Bartec APEX (APC) 07-3704 Series User manual

Manual Pressurized Cabinet
APEX (APC)
SILAS (SPC)

BARTEC GmbH
Max-Eyth-Straße 16
97980 Bad Mergentheim
GERMANY
Phone: [phone]
Fax: [phone]
Support: [email protected]
Internet: www.bartec.de
Operating Instructions
Pressurized Cabinet
APEX (APC), Type 07-3704-****/****
ATEX / IECEx Zone 1 / 21
SILAS (SPC), Type A7-3704-****/****
ATEX / IECEx Zone 2 / 22
Document Number: 01-3704-7D0001
Revision: -

APEX / SILAS
Pressurized Cabinet
Table of contents
Rev. - 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Page 1 of 40
0Table of contents
0Table of contents ................................................................................................... 1
1About these operating instructions ......................................................................... 4
Highlighting in the document ..................................................................................... 5
Warnings.................................................................................................................... 5
Symbols and icons ..................................................................................................... 6
Technical changes ..................................................................................................... 6
Languages ................................................................................................................. 6
2Safety.................................................................................................................... 7
Intended use.............................................................................................................. 7
Exclusive purpose...................................................................................................... 7
Improper use.............................................................................................................. 7
Safety instructions .................................................................................................... 7
General ...................................................................................................................... 7
Safety instructions for operation ............................................................................... 8
Instructions for safe use ............................................................................................ 9
Warranty .................................................................................................................. 10
Obligations of the owner .......................................................................................... 11
Instructions for use.................................................................................................. 11
Other applicable documents.................................................................................... 11
Standards complied with ......................................................................................... 12
APEX pressurized cabinet ........................................................................................ 12
SILAS pressurized cabinet ....................................................................................... 13
Marking and test certificate..................................................................................... 14
APEX pressurized cabinet, Zone 1 / 21 ..................................................................... 14
APEX pressurized cabinet, category Gb / Db, type pyb, type 07-3704-11**/**** ..... 14
APEX pressurized cabinet, category Gb / Db, type pxb, type 07-3704-12**/**** ..... 14
APEX pressurized cabinet, category Gb, type pyb, type 07-3704-21**/****............. 15
APEX pressurized cabinet, category Gb, type pxb, type 07-3704-22**/****............. 15
APEX pressurized cabinet, category Db, type pyb, type 07-3704-31**/****............. 15
APEX pressurized cabinet, category Db, type pxb, type 07-3704-32**/****............. 15
SILAS pressurized cabinet, Zone 2 / 22 .................................................................... 16

Table of contents
APEX / SILAS
Pressurized Cabinet
Page 2 of 40 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Rev.-
SILAS pressurized cabinet, category Gc / Dc, type pzc, type A7-3704-11**/****..... 16
SILAS pressurized cabinet, Category Gc, type pzc, type A7-3704-21**/****............ 16
SILAS pressurized cabinet, category Dc, type pzc, type A7-3704-31**/****............ 16
Avoidance of damage to property............................................................................. 17
Short circuit due to improper connection................................................................. 17
Storage at an excessively high temperature............................................................. 17
Aggressive cleaning agents...................................................................................... 17
Danger to health due to improper disposal............................................................... 17
3Product description.............................................................................................. 18
General .................................................................................................................... 18
Pressurized cabinet ................................................................................................. 19
APEX pressurized cabinet, type pyb......................................................................... 19
APEX pressurized cabinet, type pxb......................................................................... 19
SILAS pressurized cabinet, type pzc ........................................................................ 19
4Transport and storage .......................................................................................... 20
Scope of delivery...................................................................................................... 20
Packaging ................................................................................................................ 20
Transport ................................................................................................................. 20
Storage .................................................................................................................... 21
Disposal................................................................................................................... 21
5Installation .......................................................................................................... 22
Requirements placed on the location....................................................................... 22
Special conditions placed on the location................................................................ 22
Erection ................................................................................................................... 23
Mobile erection........................................................................................................ 24
6Connections......................................................................................................... 25
Purging gas supply................................................................................................... 25
Protective gas.......................................................................................................... 25
Purging gas connection............................................................................................ 26
Purging gas discharge with the gas / dust version.................................................... 26
Electrical connections ............................................................................................. 27
Wiring requirements ................................................................................................ 27
Connections............................................................................................................. 27

APEX / SILAS
Pressurized Cabinet
Table of contents
Rev. - 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Page 3 of 40
7Commissioning .................................................................................................... 28
Initial commissioning............................................................................................... 28
Putting into operation .............................................................................................. 28
Type 0(A)7-3704-1***/**** (gas/dust)..................................................................... 28
Type 0(A)7-3704-2***/**** (gas) ............................................................................. 29
Type 0(A)7-3704-3***/**** (dust)............................................................................ 29
8Operation............................................................................................................. 30
Operating phases of the APEX (SILAS) pressurized cabinet...................................... 30
Process diagram of the operating phases ................................................................ 30
Preparatory phase ................................................................................................... 30
Purging phase.......................................................................................................... 31
Operating phase....................................................................................................... 31
Purging time ............................................................................................................ 32
Manual purging time ................................................................................................ 32
Automatic purging time............................................................................................ 32
Bypass operation ..................................................................................................... 33
Operation with safety foil......................................................................................... 34
9Putting out of operation........................................................................................ 35
Shut-down............................................................................................................... 35
Cooling and discharge times .................................................................................... 35
10 Maintenance and care .......................................................................................... 36
Maintenance work ................................................................................................... 36
Maintenance intervals ............................................................................................. 36
Visual inspection...................................................................................................... 37
Cleaning................................................................................................................... 37
Regular maintenance............................................................................................... 37
Repairs .................................................................................................................... 37
Faults and troubleshooting...................................................................................... 37
11 Technical data ..................................................................................................... 38
12 Notes................................................................................................................... 40

About these operating instructions
APEX / SILAS
Pressurized Cabinet
Page 4 of 40 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Rev.-
1About these operating instructions
Please read carefully before putting the device into operation.
Please observe the corresponding user manual.
This manual contains the information required for using the control unit in
accordance with its intended purpose. It is addressed to technically qualified
personnel.
Familiarity with and the technically perfect implementation of the safety
instructions and warnings described in this manual are preconditions for safe
installation and commissioning. The safety notes and warnings in these
operating instructions are given in a general manner and only qualified
personnel will have the necessary know how to interpret and implement them
correctly in specific individual cases.
These operating instructions are an integral part of the scope of delivery even
if, for logistical reasons, they can be ordered and delivered separately.
Should you require further information, please request the required
information from your local or responsible BARTEC branch. Read the
operating instructions and in particular the safety instructions
carefully before using the device.
Keep the operating instructions during the entire service life of the
device.
Make the brief instructions accessible to all persons entrusted with
handling the device.

APEX / SILAS
Pressurized Cabinet
About these operating instructions
Rev. - 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Page 5 of 40
Highlighting in the document
Warnings
Warnings are used in this user manual to warn of property damage and
personal injury.
Always read and follow these warnings.
Warnings are specially highlighted in this user manual and identified by
symbols:
DANGER
DANGER indicates a hazardous situation which, if safety measures are not
observed, may result in death or serious injuries with permanent damage
WARNING
WARNING indicates a hazardous situation which, if safety measures are not
observed, may result in serious injuries without permanent damage.
CAUTION
CAUTION indicates a hazardous situation which, if safety measures are not
observed, can result in minor injuries.
ATTENTION
ATTENTION indicates a hazardous situation which, if the safety measures
are not observed, may result in damage to property.
Explanation of the structure of a warning notice
WARNING WORD
Identifies the source of danger, cause of danger or type of danger
Consequence of non-compliance with the described safety measure.
Safety measure
Example of a warning notice
DANGER
Operation of the APEX (SILAS) pressurized cabinet in the case of damage!
Death or serious injury.
Put the control unit out of operation and secure it against restart.

About these operating instructions
APEX / SILAS
Pressurized Cabinet
Page 6 of 40 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Rev.-
Symbols and icons
Symbol
Explanation
Important notices and information for the effective, efficient and
environmentally friendly use of the product.
Ex application; this symbol indicates special information for Ex
applications
Table 1: Symbols and icons
Technical changes
The current versions of the datasheets, operating instructions, certificates and
EC declarations of conformity as well as information on new accessories can be
downloaded from www.bartec.de under “Products” in the product area “Control
and Connection Equipment”, or requested directly from BARTEC GmbH.
Languages
The original user manual is written in German. All other available languages are
translations of the original user manual.
The user manual is available in German and English. If further languages are
required, these must be requested from BARTEC or stated when placing the
order.

APEX / SILAS
Pressurized Cabinet
Safety
Rev. - 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Page 7 of 40
2Safety
Intended use
Exclusive purpose
The APEX pressurized cabinet serves exclusively as pressurized enclosure to
EN/IEC 60079-2 and is intended for use in explosion group II, category 2G,
category 2GD or category 2D.
The SILAS pressurized cabinet serves exclusively as pressurized enclosure to
EN/IEC 60079-2 and is intended for use in explosion group II, category 3G,
category 3GD or category 3D.
The permissible operating data of the device used must be observed.
Improper use
Any other use is not in accordance with the intended purpose and may lead to
damage and accidents. The manufacturer will not be liable for any use beyond
that of its intended purpose.
Safety instructions
General
No technical modifications may be performed on the APEX (SILAS)
pressurized cabinet
Do not dry wipe or clean devices in hazardous areas!
Do not open devices in hazardous areas.
The general statutory regulations or guidelines relating to safety at work,
accident prevention and environmental protection legislation must be
observed, e.g. the German Industrial Health and Safety Ordinance
(BetrSichV) or the applicable national regulations.
Wear suitable clothing and footwear in view of the risk of dangerous
electrostatic charges.
Avoid exposure to heat outside the specified temperature range (see
Chapter “General technical data”).
Avoid exposure to moisture.

Safety
APEX / SILAS
Pressurized Cabinet
Page 8 of 40 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Rev.-
Safety instructions for operation
Commissioning
Before commissioning, check that all components and documents are
available.
Inspection
Under EN/IEC 60079-17, the owner of electrical systems in hazardous
areas is obliged to have them checked by a qualified electrician to ensure
that they are in a proper condition.
Maintenance
For electrical systems, the relevant installation and operating regulations
must be observed (e.g. Directive 99/92/EC, Directive 2014/34/EC, BetrSichV
or the nationally applicable ordinances EN/IEC 60079-14 and the DIN VDE
0100 series)!
Please observe the national waste disposal regulations for disposal.
Servicing
Regular servicing is not necessary if the device is operated correctly in
accordance with the installation instructions and ambient conditions.
BARTEC recommends annual servicing and inspection.
See Chapter “Maintenance and care”.
Repairs
Repairs on explosion-protected equipment may be done only by authorised
persons working in accordance with the latest developments in technology
and using original spare parts. The applicable provisions must be observed.
Repairs must be carried out in accordance with EN / IEC 60079-19

APEX / SILAS
Pressurized Cabinet
Safety
Rev. - 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Page 9 of 40
Instructions for safe use
The user is obliged to take all necessary precautions before using the
bypass system.
The user may only connect elements to an intrinsically safe terminal if they
have electrical properties which are lower or equal to the properties
defined in the certificates of the assigned intrinsically safe devices.
When setting up the APEX (SILAS) pressurized cabinet with HMIs in the
front, the special installation conditions concerning impact protection
must be observed.
The APEX (SILAS) pressurized cabinet is to be installed such that the risk of
a mechanical danger is low.
The outlet must be routed to a safe area if there is a combination of dust
and gas.
The APEX (SILAS) pressurized cabinet rules out the following
applications/solutions:
The introduction of easily flammable or explosive media, so-called
containment systems
The protection of large electric motors
Accessible switch cabinets containers
Batteries / storage batteries may not be fitted in an APEX (SILAS)
pressurized cabinet. The subsequent introduction of batteries /storage
batteries is also ruled out
Exception: batteries used as support batteries for SPCs, PCs which are
smaller than 1% of the free protected volume and have a capacity of < 1.5
Ah.
In this case, the APEX (SILAS) pressurized cabinet must be labelled as
follows:
WARNING –THIS ENCLOSURE CONTAINS BATTERIES –DO NOT OPEN IF AN
EXPLOSIVE ATMOSPHERE EXISTS

Safety
APEX / SILAS
Pressurized Cabinet
Page 10 of 40 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Rev.-
Warranty
WARNING
UNAUTHORISED MODIFICATIONS AND/OR ALTERATIONS TO THE
PRESSURIZED ENCLOSURE.
Explosion protection as well as design and manufacture in line with strain
and safety requirements are no longer guaranteed.
Before making any modifications or alterations, contact the
manufacturer to obtain written approval.
Use only original spare parts and original wearing parts.
Assumption of warranty
The manufacturer assumes the complete warranty only and
exclusively for the spare parts ordered from the manufacturer.
As a basic rule, our “General Terms and Conditions of Sale and Delivery” apply.
They are available to the managing operator on conclusion of contract at the
latest. Warranty and liability claims for personal injury and damage to property
are excluded if they are due to one or several of the following reasons:
Improper use of the APEX (SILAS) pressurized cabinet.
Incorrect installation, commissioning, operation and maintenance of the
APEX (SILAS) pressurized cabinet.
Non-compliance with the instructions in the manual with respect to
transport, storage, assembly, commissioning, operation and maintenance.
Unauthorised structural changes to the APEX (SILAS) pressurized cabinet.
Inadequate monitoring of parts that are subject to wear.
Improperly performed repairs.
Disasters caused by foreign bodies and force majeure.
We guarantee the APEX (SILAS) pressurized cabinet and its accessories for a
period of one year starting on the date of delivery from the Bad Mergentheim
plant. This warranty covers all parts of the delivery and is restricted to the
replacement free of charge or the repair of the defective parts in our Bad
Mergentheim plant. Any packaging delivered here should be kept where
possible. If necessary, the goods should be sent to us after written agreement.
There is no entitlement to rectification at the site of installation.

APEX / SILAS
Pressurized Cabinet
Safety
Rev. - 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Page 11 of 40
Obligations of the owner
The owner undertakes to restrict permission to work with and on the APEX /
SILAS control unit to people who:
are familiar with the basic regulations on safety and accident prevention
and have been instructed in the use of the APEX control unit;
have read and understood the documentation, the chapter on safety and
the warnings.
The owner must check that the safety regulations and accident prevention
rules valid for the respective application are observed.
Instructions for use
The control unit must be completely installed in an enclosure that meets
the requirements for the enclosure according to IEC 60079-0 with a
minimum degree of protection of IP 54 for EPL Gb and IP 6X for EPL Db.
The overvoltage category II of the non-intrinsically safe circuits according
to IEC 60664-1 must be observed
The warning “WARNING – DO NOT OPEN UNDER VOLTAGE” must be part of
the external marking of the entire electrical device or the enclosure must
have a locking system to prevent the fuses from being energised during
replacement.
Other applicable documents
The APEX pressurized cabinet and SILAS pressurized cabinet are built and
wired to meet customer requirements. As these operating instructions cannot
cover all technical details, the following documents apply in addition. It is
therefore obligatory that the entire documentation received be kept with the
APEX (SILAS) pressurized cabinet. Please make sure that the documents are
there and complete when you receive the product.
Circuit diagram
Operating instructions for the Ex p control unit and its system components
Operating instructions for the APEX (SILAS) pressurized cabinet (APC/SPC)
Test report
Delivery note
Operating instructions for the fitted components
EU Declaration of Conformity for the Ex p control unit and the APEX
pressurized cabinet or. SILAS pressurized cabinet (constituent part of the
respective operating instructions)

Safety
APEX / SILAS
Pressurized Cabinet
Page 12 of 40 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Rev.-
Standards complied with
APEX pressurized cabinet
Standard
Designation
EN 60079-0:2018
IEC 60079-0:2017
Explosive atmospheres –Part 0:
General requirements
EN 60079-1:2014
IEC 60079-1:2014
Explosive atmospheres - Part 1:
Equipment protection by pressurized enclosure “d”
EN 60079-2:2014
IEC 60079-2:2014
Explosive atmospheres - Part 2:
Equipment protection by pressurized enclosure “p”
EN 60079-7:2015 + A1:2018
IEC 60079-7:2015 + A1:2017
Explosive atmospheres - Part 7:
Equipment protection by increased safety “e”
EN 60079-11:2012
IEC 60079-11:2011 + Cor.: 2012
Explosive atmospheres - Part 11:
Equipment protection by intrinsic safety “i”
EN 60079-18:2015
IEC 60079-18:2014
Explosive atmospheres - Part 18:
Equipment protection by cast encapsulation “m”
EN 60079-28:2016
IEC 60079-28:2015
Explosive atmospheres –Part 28:
Protection of devices and transmission systems operating
with optical radiation
EN 60079-31:2014
IEC 60079-31:2013
Explosive atmospheres - Part 31:
Equipment dust ignition protection by enclosure “t”
EN 60529:1991
/ A2:2013 / AC:2019
IEC 60529:1989
/ AMD2:2013/COR1:2019
Types of protection through enclosure (IP code)
EN 61000-6-4:2019
IEC 61000-6-4:2018
Electromagnetic compatibility (EMC) –
Part 6-4: Generic standards –Emission standard for
industrial environments
EN 61000-6-2:2019
IEC 61000-6-2:2016
Electromagnetic compatibility (EMC) –
Part 3-2: Limits –Limits for harmonic current emissions
(equipment input current <= 16 A per phase)

APEX / SILAS
Pressurized Cabinet
Safety
Rev. - 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Page 13 of 40
SILAS pressurized cabinet
Standard
Designation
EN 60079-0:2018
IEC 60079-0:2017
Explosive atmospheres –Part 0:
General requirements
EN 60079-1:2014
IEC 60079-1:2014
Explosive atmospheres - Part 1:
Equipment protection by pressurized enclosure “d”
EN 60079-2:2014
IEC 60079-2:2014
Explosive atmospheres - Part 2:
Equipment protection by pressurized enclosure “p”
EN 60079-7:2015 + A1:2018
IEC 60079-7:2015 + A1:2017
Explosive atmospheres - Part 7:
Equipment protection by increased safety “e”
EN 60079-11:2012
IEC 60079-11:2011 + Cor.: 2012
Explosive atmospheres - Part 11:
Equipment protection by intrinsic safety “i”
EN 60079-15:2010
IEC 60079-15:2010
Explosive atmospheres - Part 15:
Equipment protection by class of protection “n”
EN 60079-18:2015
IEC 60079-18:2014
Explosive atmospheres - Part 18:
Equipment protection by cast encapsulation “m”
EN 60079-28:2016
IEC 60079-28:2015
Explosive atmospheres –Part 28:
Protection of devices and transmission systems operating
with optical radiation
EN 60079-31:2014
IEC 60079-31:2013
Explosive atmospheres - Part 31:
Equipment dust ignition protection by enclosure “t”
EN 60529:1991
/ A2:2013 / AC:2019
IEC 60529:1989
/ AMD2:2013/COR1:2019
Types of protection through enclosure (IP code)
EN 61000-6-4:2019
IEC 61000-6-4:2018
Electromagnetic compatibility (EMC) –
Part 6-4: Generic standards –Emission standard for
industrial environments
EN 61000-6-2:2019
IEC 61000-6-2:2016
Electromagnetic compatibility (EMC) –
Part 3-2: Limits –Limits for harmonic current emissions
(equipment input current <= 16 A per phase)

Safety
APEX / SILAS
Pressurized Cabinet
Page 14 of 40 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Rev.-
Marking and test certificate
The APEX (SILAS) pressurized cabinet is approved for the following areas
APEX pressurized cabinet, Zone 1 / 21
Only basic markings are listed in the following. Optionally, the marking can be
supplemented to include the types of protection of separately certified
components, such as "db", "eb", "ma/mb", "Ex II 2(1)G [ia Ga/Da]" or "Ex II 2(2)G
[ib Gb/Db]".
APEX pressurized cabinet, category Gb / Db, type pyb, type 07-3704-11**/****
ATEX (Europe)
07-3704-11**/****
Marking
II 2G Ex pyb IIC T3 / T4 / T5 Gb
II 2D Ex pyb IIIC T95°C / T130 °C Db
Alternatively
Marking
II 2G Ex pyb IIC T3 / T4 / T5 Gb
Ex II 3D Ex pzc IIIC T95°C / T130 °C Dc
Test certificate
BVS 20 ATEX E 060 X
IECEx (International)
07-3704-11**/****
Marking
Ex pyb IIC T3 / T4 / T5 Gb
Ex pyb IIIC T95°C / T130 °C Db
Alternatively
Marking
Ex pyb IIC T3 / T4 / T5 Gb
Ex pzc IIIC T95°C / T130 °C Dc
Test certificate
IECEx BVS 20.0048X
APEX pressurized cabinet, category Gb / Db, type pxb, type 07-3704-12**/****
ATEX (Europe)
07-3704-12**/****
Marking
II 2G Ex pxb IIC T3 / T4 / T5 Gb
II 2D Ex pxb IIIC T95°C / T130 °C Db
Alternatively
Marking
II 2G Ex pxb IIC T3 / T4 / T5 Gb
II 3D Ex pzc IIIC T95°C / T130 °C Dc
Test certificate
BVS 20 ATEX E 060 X
IECEx (International)
07-3704-12**/****
Marking
Ex pxb IIC T3 / T4 / T5 Gb
Ex pxb IIIC T95°C / T130 °C Db
Alternatively
Marking
Ex pxb IIC T3 / T4 / T5 Gb
Ex pzc IIIC T95°C / T130 °C Dc
Test certificate
IECEx BVS 20.0048X

APEX / SILAS
Pressurized Cabinet
Safety
Rev. - 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Page 15 of 40
APEX pressurized cabinet, category Gb, type pyb, type 07-3704-21**/****
ATEX (Europe)
07-3704-21**/****
Marking
II 2G Ex pyb IIC T3 / T4 / T5 Gb
Test certificate
BVS 20 ATEX E 060 X
IECEx (International)
07-3704-21**/****
Marking
Ex pyb IIC T3 / T4 / T5 Gb
Test certificate
IECEx BVS 20.0048X
APEX pressurized cabinet, category Gb, type pxb, type 07-3704-22**/****
ATEX (Europe)
07-3704-22**/****
Marking
II 2G Ex pxb IIC T3 / T4 / T5 Gb
Test certificate
BVS 20 ATEX E 060 X
IECEx (International)
07-3704-22**/****
Marking
Ex pxb IIC T3 / T4 / T5 Gb
Test certificate
IECEx BVS 20.0048X
APEX pressurized cabinet, category Db, type pyb, type 07-3704-31**/****
ATEX (Europe)
07-3704-31**/****
Marking
Ex II 2D Ex pyb IIIC T95°C / T130 °C Db
Test certificate
BVS 20 ATEX E 060 X
IECEx (International)
07-3704-31**/****
Marking
Ex pyb IIIC T95°C / T130 °C Db
Test certificate
IECEx BVS 20.0048X
APEX pressurized cabinet, category Db, type pxb, type 07-3704-32**/****
ATEX (Europe)
07-3704-32**/****
Marking
Ex II 2D Ex pxb IIIC T95°C / T130 °C Db
Test certificate
BVS 20 ATEX E 060 X
IECEx (International)
07-3704-32**/****
Marking
Ex pxb IIIC T95°C / T130 °C Db
Test certificate
IECEx BVS 20.0048X

Safety
APEX / SILAS
Pressurized Cabinet
Page 16 of 40 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Rev.-
SILAS pressurized cabinet, Zone 2 / 22
Only basic markings are listed in the following. Optionally, the marking can be
supplemented to include the types of protection of separately certified
components, such as "dc", "ec", "mc", "ic", "Ex II 3(3)G [ic Gc/Dc]", "Ex II 3(1)G
[ia Ga/Da]" or "Ex II 3(2)G [ib Gb/Db] "
SILAS pressurized cabinet, category Gc / Dc, type pzc, type A7-3704-11**/****
ATEX (Europe)
A7-3704-11**/****
Marking
II 3G Ex pzc IIC T3 / T4 / T5 Gc
II 3D Ex pzc IIIC T95°C / T130 °C Dc
Test certificate
BVS 20 ATEX E 061 X
IECEx (International)
A7-3704-11**/****
Marking
Ex pzc IIC T3 / T4 / T5 Gc
Ex pzc IIIC T95°C / T130 °C Dc
Test certificate
IECEx BVS 20.0048X
SILAS pressurized cabinet, Category Gc, type pzc, type A7-3704-21**/****
ATEX (Europe)
A7-3704-21**/****
Marking
II 3G Ex pzc IIC T3 / T4 / T5 Gc
Test certificate
BVS 20 ATEX E 061 X
IECEx (International)
A7-3704-21**/****
Marking
Ex pzc IIC T3 / T4 / T5 Gc
Test certificate
IECEx BVS 20.0048X
SILAS pressurized cabinet, category Dc, type pzc, type A7-3704-31**/****
ATEX (Europe)
A7-3704-31**/****
Marking
II 3D Ex pzc IIIC T95°C / T130 °C Dc
Test certificate
BVS 20 ATEX E 061 X
IECEx (International)
A7-3704-31**/****
Marking
Ex pzc IIIC T95°C / T130 °C Dc
Test certificate
IECEx BVS 20.0048X

APEX / SILAS
Pressurized Cabinet
Safety
Rev. - 01-3704_7D0001_Manual_APC-SPC_20200617_jrs_en.docx Page 17 of 40
Avoidance of damage to property
Short circuit due to improper connection
An incorrect connection of the power supply will destroy the electronics and
void the warranty.
Storage at an excessively high temperature
Store the APEX (SILAS) pressurized cabinet at the intended storage
temperature since otherwise damage to the electronics or seals may occur.
Ensure adequate air conditioning at high storage temperatures.
Aggressive cleaning agents
When selecting the correct cleaning agent, it is essential that it is suitable for
use since otherwise damage may occur to seals and connections.
Combustible products are generally not permitted.
Danger to health due to improper disposal
According to the European WEEE Directive, electrical and electronic equipment
may not be disposed of with household waste. Their components must be sent
separately for recycling or disposal because toxic and hazardous components
can cause long-term damage to health and the environment if not disposed of
properly.
As consumers, you are obliged under the Electrical and Electronic Equipment
Act (ElektroG) to return electrical and electronic equipment at the end of its
serviceable life free of charge to the manufacturer, the point of sale or to public
collection points set up for this purpose. Details of this are regulated by the
respective national law. The symbol on the product, the operating instructions
or/and the packaging refers to these regulations. With this type of material
separation, recycling and disposal of old devices, you make an important
contribution to the protection of our environment.
