Bartec POLARIS 17-71V2 Series User manual

User Manual - TRANSLATION
POLARIS REMOTE
POLARIS Remote KVM Digital
Typ 7-7 V2-….
ATEX / IECEx
Zone and Zone 2
Document no. 11-71V2-7D0014 / 356538
Revision B / Status: Ma 2019
Reservation: Technical data subject to change without notice. Changes, errors and
misprints ma not be used as a basis for an claim for damages.
Content Pages
English 1 - 52
GmbH
Max-E th-Straße 16 Phone: [phone] Support: [email protected]
97980 Bad Mergentheim Fax: [phone] Download: http://automation.bartec.de
GERMANY Internet: www.bartec.de

POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24" Table of Contents
EN 1/47
Technical data subject to change.
08/2017

Table of Contents POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24"
Technical data subject to change.
08/2017
. Basic safety instructions ....................................................................................................................
1.1 Notes on this manual ................................................................................................................ 1
1.1.1 Languages .................................................................................................................... 2
1.1.2 Changes in the document ............................................................................................. 2
1.2 Handling the product ................................................................................................................. 2
1.3 Intended use ............................................................................................................................. 2
1.3.1 Exclusive purpose ........................................................................................................ 2
1.3.2 Unintended use ............................................................................................................ 3
1.4 Duties of the operator................................................................................................................ 3
1.5 Safet information ..................................................................................................................... 3
1.5.1 General ......................................................................................................................... 3
1.6 General safet information for operation ................................................................................... 3
1.6.1 Maintenance ................................................................................................................. 3
1.6.2 Servicing ....................................................................................................................... 4
1.6.3 Inspection ..................................................................................................................... 4
1.6.4 Repairs ......................................................................................................................... 4
1.6.5 Commissioning ............................................................................................................. 4
1.7 Labelling, test certificate and standards .................................................................................... 4
1.8 Warrant .................................................................................................................................... 4
2. Product description............................................................................................................................. 6
2.1 Definition ................................................................................................................................... 6
2.2 Schematic design ...................................................................................................................... 7
2.2.1 Standard – Point to Point .............................................................................................. 7
2.2.2 Standard - Point-to-Point with Hand-Held Scanner ...................................................... 7
2.2.3 Special Application - Cascade Connection ................................................................... 8
3. Explosion protection and approvals ................................................................................................. 9
4. Technical data....................................................................................................................................
4.1 General technical Data............................................................................................................ 11
4.1.1 Characteristics POLARIS Remote KVM Digital 15” .................................................... 12
4.1.2 Characteristics POLARIS Remote KVM Digital 15" Sunlight ...................................... 12
4.1.3 Characteristics POLARIS Remote KVM Digital 19.1" ................................................. 13
4.1.4 Characteristics POLARIS Remote KVM Digital 17.3" ................................................. 13
4.1.5 Characteristics POLARIS Remote KVM Digital 24" .................................................... 14
4.2 Ke board ................................................................................................................................. 15
4.2.1 Explosion Protection ................................................................................................... 15
4.2.2 General data ............................................................................................................... 15
4.2.3 Characteristics of enclosure for mouse and ke board................................................ 16
4.3 Finger mouse, Trackball, Touchpad and Jo stick ................................................................... 16
4.3.1 Explosion protection ................................................................................................... 16
4.3.2 General Data .............................................................................................................. 17
4.3.3 Variants ...................................................................................................................... 17
4.4 Product Labelling .................................................................................................................... 18
5. Transport, Storage, Scope and Assembly ...................................................................................... 9
5.1 Transport ................................................................................................................................. 19
5.2 Intermediate Storage............................................................................................................... 19
5.3 Scope of deliver ..................................................................................................................... 19
5.3.1 Accessories optional ................................................................................................... 19
5.4 Assembl ................................................................................................................................. 20
5.4.1 Installation options ...................................................................................................... 20
6. Installation.......................................................................................................................................... 2
6.1 Requirements .......................................................................................................................... 21
6.2 Mechanical Installation ............................................................................................................ 22
6.2.1 Installation in 2G-/2D-enclosure ................................................................................. 22
6.2.2 Installation as a S stem Solution in the Stainless Steel Enclosure "Exclusive II" ...... 24
6.2.3 Floor mounting (Stainless steel enclosure "Exklusive II" ............................................ 25
6.2.4 Wall mounting (Stainless steel enclosure "Exklusive II" ............................................. 25
6.2.5 Table mounting swivel/tilt (Stainless steel enclosure "Exclusive II") ........................... 26

POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24" Table of Contents
Technical data subject to change.
08/2017
6.3 Electrical Installation ............................................................................................................... 27
6.3.1 Installation guidelines ................................................................................................. 27
6.4 Terminal compartments .......................................................................................................... 28
6.5 PE conductor connection ........................................................................................................ 29
6.6 Ex e terminal compartments ................................................................................................... 30
6.6.1 Cable entries .............................................................................................................. 30
6.6.2 Suppl voltage terminal assignment) .......................................................................... 31
6.6.3 Terminal Assignment for USB .................................................................................... 31
6.6.4 Terminal assignment LSA-Plus Terminal (X17-1 to X17-8) ........................................ 32
6.7 Ex i terminal compartment ...................................................................................................... 33
6.7.1 Connection of Ex i ke board to the POLARIS (optional) ............................................ 33
6.8 Scanner Connection................................................................................................................ 34
6.9 Local Unit ................................................................................................................................ 35
6.9.1 Technical Data for Local Unit ..................................................................................... 35
6.9.2 STP Cable Connection ............................................................................................... 35
6.9.3 Local Unit Connections ............................................................................................... 35
6.10 Fibre Version ........................................................................................................................... 36
6.10.1 Connector POLARIS .................................................................................................. 36
6.10.2 Technical Data for Local Unit ..................................................................................... 37
6.10.3 Local Unit Connector .................................................................................................. 37
6.11 EMC (Electromagnetic Compatibilit ) ..................................................................................... 38
6.11.1 Voltage Suppl (AC- and DC-Variants) ...................................................................... 38
6.11.2 Back-up fuse ............................................................................................................... 39
6.11.3 Interference suppression ............................................................................................ 39
6.11.4 Shielding ..................................................................................................................... 40
6.11.5 Connection of shielding .............................................................................................. 40
6.11.6 Examples of Shielding Connections ........................................................................... 40
7. Commissioning.................................................................................................................................. 42
7.1 Final Inspection ....................................................................................................................... 42
8. Operation............................................................................................................................................ 43
8.1 Commissioning........................................................................................................................ 43
8.2 Displa Settings ...................................................................................................................... 43
8.3 Touch Screen .......................................................................................................................... 43
9. Faults and troubleshooting .............................................................................................................. 44
0. Maintenance, inspection, repair ....................................................................................................... 45
10.1 Maintenance intervals ............................................................................................................. 45
10.2 Inspection ................................................................................................................................ 45
10.3 Maintenance and repair work .................................................................................................. 45
10.3.1 Instructions for Repairs ............................................................................................... 46
. Disposal.............................................................................................................................................. 46
2. Dispatch and packaging instructions .............................................................................................. 46
3. Accessories, spare parts .................................................................................................................. 47
4. Order numbers................................................................................................................................... 48
5. Additional information ...................................................................................................................... 49
15.1 Resistance list ......................................................................................................................... 49
15.2 User Notes .............................................................................................................................. 50
6. Declaration of conformity ................................................................................................................. 5

blank

POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24"
Basic
safety instructions
Technical data subject to change.
05/2019
EN 1/52
. Basic safety instructions
. Notes on this manual
Read carefully before putting the devices into operation.
The user manual is a fixed part of the product. It must be kept in the direct vicinit of the
device and the installation, operating and service staff must have access to it at all times.
The user manual contains important information, safet instructions and test certificates
which are necessar for the perfect function of the device in operation.
The user manual is directed at all individuals concerned with the commissioning, handling
and servicing of the product. The applicable guidelines and standards for areas with gas
and dust atmosphere (2014/34/EU, EN/IEC 60079-17 and
EN/IEC 60079-19) must be observed when conducting this work.
Knowledge of the safet and warning information in this user manual and the strict
compliance with it is essential for safe installation and commissioning. Accidents, injuries
and material damage can be avoided b circumspect handling and s stematicall
following the instructions.
The examples, tables, and figures provided in this user manual are for illustration
purposes. Due to the different requirements of the respective application, the BARTEC
compan cannot assume responsibilit or liabilit for actual use based on the examples
and figures.
The BARTEC compan reserves the right to carr out technical changes at an time.
In no event will BARTEC compan be responsible or liable for indirect or consequential
damages resulting from the use or application of this user manual.
Safet instructions and warnings are speciall highlighted in these operating instructions
and marked b s mbols.
DANGER
DANGER describes a directl imminent danger. If not avoided, death or severe injur will
be the consequence.
WARNING
WARNING describes a possibl imminent danger. If not avoided, death or severe injur
ma be the consequence.
CAUTION
CAUTION describes a possibl imminent danger. If not avoided, mild or slight injur ma
be the consequence.

Basic
safety instructions
POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24"
EN 2/52
Technical data subject to change.
05/2019
ATTENTION
ATTENTION describes a possibl damaging situation. If not avoided, the plant or
objects in its vicinit ma be damaged.
Important information on effective, economical & environmentall compliant handling.
. . Languages
The original user manual with safet information is written in English. All other available
languages are translations of the original user manual.
The user manual is available in German and English. If further languages are required,
these must be requested from BARTEC or stated on placing an order.
. .2 Changes in the document
BARTEC reserves the right to change the content of this document without notification.
No warrant is assumed for the correctness of the information. In cases of doubt, the
German safet instructions appl because it is not possible to rule out errors of
translation or printing. In the case of legal disputes, the “General Terms and Conditions
of Business” of the BARTEC GmbH also appl .
The current versions of the datasheets, operating instructions, certificates and EU
declarations of conformit can be downloaded from www.bartec.de or ma be requested
directl from BARTEC GmbH.
.2 Handling the product
The product described in these operating instructions has been tested and left the factor
in perfect condition as regards meeting safet requirements. To maintain this condition
and ensure that this product operates perfectl and safel , it ma be used onl in the
manner described b the manufacturer. Appropriate transportation, suitable storage and
careful operation are also essential for the perfect and safe operation of this product.
The POLARIS must be installed properl and securel if it is to work perfectl and
correctl .
The safe and perfect mounting of the POLARIS is a precondition for faultless and correct
operation.
.3 Intended use
.3. Exclusive purpose
It is used exclusivel in combination with operating devices which satisf the
requirements for Overvoltage Categor I.
The POLARIS REMOTE series have been designed speciall for use in hazardous
(potentiall explosive) areas in Zone 1 or Zones 21.
It is essential to observe the permissible operational data for the device being used.

POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24"
Basic
safety instructions
Technical data subject to change.
05/2019
EN 3/52
.3.2 Unintended use
An other use is not in accordance with the intended purpose and can cause damage
and accidents. The manufacturer will not be liable for an use be ond that of its exclusive
intended purpose.
.4 Duties of the operator
The owner/managing operator undertakes to restrict permission to work with the
POLARIS to people who:
 are familiar with the basic regulations on safet and accident prevention and have
been instructed in the use of the POLARIS;
 have read and understood the documentation, the chapter on safet and the
warnings.
The owner/managing operator must check that the safet regulations and accident
prevention rules valid for the respective application are being observed.
.5 Safety information
.5. General
 Take the device out of the hazardous area before wiping it with a dr cloth or
cleaning it!
 Do not open devices in a hazardous area.
 The general statutor regulations or directives relating to safet at work, accident
prevention and environmental protection legislation must be observed, e.g. the
German industrial health and safet ordinance (BetrSichV) or the applicable
national ordinances.
 In view of the risk of dangerous electrostatic charging, wear appropriate clothing
and footwear.
 Avoid the influence of heat that is higher or lower than the specified temperature
range.
 Protect the device from external influences! Do not expose the device to an
caustic/aggressive liquids, vapours or mist! In the event of malfunctioning or
damage to the enclosure, take the device out of the potentiall explosive area
immediatel and bring it to a safe place.
.6 General safety information for operation
.6. Maintenance
The pertinent erection and operating provisions for electrical s stems must be observed!
(e.g. Directive RL 2014/34/EU, BetrSichV and nationall applicable ordinances EN
60079-14, IEC 60079-14 and the series DIN VDE 0100)!
Observe the national waste disposal regulations when disposing of materials.

Basic
safety instructions
POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24"
EN 4/52
Technical data subject to change.
05/2019
.6.2 Servicing
No constant servicing will be necessar if operated correctl under consideration of the
assembl instructions and environmental conditions. See Chapter "Service, inspection,
repair" in this respect.
.6.3 Inspection
According to EN/IEC 60079-17 and EN/IEC 60079-19, the operator of electrical s stems
in potentiall explosive atmospheres is obliged to have these inspected b an electrician
to ensure correct condition.
.6.4 Repairs
Repairs to explosion-proof equipment ma onl be performed b persons authorized b
BARTEC, who must emplo the latest technological practices, observe the
manufacturer's instructions and use onl original spare parts. The applicable regulations
are to be observed here.
.6.5 Commissioning
It must be checked that all components and documents are available before
commissioning.
.7 Labelling, test certificate and standards
The device features an explosion protection label, as well as a test certificate. For an
explanation of the s mbols and information used, see chapter 4 "Technical data".
The POLARIS REMOTE series complies with Directive 2014/34/EU on equipment and
protective s stems intended for use in potentiall explosive atmospheres (ATEX
Directive). For information on standards that must be observed, see chapter 3 "Explosion
protection and approvals".
.8 Warranty
WARNING
Explosion protection cannot be guaranteed if non-specified components are used.
 Do not make an changes or perform an reconstruction work on the device.
 Use onl original spare parts.
The manufacturer provides a full warrant exclusivel for the spare parts it supplies.
When using parts from third parties, there is no guarantee that the have been designed
or manufactured to handle the requisite stress or offer the requisite degree of safet .

POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24"
Basic
safety instructions
Technical data subject to change.
05/2019
EN 5/52
As a fundamental rule, our “General Conditions of Sale and Deliver ” appl . These are
made available to the owner/managing operator at the latest on formation of a contract.
Guarantee and liabilit claims for personal injur and damage to propert are excluded
if the are due to one or more of the following reasons
– Use of the POLARIS for a purpose other than that for which it is intended.
– Incorrect installation, commissioning, operation and maintenance.
– Non-compliance with the instructions in the manual with respect to transport,
storage, assembl , commissioning, operation and maintenance.
– Structural modifications without our prior authorisation.
– Inadequate monitoring of components that are subject to wear
– Repairs done incorrectl .
– Disasters due to the effects of foreign matter or Act of God (events outside
human control).
BARTEC grants a warrant period of one ear on the POLARIS series, starting from the
BARTEC deliver date. The warrant period for accessories is 1 ear from the date of
deliver . This warrant covers all parts of the deliver and is limited to the free-of-charge
replacement of or repair of the defective parts b BARTEC. The packaging supplied
should ideall be retained for this purpose (return shipping). If necessar and following
written consultation, the products should be sent to us with an RMA form. No claims ma
be submitted for repair work to be performed at the installation location.

Product description POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24"
EN 6/52
Technical data subject to change.
05/2019
2. Product description
2. Definition
The POLARIS Remote KVM Digital S stem consists of a remote unit and a local unit. The
remote unit is installed internall and the local unit is contained in the scope of deliver . The
data are transferred in real time.
It is connected to the server or PC easil and directl b means of the local unit alread
included in the scope of suppl .
The POLARIS Remote KVM Digital has been optimized for signals such as HDMI/DVI and
USB. A local monitor can be connected via "Monitor Out". The local ke board and mouse
are connected to the PC directl .
The POLARIS Remote input devices are connected b onl one USB cable. If the POLARIS
Remote KVM Digital is equipped with a touch screen, the driver (which is included in the
scope of suppl ) is installed on the local PC.
An STP cable with a transmission distance of up to 100 metres is used for transfer. The
Local Unit is powered b an external power pack which is included in the scope of suppl .
The front-panel mounting design makes installation eas . On request, the devices are also
available as a read -made s stem solution in a stainless steel enclosure for wall, floor or
table mounting.
Intrinsicall safe ke boards in various national languages, and mouse, trackball, jo stick
and touchpad as front-panel installation are available. A resistive (intrinsicall safe) touch
screen and the connection of a BARTEC hand-held scanner are optional possibilities. The
intrinsicall safe input devices are supplied through barriers which are also integrated in the
POLARIS Remote.
For particularl harsh areas of use with temperatures as low as down to -40 °C, we equip
the POLARIS series with electrical heating. On request, we produce customised solutions
with more command and signalling devices.

POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24" Product description
Technical data subject to change.
05/2019
EN 7/52
2.2 Schematic design
There is firmware on both the unit remote and local unit which must have the same
firmware status for smooth transmission.
2.2. Standard – Point to Point
Local operation and the remote station are peers in the s stem
Local Unit
PC
Illustration 1: System design with STP cable up to 100 m
2.2.2 Standard - Point-to-Point with Hand-Held Scanner
The local operation and the remote station are peers in the s stem.
The hand-held scanner is connected as a USB input device from the Local Unit.
Local Unit
PC
F7 F8 F9 F10 F11 F12
Nu m Ca p s S c roll
Lo c Lo c L o c F1 F2 F3 F4 F5 F6 Es c
1 2 3 4 6 7 8 9
,
,
. -
ß
#
´
+
+
+ -
Bild En d e
Pos 1
Ein fg En tf
0 5 2 3 { [ ] \
~
}
! " § $ & / ( )
; : _
?
'
`
*
= %
Strg A lt Strg
Ein fg
En tf
Po s 1
En d e
Druc Ro llen P a u s e
Alt G r
Q
A
Y X C V B N M
S D F G H J K L Ö Ä
W E R T Z U I O P Ü 7
4
1
0
8
5
2
9
6
3
@ €
Bild N u m
En te r
<
>
^
µ
Illustration 2: System design with STP cable up to 100m and hand-held scanner

Product description POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24"
EN 8/52
Technical data subject to change.
05/2019
2.2.3 Special Application - Cascade Connection
When several POLARIS Remote devices are cascaded, the POLARIS Remote devices
are peers in the s stem. The use of the touch function must be checked in each individual
case.
Local Unit
USB/DVI
PC
USB
USB
DVI
Illustration 3: System design with STP cable up to 100 m and cascading of se eral POLARIS Remote
de ices

POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24"
Explosion protection and
approvals
Technical data subject to change.
05/2019
EN 9/52
3. Explosion protection and approvals
POLARIS REMOTE KVM Digital
Type 7-7 V2-….
ATEX
Ex protection type II 2G Ex db eb mb q [ib op pr] IIC T4 Gb
II 2D Ex mb tb IIIC T120°C Db
-20 °C ≤ Ta ≤ 60 °C
Certification IBExU 05 ATEX 1117 X
Standards in accordance with
EMC Directive 2014/34/EU
EN 60079-0:2012+A11:2013
EN 60079-1:2014
EN 60079-5:2015
EN 60079-7:2015
EN 60079-11:2012
EN 60079-18:2015
EN 60079-28:2015
EN 60079-31:2014
IECEx
Ex protection type Ex db eb q [ib op pr] IIC T4 Gb
Ex tb IIIC T120 °C Db
Certification IECEx IBE 11.0007X
Standards in accordance with
EMC Directive 2014/34/EU
IEC 60079-0:2011 Edition: 6
IEC 60079-1:2014-06 Edition: 6
IEC 60079-5:2015 Edition: 4
IEC 60079-7:2015 Edition: 5
IEC 60079-11:2011 Edition: 6
IEC 60079-18:2015 Edition: 4
IEC 60079-28:2015 Edition: 2
IEC 60079-31:2013 Edition: 2
Special conditions The intrinsicall safe circuits and the enclosure are
galvanicall connected. The equipotential bonding
must be guaranteed at the installation of the
intrinsicall safe circuits.
High charging mechanisms at the operation surface
of the Visual units respectivel accessories (for
example pneumatic particle transport) must be
excluded at the application. The degree of protection
(IP code) must be ensured b the installation of the
units in enclosures (IP code).

Explosion protection and
approvals
POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24"
EN 10/52
Technical data subject to change.
05/2019
Die POLARIS HMI are marked exclusivel according to ATEX und IECEx.
Further markings must be requested separatel .
Depending of the variant, optional additional test certificates and labeling on
request
INMETRO 11/UL-BRHZ-0131X
Customs Union Russia (EAC) TC RU C-DE.GB06.B.00334
Korea KTL 14-KB4BO-0258X
India CCEs P261984
China NEPSI GYJ18.1382X
America CSA 70010166
More test certificates www.bartec.de
EU-conformity
RoHS-Directive 2011/65/EU
Standards in accordance with
EMC Directive 20 4/30/EU
EN/IEC 61000-6-2:2005
EN 61000-6-4:2007 + A1:2011
IEC 61000-6-4:2006 + A1:2010
EN 60529:1991 + A1 2000 + A2 :2013
IEC 60529:1989 + A1 1999 + A2 :2013
Electrical safety EN/IEC 61010-1:2010
Product labelling 0044

POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24" Technical data
Technical data subject to change.
05/2019
EN 11/52
4. Technical data
4. General technical Data
Construction Front panel fitting; Optional turn-ke s stem
solutions in a stainless steel enclosure as wall,
floor or table mounting versions.
Connection to the PC with local unit (plug & pla )
through STP/S copper cable
connections
1 x HDMI/DVI in
1 x HDMI/DVI out (local monitor)
1 x USB for ke board/mouse/touch screen/
hand-held scanner
Conductor length up to 130 m with STP/S copper cable
4x2x23AWG (CAT 7)
POLARIS Remote Connection 1 x Ex e for STP/S (CAT 7)
1 x Ex e power suppl
2 x Ex i for PS/2 for intrinsicall safe ke board
and mouse
Optional interface modules 1 x Ex i Suppl module for hand-held scanner
Display Antireflection coating glass pane
Optional touch screen
Power supply AC 90 V to 253 V ± 10 %, 50 Hz to 60 Hz
DC 24 V ±10 %
Max. power consumption P
max
< 100 W depending on the version
Relative air humidity 5 to 95 % non-condensing
Vibration 0.7 G/1 mm; 5 Hz-500 Hz pulse in all 3 axes
Shock 15 G, 11 ms pulse in all 3 axes
Material
Front
Rear
Pol ester foil on anodized aluminium plate
(conditionall UV-resistant)
sheet steel bichromated
Protection class
Front
Rear
IP66
IP54
Optional approved accessories Ke board
Mouse variants
Hand-held scanner

Technical data POLARIS REMOTE - for Zone /2
POLARIS Remote KVM Digital 5" / 9. " / 24"
EN 12/52
Technical data subject to change.
05/2019
4. . Characteristics POLARIS Remote KVM Digital 5”
Display
15" graphics-capable TFT displa
XGA resolution
1024 x 768 pixels
16.7 million colours
Brightness 350 cd/m2
Visible surface
approx. 304 x 228 mm
Contrast 400:1
Backlighting LED technolog , Service life
approx. 50,000 hours (at +25 °C)
Permissible ambient temperature
Storage/Transport
Operation
-20 °C to +50 °C
0 °C to +50 °C
Dimensions
(width x height x depth) 411 mm x 332 mm x approx. 135 mm
Wall cut-out
(width x height) 394.5 mm x 315.5 mm + 0.5 mm
Weight approx. 23 kg
4. .2 Characteristics POLARIS Remote KVM Digital 5" Sunlight
Display 15" graphics-capable TFT displa
XGA resolution,
1024 x 768 pixels
16.7 million colours
Brightness 1000 cd/m
2
Visible surface
approx. 304 x 228 mm
Contrast 700:1
Backlighting LED technolog , Service life
approx. 50,000 hours (at +25 °C)
Permissible ambient temperature
Storage/Transport
Operation
-20 °C to +60 °C
-20 °C to +60 °C
Dimensions
(width x height x depth) 411 mm x 332 mm x approx. 135 mm
Wall cut-out
(width x height) 394.5 mm x 315.5 mm + 0.5 mm
Weight approx. 23 kg
