Barmesa Pumps BSP15ICU Instruction manual

Installation, Operation &
Maintenance Manual
Self-Priming Frame
Mounted Pump
BSP15ICU,
BSP20ICU &
BSP25ICU
3" x 3"
Universal Drive
IMPORTANT! - Read all instructions in this manual before operating or servicing
a pump.
barmesapumps.com

Before installation, read the following
instructions carefully. Failure to
follow instruction and safety
information could cause serious
bodily injury, death and/or property
damage. Each Barmesa product is
carefully inspected to insure proper
performance. Closely following these
instructions will eliminate potential
operating problems, assuring years
of trouble-free service.
01
General Safety Information
IMPORTANT! - Barmesa Pumps is not
responsible for losses, injury or
death resulting from failure to
observe these safety precautions,
misuse, abuse or misapplication of
pumps or equipment.
I n s t a l l a t i o n a n d
servicing is to be conducted by
qualified personnel only.
WARNING
A L L R E T U R N E D
P R O D U C T S M U S T B E
CLEANED, SANITIZED, OR
DECO N TA M I N AT E D PRIOR TO
SHIPMENT, TO INSURE EMPLOYEES
WILL NOT BE EXPOSED TO HEALTH
HAZARDS IN HANDLING SAID
MATERIAL. ALL APPLICABLE LAWS
AND REGULATIONS SHALL APPLY.
Keep clear of suction and
discharge openings. Do not
insert fingers in pump with
power connected; the rotating cutter
and/or impeller can cause serious
injury.
Always wear eye protection
when working on pumps. Do
not wear loose clothing that
may become entangled in moving
parts.
Pumps build up heat
and pressure during
operation. Allow time
fo r p um p s t o c o o l
DANGER
before handling or servicing the
p u m p o r a ny a c c e s s o r y i tem s
associated with or near the pump.
WARNING
"Danger" indicates an
imminently hazardous situation
which, if not avoided, WILL result in
death or serious injury.
"Warning" indicates
an imminenty hazardous situation
which, if not avoided, MAY result in
death or serious injury.
"Caution" indicates a
potentially hazardous situation
which, if not avoided, MAY result in
minor or moderate injury.
DANGER
CAUTION
Operation against a
closed discharge valve
will cause premature
bearing and seal failure
WARNING
on any pump, and on end suction and
self priming pump the heat build may
cause the generation of steam with
resulting dangerous pressures. It is
recommended that a high case
temperature switch or pressure relief
valve be installed on the pump body.
M a k e s u r e l i f t i n g
handles are securely fastened each
time before lifting. Do not operate
pump without safety devices in place.
Always replace safety devices that
have been removed during service or
repair. Secure the p ump in it s
operating position so it can not tip
over, fall or slide.
CAUTION
barmesapumps.com
Installation, wiring, and
junction connections must be in
accordance with the National Electric
Code and all applicable state and local
codes. Requirements may var y
depending on usage and location.
WARNING
T h i s p u m p i s n o t
i n t e n d e d f o r u s e i n
swimming pools or water
installations where there is
DANGER
human contact with pumped fluid.
D o n o t u s e t h e s e
pumps in water over 160º F. Do not
exceed manufacturers recommended
maximum performance, as this could
cause the motor to overheat.
WARNING
Risk of electric shock. To
reduce risk of electric shock,
always disconnect pump
from power source before
DANGER
handling any aspect of the pumping
system. Lock out power and tag.
C a r e f u l l y r e a d
instruction manuals supplied with
motor or engine before operating or
servicing.
WARNING
These pumps are not to
be installed in locations
classified as hazardous in
accordance with the National
Electric Code, ANSI/NFPA 70.
DANGER
IMPORTANT! - Prior to installation,
record Model Number, Serial, Amps,
Voltage, Phase and HP from pump
name plate for the future reference.
Also record the Voltage and Current
Readings at Startup:
Model Number: ____________________
Serial: ____________________
Amps:_______ Voltage:_______
Phase:_______ HP:_______

SUCTION/DISCHARGE: 3" x 3" NPT, female flange.
LIQUID TEMPERATURE: 160 °F (71 °C) max.
VOLUTE: Cast iron ASTM A-48 class 30.
BODY: Cast iron ASTM A-48 class 30.
PEDESTAL: Cast iron ASTM A-48 class 30.
IMPELLER: Open, trash type, dynamically balanced. Cast iron ASTM A-48 class 30.
SHAFT: Stainless steel.
SHAFT SLEEVE: Stainless steel.
O-RINGS: Buna-N.
PAINT: Air dry enamel, water based.
SEAL: Single mechanical with lip seal, water lubricated. Ceramic stationary part, carbon
ring seal and exclusion in the rotating part. Buna-N elastomer and stainless steel
spring.
CHECK VALVE: Flap-neoprene, weight of steel.
HARDWARE: Steel.
BEARING-DRIVE END: Single row, ball, grease lubricated.
BEARING-PUMP END: Single row, ball, grease lubricated.
SHIM SET: Stainless steel.
OPTIONAL: Bronze fitted volute and impeller.
02
Specifications & Dimensions
barmesapumps.com
BARMESA
13.07"13.07"13.07"
3.39"
8.27"8.27"8.27"
15.94"15.94"15.94"
13.77"13.77"13.77"7.5"7.5"7.5"
3.15"3.15"3.15"
7"7"7"
1.1" DIA1.1" DIA1.1" DIA
0.25" KEYWAY0.25" KEYWAY0.25" KEYWAY
5.1"5.1"5.1"
3.39"

03
Recommendations, Warnings & Installation
Receiving inspection
Upon receiving the pump, it should
be inspected for damage or
shortages. If damage has occurred,
file a claim immediately with the
company that delivered the pump. If
the manual is removed from the
packaging, do not lose or misplace.
Storage
Any product that is stored for a
period longer than six (6) months
from the date of purchase should be
bench tested prior to installation. A
bench test consists of, checking the
impeller to assure it is free turning
and a run test to assure the motor
(and switch if provided) operate
properly.
Controls
Manual models require a separate
approved pump control device or
panel for automatic operation. Be
sure the electrical specification of the
control selected properly match the
electrical specifications of the pump.
Installation
Location - The pump should be
located as near as possible to the
liquid to be pumped and in no case
should the pump be more than 25
feet above the surface of the liquid
supply. The pump should always be
as level as possible.
Allow a minimum of 18 inches in
front of the pump case cover or
hatch cover to permit easy removal
and access to the interior of the
pump. On belt driven units, allow a
minimum of 10 inches at the shaft
end to permit easy removal of the
pedestal or rotating cartridge.
All pump units rotate clockwise when
looking from the driven end of the
pump. The impellers are threaded on
the shaft and it is necessary to slide
one half of the flexible coupling back
when checking rotation in order to
eliminate the possibility of
unscrewing the impeller and
damaging the pump. NOTE: Where
impellers thread on pump shaft,
never check the direction of electric
motor rotation without first
disconnecting flexible coupling.
Locate the pump on a firm footing to
make sure the pump will not move
due to vibration. Flex coupled and V-
belt driven units should be
permanently grouted onto a cement
foundation. The pumps should be
level to provide favorable operating
conditions. In addition, the flexible
coupling should be realigned after
grouting in order to eliminate
excessive wear on the coupling.
Suction - It is advisable to use a
suction line of the same size as the
pump port size. All horizontal suction
lines should slope up to the pump to
avoid trapped air pockets. An
adjustable stand, pipe clamp or floor
flange must be installed to support
the weight of the suction line. Using
a smaller suction line than the pump
port size can cause internal damage
to the pump.
Pump Lubrication - The only part of
the pump requiring lubrication is the
bearing housing. The impeller and
shaft seal are lubricated by the liquid
being pumped and need no other
lubrication.
The bearing housing is factory filled
with 90 weight oil, for bearing
lubrication. The oil level in the
bearing housing should be
periodically checked. This is
accomplished by removing the oil
dip stick and checking oil level
shown on it. If oil is required, add
through the dip stick hole.
D O N OT O P E R AT E
PUMP WITHOUT LIQUID IN PUMP
BODY AS OPERATING DRY WILL
RESULT IN DAMAGE TO THE SEAL.
CAUTION
THIS PUMP SHOULD
NOT BE OPERATED WITHOUT A
STRAINER ON THE END OF THE
SUCTION LINE TO PREVENT STICKS,
S T O N E S , R A G S A N D O T H E R
FOREIGN MATTER FROM BEING
DRAWN INTO THE IMPELLER. THE
STRAINER SHOULD BE CLEANED
REGULARLY TO INSURE FULL FLOW.
CAUTION
Discharge - Connect discharge hose
or pipe to the side outlet on the
discharge tee or to the discharge
elbow.
Operation
Priming - Remove the priming
plug(s) (25) in the top of the pump
body (18), and fill the pump body
completely with liquid as free of
solids as possible. In freezing
weather, the pump should be primed
with warm water, if possible, to
prevent any damage that may be
caused by ice films within the pump.
Starting - Start pump by applying
power to motor or by starting engine
as outlined in the ENGINE or MOTOR
INSTRUCTION MANUAL.
Shutdown - Operation may be
discontinued by stopping the engine
as outlined in the ENGINE MANUAL
or by disconnecting electric power if
motor driven. When the pump has
been operating in freezing weather
or in liquid containing a considerable
amount of solids, it is advisable to
drain the pump body by removing
drain plug and flushing the solids out
of the body. Replace the drain plug.
barmesapumps.com

04
Operation, Service & Repair
When replacing gasket and weight
assembly onto pump body make
sure that HINGE section of gasket is
at TOP and that LARGE weight is on
PUMP SIDE of gasket.
Body, Volute and Impeller -
Disconnect suction and discharge
piping. Remove hex. nuts (21) and
lockwashers (20) then remove body
(18) and O-ring (4) from seal plate
(38). Pull volute (15) and gasket (17)
from seal plate (38). Remove hex.
head screw (13) and shakeproof
washers (14). Unscrew the impeller
(12) from shaft (1) in the right hand
direction. Take note of the size and
quantity of shims (10) & (11) used.
Shaft Seal Service - Remove rotating
member, spring and retaining ring of
seal (9) from shaft. To remove
stationary, remove hex. nuts (34) and
lockwashers (37) and pull seal plate
(38) from coupling head (32). Press
stationary out of seal plate. If any
part shows wear or damage replace
complete seal (9).
HANDLE SEAL PARTS
WITH EXTREME CARE. DO NOT
DAMAGE LAPPED FACES.
CAUTION
Press off bearings (7) & (8) from shaft
(1). Remove hex. head screws (44),
lockwashers (47) & hex. nuts (48) and
pull coupling head (32) from bearing
frame (2), replace lip seal (36).
To reassemble, lightly oil ring and
press stationary into seal plate (38).
Lightly oil inner surface of stationary
and replace seal plate (38) onto
couplig head (32). With lapped
surface facing pedestal, slide rotating
member onto shaft until lapped faces
of rotating member and stationary
are together.
At reassembly make sure to use a
combination of impeller shims (10)
and (11) to result in an impeller-to-
body clearance of approximately
0.015" max.
Pedestal & Shaft - Remove hex.
head screws (5) and lockwashers (6)
from bearing frame (2). Remove
bearing cap (28), o-ring (41), lip seal
(42) and snap ring (52). Remove shaft,
slinger and bearing assembly. To
replace inboard bearing (7) remove
snap ring (27) and slinger (3).
REASSEMBLE REMAINDER OF PUMP
IN OPPOSITE ORDER. Refill coupling
head with gear oil and pedestal with
grease.
Check Valve Service - To clean out or
repair check valve, disconnect
suction piping. Remove hex. head
screw (24) and suction flange (23).
Remove gasket (22B), weights (22A),
(22F), hex. head screw (22D),
lockwasher (22C) and hex. nut (22E)
and replace if worn or damaged.
Service & Repair
barmesapumps.com

05
Drawings
barmesapumps.com

06
Service & Repair
barmesapumps.com
For repair part please supply: Model Number and Serial as shown on Name Plate, and Part Description and Part Number as shown
on parts list.

07
Repair Parts
barmesapumps.com
For repair part please supply: Model Number and Serial as shown on Name Plate, and Part Description and Part Number as shown
on parts list.
ITEM QTY. PART # DESCRIPTION MATERIAL
1 1 30400776 Shaft Stainless
2 1 03040031 Bearing Frame Cast Iron
3 1 92010014 Slinger Buna N
4 1 92010062 O-Ring Buna N
5 4 91010343C Hex Head Screw 5/16-18UNC x 1" lg. Stainless
6 4 91010060 Lockwasher 5/16" Stainless
7 1 31020022 Inboard Bearing
8 1 31020044 Outboard Bearing
9 1 31030156 Shaft Seal C/CE/N/SS
10 3 91010121 Shim 0.010" Stainless
11 2 91010130 Shim 0.031" Stainless
03140233 Cast Iron
03140226 Bronze
03140234 Cast Iron
03140227 Bronze
03140235 Cast Iron
03140228 Bronze
13 1 91010349B Hex Head Screw 1/2"-20UNF x 1" SS Stainless
14 2 91010081 Shakeproof Washer 1/2" SS Stainless
03120040 Cast Iron
03120036 Bronze
03120041 Cast Iron
03120037 Bronze
16 2 91010181 Volute Pin
17 1 92010122 Volute Gasket
18 1 03090098 Body Cast Iron
19 5 91010378C Stud 1/2"-13UNC x 2" lgo. SS Stainless
20 5 91010062 Lockwasher 1/2" SS Stainless
21 5 91010415 Hex Nut 1/2" SS Stainless
22 1 Check Valve Assy
22A 1 03080007 Weight Ø2¾"
22B 1 92010217 Gasket Neoprene
22C 1 91010011C Lockwasher 1/4" SS Stainless
22D 1 91010342 Hex Head Screw 1/4"-20 x 1.0" Stainless
22E 1 91010411 Hex Nut 1/4" Stainless
22F 1 03080012 Weight Ø4"
23 1 03050022 Suction Flange Cast Iron
24 3 91010263 Hex Head Screw 1/2"-13UNC x 1½"
25 1 93010141 Pipe Plug 1" NPT
26 1 93010141 Pipe Plug 1" NPT
27 1 31010004 Snap Ring
28 1 03170022 Bearing Cap
29 1 30400633 Shaft Key 1/4" x 1/4" x 2¼" lg.
31 4 91010374 Stud 3/8"-16UNC x 2" SS Stainless
32 1 03020054 Coupling Head Cast Iron
33 1 93010149 Pipe Plug 3/8" NPT
34 4 91010433 Hex Nut 3/8"-16UNC SS Stainless
36 1 31010017H Lip Seal
37 4 91010061 Lockwasher 3/8" SS Stainless
38 1 03180064 Seal Plate
39 1 92010066H O-Ring Buna N
41 1 92010066G O-Ring Buna N
42 1 31120013 Lip Seal
43 1 93010041 Relief Fitting 1/8" NPT
44 4 91010348C Hex Head Screw 7/16-14UNC x 2½" lg. Stainless
47 4 91010071 Lokwasher 7/16" Stainless
48 4 91010434 Hex Nut 7/16"-14UNC Stainless
49 4 oz. 31010035 Gear Oil, ISO VG68
50 1 80062501 Vented Plug
51 4 oz. 91010043 Grease, Lithium Saop Base, NGLI-2
52 1 31010004 Snap Ring
Impeller 15CCE-ICU Ø6"
Volute 15-20CCE-ICU
Impeller 20CCE-ICU Ø6"
Impeller 25CCE-ICU Ø7"
Volute 25CCE-ICU
15
12 1
1

08
Troubleshooting Chart
Pump leaks at shaft 1. Worn mechanical seal
2. Replacement seal not installed properly
1. Replace
2. Follow Maintenance instructions carefully
1. Reinforce
2. Disassemble pump and remove
3. Replace impeller
4. Check suction line for proper size and check valve in suction
line if completely open, remove any sharp bends before pump
and shorten suction line
5. Make necessary adjustments
Pump vibrates and/or
makes excessive noise
1. Faulty suction piping (air leak)
2. Pump located too far from fluid source
3. Gate valve closed
4. Clogged strainer
5. Fouled foot-valve
6. Discharge height too great
7. Fouled impeller
8. Faulty mechanical seal
Pump runs but no fluid
1. Replace
2. Replace
3. Open
4. Clean or replace
5. Clean or replace
6. Lower the height
7. Clean or replace
8. Replace
1. Total head lower than pump rating, unit
delivering too much water
2. Specific gravity and viscosity of liquid being
pumped different than the pump rating
3. Speed to high
1. Increase back pressure on pump by turning gate valve on
discharge line to partially closed position that will not overload
motor
2. Consult factory
3. Check and correct, lower speed
Pump overloads driver
1. Mounting plate or foundation not rigid
enough
2. Foreign material in pump causing unbalance
3. Impeller bent
4. Cavitation present
5. Piping not supported to relieve any strain on
pump assembly
Corrective Action
Always disconnect the pump from the electrical power source before handling.
If the system fails to operate properly, carefully read instructions and perform maintenance recommendations.
1. Air leak in suction line
2. When unit was last turned off, water
siphoned out of pump casing
3. Suction head higher than pump designed for
4. Insufficient inlet pressure or suction head
5. Clogged foot-valve, strainer, or pump
6. Defective wearplate(s)
1. Repair or replace suction line
2. Refill (reprime) pump casing before restarting
3. Lower suction head, install foot-valve and primer
4. Increase inlet pressure by adding more water to tank or
increasing back pressure by turning gate valve on discharge line
to partially closed position
5. Unclog, clear or replace as necessary
6. Replace
Loss of suction after
satisfactory operation
1. Fill pump casing. Using a foot-valve will extend pump life and
facilitate immediate priming
2. Shorten suction head
3. Lower suction head, install foot-valve and prime.
4. Disassemble pump and clean out impeller
5. Repair or replace suction line
6. Match foot-valve to piping or install one size larger foot-valve
7. Disassemble pump and replace impeller
8. Submerge lower in water
9. Increase inlet pressure by adding more water to tank or
increasing back pressure by turning gate valve on discharge line
partially closed position
10. Increase pipe size to pump inlet size or larger
11. Replace
12. Open
13. Clean or replace
14. Clean or replace
15. Increase speed
1. Casing not filled with water
2. Total head too high
3. Suction head higher than pump designed for
4. Impeller partially or completely plugged
5. Hole or leak in suction line
6. Foot-valve too small
7. Impeller damaged
8. Foot-valve or suction line not submerged
deep enough in water; pulling air
9. Insufficient inlet pressure or suction head
10. Suction piping too small
11. Casing gasket leaking
12. Suction or discharge line valves closed
13. Piping is fouled or damaged
14. Clogged strainer or foot-valve
15. Incorrect engine speed
Little or no discharge
and unit will not prime
Symptom Possible Cause(s)
barmesapumps.com
