Bartec BCS3600ex Series User manual

User Manual
Handheld scanner series BCS 3600ex

BARTEC GmbH
Max-Eyth-Straße 16
97980 Bad Mergentheim
GERMANY
Phone: [phone]
Fax: [phone]
Support: [e-mail]
Download: http://automation.bartec.de
Internet: www.bartec.de
User Manual – Translation of the original
Hand-held scanner
BCS 3608ex-NI, BCS 3608ex-IS
BCS 3678ex-NI, BCS 3678ex-IS
ATEX / IECEx Zone 1 and Zone 21
ATEX / IECEx Zone 2 and Zone 22
NEC / CEC Class I, II, III DIV 1
NEC / CEC Class I, II, III DIV 2
Document No.: 11-A1S4-7D0001
Status: 15.04.2019 / Revision A

Handscanner
BCS 3600
ex
series
Contents
1 About this documentation ...............................................................................................................................7
1.1 Target groups .......................................................................................................................................................................7
1.2 Explanation of Symbols ........................................................................................................................................................8
1.2.1 Warnings...............................................................................................................................................................................8
1.2.2 Symbols and means of presentation ....................................................................................................................................9
1.2.3 Explanation of terms.............................................................................................................................................................9
1.3 Technical changes................................................................................................................................................................9
1.4 Languages............................................................................................................................................................................9
1.5 Reference documents.........................................................................................................................................................10
2 Safety............................................................................................................................................................... 11
2.1 Intended use.......................................................................................................................................................................11
2.2 Personnel qualifications......................................................................................................................................................12
2.3 Explosion protection ...........................................................................................................................................................12
2.3.1 Using hand-held scanners and accessories.......................................................................................................................12
2.4 Residual risks .....................................................................................................................................................................13
2.4.1 Risk of an explosion caused by electrical ignition sources .................................................................................................13
2.4.2 Damage to eyes caused by laser light................................................................................................................................14
2.4.3 Risks of cuts if the scan window is broken .........................................................................................................................14
2.4.4 Health hazard in the case of incorrect disposal..................................................................................................................14
2.5 Preventing damage to property ..........................................................................................................................................14
2.5.1 Short circuit caused by incorrect connection ......................................................................................................................14
2.5.2 Storage at too high a temperature......................................................................................................................................14
2.5.3 Contact with chemicals.......................................................................................................................................................14
2.5.4 Aggressive cleaning agents................................................................................................................................................14
3 Approval, standards....................................................................................................................................... 15
3.1 Hand-held scanner BCS 3608ex-IS.....................................................................................................................................15
3.2 Hand-held scanner BCS 3678ex-IS.....................................................................................................................................15
3.3 Universal supply module 3678ex-IS/3608ex-IS ....................................................................................................................16
3.4 Hand-held scanners BCS 3608ex-NI/BCS 3678ex-NI ..........................................................................................................16
3.5 Ex-relevant parameters for connection to universal supply module or other systems........................................................17
4 Product description........................................................................................................................................ 19
4.1 Configurations and comparison with ZEBRA hand-held scanners .....................................................................................19
4.2 Possible system configurations ..........................................................................................................................................20
4.2.1 Corded hand-held scanner BCS 3608ex-NI / BCS 3608ex-IS with universal supply module ...............................................20
4.2.2 Corded hand-held scanner BCS 3608ex-NI with HMI (only Zone 2 and 22) and HMI limiting cable*..................................21
4.2.3 Corded hand-held scanner BCS 3608ex-NI / BCS 3608ex-IS with universal supply module ...............................................22
4.2.4 Bluetooth hand-held scanners BCS 3678ex-NI / BCS 3678ex-IS with base station and Bluetooth-enabled device ............23
4.2.5 Bluetooth hand-held scanners BCS 3678ex-NI / BCS 3678ex-IS via Bluetooth universal supply module ........................... 24
4.3 Corded hand-held scanners BCS 3608ex-NI/BCS 3608ex-IS ..............................................................................................25

Contents
Handscanner
BCS 3600
ex
series
4.3.1 Construction of the corded hand-held scanners.................................................................................................................25
4.3.2 Contacts / cables ................................................................................................................................................................26
4.4 Bluetooth hand-held scanner BCS 3678ex-NI / BCS 3678ex-IS...........................................................................................28
4.4.1 Construction of the Bluetooth hand-held scanner...............................................................................................................28
4.4.2 External contacts ................................................................................................................................................................29
4.4.3 Communication via Bluetooth .............................................................................................................................................29
4.4.4 Construction of base station (cradle)..................................................................................................................................30
4.4.5 Construction of 4-slot charging station for spare batteries .................................................................................................32
4.5 Meaning of LED display / beeps.........................................................................................................................................33
4.5.1 Hand-held scanner .............................................................................................................................................................33
4.5.2 Base station ........................................................................................................................................................................33
4.6 Construction of the universal supply module......................................................................................................................34
4.6.1 Terminal assignment ..........................................................................................................................................................35
4.6.2 Setting the DIP switches (only for Zone 2/22 and Div 2) ....................................................................................................36
4.6.3 Ranges / maximum cable length of connected cable from the universal supply module to the host or PC .......................36
4.6.4 Permissible core cross-sections .........................................................................................................................................37
Permissible connection cable diameter ..............................................................................................................................37
4.6.6 Terminals for outer conductors...........................................................................................................................................37
4.6.7 Recommendation for data line............................................................................................................................................38
4.6.8 Ferrite core for data cable...................................................................................................................................................38
4.7 Product marking hand-held scanner...................................................................................................................................40
4.8 Product marking universal supply module..........................................................................................................................41
4.9 Decodable barcode types...................................................................................................................................................42
5 Transport and storage....................................................................................................................................43
5.1 Check the contents and condition of delivery .....................................................................................................................43
5.2 Storage ...............................................................................................................................................................................43
5.2.1 Battery ................................................................................................................................................................................43
6 Configuration ..................................................................................................................................................44
6.1 Programming tools..............................................................................................................................................................44
6.1.1 Programming manuals........................................................................................................................................................44
6.1.2 Zebra 123Scan Utility .........................................................................................................................................................44
6.1.3 Required programming cables............................................................................................................................................46
6.1.4 Further tools........................................................................................................................................................................46
6.2 Manuals for general programming......................................................................................................................................46
6.3 Programming for software developers................................................................................................................................47
6.3.1 Programming manuals........................................................................................................................................................47
6.3.2 Developer tools...................................................................................................................................................................47
6.3.3 Drivers ................................................................................................................................................................................47
6.4 Functions ............................................................................................................................................................................48
6.4.1 Comparison ........................................................................................................................................................................48

Handscanner
BCS 3600
ex
series
Contents
6.4.2 General Device Settings (User Preferences)......................................................................................................................48
6.4.3 Pairing (only with BCS 3678ex) ...........................................................................................................................................49
6.4.4 Number of Bluetooth Connections (only for BCS 3678ex)...................................................................................................50
6.4.5 Unpairing the Bluetooth hand-held scanner .......................................................................................................................50
6.4.6 Pairing with other Bluetooth-enabled devices (only with BCS 3678ex) ...............................................................................51
6.4.7 Scanning when out of range - Out of Range & Batch Mode (only with BCS 3678ex)..........................................................51
Prefix and Suffix..................................................................................................................................................................52
6.4.9 Advanced Data Formatting (ADF) ......................................................................................................................................53
6.4.10 Multicode Data Formatting (MDF) ......................................................................................................................................53
6.5 Pairing options for Bluetooth hand-held scanner (only for BCS 3678ex).............................................................................55
6.5.1 Radio Communication General...........................................................................................................................................55
6.5.2 Pairing between Bluetooth hand-held scanner and base station (cradle) ..........................................................................56
6.5.3 Pairing between Bluetooth hand-held scanner and universal power supply module..........................................................58
6.5.4 Pairing between Bluetooth hand-held scanner and Bluetooth enabled device...................................................................60
6.5.7 Creating Pairing Barcodes with Zebra 123 Scan Utility ......................................................................................................64
6.6 Threshold values for battery level for Bluetooth hand-held scanners.................................................................................64
6.6.3 Programming the interface parameters ..............................................................................................................................67
7 Connection / commissioning (qualified personnel) ....................................................................................68
7.1 Corded hand-held scanner BCS 3608ex-NI / BCS 3608ex-IS ..............................................................................................68
7.1.1 Connecting the connection cable to the hand-held scanner...............................................................................................68
7.2 Universal supply module.....................................................................................................................................................70
7.2.1 Establishing universal supply module connections.............................................................................................................70
7.2.2 Connecting the USM to an HID device...............................................................................................................................71
7.2.3 Connecting the USM to a PLC............................................................................................................................................71
7.3 Bluetooth hand-held scanner BCS 3678ex-NI / BCS 3678ex-IS...........................................................................................73
7.3.1 Connecting the base station to the host PC and power source..........................................................................................73
7.4 Connecting to the HMI: connecting the hand-held scanner to the HMI ..............................................................................75
Wiring diagram for Universal Supply Module (USM) ..........................................................................................................76
USM with USB-SPP Interface.............................................................................................................................................76
USM with RS232 Interface .................................................................................................................................................77
USM with RS422 Interface .................................................................................................................................................78
USM with RS485 Interface .................................................................................................................................................79
Explanation of the interfaces ..............................................................................................................................................80
Testing the communication (RS232 or USB-SPP) .............................................................................................................82
8 Operation......................................................................................................................................................... 84
8.1 Bluetooth hand-held scanners BCS 3678ex-NI / BCS 3678ex-IS.........................................................................................84
8.1.1 Changing the battery ..........................................................................................................................................................84
8.1.2 Placing the hand-held scanner in the base station.............................................................................................................86
8.1.3 Connecting the Bluetooth hand-held scanner to the base station ......................................................................................87
8.1.4 Charging the battery ...........................................................................................................................................................87
8.2 Inspection to be conducted prior to use..............................................................................................................................90

Contents
Handscanner
BCS 3600
ex
series
8.3 Scanning.............................................................................................................................................................................91
8.3.1 Optimal scan position .........................................................................................................................................................92
9 Cleaning .......................................................................................................................................................... 93
9.1 Suitable cleaning agents.....................................................................................................................................................93
9.2 Cleaning the enclosure.......................................................................................................................................................93
9.3 Cleaning the scan window..................................................................................................................................................93
9.4 Cleaning the contacts .........................................................................................................................................................93
10 Maintenance, inspection, repair.................................................................................................................... 94
10.1 Maintenance intervals.........................................................................................................................................................94
10.2 Returning faulty devices .....................................................................................................................................................94
11 Faults – causes and remedies.......................................................................................................................95
11.1 Restoring the connection between Bluetooth hand-held scanner and base station ...........................................................97
11.2 Resetting the hand-held scanner........................................................................................................................................97
Set Factory Default - Remove Custom Defaults (Reset to Factory Defaults).....................................................................98
Write to Custom Defaults - Set user-defined default values...............................................................................................98
11.2.3 Notes on resetting the hand-held scanners........................................................................................................................99
Pairing with base station doesn’t work................................................................................................................................99
Base station does not work...............................................................................................................................................100
12 Disposal......................................................................................................................................................... 101
13 Ambient conditions ...................................................................................................................................... 102
14 Scope of delivery.......................................................................................................................................... 103
15 Annex............................................................................................................................................................. 104
15.1 Technical data ..................................................................................................................................................................104
15.2 Approved accessories ......................................................................................................................................................104
15.3 Notice................................................................................................................................................................................106

Handscanner
BCS 3600
ex
series
1About this documentation
Subject to technical modifications
Revision A / 04/2019
7 / 106
1About this documentation
Read carefully before commissioning the device.
The User Manual is an integral part of the device.
The User Manual is directed at all persons who are entrusted with handling the device.
Knowledge of the safety instructions and warnings in this User Manual and strict compliance with
them is essential for safe handling.
‒Carefully read the User Manual and especially the safety instructions before using the device.
‒Keep the User Manual throughout the service life of the device.
‒Make the User Manual accessible to all people who are entrusted with handling the device.
1.1 Target groups
Table 1Tasks of the various target groups
Target group
Tasks
Company electrician
•Connection
•Commissioning and decommissioning
•Repair
•Cleaning
IT specialist •Configuration
•Cleaning
Forwarding agent
•Transport
Operator
•Operating the scanner after instruction
by the operating company
•Changing batteries
•Bluetooth version: charging the battery
•Cleaning

1About this documentation
Handscanner
BCS 3600
ex
series
8 / 106
Subject to technical modifications
Revision A / 04/2019
1.2 Explanation of Symbols
1.2.1 Warnings
Warnings are used in this User Manual to warn of the risks of damage to property and personal injuries.
Always read and follow these warnings.
Warnings in this User Manual are specially highlighted and indicated by symbols:
DANGER
DANGER designates a hazardous situation that can lead to death or serious, permanent
injuries if safety measures are disregarded.
WARNING
WARNING designates a hazardous situation that can lead to serious but not permanent injuries
if safety measures are disregarded.
CAUTION
CAUTION designates a hazardous situation that can lead to minor injuries if safety measures
are disregarded.
ATTENTION
ATTENTION designates a hazardous situation that can lead to material damage if safety
measures are disregarded.
Explanation of the structure of a warning
WARNING TERM
Specification of the source of danger, cause of danger or type of danger
Consequence if the safety measures described are disregarded.

Safety measure
Example of a warning
DANGER
Changing the battery in a potentially explosive atmosphere!
Death or serious injury.

Only change the battery outside the potentially explosive atmosphere.

Handscanner
BCS 3600
ex
series
1About this documentation
Subject to technical modifications
Revision A / 04/2019
9 / 106
1.2.2 Symbols and means of presentation
Table 2Symbols and means of presentation
1.2.3 Explanation of terms
Some abbreviations are used in the documentation.
IS - Intrinsically Safe is used as an umbrella term for the Zone 1 and Division 1 versions.
NI - Non Incendive is used as an umbrella term for Zone 2 and Division 2.
BCS 3600ex - stands for the entire explosion-protected product range.
1.3 Technical changes
The current versions of data sheets, operating instructions, certificates, EU declarations of conformity
and information about new accessories can be downloaded from www.bartec.com under “Products” in
the “Automation & Enterprise Mobility ” product area or can be requested directly from BARTEC GmbH
(see Chapter 1.5).
Please find further Service and Support download information on
http://automation.bartec.de/indexE.htm
1.4 Languages
The original User Manual was drawn up in German. All other available languages are translations of
the original User Manual.
The User Manual is available in German, English and French. If other languages are required, these
should be requested from BARTEC or specified when placing the order.
Symbol
Explanation
Important advice and information for the effective, efficient and environmentally
sound use of the product.
Condition that must be met before the subsequent actions can be performed.
Individual steps you must take.
1., 2., … Various steps to be performed in the order specified.
Indication of the results of a step or of several steps for monitoring success.

1About this documentation
Handscanner
BCS 3600
ex
series
10 / 106
Subject to technical modifications
Revision A / 04/2019
1.5 Reference documents
All documents are available online from the following websites:
‒BARTEC (global): www.bartec.com
‒BARTEC: http://automation.bartec.de
‒ZEBRA (ZEB): www.zebra.com
In the event of an overlaps with Zebra user manuals, the instructions in the BARTEC User Manual
apply. The BARTEC User Manual takes priority.
Document
Explanation
Download site
BARTEC
Quick Start Guide
BCS 3608ex-NI/BCS 3608ex-IS/
BCS 3678ex-NI/BCS 3678ex-IS
Guidelines on
commissioning and the
safe use of hand-held scanners
(including installation, safety information
related to explosion protection and
information regarding programming)
global
Data sheet
BCS 3608ex-NI/BCS 3608ex-IS/
BCS 3678ex-NI/BCS 3678ex-IS
Data on explosion protection and
technical data for hand-held scanners,
universal supply module and
accessories
global
ZEBRA
For DS3608-HP and DS3678-
HP:
•Product Reference
Guide
•Multicode Data
Formatting and
Preferred Symbol
•Advanced Data
Formatting (ADF)
•Simple Serial
Interface
Programmer's Guide
Instructions for commissioning,
operating, configuring, programming
and maintaining hand-held scanners (full
information can be found on the ZEBRA
support page).
ZEB
Table 3Reference documents
Further information on programming hand-held scanners can be found in the original Zebra
documentation. The explosion protected BARTEC BCS 3608ex-NI / BCS 3608ex-IS / BCS 3678ex-NI
/ BCS 3678ex-IS hand-held scanners are based on the Zebra DS3608-HP and DS3678-HP hand-
held scanners.

Handscanner
BCS 3600
ex
series
2Safety
Subject to technical modifications
Revision A / 04/2019
11 / 106
2Safety
2.1 Intended use
The hand-held scanners in the BCS 3600ex series are hand-operated items of electrical equipment.
They are used for the mobile capture, processing and transfer of data within potentially explosive
atmospheres.
The data are transferred either using a connection cable (BCS 3608ex) or using a Bluetooth connection
(BCS 3678ex).
The hand-held scanners in the BCS 3600ex series have been modified for use in the following potentially
explosive atmospheres:
Configuration
Approved zone
BCS 3678
ex
-IS
(Type 17-A1S4-XXXX)
ATEX / IECEx Zone 1 and
Zone 21
NEC / CEC Class I, II, III DIV 1
BCS 3608
ex
-IS
(Type 17-A1S4-XXXX)
BCS 3678
ex
-NI
(Type B7-A2S4-XXXX)
ATEX / IECEx Zone 2 and
Zone 22
NEC / CEC Class I, II, III DIV 2
BCS 3608
ex
-NI
(Type B7-A2S4-XXXX)
Table 4Assignment configuration for the explosion protected area
The hand-held scanners may only be used together with operating equipment that corresponds to
Installation Category I.
You must comply with the permissible ambient conditions for the device used (see chapter 14).

2Safety
Handscanner
BCS 3600
ex
series
12 / 106
Subject to technical modifications
Revision A / 04/2019
2.2 Personnel qualifications
The following skills are required for handling the device:
Target group
Skills
Qualified electricians •Professional training
•Knowledge and experience to
recognise and avoid risks that can
emanate from electricity
•Understanding of the overall system
•Special instruction for potentially
explosive atmospheres
IT specialists
•Understanding of the overall system
•Configuration/programming
•Understanding of programming
manuals
Warehouse and transport employees
•Loading and transport activities
•Correct storage
Operators
•Instruction by the operating company
on operation, changing and loading
the battery
•Special instruction for potentially
explosive atmospheres
Table 5Personnel qualifications
2.3 Explosion protection
Incorrect use of the hand-held scanner and its accessories can trigger fires and explosions in potentially
explosive atmospheres.
Read the instructions in this Manual thoroughly and follow them when using the device.
In the event of an overlaps with user manuals from Zebra, the instructions in the BARTEC User Manual
apply. The BARTEC User Manual takes priority.
2.3.1 Using hand-held scanners and accessories
Always carry out an inspection prior to use (see Chapter 8.2).
Ensure that the application area corresponds to the explosion protection marking and permissible
ambient conditions (see chapter 14).
Remove the device from the potentially explosive atmosphere immediately in the event of a
malfunction or damaged enclosure.
Only use accessories specified by BARTEC in the potentially explosive atmosphere.
Have all maintenance work on and inspections of accessories conducted by authorised personnel.
Have all repairs to the hand-held scanner conducted by BARTEC.

Handscanner
BCS 3600
ex
series
2Safety
Subject to technical modifications
Revision A / 04/2019
13 / 106
2.4 Residual risks
2.4.1 Risk of an explosion caused by electrical ignition sources
Electrical ignition sources can trigger fires and explosions in a potentially explosive atmosphere.
Non-approved components
Specific hand-held scanners and accessories (including universal supply module, battery, cable) are
suitable for each potentially explosive atmosphere. Hand-held scanners and components that have not
been approved for the respective potentially explosive atmosphere may trigger explosions.
Only use components that have been approved for the relevant potentially explosive atmosphere.
Spark formation during battery change and cable connection
Sparks can arise when changing the battery or connecting cables. Sparks can trigger an explosion in
a potentially explosive atmosphere.
Only insert or remove the battery outside the potentially explosive atmosphere.
Only connect or disconnect the cable outside the potentially explosive atmosphere.
Always have cables connected by a qualified electrician.
Spark formation caused by the battery falling out / the connection cable coming unplugged
The following risks arise if the safety lock on the underside of the hand-held scanner is not correctly
closed:
‒The battery on a Bluetooth hand-held scanner can fall out.
‒The connection cable on a corded hand-held scanner can come unplugged.
This can produce sparks which can trigger an explosion.
Check that the safety lock is correctly closed before taking the hand-held scanner into the
potentially explosive atmosphere.
Broken enclosure: loss of explosion protection
The hand-held scanner has been tested for falls from a height of up to 2.4 m (7.9 ft) (Zone 2 / Div. 2)
and 1.2 m (4 ft) (Zone 1 / Div. 1). There is a risk of the enclosure breaking during falls from a greater
height, in which case the explosion protection is no longer guaranteed.
Protect hand-held scanners from falling from a greater height.
If the hand-held scanner has fallen from a greater height or you suspect a damaged enclosure:
– Remove the hand-held scanner from the potentially explosive atmosphere immediately.
– Send the faulty hand-held scanner to BARTEC and reference the RMA number you were
issued.
Corrosion: loss of explosion protection
The enclosure of the hand-held scanner has protection class IP65, however constant exposure to
moisture can lead to corrosion. This may lead to the loss of the explosion protection.
Protect hand-held scanners against constant exposure to moisture.
Do not subject hand-held scanners to any damp weather conditions.

2Safety
Handscanner
BCS 3600
ex
series
14 / 106
Subject to technical modifications
Revision A / 04/2019
2.4.2 Damage to eyes caused by laser light
The hand-held scanner operates with a Class 2 laser. Laser beams can damage eyes.
Do not look into the laser beam.
2.4.3 Risks of cuts if the scan window is broken
The scan window may become damaged if the hand-held scanner falls down. There is a risk of cuts if
you reach into the broken or cracked area.
When getting the hand-held scanner out, secure it to prevent it falling down.
Only get the hand-held scanner out when it reaches its destination.
If the scan window is broken:
– Do not touch the broken area.
– Do not use the hand-held scanner.
– Send the faulty hand-held scanner to BARTEC and reference the RMA number you were
issued.
2.4.4 Health hazard in the case of incorrect disposal
Lithium ion batteries on the Bluetooth hand-held scanner contain pollutants that can be harmful to
health.
Dispose of batteries in an environmentally sound way in accordance with regional regulations.
2.5 Preventing damage to property
2.5.1 Short circuit caused by incorrect connection
Incorrect electrical connection can cause a short circuit, thereby damaging the hand-held scanner.
Always have the hand-held scanner connected by a qualified electrician in accordance with the
connection diagram.
2.5.2 Storage at too high a temperature
A thermal fuse prevents the hand-held scanner getting too hot during operation and triggering an
explosion. There is also a risk of the hand-held scanner getting too hot if the hand-held scanner is
stored outside of the permissible ambient temperatures. The hand-held scanner is damaged as soon
as the thermal fuse responds.
Only store the hand-held scanner within the permissible ambient temperatures.
2.5.3 Contact with chemicals
The enclosure of the hand-held scanner consists of polycarbonate that has only limited chemical
resistance. Contact with chemicals can break the enclosure.
Do not bring the hand-held scanner into contact with chemicals.
2.5.4 Aggressive cleaning agents
Aggressive cleaning agents can attack and fade the scan window, thereby impairing the scanning
functionality. In extreme cases scanning is no longer possible.
Only use a damp cloth to clean the hand-held scanner.

Handscanner
BCS 3600
ex
series
3Approval, standards
Subject to technical modifications
Revision A / 04/2019
15 / 106
3Approval, standards
3.1 Hand-held scanner BCS 3608ex-IS
Table 6Hand-held scanner BCS 3608ex-IS
Further approvals and certificates can be found at www.bartec.com
3.2 Hand-held scanner BCS 3678ex-IS
Further approvals and certificates can be found at www.bartec.com
Standard
Ex protection type
Certification
ATEX
Zone 1/21
II 2G Ex ia ma op is IIC T4 Gb
II 2D Ex ia ma op is IIIC T135°C Db IP 64
EPS 18 ATEX 1 199 X
IECEx
Zone 1/21
Ex ia ma op is IIC T4 Gb
Ex ia ma op is IIIC T135°C Db IP 64
IECEx EPS 18.0100X
NEC/CEC
Div 1
Class I, II, III Div 1
Class I Div 1 Groups A, B, C and D
Class II Div 1 Groups E, F
Class III
Class I Div 1
Class I Div 1 Groups A, B, C and D T4
Applied for
Standard Ex protection type Certification
ATEX
Zone 1/21
II 2G ia ma op is IIC T4 Gb
II 2D Ex ia ma op is III T135 ^C Db IP 64
EPS 17 ATEX 1 177 X
IECEx
Zone 1/21
Ex ia ma op is IIC T4 Gb
Ex ia ma op is IIIC T135°C Db IP 64
IECEx EPS 17.0090X
NEC/CEC
Div 1
Class I, II, III Div 1
Class I Div 1 Groups A, B, C and D
Class II Div 1 Groups E, F
Class III
Class I Div 1
Class I Div 1 Groups A, B, C and D T4
Applied for
Table 7Hand-held scanner BCS 3678ex-IS

3Approval, standards
Handscanner
BCS 3600
ex
series
16 / 106
Subject to technical modifications
Revision A / 04/2019
3.3 Universal supply module 3678ex-IS/3608ex-IS
Further approvals and certificates can be found at www.bartec.com
The universal supply module Zone 2/22 and Div 2 are included in the certificate of the Zone 2/22
and Div 2 hand-held scanner.
3.4 Hand-held scanners BCS 3608ex-NI/BCS 3678ex-NI
Standard
Ex protection type
Certification
ATEX
Zone 2/22
II 3G Ex ic IIC T4 Gc
II 3D Ex ic IIIB T135°C Dc IP 64
EPS 16 ATEX 1113 X
IECEx
Zone 2/22
Ex ic IIC T4 Gc
Ex ic IIIB T135°C Dc IP 64
IECEx EPS 16.0050X
ETL Div 2 Class I,II,III Div 2
Class I Div 2 Groups A,B,C,D
Class II Div 2 Group F,G
Class III
Class I Div 2
Class I Div 2 Groups A,B,C and D T4
Conforms to ANSI/UL Std. 60950
Cert. to CAN/CSA Std. C22.2 No. 60950
5012876
Table 9Hand-held scanner BCS 3608ex-NI/BCS 3678ex-NI
Further approvals and certificates can be found at www.bartec.com
Standard
Ex protection type
Certification
ATEX
Zone 1/21
II 2G Ex ma [ia] IIC T4 Gb
II 2D Ex ma [ia] IIC T135°C Db IP 64
Applied for
IECEx
Zone 1/21
Ex ma [ia] IIC T4 Gb
Ex ma [ia] IIC T135°C Db IP 64
Applied for
NEC/CEC
Div 1
Class I, II, III Div 1
Class I Div 1 Groups A, B, C und D
Class II Div 1 Groups E, F
Class III
Class I Div 1
Class I Div 1 Groups A, B, C und D T4
Applied for
Table 8Universal Versorgungsmodul 3678ex-IS/3608ex-IS

Handscanner
BCS 3600
ex
series
3Approval, standards
Subject to technical modifications
Revision A / 04/2019
17 / 106
3.5 Ex-relevant parameters for connection to universal supply module or other
systems
Important information for connecting the corded hand-held scanner BCS 3608ex-NI to a Universal
Supply Module (USM) or to third-party systems.
•ATEX/IECEx – Zone 2/22
•Class I, II Division 2
•Class III
Figure 1 Ex relevant paramaters for the connection of the USM
Available USM:
available for input
voltage
available for use in hazardous
areas:
USM for BCS 3608ex-NI 24 V DC 85 to 250 V
AC
ATEX/IECEx
Zone 2/22
Class I, II
Division 2
Class III
Type: B7-A2Z0-0042 Yes Yes Yes No
Version for US + Canada
Type: B7-A2Z0-004200US
Yes No Yes Yes
Table 10 Available USM
Safe area
Ex-relevant parameters
for BARTEC UVM
USM Output values:
Voc 5 V
Isc 1 A
Ca1000 μF
La 80 μH
Ex-relevant parameters
for BCS 3608ex-NI
Input values:
Vmax 5 V
Imax 1 A
Ci0,3 μF
Li0,1 μH

3Approval, standards
Handscanner
BCS 3600
ex
series
18 / 106
Subject to technical modifications
Revision A / 04/2019
Important Ex-relevant technical data for the connection of a non-incendive wired field device (e.g.
BCS 3608ex-NI) with another associated non-incendive wired field device (e.g. USM B7-A2Z0-0042).
The USM can also be replaced by power supply modules from other manufacturers provided that the
following calculation formula is adhered to.
Calculation
formula BCS 3608ex-NI Maximum output values of the used supply module:
Functional
minimum
values
V
max
≥ V
oc
V
max
5 V DC
V
oc
5 V
4,8 V DC
I
max
≥ I
sc
I
max
1 A
I
max
1 A
500 mA
Minimum output values of the used
supply module:
Ca≥ Ci+ CKabel Ci0,3 μF + CKabel
BARTEC USM: C
a
= 1000μF (is ≥ C
i
+
CKabel)
external system Ca≥ Ci+ CKabel
(kundenspezifisch)
-
La≥ Li+ LKabel Li0,1 μH + LKabel
BARTEC USM: L
a
= 80μH(is ≥ L
i
+
LKabel)
external system: La≥ Li+ LKabel
(customized)
-
Table 11 Ex relevant date for the connection of the USM
C
Kabel
and L
Kabel
depend on the connection cable used on the BCS 3608
ex
-NI.
