DP-2000
Using the new 0.98 inch DLP Cinema® Chip from
Texas Instruments, Barco introduces the DP-2000, a
new Barco digital cinema platform projector for large
and mid-market venues. The DP-2000 delivers remark-
able brightness without sacrificing resolution, modu-
larity, serviceability or overall system flexibility. The
DP-2000 is suitable for a wide range of screens up to
20m and also is the most cost-effective 3D projector on
the market today.
128844 - Leaflets.indd 3 23-02-2007 10:21:51

Barco nv
Media & Entertainment Division
Noordlaan 5, 8520 Kuurne, Belgium
T [phone] - F [phone]
email: [e-mail]
11101 Trade Center Drive,
Rancho Cordova, CA 95670, USA
T [phone] - F [phone]
www.barco.com
Technical specifications
Digital Micro Mirror devices 3 x 0.98” DC2K dark metal devices
Native resolution 2048 x 1080
Housing hermetically sealed DMD’s and optical assembly
Pedestal universal pedestal (optional)
Lamps 1.5kW - 4kW Xenon lamp size
Lamp power 1.5kW - 4kW
Screen width (screen gain 1:8) @14ftL * 20m - 65ft
Screen width (screen gain 1:3) @14ftL * 17m - 56ft
(*) = ± 10 variation possible between units
Contrast 2000:1
Digital video inputs 2 x SMPTE 292M inputs
2 x DVI input
both selectable as single and dual link
Prime lenses 1.6-2.5
1.75-2.4
1.95-3.2
Projector diagnostics via PC touch panel
via Communicator control software
via SNMP agent
Power requirements 220V
18.000 BTU / hr (with 4kW lamp)
Dimensions projector:
505(H) x 689(W) x 1018(D) mm
19.9(H) x 27.1(W) x 40.0(D) inch
NB.: min. 5 cm of air inlet spacing required
at the bottom of projector
Weight projector: 90kg (199lbs)
Max. ambient 35°C / 95°F
Options CLO-constant light output
ACS-2048
SNMP agent
motorized/memorized lens focus, zoom & shift
automatic XYZ lamp alignment
Order information R9004442
R599148 © 2007 Barco
Technical specifications are subject to change without prior notice
