Barco LX-5 SERIES User manual

If you seek the ultimate in resolution and image quality, there is no better
choice than Barco’s LX-5.
Barco’s LX-5 pushes innovative LCoS display technology to its limits by being
the world’s first projector with an incredibly detailed resolution of 10 million
pixels, and a 10,000:1 high dynamic contrast ratio. This results in the best,
most detailed image quality currently available on the market.
The LX-5 produces high-density pixels to paint images with such fine detail
that they enhance the human perception of reality. This level of accuracy is
perfect for applications such as product design, model review, aerial views,
close-up image analysis and other purposes that require highly detailed visu-
alization.
Up to four sources with a resolution greater than 1080p HD can be
simultaneously displayed with Barco’s LX-5, with each image retaining its
native high resolution and outstanding color qualities. Cost-effective, easy to
install and maintain, the LX-5 is the ideal single-projector solution for any
visualization environment that requires pristine, ultra-realistic image and
color quality.
LX-5
10 megapixel LCoS projector for ultra-realistic visualization

www.barc .c m
R5990106 December 2007
The information and data given are typical for the equipment described.
However any individual item is subject to change without any notice.
The latest version of this product sheet can be found on www.barco.com.
LX-5 technical specifications
EMEA & ROW
Noordlaan 5
8520 Kuurne - Belgium
Tel. [phone]
Fax [phone]
Barco
Presentation & Simulation Division
[e-mail]
USA
600 Bellbrook Avenue
Xenia, OH 45385-4053
Tel. [phone]
Fax [phone]
APAC
7F, Fen ang Road 138
200 031 Shanghai - China
Tel. [phone]
Fax [phone]
Dimensi ns
Light utput
4,500 lumens
C ntrast rati
> 10,000:1 contrast ratio
Res luti n
4,096 x 2,400 pixels (10Mp)
Display techn l gy
LCoS
Lamps
Lamp
800W Xenon
Lamp lifetime (typical)
Warranted 750 hrs - max 1,500 hrs
Dimensi ns
Weight
Body only: 50kg / 110 lbs
Height - width - length
390 x 660 x 830 mm
15.35 ” x 25.99 ” x 32.67 ”
Lenses
Available z m lenses
TLB HB (1.5 - 1.9:1) included
Available fixed f cal lenses
TLB HB (1:1)
Features
Special features
Up to 4 picture-and-picture data and images
Adjustable color temperature
High dynamic range compatible
Inputs and utputs
Inputs
4x dual DVI-D (up to 12 bit)
Cmmunicati n p rts
RS232 in/out on D9
RJ45 (10/100 Base-T Ethernet)
USB port
C mpatibility
Data
Computer graphics formats VGA, SVGA, XGA, SXGA, UXGA,
1080p HD, 2K up to 4K and 10M
Safety
Safety regulati ns
UL 60950
CE compliant
RoHS and WEEE compliant
P wer
AC p wer
100 - 240 VAC/50-60 Hz
Max. p wer c nsumpti n
1500 Watt
Order inf
Order inf
LX-5 R9011220
