Bartec TC77ex-NI User manual

Touch Computer TC77ex-NI
Quick Start Guide
EN-A260-7E0001-01/2020-EM-447055

BARTEC GmbH
Max-Eyth-Straße 16
Fon: [phone]
Support:
em[email protected]
97980 Bad Mergentheim
Fax: [phone]
Download:
http://automation.bartec.de
GERMANY
Internet:
www.bartec.com
Quick start guide - Translation
TC77ex-NI
Touch Computer
Type B7-A26*-***3/********
ATEX / IECEx Zone 2 / 22
Class I, II, III Division 2
Document No.: B1-A260-7E0001
Status: January 2021
Proviso: Subject to technical changes. Changes, mistakes and printing errors do
not substantiate any claim to damages.
Content
Pages
English
1-36

Table of content
TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
Subject to technical changes.
01/2021
1Basic safety information ...................................................................................................................... 1
1.1 Information on this Quick Start Guide............................................................................... 1
1.1.1 Languages........................................................................................................................ 2
1.1.2 Changes in the document................................................................................................. 2
1.1.3 Registered trademarks ..................................................................................................... 2
1.2 Handling the product ........................................................................................................ 2
1.3 Intended use..................................................................................................................... 3
1.3.1 Exclusive purpose ............................................................................................................ 3
1.3.2 Unintended use ................................................................................................................ 3
1.4 Duties of the operator....................................................................................................... 3
1.5 Safety information............................................................................................................. 3
1.6 Maintenance..................................................................................................................... 4
1.6.1 Servicing........................................................................................................................... 4
1.6.2 Inspection......................................................................................................................... 4
1.6.3 Repairs............................................................................................................................. 4
1.6.4 Commissioning................................................................................................................. 4
1.7 Labelling, test certificate, and standards .......................................................................... 4
1.8 Warranty........................................................................................................................... 5
1.9 Co-applicable documents................................................................................................. 6
1.10 Definition of terms............................................................................................................. 6
1.11 Configuration .................................................................................................................... 7
2Product description.............................................................................................................................. 8
2.1 TC77ex-NI ......................................................................................................................... 8
2.2 Purpose of use ................................................................................................................. 8
3Structure................................................................................................................................................ 9
4Technical data..................................................................................................................................... 11
4.1 Explosion protection ....................................................................................................... 11
4.2 Features ......................................................................................................................... 12
4.2.1 Performance features..................................................................................................... 12
4.2.2 Physical features ............................................................................................................ 12
4.2.3 User environment ........................................................................................................... 13
4.2.4 Barcode capture ............................................................................................................. 13
4.3 Battery............................................................................................................................ 14
4.4 Product labelling............................................................................................................. 15
4.4.1 Touch Computer............................................................................................................. 15
4.4.2 Battery............................................................................................................................ 16
5Transport and storage........................................................................................................................ 17
5.1 Transport........................................................................................................................ 17
5.2 Storage........................................................................................................................... 17
6Commissioning................................................................................................................................... 18
6.1 Requirements in potentially explosive atmosphere ........................................................ 18
6.2 First steps....................................................................................................................... 20

Table of content
TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
Subject to technical changes.
01/2021
7Operation............................................................................................................................................. 21
7.1 Handling accessories ..................................................................................................... 21
7.1.1 Insert SIM card ............................................................................................................... 21
7.1.2 Insert microSD card........................................................................................................ 24
7.1.3 Insert/change battery...................................................................................................... 26
7.1.4 Charging the Main battery .............................................................................................. 29
7.1.5 Charging the spare battery............................................................................................. 30
7.2 Scanning ........................................................................................................................ 32
8Disposal............................................................................................................................................... 33
9EU Declaration of Conformity............................................................................................................ 34
10 Notes.................................................................................................................................................... 36

TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
Basic safety information
Subject to technical changes.
01/2021
1/36
1Basic safety information
1.1 Information on this Quick Start Guide
Read carefully before putting the devices into operation.
The Quick Start Guide is a fixed part of the product. It must be kept in the direct vicinity of
the device and the installation, operating and service staff must have access to it at all
times.
The Quick Start Guide contains important information, safety instructions and test
certificates which are necessary for the perfect function of the device in operation.
The Quick Start Guide is directed at all individuals concerned with the commissioning,
handling and servicing of the product. The applicable guidelines and standards for areas
with gas and dust atmosphere (EN/IEC 60079-17, EN/IEC 60079-19) must be observed
when conducting this work.
Knowledge of the safety and warning information in this Quick Start Guide and the strict
compliance with it is essential for safe installation and commissioning. Accidents, injuries
and material damage can be avoided by circumspect handling and systematically
following the instructions.
The examples, tables, and figures provided in this Quick Start Guide are for illustration
purposes. Due to the different requirements of the respective application, the BARTEC
company cannot assume responsibility or liability for actual use based on the examples
and figures.
The BARTEC company reserves the right to carry out technical changes at any time.
In no event will BARTEC company be responsible or liable for indirect or consequential
damages resulting from the use or application of this Quick Start Guide.
Safety and warning information is particularly emphasised in this Quick Start Guide and
marked by symbols.
DANGER
DANGER describes a directly imminent danger. If not avoided, death or severe injury
will be the consequence.
WARNING
WARNING describes a possibly imminent danger. If not avoided, death or severe injury
may be the consequence.
CAUTION
CAUTION describes a possibly imminent danger. If not avoided, mild or slight injury may
be the consequence.
ATTENTION
ATTENTION describes a possibly damaging situation. If not avoided, the plant or
objects in its vicinity may be damaged.
Important information on effective, economical & environmentally compliant handling.

Basic safety information
TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
2/36
Subject to technical changes.
01/2021
1.1.1 Languages
The original Quick Start Guide with safety information is written in German. All other
available languages are translations of the original Quick Start Guide.
The Quick Start Guide is available in German and English. If further languages are required,
these must be requested from BARTEC or stated on placing an order.
1.1.2 Changes in the document
BARTEC reserves the right to change the content of this document without notification. No
warranty is assumed for the correctness of the information. In cases of doubt, the German
safety instructions apply because it is not possible to rule out errors of translation or printing.
In the case of legal disputes, the “General Terms and Conditions of Business” of the
BARTEC Group also apply.
The current versions of the datasheets, user manual, certificates and EU declarations of
conformity can be downloaded from www.bartec.com or may be requested directly from
BARTEC GmbH.
1.1.3 Registered trademarks
Bluetooth® is a registered trademark of Bluetooth Special Interest Group
Android The "Android" name, the Android logo, the Google Play trademark and
other Google trademarks are the property of Google LLC.
WiFi is a registered trademark of Wi-Fi-Alliance, an association of
manufacturers founded in 1999.
1.2 Handling the product
The product described in this Quick Start Guide left the factory in a perfect and tested state
in terms of safety. To maintain this state and to achieve a perfect and safe operation of this
product, it may only be operated in the manner described by the manufacturer. In addition,
the perfect and safe operation of this product requires correct transportation, proper storage
and careful operation.
The safe and perfect handling of the Touch Computer is a prerequisite for its perfect and
correct functioning.

TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
Basic safety information
Subject to technical changes.
01/2021
3/36
1.3 Intended use
1.3.1 Exclusive purpose
The Touch Computer series is a handheld piece of electrical equipment. It serves the
purpose of the mobile recording, processing and/or radio transmission of data within
potentially explosive atmospheres.
It is used exclusively in combination with devices which comply with the requirements
placed on the overvoltage category I.
The admissible operating data of the device used must be considered.
1.3.2 Unintended use
Any other use is unintended and may lead to damage and accidents. The manufacturer
shall not be liable for any use extending beyond the exclusive purpose.
1.4 Duties of the operator
The operator undertakes to only permit persons to work with the Touch Computer who
are acquainted with the basic regulations on safety and accident prevention, and who have
been inducted in the use of the Touch Computer,
have read and understood the documentation, the safety chapter and the warnings.
The operator checks that the safety and accident prevention regulations applicable to the
respective case of use have been observed.
1.5 Safety information
Do not dry wipe or clean devices in potentially explosive atmospheres!
Do not open devices in potentially explosive atmospheres.
Do not replace or charge battery in potentially explosive atmospheres.
General statutory provisions or guidelines on occupational health and safety, accident
prevention provisions and environmental protection laws must be heeded, e.g. Operational
Safety Ordinance (BetrSichV) and nationally applicable ordinances.
Use suitable clothing and shoes with respect to the danger of hazardous electrostatic
charges.
Avoid heat influences outside the specified temperature range.
Protect device from external influences! Do not expose device to caustic/aggressive liquids,
vapours or spray. In the case of malfunction or damaged enclosure, remove the device
immediately from the potentially explosive atmosphere and bring it to a safe place.

Basic safety information
TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
4/36
Subject to technical changes.
01/2021
1.6 Maintenance
The pertinent erection and operating provisions for electrical systems must be observed!
(e.g. Directive 2014/34/EU, BetrSichV and nationally applicable ordinances
EN/IEC 60079-14 and the series DIN VDE 0100)!
Observe the national waste disposal regulations when disposing of the devices.
1.6.1 Servicing
No constant servicing will be necessary if operated correctly under consideration of the
assembly instructions and environmental conditions. See Chapter “Service, inspection,
repair” in this respect.
1.6.2 Inspection
According to EN/IEC 60079-17 and EN/IEC 60079-19 the operator of electrical systems in
potentially explosive atmospheres is obliged to have these inspected by an electrician to
ensure correct condition.
1.6.3 Repairs
Repairs to explosion-protected devices may only be performed by authorised personnel
with original spare parts and according to the state of the art.
Therfore all repairs to the Touch Computer have to conducted by BARTEC.
1.6.4 Commissioning
It must be checked that all components and documents are available before commissioning.
1.7 Labelling, test certificate, and standards
Labels on explosion protection and the test certificate are attached to the Touch Computer.
See Chapter 3 “Technical data” with respect to labelling.
The guidelines and standards applicable to the Touch Computer for devices and protected
systems for intended use in potentially explosive atmospheres are provided in Chapter 3
“Technical data”.

TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
Basic safety information
Subject to technical changes.
01/2021
5/36
1.8 Warranty
WARNING
No changes or retrofits may be made without the written consent of the
manufacturer.
If non-specified components are used, the explosion protection will no longer be
guaranteed. In the case of externally procured parts, it is not guaranteed that these have
been designed and manufactured in accordance with their load and requisite safety.
Contact the manufacturer before any changes or retrofits to receive a release.
Only use original spare and wearing parts.
The manufacturer shall exclusively assume the complete warranty only for spare parts
ordered from him.
Our “General Terms and Conditions of Sale and Delivery” shall apply in principle. These
shall be made available to the operator on signing of contract at the latest. Warranty and
liability claims in the case of injury and damage to property shall be excluded if they are
attributable to one or several of the following causes:
Unintended use of the Touch Computer.
Incorrect handling
Failure to observe the information in the Quick Start Guide and the user manual
with respect to transport, storage, commissioning, operation and service.
Independent structural changes
Faulty monitoring of parts subject to wear and tear.
Incorrectly performed repairs.
Cases of disaster through the impact of foreign bodies and force majeure.
We grant a warranty period of one year starting from the date of delivery from the Bad
Mergentheim factory on the Touch Computer (exception: battery 6 months). The warranty
period for accessories is one year starting from the date of delivery from the Bad
Mergentheim factory. This warranty covers all parts of the delivery and shall be restricted
to the free replacement or repair of the defective parts in our Bad Mergentheim factory. For
this purpose, any packaging supplied must be kept where possible. In the case of warranty,
the goods must be returned to us after written agreement using an RMA form. There shall
be no claim to repair at the sight of erection.
The information contained herein refers to the explosion-protected version of the Touch
Computer TC77ex-NI.
This Quick Start Guide contains all important information on the subject of explosion
protection.
Further product information on handling and commissioning can be found on the BARTEC
support page: https://automation.bartec.de/mobileE.htm

Basic safety information
TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
6/36
Subject to technical changes.
01/2021
1.9 Co-applicable documents
All documents are available online from the following websites:
BARTEC: www.bartec.com or http://automation.bartec.de
ZEBRA: www.zebra.com
In the event of an overlaps with Zebra, the instructions of BARTEC apply.
Document BARTEC
Explanation
Quick Start Guide
Touch Computer TC77ex-NI
The safety relevant information, initial use
and further data of the Touch Computer
TC77ex-NI are described in this Quick Start
Guide.
Data sheet
Touch Computer TC77ex-NI
This technical data sheet contains the most
important explosion-relevant technical data
as well as general technical data.
Document ZEBRA
Explanation
For TC77
TC77 Touch Computer
Quick Start Guide
TC77 Touch Computer
Integrator Guide
TC77 Touch Computer
User Guide
Instructions for commissioning, operating,
configuring, programming and maintaining of
the Touch Computer.
1.10 Definition of terms
A few abbreviations are used in the documentation.
NI
=
Non Incendive
is used as generic term for Zone 2 and Division 2 version
TC
=
Touch Computer
stands for the entire product series

TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
Basic safety information
Subject to technical changes.
01/2021
7/36
1.11 Configuration
The devices are only supplied with preinstalled operating system.
Customer software or further applications are not contained in the delivery.
This Quick Start Guide refers to the following configurations:
Configuration
Version
Processor
Qualcomm Snapdragon 660 Octa-Core, 2.2 GHz
Display
4.7“Color Display with 1280 x 720 Pixel resolution
Memory
4 GB
Mass storage
32 GB
Operating system
Android 10
The TC77ex-NI is compatible up to Android R and is delivered by
BARTEC according to the currently available Android version.
WLAN
IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w
Bluetooth
5.0
NFC
ISO 14443 Type A and B; F; FeliCa and ISO 15693 cards; P2P
mode and Card Emulation via Host
SAM support for Calypso, Felica and Mifare technology
Dual SAM support on TC77 SAM SKU
Scanner
SE4770-SR:
1D/2D standard range omnidirectional imager

Product description
TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
8/36
Subject to technical changes.
01/2021
2Product description
2.1 TC77ex-NI
The TC77ex-NI is a tough Touch Computer with 4.7" color display, which has been designed
for use in the industrial environments and especially developed by BARTEC in close
cooperation with ZEBRA for use in potentially explosive atmospheres.
2.2 Purpose of use
The Touch Computer TC77ex-NI are handheld electrical devices. They serve the purpose
of entry, processing and (radio) transmission of data within potentially explosive
atmospheres.
The Touch Computer TC77ex-NI are used exclusively in combination with devices which
comply with the requirements placed on the overvoltage category I.
The Touch Computer TC77ex-NI, Type B7-A26*-***3/******** have been modified for use
in the following potentially explosive atmospheres:
ATEX / IECEx Zone 2 and Zone 22
Class I, II, II Div. 2, Groups A, B, C, D, F, G; T4

TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
Structure
Subject to technical changes.
01/2021
9/36
3Structure
1
Touch Screen
Displays all information needed to operate the device.
2
Scan Button
Initiates data capture (programmable).
3
PTT Button
Initiates push-to-talk communications (programmable).
4
Back Button
Displays the previous screen.
5
Home Button
Displays the Home screen with a single press.
On device with GMS, opens the Google Now screen when held for a
short period of time.
6
Microphone
Use for communications in Handset mode.
7
Charging Contacts
Provides power to the device from cables and cradles.
8
Speaker
Provides audio output for video and music playback. Provides audio in
speakerphone mode.
9
Search Button
Opens the Recent App screen.
10
Menu Button
Opens a menu with items that affect the current screen or app.
11
Light Sensor
Determines ambient light for controlling display backlight intensity.
12
Proximity Sensor
Determines proximity for turning off display when in handset mode.
13
Power Button
Turns the display on and off. Press and hold to reset the device, power
off or swap battery. Press quickly twice when the screen is locked to
open the camera app.
14
Microphone
Use for communications in Speakerphone mode.
15
Receiver
Use for audio playback in Handset mode.
16
Charging/Notification LED
Indicates battery charging status while charging and app generated
notifications.
17
Data Capture LED
Indicates data capture status.
18
Front Facing Camera
Use to take photos and videos.

Structure
TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
10/36
Subject to technical changes.
01/2021
19
Interface Connector
Provides USB host and client communications, audio and device
charging
via cables and accessories.
20
Exit Window
Provides data capture using the imager.
21
Microphone
Use during video recording and for noise cancellation.
22
Scan Button
Initiates data capture (programmable).
23
Volume Up/Down Button
Increase and decrease audio volume (programmable).
24
Battery Release Latches
Press to remove the battery.
25
Elastic Sleeve
Use to hold optional stylus.
26
Battery
Provides power to the device.
27
Hand strap
Use to securely hold the device in your hand.
28
Hand strap Mounting Point
Provides latching point for the hand strap.
29
Camera
Takes photos and videos.
30
Camera Flash
Provides illumination for the camera.

TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
Technical data
Subject to technical changes.
01/2021
11/36
4Technical data
4.1 Explosion protection
ATEX Zone 2 / Zone 22
Type B7-A26*-***3/********
TC77ex-NI
Labelling
Ex II 3G Ex ic op is IIC T5 Gc
Ex II 3D Ex ic op is IIIB T100 °C Dc
-20 °C ≤ Ta ≤ +50 °C
Test certificate
EPS 17 ATEX 1 028 X
Standards
See chapter: EU Declaration of Conformity
IECEx Zone 2 / Zone 22
Type B7-A26*-***3/********
TC77ex-NI
Labelling
Ex ic op is IIC T5 Gc
Ex ic op is IIIB T100 °C Dc IP 64
-20 °C ≤ Ta ≤ +50 °C
Test certificate
IECEx EPS 17.0012X
Standards
See chapter: EU Declaration of Conformity
Class I, II, III, Division 2
Type B7-A26*-***3/********
TC77ex-NI
Labelling
Class I,II,III Div 2
Class I Div 2 Groups A,B,C,D
Class II Div 2 Group F,G
Class III
Test certificate USA and Canada
5012876
Standards
UL 60950-1:2007 Ed.2+R:14Oct2014
CSA C22.2#60950-1:2007 Ed.2+A1;A2
UL 121201:2017 Ed.9
CSA C22.2#213:2017 Ed.3
X - labelling (special conditions of use for secure operation within the potentially
explosive atmosphere)
Only use battery type B7-A2Z0-0072.
The battery shall only be charged and changed in an area known to be non-hazardous.
USB port shall not be used in hazardous area.
Only the screen protector type B7-A2Z0-0051 may be used.
The device must be protected from impacts with high impact energy, against excessive
UV light emission and high electrostatic charge processes.

Technical data
TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
12/36
Subject to technical changes.
01/2021
4.2 Features
4.2.1 Performance features
CPU
Qualcomm Snapdragon 660 Octa-core, 2.2 GHz
Operating system
Android 10
Hardware is compatible up to Android R and is
delivered by BARTEC according to the currently
available Android version.
Memory
4 GB RAM; 32 GB Flash
Extension slot
MicroSD card slot
up to 32 GB SDHC and up to 256 GB SDXC
Optional MicroSD card from BARTEC:
32 GB Order number 17-A1Z0-0010
4.2.2 Physical features
Dimensions:
(Length x Width x Height)
161 x 84 x 28 mm
(6.3 x 3.3 x 1.1 inch)
Weight
(including battery)
approx. 376 g
(approx. 13.3 oz)
Display
4.7" Colour display
1280 x 720 pixel
Touchscreen
Dual mode capacity touch
Touch function with stylus, finger or glove
depending on the mode selected
Background lighting
LED technology
Network connections
WWAN (cellular, WLAN (WiFi),
WPAN (Bluetooth);
USB 2.0 High Speed (host and client)
Interactive sensor technology
Light Sensor: Automatically adjusts display
backlight brightness
Motion Sensor: eCompass, 3-axis Gyro,
3-axis accelerometer
Atmospheric Pressure Sensor

TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
Technical data
Subject to technical changes.
01/2021
13/36
4.2.3 User environment
Operating temperature
-20 °C to +50 °C ( -4 °F to +122 °F)
Charging temperature
0 °C to +40 °C (+32 °F to +104 °F)
Storage temperature
(without battery)
-40 °C to +70 °C (-40 °F to +158 °F)
Relative humidity
5 % to 90 % (non-condensing)
Class of protection (IEC 60529)
IP 65 and IP 68
4.2.4 Barcode capture
1D-/2D Barcodes
SE4770-SR
1D-/2D Omni-Direktional Imager Engine
The scanning range of the scanner depends on the used barcode type, the print quality
and the module width (in mil).
The scanner used comply with laser class CDRH Class II / IEC 825 Class 2.
Further detailed information on the used scanner can be found in the “TC77XX Touch
Computer Integrator Guide (EN)” from ZEBRA.

Technical data
TC77ex-NI - Touch Computer
Type B7-A26*-***3/********
14/36
Subject to technical changes.
01/2021
4.3 Battery
The life of the battery will depend on different use factors and the device settings, e.g.:
Use and setting of WLAN/Bluetooth
Background lighting/screensaver
The settings in power management
Use and setting of scanner
Battery
Type B7-A2Z0-0072
(only change and charge in the safe area)
Lithium ion battery 3.7 V/4620 mAh (17.1 Wh)
Operating temperature
During charging
0 °C to +40 °C (+32 °F to 104 °F)
During discharging
-20 °C to +50 °C (-4 °F to 122 °F)
Storage temperature
-20 °C to +50 °C (-4 °F to 122 °F)
Relative humidity
20 % to 95 % (non condensing)
Charging times
less than 5 hours
UN38.3 compliant
Yes
Charge the batteries at temperatures from 0°C to 40°C (32°F to 104°F). The device or
charging station always performs the battery charging in a safe and intelligent way. At
higher temperatures, such as about +37°C (+98°F), the device or charging station can
alternately activate and deactivate battery charging for a short time to keep the battery at
acceptable temperatures. The device and the charging station indicate via their LED when
charging is disabled due to abnormal temperatures.
