FAQ - Frequently Asked Questions
10.1" Industry Tablet PC
HotTab on Agile series
Installation
Required driver
Setup
Troubleshooting
Relevant for
Agile X-IS
Status: November 2020
Reservation: Technical data subject to change without notice. Changes, errors and
misprints may not be used as a basis for any claim for damages.

Table of content
Agile X IS
FAQ: HotTab
1/9
Subject to technical changes.
09/2020
Subject to technical changes.
10/2020
1. About HotTab Utility ............................................................................................................................. 2
2. Installation............................................................................................................................................. 3
2.1 Required software ............................................................................................................ 3
2.1.1 Download of HotTab utility................................................................................................ 3
2.1.2 Download of WMMIO driver ............................................................................................. 4
2.2 WMMIO driver .................................................................................................................. 4
2.3 HotTab utility .................................................................................................................... 6
2.3.1 Installation with “Setup” .................................................................................................... 6
2.3.2 Installation in background with PowerShell (recommend for Windows 8 / 10) ................. 6
2.3.3 Installation in background with CMD (recommend for Windows 7) .................................. 7
3. Interface Assignment ........................................................................................................................... 9

Agile X IS
FAQ: HotTab
FAQ
Subject to technical changes.
10/2020
2/9
1. About HotTab Utility
The description in this manual describe following HotTab version or later.
Device:
Version:
Agile X IS
version A40.1.82
For later versions it could be that not all available menus are listed and described.
HotTab provides quick access to the tablet’s functions and features, such as turning on/off Wifi, Bluetooth,
GPS, programming function key, and changing power management.
As Windows starts up, HotTab starts and runs in the background. To display the HotTab control utility, press
the (Menu) Button located on the front panel, OR launching the HotTab Utility application.
HotTab Utility Icon
Menu Button on the Front side
HotTab is designed to be a quick access utility; therefore the main user interface will be on the right side of
the screen without blocking the content on screen. There are 4 main menu options: Short cut, Camera,
Device and Settings. Operations and functions on each menu options are explained in detail in the coming
sections.
Shortcuts button allows users to configure short cut to quickly access
programs with a few tabs.
Camera button allows users take a picture or record a video. User can also
adjust setting related to camera in this menu option.
Device ON/OFF button enables/disables tablet computer’s hardware
functions. The configurable functions are Wi-Fi, WWAN (3G/4G/LTE), GPS,
Bluetooth, Camera, LED indicators, Barcode Reader, RFID Reader,
Expansion Port, and GPS Antenna routing options.
Setting menu provides information about installed versions and battery status.
BIOS Version
HotTab Version
OS Version
Serial Number
Battery status

FAQ
Agile X IS
FAQ: HotTab
3/9
Subject to technical changes.
09/2020
Subject to technical changes.
10/2020
2. Installation
2.1 Required software
For use of HotTab utility following software is required.
Software and installation sequence
Required for Agile X-IS
Type: 17-A1B4-…/…….
1. Driver - WMMIO v3.1WHQL
for Windows 8.1/10 (64-Bit)
Driver is necessary for use of the HotTab
System Utility
Yes
2. Hottab System Utility
Yes
3. Hottab Camera Application
Yes
Check the installed HotTab utility and WMMIO driver version before you start installation
of latest available version.
You can check the installed version:
HotTab utility:
-In settings under category apps or installed programs
-In HotTab tool under category settings
WMMIO driver:
-In device manager under category system devices
If installed version is older than new version then uninstall first before you start installation.
2.1.1 Download of HotTab utility
The latest version is available on BARTEC download page.
https://automation.bartec.de/tabletpcE.htm
1. Select the device
2. Go to section “Tools”
3. Download HotTab utility

Agile X IS
FAQ: HotTab
FAQ
Subject to technical changes.
10/2020
4/9
2.1.2 Download of WMMIO driver
The latest version is available on BARTEC download page.
https://automation.bartec.de/tabletpcE.htm
1. Select the device
2. Go to section “Driver”
3. Download WMMIO driver
2.2 WMMIO driver
1. First navigate to the driver directory and start the CMD console from there as administrator.
Click on:
1. Open “File”
2. Open “Command Prompt”
3. Open “Command Prompt as administrator”
2. Enter ”install” (name of the batch file) in the window and start the installation with press of “Enter”
key.

FAQ
Agile X IS
FAQ: HotTab
5/9
Subject to technical changes.
09/2020
Subject to technical changes.
10/2020
3. Installation will be done automatically.
Press “Enter” key after message appears that “drivers installed successfully”.
4. After the installation a new device “WMMIO Driver”will appear in “Device Manager” under section
"System devices".

Agile X IS
FAQ: HotTab
FAQ
Subject to technical changes.
10/2020
6/9
2.3 HotTab utility
The HotTab utility can be installed with two procedures.
By use of setup.exe file.
Installation in background
2.3.1 Installation with “Setup”
1. Download HotTab utility.
2. Unzip the package and store it on your device.
3. Go to the folder in what you stored HotTab utility.
4. Start installation of HotTab utility with double click on “setup.exe” file.
5. Follow the installation setup.
6. Perform a reboot to finish the installation.
If you have Agile X IS (type: 17-A1B4-.…/…….) then installation of “HotTab camera
utility” is identical procedure as “HotTab utility”.
2.3.2 Installation in background with PowerShell (recommend for Windows 8 / 10)
1. Download HotTab utility.
2. Unzip the package and store it on your device.
3. Go to the folder in what you stored HotTab utility.
4. Open “PowerShell as administrator

FAQ
Agile X IS
FAQ: HotTab
7/9
Subject to technical changes.
09/2020
Subject to technical changes.
10/2020
5. Start installation of HotTab utility by using the command
“msiexec /package SetupStandard.msi /quiet” and press “Enter”.
6. After a while PowerShell will be ready for use (Hottab application is also installed)
No message is displayed after successful installation.
If the customer wants to make sure that everything run smoothly, he has to query the
variable “ERRORLEVEL” in the batch file.
More information can be found on Microsoft page (msiexec):
https://msdn.microsoft.com/en-us/library/windows/desktop/aa372024(v=vs.85).aspx
2.3.3 Installation in background with CMD (recommend for Windows 7)
1. Download HotTab utility.
2. Unzip the package and store it on your device.
3. Open “Command Prompt as Administrator”.

Agile X IS
FAQ: HotTab
FAQ
Subject to technical changes.
10/2020
8/9
4. Start installation of HotTab utility by using the command
“msiexec /i "C:\Users\test\Desktop\Hottab_AXIS_A40.1.82\SetupStandard.msi" /quiet” and
press “Enter”.
The marked path indicates the storage location of the package
5. After a while CMD will be ready for use (Hottab application is also installed)
No message is displayed after successful installation.
If the customer wants to make sure that everything run smoothly, he has to query the
variable “ERRORLEVEL” in the batch file.
More information can be found on Microsoft page (msiexec):
https://msdn.microsoft.com/en-us/library/windows/desktop/aa372024(v=vs.85).aspx

FAQ
Agile X IS
FAQ: HotTab
9/9
Subject to technical changes.
09/2020
Subject to technical changes.
10/2020
3. Interface Assignment
All modules what are built in and managed via HotTab are internal connected to COM ports.
Following is the interface list and what modules are assigned.
COM-Port
Module
Description
COM 1
RS232 I/O
30-pin combo connector on Agile X
COM 2
RS232 I/O
Expansion port on Agile X back sight
COM 3
HF Reader
RFID HF RF521 reader optional build in Agile X
COM 5
WWAN module
For available LTE modules
COM 6
WWAN module
For available LTE modules
COM 9
GPS
For build in GPS module
COM 11
RS232 I/O
Docking connector on Agile X
COM 12
-
reserved
COM 15
Barcode Reader
1D/2D Imager optional build in Agile X
COM 20
RFID UHF Add On Module
Build on optional on expansion port
COM 21
-
reserved
COM 34
-
reserved
