BARRON Exitronix NXFX Series User manual

IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations,
if applicable.
• Do not mount near gas or electrical heaters.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• For 2CI operation - ensure that both AC power and auxiliary power are not simultaneously live.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
SAVE THESE INSTRUCTIONS!
Technical Support ■ [phone] ■ [email protected]
NXFX Series
Installation Instructions
10070226 REV 1 - 08/20 800-533-3948 www.barronltg.com
1

Ceiling or End Mount (Fig. 1a)
1. Remove the lens by removing the (6) screw caps and the (6) screws with O-rings and set all aside.
2. Remove the EXIT template and diffuser and set both aside.
3. Remove the inner frame by removing the (4) screws and set aside.
4. Punch out desired knockouts located in the top or side of the enclosure.
5. Remove the small rectangular gasket with two holes from the gasket sheet and position it between the enclosure and
the canopy, aligning the two holes in each part.
6. Secure the canopy to the enclosure with the (2) sets of threaded bushings and nuts, ensuring that the canopy has a
proper seal with the enclosure.
7. Remove the square gasket from the gasket sheet, then route wires out through the canopy, followed by the mounting
plate and the square gasket. Ensure that the mounting plate is in the correct orientation (see Fig. 1b).
8. Make electrical connections; see Electrical Connections section.
9. Secure the mounting plate to the J-box.
10. Secure the canopy to the mounting plate, ensuring that the canopy has a proper seal with the mounting surface.
11. Connect the battery, if included.
Fig. 1a J-Box
Square Gasket
J-Box Mounting
Screw
Diffuser
Screw
Cap
EXIT Template
Lens
O-Ring
Stainless Steel
Screw
Enclosure
Inner Frame
Frame
Screw
J-Box Mounting
Plate
Canopy
O-Ring
Stainless Steel
Screw
Small Rectangular
Gasket
Threaded
Bushing
Mounting Plate “feet” face
away from the J-Box
Fig. 1b
NXFX Series
Installation Instructions
10070226 REV 1 - 08/20 2800-533-3948 www.barronltg.com

Ceiling or End Mount, Continued
12. Replace the inner frame using the (4) screws from Step 3.
13. Remove the chevron(s) from the EXIT template, if desired.
14. Replace the diffuser and EXIT template.
15. Replace the lens and secure using the (6) screws with O-rings from Step 1. Ensure the O-rings make a proper seal.
16. Cover the (6) screws with the (6) screw caps from Step 1.
Wall Mount (Fig. 1)
1. Remove the lens by removing the (6) screw caps and the (6) screws with O-rings and set all aside.
2. Remove the EXIT template and diffuser and set both aside.
3. Punch out one of the center knockout and any desired knockouts for mounting to the junction box located in the
backplate.
4. Route wires out through the center hole of the backplate and the corresponding hole in the back gasket.
5. Make electrical connections; see Electrical Connections section.
6. Secure the unit to the J-box, ensuring that the gasket aligns properly with the backplate and makes a proper seal with
the backplate and the wall.
7. Connect the battery, if included.
8. Remove the chevron(s) from the EXIT template, if desired.
9. Replace the diffuser and EXIT template.
10. Replace the lens and secure using the (6) screws with O-rings from Step 1. Ensure the O-rings make a proper seal.
11. Cover the (6) screws with the (6) screw caps from Step 1.
Fig. 2 J-Box
Back Gasket
J-Box Mounting
Screw
Diffuser
Screw
Cap
EXIT Template
Lens
O-Ring
Stainless Steel
Screw
Enclosure
Backplate
NXFX Series
Installation Instructions
10070226 REV 1 - 08/20 3
800-533-3948 www.barronltg.com

Fig. 3
Wall Mount Using Mounting Brackets (Fig. 3)
Note: For optimal weatherproofing when using the mounting brackets, Barron Lighting
recommends using flexible, UL Listed for Wet Location conduit as the means to provide line
voltage to the unit. Use flexible conduit only; not for use with rigid conduit.
1. Secure the (2) mounting brackets to the back of the fixture using the (4) bracket mounting
screws (provided).
2. If using a J-box, remove the (2) rectangular gasket pieces from the sides of the back gasket and discard. Attach the
modified back gasket to the back of the fixture.
3. Follow steps 1-2 in the Wall Mount section.
4. Remove the appropriate knockouts depending on the line voltage access:
a. If using a J-box, remove one of the center knockouts from the back of the fixture. For a better seal, remove
additional knockouts to allow for screws to secure the fixture to the J-box.
b. If using flexible conduit, remove the inner frame by removing the (4) screws and set aside. Punch out the
desired knockout located in the top or side of the enclosure.
5. Using the brackets as a template, align the fixture to the mounting location and mark the drill locations on the wall.
6. Install wall anchors in the (4) marked locations.
7. Make electrical connections; see Electrical Connections section.
8. Secure the fixture to the wall using (4) screws. If using a J-box and additional knockouts were removed in Step 4a,
secure the fixture to the J-box at this time.
9. Connect the battery, if included.
10. If the inner frame was removed, resecure it to the fixture using the (4) screws from Step 4b.
11. Follow steps 8-11 in the Wall Mount section.
Modified Back
Gasket
Mounting
Bracket
Screw
Wall
Anchor
Wall
Screw
Mounting
Bracket
NXFX Series
Installation Instructions
10070226 REV 1 - 08/20 4800-533-3948 www.barronltg.com

Electrical Connections
All electrical connections should be made inside
the J-box. Make electrical connections as follows:
Note: Cap unused leads to prevent shorting.
AC Only or With Battery Models (Fig. 4 and 5)
120 or 277VAC
White - Common
Black - 120VAC
Red - 277VAC
Two Circuit Input (2CI) Models (Fig. 6 and 7)
2CI option models have two inputs, one for the
AC input and the other for the auxiliary input.
Please make connections as follows:
120 or 277VAC Line Auxiliary Line
White - Common Gray - Common
Black - 120VAC Yellow - 120 or 277VAC
Orange - 277VAC
Note: The AC and auxiliary power cannot be
simultaneously live, consult factory for a
solution.
Fig. 4 - AC Only
Fig. 5 - With Battery
Fig. 6 - 2CI with 120VAC Input
Fig. 7 - 2CI with 277VAC Input
Red (277VAC)
Black (120VAC)
White (Com)
LED
Indicator
PCB/LED Board
Transformer
Red (277VAC)
Black (120VAC)
White (Com)
Transformer
LED
Indicator
Magnetic
Test Switch
Battery
LED
Indicator 2CI1 Relay
Generator/UPS
Yellow (120VAC)
Gray (Com)
Utility Power
Black (120VAC)
White (Com)
Transformer
PCB/LED Board
LED
Indicator 2CI7 Relay
Generator/UPS
Yellow (277VAC)
Gray (Com)
Utility Power
Orange (277VAC)
White (Com)
Transformer
PCB/LED Board
PCB/LED Board
NXFX Series
Installation Instructions
10070226 REV 1 - 08/20 5 800-533-3948 www.barronltg.com

Self-Test/Self-Diagnostics (G2)
Operation
The purpose of this option is to provide Self-testing and Self-diagnostic capabilities to the EXIT sign. At predetermined
intervals, the EXIT sign will automatically switch into battery mode. Refer to the Self-Test Features section of this page
for timing details. The EXIT sign will also perform various Self-diagnostic tests of the unit. Visual signaling will alert
maintenance personnel to a fault of the EXIT sign electronics, battery and/or battery charger. The circuitry continuously
monitors the operating condition of the EXIT sign and battery charging circuit/battery supply voltage. Refer to the LED
Indicator section below for fault reporting details.
Self-Test Features
• The EXIT sign will automatically switch to battery mode every 30 days for a period of 30 seconds.
• The EXIT sign will automatically switch to battery mode every 180 days for a period of 30 minutes.
• The EXIT sign will automatically switch to battery mode every 365 days for a period of 90 minutes.
LED Indicator
The EXIT sign is equipped with a bi-color LED, which displays green and/or red.
• A steady green LED indicates that normal AC power is being supplied to the EXIT sign and the battery is fully charged.
• A flashing green LED indicates that the EXIT sign is undergoing a test.
• A flashing red and green LED indicates that the battery is being charged.
• A red LED indicates whenever the Self-diagnostics system has detected a fault condition. Refer to the chart below
when a red LED is displayed:
Test Switch Feature
MANUAL TEST – Placing the provided magnet near the magnetic test switch and pulling it away
will switch the EXIT sign into battery mode for 30 seconds.
Use in accordance with local building codes.
Red LED Indication
Steady
Blinking 1 Time
Blinking 2 Times
Blinking 4 Times
Unit Fault
Battery Disconnected
Battery Failure
LED Failure
Battery Charge Failure
Corrective Action
Check Battery Connection
Replace Battery
Check Battery then Consult Factory
Check Battery then Consult Factory
Note: For fixtures with
battery only
