> O u t 1 ( D V I - D ) A
O u t 2 ( H D 1 5 ) B
O u t 3 ( H D M I ) A
O u t 4 ( D P ) A
O u t 5 ( S D I 1 ) A
O u t 6 ( S D I 2 ) B
O u t 7 ( C o p ) A

26-0904001-00 Rev 00.00 9
3. Output Configuration
Once the mode and connectors have been setup, specific configuration of the two outputs
can be performed.
Output Resolution
1) In the OUTPUT setup menu, the first two lines (labelled CHA and CHB) show the
current resolution and frame rate for each channel.
2) Select either of these menu items to change the output resolution / frame rate to
the desired choice.
Area of Interest
1) Select the AREA OF INTEREST submenu under OUTPUT.
2) The first field (labelled CHANNEL) allows the selection of A or B to allow
independent AOI adjustments for each output.
3) The same operation is also available under the LED SETUP  WALL SIZING (AOI)
submenu.
Output Timing Adjustment
1) Select the TIMING ADJUST submenu under OUTPUT.
2) The first field (labelled CHANNEL) allows the selection of A or B to allow
independent timing adjustments for each output.

26-0904001-00 Rev 00.00 10
Output Effects
1) Select the EFFECTS submenu under OUTPUT.
2) The first field (labelled CHANNEL) allows the selection of A, B or ALL to allow for
independent or simultaneous adjustments for each output.
Genlock
1) Select the GENLOCK submenu under OUTPUT.
2) The first field (CHA SOURCE) can be selected and will offer all the standard
Genlock source options (FREERUN, EXT or IN #).
3) The second field in the menu (CHB SOURCE) will default to LOCK TO A. With this
option, Channel B will stay locked to Channel A at all times, regardless of the
Genlock source selected for Channel A. If desired, this field can also be changed
to FREERUN in order to disable the locked association with Channel A.
) The H/V OFFSET submenu allows the selection of A or B to allow for the
independent adjustment of H and V Offset for each channel.
5) The current lock status for Channel A and B is displayed at the bottom of the
GENLOCK menu.
GENLOCK
> CHA Source Freerun
CHB Source Lock to A
H/V Offset >>

26-0904001-00 Rev 00.00 11
Save and Reset Output Configs
1) Within the SAVE CONFIG and RESET CONFIG submenus under OUTPUT, the first
field allows for the selection of A, B or ALL. Make the appropriate selection when
saving or resetting output configurations.
Pan / Zoom
1) Select the PAN/ZOOM button on the front panel of the ImagePRO-II.
2) The first field (labelled CHANNEL) allows the selection of A or B to allow
independent Pan and Zoom adjustments for each output channel.
3) The same operation is also available under the LED SETUP  IMAGE SIZING
submenu.
Logo Backup and Restore
1) Within the SETUP  LOGO menu the BACKUP LOGO and RESTORE LOGO
submenus have the CHANNEL selection for the first field. This allows for
independent backup or restore of logos for each channel.

26-0904001-00 Rev 00.00 12
4. General Operation
1) In addition to the input and output connectors provided in ImagePro-II, the
ImagePro-II Dual output unit provides a second SDI input (SDI 6) and associated
loop-through as well as a second SDI output (SDI 2 OUT).
2) When switching from Single mode to Dual2K mode, the user will be prompted to
take corrective action if the following items are not setup correctly. Until these
items are corrected, the unit will not be allowed to enter Dual2K mode.
a. ALL Inputs connected to the ImagePRO-II must not exceed the maximum
pixel rate of 165MHz.
b. Resolution/frame rates programmed for ALL input EDIDs must not exceed
the maximum pixel rate of 165MHz.
c. The current Output resolution/frame rate selection must not exceed
20 8x1200@60.
3) After the mode has been changed from Single mode to Dual2K mode, the
following will be true:
a. Channel A and Channel B are both configured to match the Single mode
configuration as defined prior to entering Dual2K mode.
b. All output connectors are assigned to Channel A.
c. A Logo saved in Single mode will be available for both Channel A and
Channel B.
d. Channel B Genlock will default to “Lock to A”
) When in Dual2K mode,
a. The maximum Output Resolution for each channel is 20 8x1200@60.
b. The maximum Logo Resolution is 20 8x1200.
c. Input maximum pixel rate can not exceed 165MHz
5) Source Transitions, Freeze and Logo captures will be done synchronously on
Channels A and B.
a. Note: When a Logo capture is performed, Channel A and B will perform a
freeze function simultaneously and the logo images will then be captured.
If the two output channels are not genlocked, it is possible that the image
frozen will be 1 frame apart between the two outputs.
6) When changing the mode from Dual2K mode to Single mode, the following will
happen:
a. The user will be prompted with a warning that Channel B settings will be
discarded if the SEL button is pushed to “Confirm”. Pressing the “ESC”
button will cancel this operation.
b. The single channel configuration will match Channel A as defined in
Dual2K mode, just prior to entering Single mode.
c. All output connectors are assigned to the Single channel.

26-0904001-00 Rev 00.00 13
5. Remote Command
The following commands have been updated as of software release 02.00.02.
ICH
Description: Input Channel Settings
Required parameters:
--con (connector)
--ch (channel)
--itype (input type), only for commands to DVI connector
Parameters:
--con (connector) : 0-5, see below for input connector numbers.
--ch (channel) : 0-1, input channel
--itype (input type) : 0 = digital, 1 = analog
--iwin : option to set input window
--hpos (Input Window H Position, pixels)
--vpos (Input Window V Position, pixels)
--hsize (Input Window H Size, pixels)
--vsize (Input Window V Size, pixels)
--mask : option to set the mask window
--left (Mask Left in percentage)
--right (Mask Right in percentage)
--top (Mask Top in percentage)
--bottom (Mask Bottom in percentage)
--at (aspect ratio type) : 0-6, see below for aspect ratio numbers
--ar (custom aspect ratio) : 0.25 - 10.00, custom aspect ratio. artype
must be set to 0
Examples:
ICH --con 3 --ch 0 --at 6 --ar 1.91
Update DP input, aspect ratio type to Custom, and custom aspect ratio to 1.91
ICH --con 0 --itype 0 --ch 0 --iwin --hpos 10
Update DVI (digital in) input, Input Window H Position to 10
ICH --con 1 --ch 0 --mask --left 5.10
Update HD-15 input, Mask Left by 5.10%
Query Format 1 (Aspect ratio): ICH --con (connector) --ch (channel) --?
Query Response 1 : Input Channel Aspect Ratio Setting in the following format
ICH --at (AR type) --ar (Custom AR)

26-0904001-00 Rev 00.00 14
Query Format 2 (Input window): ICH --con (connector) --ch (channel) --iwin --?
Query Response 2 : Input Channel Window Setting in the following format
ICH --hpos (H Position) --vpos (V Position) --hsize (H Size) --vsize (V Size)
Query Format 3 (Mask): ICH --con (connector) --ch (channel) --mask --?
Query Response 3 : Input Channel Mask Setting in the following format
ICH --left (Left) --right (Right) --top (Top) --bottom (Bottom)
Connectors:
0=DVI
1=HD15
2=HDMI
3=DP
=SDI1
5=SDI2 (available when Dual option mezzanine installed)
Aspect Ratio type
0=1:1
1=3:2
2= :3
3=5:
=16:10
5=16:9
6=Custom. Use --ar to specify actual aspect ratio
IMGR
Description: Input Manager Settings
Parameters:
--acq (acquire mode) : 0 = Off, 1 = On
--con (active connector) : 0-7, see below for connector numbers
--frz (freeze mode) : 0 = Off, 1 = On
--save (save input configuration)
--recall (recall input configuration)
--reset (reset input configuration)
Query Format: IMGR --?
Query Response: Input Manager Settings in the following format
IMGR --acq (acquire mode) --con (active connector) --frz (freeze mode)
Connectors:
0=DVI
1=HD15
2=HDMI
3=DP
=SDI1
5=SDI2 (available when Dual option mezzanine installed)
6=Logo
7=Black

26-0904001-00 Rev 00.00 15
STMGR
Description: Logo Management Settings
Parameters:
--deleteall : Delete logo
--eraseall : Erase logo (destructive)
--captureall : Capture logo
--infoall : Logo H/V information
Query Format: n/a
OCON
Description: Output Connector Settings
Required parameters:
--ocon (output connector) , for output connectors
Parameters:
--ocon (output connector) : 0-6, see below for connector numbers.
--ch (channel select) : 0-1
--syncpol (sync polarity) : 0=+H+V, 1=+H-V, 2=-H+V, 3=-H-V
--bitdepth (color bit depth) : 0-6bit, 1-8bit, 2-10bit, 3-12bit
--csp (color space) : 0-RGB, 1-SMPTE
Query Format: OCON --ocon (connector) [--qall|--qsettings|--qstatus]
Query Response: Output Connector Settings in XML format
Output Connectors:
0=DVI
1=HD15
2=HDMI
3=DP
=SDI1
5=SDI2 (available when Dual option mezzanine installed)
6=BNC Composite

26-0904001-00 Rev 00.00 16
SYSMGR
Description: System Manager Settings
Parameters:
--blkinv (Black Invalid Mode) : 0=OFF, 1=ON
--vfd (VFD Brightness) : 0..6
--opmode (Operation Mode) : 0=SingleChannel, 1=DualChannel,
2=3DProcessing
Note: For the new operating take full effect, you must save settings and reboot the
unit.
--conmode (Encore Connect Mode)
: 0=OFF, 1=ON
--unitid (Encore Unit ID)
: 1..32
--encoreip (Encore IP address) : xxx.xxx.xxx.xxx
Query Format: SYSMGR --?
Query Response: System Manager Settings in the following format
SYSMGR --blkinv (Black Invalid Mode) --vfd (VFD Brightness) --opmode
(Operation Mode) --conmode (Encore Connect Mode) --unitid (Encore Unit ID)
--encoreip (Encore IP Address)
UINPUT
Description: Input Settings
Required parameters:
--con (connector)
--itype (input type), for commands to DVI input settings
Parameters:
--con (connector) : [0..5], see below for connector numbers.
--itype (input type) : 0 = digital, 1 = analog
--deint (deinterlacing type) : 0 = MotionAdaptive, 1 = FieldToFrame
--motion (motion threshold) : [0..15]
Examples:
UINPUT --con 0 --itype 0 --deint 0
(Update DVI (digital in) input, deinterlacing type to Motion Adaptive
Query Format: UINPUT --con (connector) --?
Query Response: Input Settings in the following format
UINPUT --deint (deinterlacing type) --motion (motion threshold)
Connectors:
0=DVI
1=HD15
2=HDMI
3=DP
=SDI1
5=SDI2 (available when Dual option mezzanine installed)

26-0904001-00 Rev 00.00 17
VFS
Description: Video Format Settings
Required parameters:
--con (connector) , for input video format
--och (output channel) , for output video format
--itype (input type) , for commands to DVI Input settings
Parameters:
--con (connector) : 0-5, see below for input connector numbers.
--och (output channel) : 0-1, for output commands
--itype (input type) : 0 = digital, 1 = analog
--new (new format name) : Use "" around the format name. Use
VFSTDLIST to get the standard format names. This command option
changes the format to "new format name".
--enum (new format enum) : Use VFSTDLIST to get the video format
numbers.
--reset (reset to default timing based from format table)
--name (format name) :This command option simply renames the
current format.
--hsync (horizontal sync)
--hact (horizontal active)
--hfp (horizontal front porch)
--hpos (horizontal position)
--htot (horizontal total)
--vsync (vertical sync)
--vact (vertical active)
--vfp (vertical front porch)
--vpos (vertical position)
--vtot (vertical total)
Connectors:
0=DVI
1=HD15
2=HDMI
3=DP
=SDI1
5=SDI2 (available when Dual option mezzanine installed)
Query Format: VFS --?
Query Response: Video Format settings in the following format:
VFS --name "format name" --hsync (hsync) --hact (hact) --hfp (hfp) --htot
(htot) --vsync (vsync) --vact (vact) --vfp (vfp) --vtot (vtot)
VIDCOL
Description: Video Color Settings for Input / Output
Required parameters:
--con (connector) , for input video color
--och (output channel) , for output video color
--itype (input type) , for commands to DVI input settings

26-0904001-00 Rev 00.00 18
Parameters:
--con (connector) : 0-
5, see below for connector numbers.
--och (output channel) : 0-1
--itype (input type) : 0 = digital, 1 = analog
--brt (overall brightness) : [50..150]
--cbrt (individual brightness) : [50..150]
--cnt (overall contrast) : [50..150]
--ccnt (individual contrast) : [50..150]
--col (color) (must be supplied for --cbrt or --ccnt parameters)
0 = all color
1 = red
2 = green
3 = blue
--sat (saturation) : [0..125]
--hue (hue) : [-90..90]
--cinv (color invert) : 0 = Normal, 1 = Inverted Color
--csp (colorspace) : 0 = RGB, 1 = YUV
--gamma (gamma) : 0.3 - 3.0
--mono (monochrome) : 0 = Normal, 1 = Monochrome
Query Format 1 (Input): VIDCOL --con (connector) --?
Query Response 1 : Video Color Settings in the following format
VIDCOL --brt (ovr bright) --cbrt (R bright) (G bright) (b bright) --cnt (ovr
contr) --ccnt (R contr) (G contr) (B contr)
--sat (saturation) --hue (hue) --cinv (invert) --csp (colorspace) --gamma
(gamma) --mono (monochrome)
Query Format 2 (Output): VIDCOL --och (output channel) --?
Query Response 1 : Video Color Settings in the following format
VIDCOL --brt (ovr bright) --cbrt (R bright) (G bright) (b bright) --cnt (ovr
contr) --ccnt (R contr) (G contr) (B contr)
--sat (saturation) --hue (hue) --cinv (invert) --csp (colorspace) --gamma
(gamma) --mono (monochrome)
Connectors:
0=DVI
1=HD15
2=HDMI
3=DP
=SDI1
5=SDI2 (available when Dual option mezzanine installed)
VIEW
Description: View Settings
Required parameters:
--con (connector)
--ch (channel) , required for --percent or --pixel parameters
not required for --units or --save or --recall or --reset
Parameters:
--con (connector) :0-5, see below for input connector numbers.

26-0904001-00 Rev 00.00 19
--ch (channel) :0-1, input channel
--units (units) :0 = percent, 1 = pixel
--percent :if values are given in percent, See PANZOOM --help for
parameter details
--pixel :if values are given in pixel, See RECT --help for parameter
details
--save (save view settings)
--recall (recall view settings)
--reset (reset view settings)
Query Format 1 (Unit): VIEW --con (connector) --ch (channel) --?
Query Response 1: View Settings in the following format
VIEW --unit (units)
Query Format 2 (percent values): VIEW --con (connector) --ch (channel) --percent --
?
Query Response 1: View Settings in the following format
VIEW --hpos (h pos) --vpos (v pos) --hsize (h size) --vsize (v size)
Query Format 3 (pixel values): VIEW --con (connector) --ch (channel) --pixel --?
Query Response 1: View Settings in the following format
VIEW --hpos (h pos) --vpos (v pos) --hsize (h size) --vsize (v size)
Connectors:
0=DVI
1=D15
2=HDMI
3=DP
=SDI1
5=SDI2 (available when Dual option mezzanine installed)
VIDREF
Description: Video Sync Reference Settings
Command Format: VIDREF --hoffset1 (h offsetA) --voffset1 (v offsetA)
--hoffset2 (h offsetB) --voffset2 (v offsetB)
--src (source A) --srcb (source B)
Parameters: --hoffset1 (Chan A h offset) : (-HTotal/2)...(HTotal/2)
--voffset1 (Chan A v offset) : (-VTotal/2)...(VTotal/2)
--hoffset2 (Chan B h offset) : (-HTotal/2)...(HTotal/2)
--voffset2 (Chan B v offset) : (-VTotal/2)...(VTotal/2)
--src (Chan A lock source) : 0-freerun, 1-ext sync, 2-DVI, 3-HD15
-HDMI, 5-DP, 6-SDI1, 7-SDI2
--srcb (Chan B lock source) : 0-freerun, 1-Channel A
Query Format: VIDREF [--qall|--qsettings|--qstatus]
Query Response: Video Reference settings in XML format
