Barco FL35 Installation manual

F(L)35, FS35 IR, F85
ASCII Commands Protocol Reference Manual
601–0381–00/00
21/10/2015

Barco Fredrikstad AS
Habornveien 53, N-1630 Gamle Fredrikstad, Norway
Phone: [phone]
Fax: [phone]
Support: [email protected]
Visit us at the web: www.barco.com
Printed in NO

Changes
Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war-
ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the
program(s) described in this publication at any time without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the information in this
publication; these changes are incorporated in new editions of this publication.
The latest edition of Barco manuals can be downloaded from the Barco web site www.barco.com or from the secured Barco web site
https://www.barco.com/en/signin.
Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be recorded, transmitted or
stored in a retrieval system without the prior written consent of Barco.
Trademarks
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders.
All brand and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for
the products or their manufacturers.

1. Communication settings
1. COMMUNICATION SETTINGS
Overview
• Set up LAN Communication
• Set up RS232 communication
1.1 Set up LAN Communication
General
The supported RS232 settings are as follows:
Parameter Data
Baud rate 19200
Data bits 8
Parity None. There is no parity bit used to perform error checking.
Stop bits 1. One stop bit is used to define the end of a character.
Flow control None.
General
The default settings of the projector when shipped are as follows:
Description Value
DHCP On
IP address 0.0.0.0
Subnet mask 0.0.0.0
Default gateway 0.0.0.0
TCP/UDP port 1025
Input IP settings on the projector
Before you connect the projector to your LAN make sure that the IP settings are set correctly, according to your LAN configuration.
IP settings can be changed using the projector On Screen Display (OSD) Settings menu.
Set up can be done automatically using DHCP (Dynamic Host Configuration Protocol). When DHCP is enabled, it may take up to a
minute for the projector to receive IP settings from the DHCP server. The IP address will be updated and shown in the OSD. If there
is no DHCP server in the network the projector will be assigned a “zero configuration” address, 169.254.0.0/16.
Alternatively, DHCP can be manually disabled and the user can manually input the projector IP address, Subnet mask and Gateway
in the LAN network menu of the OSD.
To renew an IP address, select “renew” in the OSD LAN settings menu.
Connect the projector and the host
As soon as the projector IP settings are set correctly, you can physically connect the selected host, for example a computer, and the
projector. This can be done in two ways:
• use a crossover twisted pair (TP) cable directly from the computer to the projector
• use two straight-through TP cables with a HUB or a switch between them
1.2 Set up RS232 communication
Connect to the projector
Connect the projector and host using a standard straight through serial cable (host : female, projector : male).
Pin 2 connects to Pin 2, Pin 3 connects to Pin 3, and Pin 5 connects to Pin 5.
601–0381–00 F(L)35, FS35 IR, F85 21/10/2015 1

1. Communication settings
Maximum length of the RS-232 cable is 15.25m (50ft).
2601–0381–00 F(L)35, FS35 IR, F85 21/10/2015

2. Communication protocol definitions
2. COMMUNICATION PROTOCOL DEFINITIONS
About
This section describes the definitions used in the communications protocol. When the projectors are connected to either RS232 or
LAN you can control the projectors through this ASCII based protocol.
Some commands will generate OSD feedback. This can be stopped by turning off the OSD from the projector’s
menu system or by setting “OSDC” to value 0 (OSD off) or value 1 (OSD show only warnings).
Overview
•Timing
• Serial Communications Protocol
• Examples
2.1 Timing
General timing constraints
Behavior Constraint
Power on (wake from standby) At least 30 seconds wait after power up complete before sending next command
Command Response required before sending next command
No response received At least 2 seconds before re-sending if no response received
Between commands Minimum 500 ms delay required between commands
After sending 20 commands Minimum 5 seconds delay required
2.2 Serial Communications Protocol
Definitions
Like every communication method the serial communication uses a particular protocol (ANSI) which must be respected in order to
allow communication to take place.
The header is ASCII colon ’:’ character.
Use of a separator is optional in the command protocol. The protocol accepts one ASCII SPACE between fields, or no ASCII SPACE
between fields.
All acknowledgement protocol use an ASCII SPACE (single) as a separator.
The terminator is ASCII value carriage return (CR)/hex value 0x0D.
The following table gives a summary of the predefined communication terms.
Header Message body Terminator
Limitations 1 byte N bytes 1 byte
Definition ASCII colon :Mnemonic Modifier Value Target Carriage Return (Hex 0x0D)
Example :POWR1 CR
Header
The header informs the projector (in case of transmission) or the computer (in case of reception) that a new data transfer will take
place.
Message body
The message body defines the action to be performed. The message body is built up of several fields:
601–0381–00 F(L)35, FS35 IR, F85 21/10/2015 3

2. Communication protocol definitions
Mnemonic Modifier Value Target
Limitations 4 bytes 1 byte N bytes, max 6 bytes N bytes, max 4
Inclusion Required Optional Optional Optional
Example POWR A1CR
Mnemonic bytes (4 bytes)
The mnemonic is a 4 byte ASCII command (key identifier). This is required in all serial communications.
Modifier byte (1–2 bytes)
The modifier is used to constrain or modify the mnemonic command.
Modifier Description
RRelative change. Given value will be relative to existing value. e.g. BRIG10 will increase brightness by 10 steps.
ANot normally used. Manually request acknowledgement/read back the result of the command.
? Get current value
?M Get maximum value
?N Get minimum value
?D Get default value
?S Get default step value
Terminator
The terminator informs the projector (in case of transmission) or the computer (in case of reception) that the data transfer is complete
and that the interpretation of the command and data bytes can start.
Acknowledgement
If the command is understood by the projector then an ’ACK’ command is sent back. The ’ACK’ command uses the following protocol:
Ack. Address Separator Command Separator Value Terminator
Limitations 1 byte 1–3 bytes 1 byte 4 bytes 1 byte 6 bytes 1 byte
Definition ASCII % Projector
address
ASCII space Mnemonic ASCII space Numeric
value
Carriage
Return (Hex
0x0D)
Example %001 Space POWR Space 000001 CR
Some commands could return a value that is more than 6 bytes, for example, strings. This is identified by the acknowledgement
including the alphanumeric value ’eXXXXX’.
Address functionality is no longer used. Address bytes will always be 001.
For example:
> :seri ?
> %001 SERI e00001 07010001
Invalid command
If the input command is not valid, then the projector acknowledgement may include an error message in the value field.
Ack. Address Separator Command Separator Value Terminator
Limitations 1 byte 1–3 bytes 1 byte 4 bytes 1 byte 6 bytes 1 byte
Definition ASCII % Projector
address
ASCII space Mnemonic ASCII space Numeric
value of error
Carriage
Return (Hex
0x0D)
Example %001 Space POWR Space !00001 CR
Error code Error message Description
!00001 Access denied User does not have sufficient access rights to perform this command.
4601–0381–00 F(L)35, FS35 IR, F85 21/10/2015

2. Communication protocol definitions
Error code Error message Description
!00002 Not available Logic conflict prevents command being available. For example, contrast is not
available when the projector is searching for sources.
!00003 Not implemented Command not available for this projector configuration. See relevant comments
section in ASCII commands for information.
!00004 Value out of range Value is not within valid range.
2.3 Examples
SET commands
Command Description
:POWR1’CR’ Set power on
%001 POWR 000001’CR’ Acknowledge power on
Command Description
:BRIG 60’CR’ Set brightness to 60
%001 BRIG 000060’CR’ Acknowledge brightness
Command Description
:CNTR R1’CR’ Increase contrast
%001 CNTR 000061’CR’ Acknowledge increase contrast
Command Description
:CNTR R-2’CR’ Decrease contrast
%001 CNTR 000059’CR’ Acknowledge decrease contrast
SET commands with target
Command Description
:TATB 1 3’CR’ Set aspect trigger behavior 16:10 to off
%001 TATB 000001’CR’ Acknowledge set aspect trigger behavior 16:10 to off
GET commands
Command Description
:CNTR?’CR’ Get current value contrast
%001 CNTR 000059’CR’ Acknowledge get current value contrast
Command Description
:BRIG ?N’CR’ Get minimum value brightness
%001 CNTR 000000’CR’ Acknowledge get minimum value brightness
GET commands with target
Command Description
:TATB ? 3 Get aspect trigger behavior 16:10
%001 TATB 000001 ’CR’ Acknowledge get aspect trigger behavior 16:10
601–0381–00 F(L)35, FS35 IR, F85 21/10/2015 5

Command Description Platforms
Operations
supported
Level Value Target Comments
POWR
Power GP3, GP4 Get, Set End User 0 - power off, 1 - power on
POST
Power state GP3, GP4 Get End User See value table POST
IABS
Set source abs values GP3, GP4 Get, Set End User See value table IABS
IDVI
Select DVI GP3, GP4 Get, Set End User 1 - DVI 1, 2 - DVI 2
IHDM
Select HDMI GP3, GP4 Get, Set End User 1 - HDMI 1, 2 - HDMI 2
IVGA
Select VGA GP3, GP4 Get, Set End User 1 - VGA 1, 2 - VGA 2
IDHD
Select dual head DVI GP3, GP4 Get, Set End User
IDHH
Select dual head HDMI GP3, GP4 Get, Set End User
IDHX
Select dual head XP2 GP3, GP4 Get, Set End User
IXP2
Select XP2 GP3, GP4 Get, Set End User
IYPP
Select component GP3, GP4 Get, Set End User
ISTS
Signal Status GP3, GP4 Get End User
0 - searching 1 - locked to
source
BRIG
Brightness GP3, GP4 Get, Set End User
CNTR
Contrast GP3, GP4 Get, Set End User
CSAT
Saturation GP3, GP4 Get, Set End User
PRST
Picture Reset GP3, GP4 Get, Set End User
PMUT
Picture Mute GP3, GP4 Get, Set End User 0 - disable, 1 - enable
SABS
Set Scaling abs value GP3, GP4 Get, Set End User See value table SABS
S1T1
Select Scaling 1:1 GP3, GP4 Get, Set End User
S169
Select Scaling 16:9 GP3, GP4 Get, Set End User
SS43
Select Scaling 4:3 GP3, GP4 Get, Set End User
SFLA
Select Scaling Fill All GP3, GP4 Get, Set End User
SFAR
Select Scaling Fill Aspect Ratio GP3, GP4 Get, Set End User
S235
Select Scaling Fill 2.35:1 GP3, GP4 Get, Set End User
SANL
Select Scaling Anamorphic Lens GP3, GP4 Get, Set End User
AUTO
Auto adjust current source GP3, GP4 Set End User
FRZE
Freeze Image GP3, GP4 Get, Set End User 0 - disable, 1 - enable
GAFI
Select Gamma Film GP3, GP4 Get, Set End User 1 - Film 1, 2 - Film 2
GAVI
Select Gamma Video GP3, GP4 Get, Set End User 1 - Video 1, 2 - Video2
GACO
Select Gamma Computer GP3, GP4 Get, Set End User 1 - Computer 1, 2 - Computer
2
GABS
Set Gamma abs value GP3, GP4 Get, Set End User See value table GABS
CTWP
Color Management Processed
Test Patterns
GP3, GP4 Get, Set End User
RCMN
Color management Reset to
Native
GP3, GP4 Set End User
RWHN
Color Management reset white to
native
GP3, GP4 Set End User
ACAL
AD calibration GP3, GP4 Set End User
Picture->Calibration
Picture->RealColor
Source selection
Power
3. ASCII Command Sets
601-0381-00_GP3/GP4
Sicilium_1_24
6

HPOS
Horizontal positon GP3, GP4 Get, Set End User Only for analog sources
VPOS
Vertical position GP3, GP4 Get, Set End User Only for analog sources
FREQ
Frequency GP3, GP4 Get, Set End User Only for analog sources
PHSE
Phase GP3, GP4 Get, Set End User Only for analog sources
DCSP
Color Space GP3, GP4 Get, Set End User
0 - auto, 1 - RGB, 2 - REC
709, 3 - REC 601
DVST
Input Level GP3, GP4 Get, Set End User
0 - auto, 1 - computer, 2 -
video
CTYP
Input Cropping Mode GP3 Get, Set End User
0 - Disabled, 1 - Auto, 2 -
2.35:1, 3 - Manual
COFF
Select Input Cropping Mode
Disabled
GP3 Get, Set End User
CAUT
Select Input Cropping Mode Auto GP3 Get, Set End User
C235
Select Input Cropping Mode
2.35:1
GP3 Get, Set End User
CMAN
Select Input Cropping Mode
Manual
GP3 Get, Set End User
CTOP
Input Cropping Top GP3 Get, Set End User 35 - input image height
CBTM
Input Cropping Bottom GP3 Get, Set End User 35 - input image height
BCCR
BrilliantColor Control GP3 Get, Set End User See value table BCCR
BCEN
BrilliantColor Enable GP3 Get, Set End User 0 - disable, 1- enable
CMOD
Color Management Enable GP3, GP4 Get, Set End User 0 - disable, 1- enable
CMWH
Color Management White GP3, GP4 Get, Set End User 0 - temperature, 1 - coordinate
CMXV
Color Management X-Coordinate
GP3, GP4 Get, Set End User
CMYV
Color Management Y-Coordinate
GP3, GP4 Get, Set End User
CMTV
Color Management Temperature GP3, GP4 Get, Set End User 3200 - 9300
RD65
Reset to D65 GP3, GP4 Set End User
DSCR
Desired Coords Mode GP3, GP4 Get, Set End User See value table DSCR
BAGA
Balanced Gains GP3, GP4 Get, Set End User 0 - disable, 1- enable
DSRX
Desired Red X GP3, GP4 Get, Set End User
DSRY
Desired Red Y GP3, GP4 Get, Set End User
DSRG
Desired Red Gain GP3, GP4 Get, Set End User
DSGX
Desired Green X GP3, GP4 Get, Set End User
DSGY
Desired Green Y GP3, GP4 Get, Set End User
DSGG
Desired Green Gain GP3, GP4 Get, Set End User
DSBX
Desired Blue X GP3, GP4 Get, Set End User
DSBY
Desired Blue Y GP3, GP4 Get, Set End User
DSBG
Desired Blue Gain GP3, GP4 Get, Set End User
DSCX
Desired Cyan X GP3, GP4 Get, Set End User
DSCY
Desired Cyan Y GP3, GP4 Get, Set End User
DSCG
Desired Cyan Gain GP3, GP4 Get, Set End User
DSMX
Desired Magenta X GP3, GP4 Get, Set End User
DSMY
Desired Magenta Y GP3, GP4 Get, Set End User
DSMG
Desired Magenta Gain GP3, GP4 Get, Set End User
DSYX
Desired Yellow X GP3, GP4 Get, Set End User
DSYY
Desired Yellow Y GP3, GP4 Get, Set End User
Picture->RealColor
Picture->Advanced
Picture->Advanced->Input Cropping
3. ASCII Command Sets
601-0381-00_GP3/GP4
Sicilium_1_24
8

DSYG
Desired Yellow Gain GP3, GP4 Get, Set End User
DSWG
Desired White Gain GP3, GP4 Get, Set End User
DFRX
Factory Desired Red X GP3, GP4 Get, Set Manufacturing
DFRY
Factory Desired Red Y GP3, GP4 Get, Set Manufacturing
DFRG
Factory Desired Red Gain GP3, GP4 Get, Set Manufacturing
DFGX
Factory Desired Green X GP3, GP4 Get, Set Manufacturing
DFGY
Factory Desired Green Y GP3, GP4 Get, Set Manufacturing
DFGG
Factory Desired Green Gain GP3, GP4 Get, Set Manufacturing
DFBX
Factory Desired Blue X GP3, GP4 Get, Set Manufacturing
DFBY
Factory Desired Blue Y GP3, GP4 Get, Set Manufacturing
DFBG
Factory Desired Blue Gain GP3, GP4 Get, Set Manufacturing
DFCX
Factory Desired Cyan X GP3, GP4 Get, Set Manufacturing
DFCY
Factory Desired Cyan Y GP3, GP4 Get, Set Manufacturing
DFCG
Factory Desired Cyan Gain GP3, GP4 Get, Set Manufacturing
DFMX
Factory Desired Magenta X GP3, GP4 Get, Set Manufacturing
DFMY
Factory Desired Magenta Y GP3, GP4 Get, Set Manufacturing
DFMG
Factory Desired Magenta Gain GP3, GP4 Get, Set Manufacturing
DFYX
Factory Desired Yellow X GP3, GP4 Get, Set Manufacturing
DFYY
Factory Desired Yellow Y GP3, GP4 Get, Set Manufacturing
DFYG
Factory Desired Yellow Gain GP3, GP4 Get, Set Manufacturing
DFWG
Factory Desired White Gain GP3, GP4 Get, Set Manufacturing
MSRX
Measured Red X GP3, GP4 Get, Set End User
MSRY
Measured Red Y GP3, GP4 Get, Set End User
MSRL
Measured Red Luminance GP3, GP4 Get, Set End User
MSGX
Measured Green X GP3, GP4 Get, Set End User
MSGY
Measured Green Y GP3, GP4 Get, Set End User
MSGL
Measured Green Luminance GP3, GP4 Get, Set End User
MSBX
Measured Blue X GP3, GP4 Get, Set End User
MSBY
Measured Blue Y GP3, GP4 Get, Set End User
MSBL
Measured Blue Luminance GP3, GP4 Get, Set End User
MSWX
Measured White X GP3, GP4 Get, Set End User
MSWY
Measured White Y GP3, GP4 Get, Set End User
MSWL
Measured White Luminance GP3, GP4 Get, Set End User
MSDX
Measured BC1 X GP3 Get, Set End User
MSDY
Measured BC1 Y GP3 Get, Set End User
MSDL
Measured BC1 Luminance GP3 Get, Set End User
MSEX
Measured BC2 X GP3 Get, Set End User
MSEY
Measured BC2 Y GP3 Get, Set End User
MSEL
Measured BC2 Luminance GP3 Get, Set End User
MFRX
Factory Measured Red X GP3, GP4 Get, Set Manufacturing
MFRY
Factory Measured Red Y GP3, GP4 Get, Set Manufacturing
MFRL
Factory Measured Red
Luminance
GP3, GP4 Get, Set Manufacturing
MFGX
Factory Measured Green X GP3, GP4 Get, Set Manufacturing
MFGY
Factory Measured Green Y GP3, GP4 Get, Set Manufacturing
MFGL
Factory Measured Green
Luminance
GP3, GP4 Get, Set Manufacturing
3. ASCII Command Sets
601-0381-00_GP3/GP4
Sicilium_1_24
9

MFBX
Factory Measured Blue X GP3, GP4 Get, Set Manufacturing
MFBY
Factory Measured Blue Y GP3, GP4 Get, Set Manufacturing
MFBL
Factory Measured Blue
Luminance
GP3, GP4 Get, Set Manufacturing
MFWX
Factory Measured White X GP3, GP4 Get, Set Manufacturing
MFWY
Factory Measured White Y GP3, GP4 Get, Set Manufacturing
MFWL
Factory Measured White
Luminance
GP3, GP4 Get, Set Manufacturing
MFDX
Factory Measured BC1 X GP3 Get, Set Manufacturing
MFDY
Factory Measured BC1 Y GP3 Get, Set Manufacturing
MFDL
Factory Measured BC1
Luminance
GP3 Get, Set Manufacturing
MFEX
Factory Measured BC2 X GP3 Get, Set Manufacturing
MFEY
Factory Measured BC2 Y GP3 Get, Set Manufacturing
MFEL
Factory Measured BC2
Luminance
GP3 Get, Set Manufacturing
CMTP
Color Management Test Patterns GP3, GP4 Get, Set End User
IBCO
Individual brightness and contrast
offset adjustments
GP3, GP4 Get, Set End User 0 - disable, 1 - enable
0-RGB, 1-IR
(if available)
BOR0
Brightness offset red GP3, GP4 Get, Set End User
BOG0
Brightness offset green GP3, GP4 Get, Set End User
BOB0
Brightness offset blue GP3, GP4 Get, Set End User
COR0
Contrast offset red GP3, GP4 Get, Set End User
COG0
Contrast offset green GP3, GP4 Get, Set End User
COB0
Contrast offset blue GP3, GP4 Get, Set End User
DESK
Select orientation - Desktop Front GP3, GP4 Get, Set End User
CEIL
Select orientation - Ceiling Front GP3, GP4 Get, Set End User
RDES
Select orientation - Desktop Rear GP3, GP4 Get, Set End User
RCEI
Select orientation - Ceiling Rear GP3, GP4 Get, Set End User
ORIE
Select orientation - Absolute
value
GP3, GP4 Get, Set End User See value table ORIE
SCAN
Source Scan GP3, GP4 Get, Set End User 0 - disable, 1 - enable
IR01
IR Enable 1 GP3, GP4 Get, Set End User 0 - disable, 1 - enable
IR02
IR Enable 2 GP3, GP4 Get, Set End User 0 - disable, 1 - enable
IR03
IR Enable 3 GP3 Get, Set End User 0 - disable, 1 - enable
OSDC
OSD Enable GP3, GP4 Get, Set End User See value table OSDC
TEST
Test Image GP3, GP4 Get, Set End User 0 - 7 different test patterns
DHED
Dual Head Setup Mode GP3, GP4 Get, Set End User 0 - off, 1 - side by side
SVGA
Sync termination VGA GP3, GP4 Get, Set End User 0 - 2.2kOhm, 1 - 75Ohm
SNCL
Sync level VGA GP3, GP4 Get, Set End User 0-255
SNCS
Sync Level SOG GP3, GP4 Get, Set End User 0-31 Infitec only
OPFI
Infitec filter GP3 Get, Set End User 0 - disable, 1 - enable Infitec only
CSCC
Infitec CSC GP3 Get, Set End User 0 - disable, 1 - enable
EDIR
Edit resolution GP3, GP4 Get, Set End User See value table EDIR
EDIT
Edid type GP3, GP4 Get, Set End User See value table EDIT
Installation
Picture->Advanced->Source Correction
3. ASCII Command Sets
601-0381-00_GP3/GP4
Sicilium_1_24
10

ECOM
Eco Mode GP3, GP4 Get, Set End User 0 - disable, 1 - enable
LPW1
Lamp1 Power GP3, GP4 Get, Set End User
LPW2
Lamp2 Power GP3, GP4 Get, Set End User
LMOD
Lamp Mode GP3, GP4 Get, Set End User See value table LMOD
LDLY
Lamp Auto Switch Delay GP3, GP4 Get, Set End User
LPW1
LED Power GP3 Get, Set End User
DBDI
LED Power GP3 LED Get, Set End User
Use LPW1, this is for legacy
support
LDMM
LED Dim Mode GP3 LED Get, Set End User 0 - standard, 1 - custom
LDCR
LED Dim Custom Red GP3 LED Get, Set End User
LDCG
LED Dim Custom Green GP3 LED Get, Set End User
LDCB
LED Dim Custom Blue GP3 LED Get, Set End User
TRG1
Trigger 1 Mode GP3, GP4 Get, Set End User See value table TRGx
TRG2
Trigger 2 Mode GP3, GP4 Get, Set End User See value table TRGx
TATB
Aspect Trigger Behavior GP3, GP4 Get, Set End User See value table TATB
See value
table TATB
FLSO
Frame lock Source GP3, GP4 Get, Set End User 0 - Internal, 1 - External
FLOS
Frame lock Output Signal GP3, GP4 Get, Set End User
0 - Off , 1 - Frame lock, 2 -
Pass-through
FLST
Frame lock Status GP3, GP4 Get End User Print current frame lock status
TSLR
3D source L/R sync GP3, GP4 Get, Set End User 0 - None, 1 - BNC sync-in
TDLR
3D display L/R sync GP3, GP4 Get, Set End User 0 - None, 1 - BNC sync-in
TBOS
3D BNC sync-out signal See value table TBOS
FCRE
Factory Reset GP3, GP4 Set End User
FCRL
Factory reset level GP3, GP4 Get, Set Power User 0 - limited, 1 - full
PINC
PIN Code GP3, GP4 Set End User Must be executed in standby
CODE
Service Code GP3, GP4 Set Power User
RCID
RCID Internal GP3, GP4 Get, Set End User
DPMS
DPMS GP3, GP4 Get, Set End User 0 - disable, 1 - enable
DPMT
DPMS Timeout GP3, GP4 Get, Set End User
KEYB
Backlight Timeout GP3, GP4 Get, Set End User
MNUT
Menu Timeout GP3, GP4 Get, Set End User
BACK
Background color GP3, GP4 Get, Set End User
SPLH
Splash GP3, GP4 Get, Set End User
LMUT
LED indicators mute GP3, GP4 Get, Set End User 0 - off, 1 - on
BAUD
Baud rate GP3, GP4 Get, Set End User See value table BAUD
Installation->Trigger
Settings
Installation->Frame lock setup
Installation->LED
Installation->Lamp
3. ASCII Command Sets
601-0381-00_GP3/GP4
Sicilium_1_24
11

RTCH
Real Time Clock Hour GP3, GP4 Get, Set End User
RTCM
Real Time Clock Minute GP3, GP4 Get, Set End User
RTCS
Real Time Clock Second GP3, GP4 Get, Set End User
RTCD
Real Time Clock Day GP3, GP4 Get, Set End User
RTCN
Real Time Clock Month GP3, GP4 Get, Set End User
RTCY
Real Time Clock Year GP3, GP4 Get, Set End User
RTCW
Real Time Clock Day of Week GP3, GP4 Get End User
UMST
Store profile GP3, GP4 Set End User Profile number (0 - 9)
UMRC
Recall profile GP3, GP5 Set End User Profile number (0 - 9)
TDSM
Stereo Mode GP3 120Hz, GP4 Get, Set End User See value table TDSM
TDGT
Glass type GP3 120Hz, GP4 Get, Set End User
0 - DLP Link™, 1 - IR, 2 - IR
high brightness
TDGD
Genlock phase delay GP3 120Hz, GP4 Get, Set End User
TDSE
Swap eyes GP3 120Hz, GP4 Get, Set End User 0 - off, 1 - on
AUXL
Full spectrum mode enable GP3 LED IR Get, Set End User 0 - disable, 1 - enable
DISL
RGB LEDs enable GP3 LED IR Get, Set End User 0 - disable, 1 - enable
LDMM
LED Dim Mode GP3 LED IR Get, Set End User 0 - standard, 1 - custom
LPW1
LED Power GP3 Get, Set End User
LDCR
LED Dim Custom Red GP3 LED IR Get, Set End User
LDCG
LED Dim Custom Green GP3 LED IR Get, Set End User
LDCB
LED Dim Custom Blue GP3 LED IR Get, Set End User
IBCO
Individual brightness and contrast
offset adjustments
GP3, GP4 Get, Set End User 0 - disable, 1 - enable
0-RGB, 1-IR
(if available)
BOR0
Brightness offset red GP3 LED IR Get, Set End User
BOG0
Brightness offset green GP3 LED IR Get, Set End User
BOB0
Brightness offset blue GP3 LED IR Get, Set End User
COR0
Contrast offset red GP3 LED IR Get, Set End User
COG0
Contrast offset green GP3 LED IR Get, Set End User
COB0
Contrast offset blue GP3 LED IR Get, Set End User
IR control->RGB adjustments
IR control
Stereo
Profiles
Settings->Set date and time
3. ASCII Command Sets
601-0381-00_GP3/GP4
Sicilium_1_24
12

AUXD
IR LED power GP3 LED IR Get, Set End User
GAB1
Set Gamma abs value IR channel
GP3 LED IR
WUXGA Get, Set
End User See value table GABS
SCMP
sub channel mapping
GP3 LED IR
WUXGA and Get, Set
End User
0 - RGB->RGB, 1 - R->RGB, 2
- G->RGB, 3 - B->RGB
IBCO
Individual brightness and contrast
offset adjustments
GP3, GP4 Get, Set End User 0 - disable, 1 - enable
0-RGB, 1-IR
(if available)
BOR1
Brightness offset red
GP3 LED IR
WUXGA
Get, Set
End User
BOG1
Brightness offset green
GP3 LED IR
WUXGA
Get, Set
End User
BOB1
Brightness offset blue
GP3 LED IR
WUXGA
Get, Set
End User
COR1
Contrast offset red
GP3 LED IR
WUXGA
Get, Set
End User
COG1
Contrast offset green
GP3 LED IR
WUXGA
Get, Set
End User
COB1
Contrast offset blue
GP3 LED IR
WUXGA
Get, Set
End User
IRFI
IR Filter enable GP3 LED IR MKII Get, Set End User
FOIN
Focus In GP3, GP4 Set End User 1 - Slow, 2 - Medium, 3 - Fast
FOUT
Focus Out GP3, GP4 Set End User 1 - Slow, 2 - Medium, 3 - Fast
ZOIN
Zoom In GP3, GP4 Set End User 1 - Slow, 2 - Medium, 3 - Fast
ZOUT
Zoom Out GP3, GP4 Set End User 1 - Slow, 2 - Medium, 3 - Fast
IROP
Iris Open GP3, GP4 Set End User 1 - Slow, 2 - Medium, 3 - Fast
IRCL
Iris Close GP3, GP4 Set End User 1 - Slow, 2 - Medium, 3 - Fast
LSDW
Lens Shift Down GP3, GP4 Set End User 1 - Slow, 2 - Medium, 3 - Fast
LSUP
Lens Shift Up GP3, GP4 Set End User 1 - Slow, 2 - Medium, 3 - Fast
LSLF
Lens Shift Left GP3, GP4 Set End User 1 - Slow, 2 - Medium, 3 - Fast
LSRH
Lens Shift Right GP3, GP4 Set End User 1 - Slow, 2 - Medium, 3 - Fast
SHUT
Shutter GP3, GP4 Set End User 0 - disable, 1 - enable
LENS
Lens ID GP3, GP4 Get End User
LMON
Lens Monitoring GP3, GP4 Get, Set Power User 0 - disable, 1 - enable
ZOPO
Zoom position GP3, GP4 Get, Set End User
FOPO
Focus position GP3, GP4 Get, Set End User
IRPO
Iris position GP3, GP4 Get, Set End User
LRM1
Lamp1 Estimated Remaining
Lamp Time
GP3, GP4 Get End User
LTR1
Lamp1 Runtime GP3, GP4 Get End User
LHO1
Lamp Channel 1 Total Time GP3, GP4 Get End User
See value table LST1 and
LST2
LST1
Lamp1 Status GP3, GP4 Get End User
LRM2
Lamp2 Estimated Remaining
Lamp Time
GP3, GP4 Get End User
LTR2
Lamp2 Runtime GP3, GP4 Get End User
LHO2
Lamp Channel 2 Total Time GP3, GP4 Get End User
See value table LST1 and
LST2
LST2
Lamp2 Status GP3, GP4 Get End User
UTOT
Unit Time Total GP3, GP4 Get End User
Lamp status
Lens control
IR control->IR adjustments
3. ASCII Command Sets
601-0381-00_GP3/GP4
Sicilium_1_24
13

MENU
Menu Navigate Toggle OSD
Menu
GP3, GP4 Set End User
NVUP
Menu Navigate Up GP3, GP4 Set End User
NVDW
Menu Navigate Down GP3, GP4 Set End User
NVLF
Menu Navigate Left GP3, GP4 Set End User
NVRH
Menu Navigate Right GP3, GP4 Set End User
NVOK
Menu Navigate Ok GP3, GP4 Set End User
ECHO
Communication Response
(on/off) GP3, GP4 Set End User
LANG
Language GP3, GP4 Get, Set End User
SINF
Show OSD Info GP3, GP4 Set End User
CWI1
Color Wheel Index 1 GP3 Get, Set Power User
CWI2
Color Wheel Index 2 GP3 Get, Set Power User
CRST
Reset All Counters GP3, GP4 Set Manufacturing
MAYR
Manufacture Year GP3, GP4 Get Manufacturing
MAWE
Manufacture Week GP3, GP4 Get Manufacturing
LFMP
LFM Performed GP3, GP4 Set Power User
GPEN
Enable Power User Gammas GP3, GP4 Get, Set Power User
AFCL
AD Factory Calibrate GP3, GP4 Set Manufacturing
LSDI
Lens shift disable GP3, GP4 Get, Set Power User 0 - enable 1 - disable
BCPE
Enable Power User brilliant color
modes
GP3 Get, Set Power User 0 - enable 1 - disable
STRS
Skip reset timeout (mirror
exercise)
GP3 Get, Set Manufacturing
0 - do not skip 1 - skip
(WQXGA only)
CALM
LED Calibration mode GP3 LED Get, Set Power User 0 - disable, 1 - enable
LVCA
LED voltage calibration start GP3 LED Set Service Partner
LVCS
LED voltage calibration status GP3 LED Get Service Partner
0 - done, 1 - in progress, 2 -
failed
LVCE
LED voltage calibration error
code GP3 LED Get Service Partner
bit wise error code see value
table LVCE
LIVR
LED input voltage red GP3 LED Get Service Partner
LIVG
LED input voltage green GP3 LED Get Service Partner
LIVB
LED input voltage blue GP3 LED Get Service Partner
LDVR
LED drop out voltage red GP3 LED Get Service Partner
LDVG
LED drop out voltage green GP3 LED Get Service Partner
LDVB
LED drop out voltage blue GP3 LED Get Service Partner
UINV
Update internal sensor values
factory
GP3 LED Set Manufacturing
UIVU
Update internal sensor values
user
GP3 LED Set Power User
INCS
Internal sensor calibration status GP3 LED Get Power User
0 - done, 1 - in progress, 2 -
failed
INCE
Internal sensor calibration error
code
GP3 LED Get Power User
bit wise error code see value
table INCE
INTR
Internal sensor value red GP3 LED Get Power User
INTG
Internal sensor value green GP3 LED Get Power User
INTB
Internal sensor value blue GP3 LED Get Power User
INDR
Internal sensor duration value red GP3 LED Get Power User
Menu navigate
Miscellaneous
Service->LED calibration
Service
3. ASCII Command Sets
601-0381-00_GP3/GP4
Sicilium_1_24
14

INDG
Internal sensor duration value
green
GP3 LED Get Power User
INDB
Internal sensor duration value
blue
GP3 LED Get Power User
THRM
Thermal Status GP3, GP4 Get Power User
FAN1
Fan Speed 1 GP3, GP4 Get Power User
FAN2
Fan Speed 2 GP3, GP4 Get Power User
FAN3
Fan Speed 3 GP3, GP4 Get Power User
FAN4
Fan Speed 4 GP3, GP4 Get Power User
FAN5
Fan Speed 5 GP3, GP4 Get Power User
FAN6
Fan Speed 6 GP3, GP4 Get Power User
FAN7
Fan Speed 7 GP3, GP4 Get Power User
FAN8
Fan Speed 8 GP3, GP4 Get Power User
SNS1
Sensor Value 1 GP3, GP4 Get Power User
SNS2
Sensor Value 2 GP3, GP4 Get Power User
SNS3
Sensor Value 3 GP3, GP4 Get Power User
SNS4
Sensor Value 4 GP3, GP4 Get Power User
SNS5
Sensor Value 5 GP3, GP4 Get Power User
SNS6
Sensor Value 6 GP3, GP4 Get Power User
SNS7
Sensor Value 7 GP3, GP4 Get Power User
SNS8
Sensor Value 8 GP3, GP4 Get Power User
PLAT
Platform Name String GP3, GP4 Get Power User Extended Protocol
SERI
Serial Number String GP3, GP4 Get Power User Extended Protocol
MODL
Model Name String GP3, GP4 Get Power User Extended Protocol
PART
Part Number String GP3, GP4 Get Power User Extended Protocol
SVER
Software Version GP3, GP4 Get Power User Extended Protocol
PRID
Product ID GP3, GP4 Get Power User
ACSS
Current Access Level GP3, GP4 Get End User
MACA
MAC address GP3, GP4 Get End User Extended Protocol
IPAD
IP address GP3, GP4 Get End User See value table LEST
LEST
Indicator LED state GP3, GP4 Get End User Extended Protocol
SWSN
SVN SW Revision GP3, GP4 Get Power User
FLFS
Frame lock(2D) frequency GP3, GP4 Get End User See value table FLSS
FLSS
Frame lock(2D) status GP3, GP4 Get End User
TDFS
3D LR frequency GP3, GP4 Get End User
TDDS
3D LR duty cycle GP3, GP4 Get End User See value table TDSS
TDSS
3D LR status GP3, GP4 Get End User
X1ID
Xport 1 ID GP3, GP4 Get Manufacturing
X2ID
Xport 2 ID GP3, GP4 Get Manufacturing
Status
Thermal
3. ASCII Command Sets
601-0381-00_GP3/GP4
Sicilium_1_24
15

LMBX
Lamp data mailbox GP3 Get, Set Manufacturing Data
0 - Lamp 1, 1
- Lamp 2
LMBP
Lamp data mailbox position GP3 Get, Set Manufacturing Data
0 - Lamp 1, 1
- Lamp 2
LMBC
Lamp data mailbox checksum GP3 Get, Set Manufacturing Data
0 - Lamp 1, 1
- Lamp 2
Lamp data
3. ASCII Command Sets
601-0381-00_GP3/GP4
Sicilium_1_24
16

Value tables
IABS
Set source abs values
Value Description
0 VGA 1
1 VGA 2
2 DVI 1
7Component
8 HDMI 1
10 DVI 2
11 HDMI 2
12 Dual Head DVI
13 Dual Head HDMI
14 Dual Head XP2
15 XP2 A
16 XP2 B
SABS
Set scaling abs values
Value Description
01:1
1Fill All
2 Fill Aspect Ratio
3Fill 16:9
4Fill 4:3
5Fill 2.35:1
11 Anamorphic Lens
LST1 and LST2
Lamp status
Value Description
0 Defect
1Warming up
2Lamp is on
3Lamp is off
4Lamp is cooling down
5Lamp is not present
GABS
Set Gamma abs value
Value Description
0 Film 2.2
1 Film 2.8
2Video 1
3Video 2
4 Film 2.4
5 Film 2.6
7 Computer 1
8 Computer 2
9Linear (when available)
10 AD calibration (when available)
11 DICOM (when available)
12 DICOM ambient 10 LUX (when available)
13 DICOM ambient 60 LUX (when available)
14 DICOM ambient 180 LUX (when available)
15 DICOM ambient 250 LUX (when available)
16 DICOM ambient 300 LUX (when available)
17 DICOM ambient 400 LUX (when available)
20 Custom 1 (when available)
21 Custom 2 (when available)
22 Dynamic (when available)
3. ASCII Command Sets
601-0381-00_GP3/GP4
Sicilium_1_24
17
