Barco iD H250 User manual

Barco iD H250/500
Owners manual
R9010520
R9010570
R59770079/01
23/07/2007

Product revision
Firmware: V1.20
Barco nv Presentations
Noordlaan 5, 8520 Kuurne
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Visit us at the web: www.barco.com
PrintedinBelgium

Changes
Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war-
ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the
program(s) described in this publication at any time without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the information in this
publication; these changes are incorporated in new editions of this publication.
Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be recorded, transmitted or
stored in a retrieval system without the prior written consent of Barco.
eCos
The software in this product uses eCos, the Embedded Configurable Operating System.
This is the license for eCos:
Copyright (C) 1998, 1999, 2000, 2001, 2002, 2003 Red Hat, Inc.
Copyright (C) 2002, 2003 John Dallaway
Copyright (C) 2002, 2003 Nick Garnett
Copyright (C) 2002, 2003 Jonathan Larmour
Copyright (C) 2002, 2003 Andrew Lunn
Copyright (C) 2002, 2003 Gary Thomas
Copyright (C) 2002, 2003 Bart Veer
eCos is free software; you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the Free
Software Foundation; either version 2 or (at your option) any later version.
eCos is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABIL-
ITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details.
You should have received a copy of the GNU General Public License along with eCos; if not, write to the Free Software Foundation, Inc.,
59 Temple Place, Suite 330, Boston, MA 02111-1307 USA.
As a special exception, if other files instantiate templates or use macros or inline functions from this file, or you compile this file and link it
with other works to produce a work based on this file, this file does not by itself cause the resulting work to be covered by the GNU General
Public License. However the source code for this file must still be made available in accordance with section (3) of the GNU General Public
License.
This exception does not invalidate any other reasons why a work based on this file might be covered by the GNU General Public License.
The eCos source used to build the software used in the Barco iCon is available on request from Barco.
EN55022/CISPR22 Class A ITE (Information Technology Equipment)
Class A ITE is a category of all other ITE which satisfies the class A ITE limits but not the class B ITE limits. Such equipment should not
be restricted in its sale but the following warning shall be included in the instructions for use:
Warning : This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.
Guarantee and Compensation
Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee. On receipt, the purchaser
must immediately inspect all delivered goods for damage incurred during transport, as well as for material and manufacturing faults Barco
must be informed immediately in writing of any complaints.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning,
at latest 30 days after the transfer of risks. In the event of justified notice of complaint, Barco can repair the fault or provide a replacement
at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a
reduction in the purchase price or cancellation of the contract. All other claims, in particular those relating to compensation for direct or
indirect damage, and also damage attributed to the operation of software as well as to other services provided by Barco, being a component
of the system or independent service, will be deemed invalid provided the damage is not proven to be attributed to the absence of properties
guaranteed in writing or due to the intent or gross negligence or part of Barco.

If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly,
in particular if the systems are commissioned operated incorrectly or if, after the transfer of risks, the goods are subject to influences not
agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid. Not included in the guarantee coverage are
system failures which are attributed to programs or special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear as
well as normal maintenance are not subject to the guarantee provided by Barco either.
The environmental conditions as well as the servicing and maintenance regulations specified in the this manual must be complied with by
the customer.
Trademarks
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders.
All brand and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for
the products or their manufactures.

Table of contents
TABLE OF CONTENTS
1. Packaging............................................................................................................ 3
1.1 Unpacking ............................................................................................................................ 3
2. Installation guidelines............................................................................................. 5
2.1 Safety warnings....................................................................................................................... 5
2.2 Installation guidelines ................................................................................................................ 5
3. Installation........................................................................................................... 7
3.1 Battery installation in the RCU....................................................................................................... 8
3.2 Lens installation . . .................................................................................................................... 8
3.3 Removing the lens.................................................................................................................... 9
3.4 Lens range . ........................................................................................................................... 9
3.5 Lens Formulas . . . . ...................................................................................................................10
3.6 Projector configuration ..............................................................................................................10
3.7 Positioning the projector............................................................................................................. 11
4. Connections........................................................................................................15
4.1 Power connection ...................................................................................................................15
4.2 Signal connections . . . ...............................................................................................................15
4.2.1 The input section..............................................................................................................15
4.2.2 Connecting a Composite video signal. .. .....................................................................................17
4.2.3 Connecting an S-Video signal ................................................................................................17
4.2.4 Connecting an RGB signal . . . ................................................................................................17
4.2.5 Connecting a Component Video signal . .....................................................................................18
4.2.6 Connecting a DVI signal . . ....................................................................................................19
4.2.7 Connecting a computer signal . . . ............................................................................................20
4.2.8 The DVI output................................................................................................................ 20
4.3 Communication connections . . . . ....................................................................................................21
4.3.1 RS232/RS422 Connections . . ................................................................................................22
4.3.2 Ethernet Connections . . . . . ....................................................................................................22
5. Setup ................................................................................................................25
5.1 RCU & Local keypad ................................................................................................................ 25
5.2 Terminology overview ...............................................................................................................27
5.3 Switching on .........................................................................................................................28
5.4 Setting up the RCU address . . . . ....................................................................................................29
5.5 Setting up the projector address (only if necessary) . . .............................................................................30
5.6 Setting up the orientation ........................................................................................................... 31
5.7 Adjusting the lens.................................................................................................................... 31
5.8 Setup the baudrate for serial communication. . .....................................................................................33
5.9 Network settings.....................................................................................................................34
5.10 Preferences..........................................................................................................................35
5.10.1 Language setting. . . ...........................................................................................................35
5.10.2 Automatic startup ............................................................................................................. 36
6. Getting started.....................................................................................................39
6.1 Start up ..............................................................................................................................39
6.2 Selecting a source................................................................................................................... 39
6.3 Adjusting the image .................................................................................................................39
7. Advanced ...........................................................................................................41
7.1 The OSD Menu ..................................................................................................................... 41
7.2 Using the Dialog boxes..............................................................................................................42
7.3 Source selection.....................................................................................................................43
7.3.1 Source selection ..............................................................................................................43
7.3.2 Composite video .............................................................................................................43
7.3.3 S-Video........................................................................................................................44
7.3.4 RGB-YUV .....................................................................................................................44
7.3.5 PC ............................................................................................................................. 45
7.3.6 DVI ............................................................................................................................45
7.4 General ..............................................................................................................................46
7.4.1 Pause..........................................................................................................................46
7.4.2 Freeze......................................................................................................................... 47
7.4.3 Identification...................................................................................................................47
7.5 Image ................................................................................................................................48
7.5.1 Image settings ................................................................................................................49
7.5.1.1 Setting the Contrast ...................................................................................................49
7.5.1.2 Setting the Brightness..................................................................................................49
7.5.1.3 Color....................................................................................................................50
7.5.1.4 Tint (NTSC video signals only).........................................................................................50
7.5.1.5 Sharpness . . . ...........................................................................................................50
7.5.1.6 Gamma ................................................................................................................51
7.5.1.7 Phase (RGB signals only)..............................................................................................51
R59770079 BARCO ID H250/500 23/07/2007 1

Table of contents
7.5.1.8 Noise Reduction (only for video signals) . .............................................................................52
7.5.2 Aspect ratio ................................................................................................................... 53
7.5.3 Color temperature.............................................................................................................56
7.5.4 Film mode detection (video only).............................................................................................57
7.5.5 Input balance. . . ...............................................................................................................58
7.5.6 Automatic gain control (AGC) ................................................................................................61
7.5.7 Manual gain control ...........................................................................................................62
7.6 Lamp management . . . ...............................................................................................................62
7.6.1 Runtimes .....................................................................................................................62
7.6.2 Lamp mode ...................................................................................................................63
7.6.3 History.........................................................................................................................65
7.6.4 Reset lamp Runtime ..........................................................................................................65
7.6.5 Clear lamp error...............................................................................................................66
7.6.6 Lamp runtime warning........................................................................................................67
7.7 Image files ...........................................................................................................................68
7.7.1 Introduction to Image files .................................................................................................... 68
7.7.2 Load file . . . . ...................................................................................................................69
7.7.3 Forced file load................................................................................................................ 70
7.7.4 Auto Image....................................................................................................................71
7.7.5 Edit file ........................................................................................................................72
7.7.6 Save as (create a custom file)................................................................................................74
7.7.7 Rename file ...................................................................................................................74
7.7.8 Copy........................................................................................................................... 75
7.7.9 Delete .........................................................................................................................76
7.8 Display setup ........................................................................................................................77
7.8.1 Dynacolor™................................................................................................................... 77
7.8.2 Brilliant ColorTM mode ........................................................................................................86
7.8.3 Full screen synchronous representation .....................................................................................87
7.8.4 Text box .......................................................................................................................87
7.8.5 Menu bar position............................................................................................................. 88
7.8.6 Status bar position............................................................................................................88
7.8.7 Sliderbox position.............................................................................................................89
7.8.8 Softedge. . . . ...................................................................................................................90
7.8.8.1 Softedge Border . . . .....................................................................................................90
7.8.8.2 Black level ..............................................................................................................91
8. Maintenance........................................................................................................93
8.1 Cleaning the lens . ...................................................................................................................93
9. Image files ..........................................................................................................95
9.1 Image files ...........................................................................................................................95
10. Troubleshooting...................................................................................................99
10.1 Using the OSD.......................................................................................................................99
Index.................................................................................................................... 101
2R59770079 BARCO ID H250/500 23/07/2007

1. Packaging
1. PACKAGING
1.1 Unpacking
CEE7
European power plug to connect the power cord to the wall outlet.
ANSI 73.11
American power plug to connect the power cord to the wall outlet.
Content
• 1 projector (weight ± 14 kg or 31 lbs)
• 1 remote control unit RCU + 2 batteries.
• 2 power cables with outlet plug type CEE7 and ANSI 73.11.
• 1 owners manual
• 1 safety manual
• 1 CDROM (containing manuals)
Form
The projector is packed in a carton box. To provide protection during transportation, the projector is surrounded with foam. The
package is secured with banding and fastening clips.
R824562
R824561
R824518
(+ cable basket R72440
8
R825784
Projector
Image 1-1
Lens packaging
The Lens is supplied as an individual item.
Thelensispackedinacartonbox.
Save the original shipping cardboard and packing material, they will be necessary if you ever have to transport
the lens.
CAUTION:Never transport the projector with the lens mounted on it !
Always remove the lens before transporting the projector.
R59770079 BARCO ID H250/500 23/07/2007 3

1. Packaging
How to unpack the projector
1. Release the cord straps.
PULL
TO OPE
Image 1-2
2. Remove the assembly from the pallet
3. Remove the cardboard cover
4. Remove the large cardboard
5. Remove the 8 foam parts
6. Loosen and remove the 3 screws spacers fixing the projector to the wooden board
7. Remove the projector from the board
Save the original shipping carton and packing material, they will be necessary if you ever have to ship your
projector. For maximum protection, repack your projector as it was originally packed at the factory.
4R59770079 BARCO ID H250/500 23/07/2007

2. Installation guidelines
2. INSTALLATION GUIDELINES
Overview
• Safety warnings
• Installation guidelines
2.1 Safety warnings
WARNING:Before installing the projector, read first the safety instructions in the safety manual (R5975258)
delivered with the projector.
Insure that the projector is installed in an easy to evacuate room in case of a lamp explosion.
Mercury Vapor Warnings
Keep the following warnings in mind when using the projector. The lamp used in the projector contains mercury. In case of a lamp
rupture, explosion there will be a mercury vapor emission. In order to minimize the potential risk of inhaling mercury vapors:
• Ensure the projector is installed only in ventilated rooms.
• Replace the lamp module before the end of its operational life.
• Promptly ventilate the room after a lamp rupture, explosion has occurred, evacuate the room (particularly in case of a pregnant
woman).
• Seek medical attention if unusual health conditions occur after a lamp rupture, explosion, such as headache, fatigue, shortness
of breath, chest-tightening coughing or nausea.
2.2 Installation guidelines
Ambient temperature check
Careful consideration of things such as image size, ambient light level, projector placement and type of screen to use are critical to
the optimum use of the projection system.
Max. ambient temperature : 40 °C or 104 °F
Min. ambient temperature : 0 °C or 32 °F
The projector will not operate if ambient air temperature falls outside this range (0°C- 40°C or 32°F-104°F).
Environment
Do not install the projection system in a site near heat sources such as radiators or air ducts, or in a place subject to direct sunlight,
excessive dust or humidity. Be aware that room heat rises to the ceiling; check that temperature near the installation site is not
excessive
CAUTION:Harmful Environmental Contamination Precaution
Environment condition check
A projector must always be mounted in a manner which ensures the free flow of clean air into the projectors ventilation inlets as well
as free flow at the ventilation outlets. The installation must also allow easy access to the consumable parts ( dustfilters, lamps, ...)
For installations in environments where the projector is subject to airborne contaminants such as that produced by smoke machines
or similar (these deposit a thin layer of greasy residue upon the projectors internal optics and imaging electronic surfaces, degrading
performance), then it is highly advisable and desirable to have this contamination removed prior to it reaching the projectors clean
air supply. Devices or structures to extract or shield contaminated air well away from the projector are a prerequisite, if this is not
a feasible solution then measures to relocate the projector to a clean air environment should be considered. Make sure that the
projector never runs with dirty dustfilters as this will dramatically reduce the lifetime of the consumables. It is advised to clean the
dustfilters on a regular basis and to replace them at any lamp change. Barco reserves itself the right to refuse warranty replacement
of consumables if they have been used in a projector with dirty airfilters. Only use the manufactures recommended cleaning kit which
has been specifically designed for cleaning optical parts, never use industrial strength cleaners on a projectors optics as these will
degrade optical coatings and damage sensitive optoelectronics .
Failure to take suitable precautions to protect the projector from the effects of persistent and prolonged air contaminants will culmi-
nate in extensive and irreversible ingrained optical damage. At this stage cleaning of the internal optical units will be non-effective
and impracticable. Damage of this nature is under no circumstances covered under the manufactures warranty and may deem the
R59770079 BARCO ID H250/500 23/07/2007 5

2. Installation guidelines
warranty null and void. In such a case the client shall be held solely responsible for all costs incurred during any repair. It is the
clients responsibility to ensure at all times that the projector is protected from the harmful effects of hostile airborne particles in the
environment of the projector. The manufacture reserves the right to refuse warranty repair if a projector has been subject to wantful
neglect, abandon or improper use.
What about ambient light ?
The ambient light level of any room is made up of direct or indirect sunlight and the light fixtures in the room. The amount of ambient
light will determine how bright the image will appear. So, avoid direct light on the screen. Windows that face the screen should be
covered by opaque drapery while the set is being viewed. It is desirable to install the projection system in a room whose walls and
floor are of non-reflecting material. The use of recessed ceiling lights and a method of dimming those lights to an acceptable level
is also important. Too much ambient light will ‘wash out’ of the projected image. This appears as less contrast between the darkest
and lightest parts of the image. With bigger screens, the ‘wash out’ becomes more important. As a general rule, darken the room to
the point where there is just sufficient light to read or write comfortably. Spot lighting is desirable for illuminating small areas so that
interference with the screen is minimal.
Which screen type ?
There are two major categories of screens used for projection equipment. Those used for front projected images and those for rear
projection applications. Screens are rated by how much light they reflect (or transmit in the case of rear projection systems) given a
determined amount of light projected toward them. The ‘GAIN’ of a screen is the term used. Front and rear screens are both rated
in terms of gain. The gain of screens range from a white matte screen with a gain of 1 (x1) to a brushed aluminized screen with a
gain of 10 (x10) or more. The choice between higher and lower gain screens is largely a matter of personal preference and another
consideration called the Viewing angle. In considering the type of screen to choose, determine where the viewers will be located
and go for the highest gain screen possible. A high gain screen will provide a brighter picture but reduce the viewing angle. For
more information about screens, contact your local screen supplier.
Image size
The projector is designed for projecting an image size with a screenwidth from 1.00m (3.3ft) to 6.00m (19.7ft) with an aspect ratio of
16 to 9.
6R59770079 BARCO ID H250/500 23/07/2007

3. Installation
3. INSTALLATION
Overview
• Battery installation in the RCU
• Lens installation
• Removing the lens
• Lens range
• Lens Formulas
• Projector configuration
• Positioning the projector
Dimensions
Dimensions are given in mm and inch ( 1inch = 25.4 mm)
L
eng
th
w
ith
diff
eren
t
l
enses : see
t
a
bl
e
Cold air IN Cold air IN
69
20
Cold air OUT
415
487 (length without Cable Basket)
45
78
305
281
152
380
195
Image 3-1
R59770079 BARCO ID H250/500 23/07/2007 7

3. Installation
3.1 Battery installation in the RCU
How to install the battery
Two batteries are packed together with the RCU. Before using your RCU, install first these batteries.
1. Remove the battery cover on the backside by pushing the handle a little towards the bottom of the RCU.
2. Lift up the top side of the cover at the same time.
3. Insert the batteries as indicated in the RCU.
4. Put the battery cover on its place.
How to replace the batteries in the RCU
To replace the batteries :
1. Remove the battery cover on the backside by pushing the handle a little towards the bottom of the RCU.
2. Lift up the top side of the cover at the same time.
3. Push on the + side of the battery towards the - side
4. Lift up the battery at the same time.
5. Repeat for the second battery.
6. Insert the batteries as indicated in the RCU (battery type AA or LR6 or equivalent).
7. Put the battery cover on its place.
Image 3-2
3.2 Lens installation
How to install ?
1. Take the lens out of its packing material
2. Fix the lens by placing it in the housing
8R59770079 BARCO ID H250/500 23/07/2007

3. Installation
Image 3-3
Note: In case of a motorized lens the female jack must be in front of the male jack located in the upper-left part of the housing
in the projector
3. Push carefully to lock the lens in the housing
3.3 Removing the lens
How to remove the lens ?
1. Unlock the lens by pulling the handle located on the right side of the projector
Image 3-4
Image 3-5
location of the lens handle
2. Remove the lens out of its housing
CAUTION:Never transport the projector with the lens mounted on it !
Always remove the lens before transporting the projector.
3.4 Lens range
Overview table
Lens Partnumber
QCLD (0.85:1) R9849860
QCLD (1.1-1.3:1) R9849850
CLD (1.2-1.6:1) R9849870
R59770079 BARCO ID H250/500 23/07/2007 9

3. Installation
Lens Partnumber
CLD (1.6-2.4:1) R9849880
CLD (2.4-4.3:1) R9849890
See the Maintenance appendix for more information about lens cleaning.
When using a HD projector (for example an iCon) in retro projection, it is advised to use a QCLD lens.
3.5 Lens Formulas
Formulas
Lenses Metric Formulas (meter) Inch formulas (inch)
QCLD (0.85:1) PD=0.79XSW+0.06 PD = 0.79 X SW + 2.36
QCLD (1.1-1.3:1) PDmin =1.02XSW+0.05
PDmax =1.2XSW+0.06
PDmin =1.02XSW+1.97
PDmax = 1.2 X SW + 2.36
CLD (1.2-1.6:1) PDmin = 1.1 X SW + 0.02
PDmax =1.51XSW+0.02
PDmin =1.1XSW+0.79
PDmax =1.51XSW+0.79
CLD (1.6-2.4:1) PDmin =1.46XSW+0.00
PDmax = 2.21 X SW - 0.02
PDmin =1.46XSW+0.00
PDmax = 2.21 X SW - 0.79
CLD (2.4-4.3:1) PDmin = 2.2 X SW - 0.03
PDmax = 3.99 X SW - 0.01
PDmin = 2.2 X SW - 1.18
PDmax = 3.99 X SW - 0.39
3.6 Projector configuration
The different configurations
Depending on the installation the projector can be mounted in different ways, the 4 different configurations are:
1. Rear/Ceiling
2. Rear/Table
3. Front/Ceiling
4. Front/Table
10 R59770079 BARCO ID H250/500 23/07/2007

3. Installation
12
34
Image 3-6
The configuration should also be communicated to the projector. This is done in the Installation menu through
the Projector Configuration parameter. (See Setup section)
3.7 Positioning the projector
On-Axis projection
Projection where the projector is positioned so as to have the centre of the lens coinciding with the centre of the screen.
Positioning the projector
The position of the projector with reference to the screen may also be different depending on the installation. Basically the projector
can be positioned in an On-Axis or Off-Axis configuration. Several parameters can be calculated determining the position in any
installation.
R59770079 BARCO ID H250/500 23/07/2007 11

3. Installation
P
PD
x
F
a
b
c
S
S
B
SH
SW
SH
SW
F
CD=SH/2+B-A
A
front plate
Image 3-7
12 R59770079 BARCO ID H250/500 23/07/2007

3. Installation
P
PD
F
a
b
c
S
S
B
SH
SW
SH
SW
F
CD=B-A
A
front plate
Image 3-8
A 100% Off-Axis position means that the position of the centre of the lens is shifted by half the screen height.
Never use a short throw lens in an Off-Axis installation. Shifting the lens will not guarantee optimal image
quality.
CAUTION:Only for projectors containing a Server (Single Board Computer) : The harddisk in the server is
formatted in horizontal position but can operate in all axes (6 directions). The projector should not be tilted
more then +/- 5 degrees from these positions, otherwise error rates will increase.
R59770079 BARCO ID H250/500 23/07/2007 13

3. Installation
CAUTION:Never place the projector on either side !
Floor Floor
Image 3-9
14 R59770079 BARCO ID H250/500 23/07/2007

4. Connections
4. CONNECTIONS
Overview
• Power connection
• Signal connections
• Communication connections
4.1 Power connection
Power connection
1. Use the supplied power cord to connect the projector to the power outlet.
2. Plug the female power connector into the male connector at the front of the projector.
Image 4-1
Power connections
4.2 Signal connections
Overview
• The input section
• Connecting a Composite video signal
• Connecting an S-Video signal
• Connecting an RGB signal
• Connecting a Component Video signal
• Connecting a DVI signal
• Connecting a computer signal
• The DVI output
4.2.1 The input section
Input layers
The input section is located at the front of the projector and is composed of 3 layers which can be equipped with different input
modules depending on the ordered options .
The standard layers :
• Layer 1: DVI Input/Output module:
• Layer 2: RGBHV & Video analog input module
• Layer 3: DVI & Computer (D15) input module
• Layer 4 : Ethernet card
The different available options :
R59770079 BARCO ID H250/500 23/07/2007 15

4. Connections
• HD SDI/SDI input output input module on Layer 3
When using the HD SDI option, there is always a possibility to connect a VGA signal on the RGBHV input
using an adapter.
Image 4-2
L1
LAYER 1
L1
LAYER 2
L1
LAYER 3
L1
LAYER 4
Image 4-3
Input section
L1
LAYER 1
L1
LAYER 2
L1
LAYER 3
L1
LAYER 4
Image 4-4
Input with HDSDI/SDI module (ordered with HDSDI/SDI option)
16 R59770079 BARCO ID H250/500 23/07/2007
