BARRON Exitronix CP-EX Series User manual

Technical Support ■ [phone] ■ [email protected]
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations if
applicable.
• Do not mount near gas or electrical heaters.
• Do not use outdoors.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
• For use with metal enclosed wiring systems.
SAVE THESE INSTRUCTIONS!
CP-EX Series
Installation Instructions
10070224 REV 1 - 07/20 1800-533-3948 www.barronltg.com

Surface Wall Mount
1. Install the (4) mounting feet to the back of the fixture. (Fig. 1)
2. Remove the (2) cover screws and set aside. (Fig. 2)
3. Swing down the cover assembly and the reflector plate. (Fig. 3)
4. Drill a 7/8” hole in the back of the fixture (see Fig. 2) for the AC supply
and/or remote load, making sure to avoid locations that would interfere
with the contents within the housing. Install the bushing (provided).
5. Mount the fixture to the mounting surface by fastening the mounting feet
using (4) fasteners (provided by others).
6. Make electrical connections; see Electrical Connections section.
7. Connect the battery to the PCB using the wire lead(s) from the positive
circuit board terminal (+) to the positive terminal connector on the battery.
Note: For large units, the battery/batteries may be shipped separate from
the housing. Install the battery/batteries into the housing and make the
appropriate battery connections.
8. If desired, remove appropriate chevrons. Chevrons are made of 2 layers
of self-adhesive vinyl. To remove, manuver a utility knife underneath the
desired chevron so that both layers of vinyl are penetrated. Carefully peel
the chevron away from the lens, working around the perimeter of the
chevron until fully removed. Remove the backing from the double sided
tape, align, then adhere the colored diffuser to the inside of the cover.
(Fig. 4)
9. Position the reflector and secure with ties.
10. Close cover and secure cover screws.
Fig. 1
Cover
Screws
Mounting
Feet
Magnetic
Test Switch
Battery
Fig. 3
Fig. 4
Reflector
Plate
Cover
Assembly
Fig. 2
Drill Out
Hole in
Back of
Fixutre
CP-EX Series
Installation Instructions
10070224 REV 1 - 07/20 2800-533-3948 www.barronltg.com

Orange (277VAC) or Red (347VAC)
Black (120VAC)
White (Com)
LED
Indicator Transformer
LED
Indicator
Electrical Connections
All electrical connections should be made inside the
J-box. Make electrical connection as follows:
Note: Cap unused leads to prevent shorting.
AC Only or With Battery Models (Fig. 5 and 6)
120, 277, or 347VAC
White - Common
Black - 120VAC
Orange - 277VAC
or Red - 347VAC
Two Circuit Input (2CI) Models (Fig. 7)
2CI option models have two inputs, one for the AC
input and the other for the auxiliary input. Please
make connections as follows:
105-360VAC Line Auxiliary Line
White - Common Blue - Common
Black - 105-360VAC Brown - 105-360VAC
External DC Supply Models (Fig. 8)
If emergency power from an external DC power
supply is desired, make connections as follows:
120, 277, or 347VAC External DC Supply
White - Common Purple - Negative
Black - 120VAC Yellow - 6-24VDC
Orange - 277VAC
or Red - 347VAC
Note: The AC and auxiliary power cannot be
simultaneously live, consult factory for a
solution.
NiCad Battery
Fig. 5 - AC Only
Fig. 6 - With Battery
Fig. 7 - Two Circuit Input (2CI)
2CI Relay
Generator/UPS
Brown (105-360VAC)
Blue (Com)
Utility Power
Black (105-360VAC)
White (Com)
Fig. 8 - External DC Supply
Orange (277VAC) or Red (347VAC)
Black (120VAC)
White (Com)
Yellow (6-24VDC)
Purple (Negative) External DC Supply
LED
Indicator
Transformer
Transformer
PCB/LED Board
PCB/LED Board
PCB/LED Board
PCB/LED Board
Orange (277VAC) or Red (347VAC)
Black (120VAC)
White (Com)
LED
Indicator Transformer
CP-EX Series
Installation Instructions
10070224 REV 1 - 07/20 3800-533-3948 www.barronltg.com

CP-EX Series
Installation Instructions
10070224 REV 1 - 07/20 4800-533-3948 www.barronltg.com
Self-Test/Self-Diagnostics (G2)
Operation
The purpose of this option is to provide Self-testing and Self-diagnostic capabilities to the EXIT sign. At predetermined
intervals, the EXIT sign will automatically switch into battery mode. Refer to the Self-Test Features section of this page for
timing details. The EXIT sign will also perform various Self-diagnostic tests of the unit. Visual signaling will alert maintenance
personnel to a fault of the EXIT sign electronics, battery and/or battery charger. The circuitry continuously monitors the
operating condition of the EXIT sign and battery charging circuit/battery supply voltage. Refer to the LED Indicator section
below for fault reporting details.
Self-Test Features
• The EXIT sign will automatically switch to battery mode every month for a period of 5 minutes.
• The EXIT sign will automatically switch to battery mode twice, 24 hours apart, every 6 months for a period of 90
minutes.
LED Indicator
The unit is equipped with a bi-color LED, which displays green and/or red.
• A steady green LED indicates that normal AC power is being supplied to the EXIT sign.
• A flashing green LED indicates that the EXIT sign is undergoing a test.
• A flashing red and green LED indicates that the battery is under high charge.
• A red LED indicates whenever the Self-diagnostics system has detected a fault condition.
Refer to the chart below when the red “UNIT ALERT” LED is blinking:
Test Button Features
LED TEST – Pressing and holding the test button for 3 seconds will test the LEDs. The LED indicator will blink red 3 times.
MANUAL TEST – Pressing the test button will switch the unit into battery mode for a set amount of time. The desired length
of the test is determined by the number of times the test button is pressed.
• Pressing the test button once will switch the unit into battery mode for a period of 2 seconds.
• Pressing the test button twice within 2 seconds will switch the unit into battery mode for a period of 15 minutes.
Pressing and holding the test button for 5 seconds while the unit is MANUAL TEST mode will cancel the manual test and
return the unit to normal AC power.
Use in accordance with local building codes.
Red LED Indication
Steady
Blinking 1 Time
Blinking 2 Times
Blinking 3 Times
Unit Fault
Battery Disconnected
Battery Failure
Battery Charge Failure
LED Failure
Corrective Action
Check Battery then Consult Factory
Replace Battery
Check Battery then Consult Factory
Check Battery then Consult Factory
