Impact Blow Gun
Product
introduction
Application
example video
High Peak Pressure Type
IBG1 Series
Compact Type
IBG2 Series
p. 4p. 5
M Occupied volume:
13% reduction
M Lightweight:
21% reduction
M Peak pressure:
3 times or more
Peak
pressure
87%
reduction
97%
reduction
3 times
or more
2.5 times
or more
Air
consumption
Operation
time
∗1∗2
IBG1
IBG2
Increased impact force
due to higher peak pressure
Instantaneous air blow
reduces air consumption and operation time
IBG1
RoHS
CAT.ES50-40B
IBG Series
Impact Blow Gun
Air Saving

Grip outer circumference:
Approx. 17% reduction
9.3 mm
shorter
Height
Depth
7 mm shorter
174.5 mm
76 mm
Slim, easy-to-hold grip
Variations
∗1 Operating pressure: 0.5 MPa
∗1 Compared with the existing VMG series model ∗2 The amount of air filled in the tank at 0.5 MPa operating pressure
Peak pressure
Peak pressure comparison A compact type has been added.
IBG1 Series
IBG2 Series
Tank capacity: 70 cc
Tank capacity: 100 cc
VMG Series
Series Peak pressure∗1
Size
(Height x Depth x Width)
[mm]
Weight
[g]
Tank capacity
[cc]
Air
consumption∗2
[cc]
Supply port
High Peak Pressure Type
IBG1 Series
3 times
or more
183.8 x 83 x 41 380 100 600
Screw-in type
(Rc, NPT, G) 3/8
One-touch fittings
ø6 to ø10
ø1/4" to ø3/8"
S coupler
R3/8
Compact Type
IBG2 Series
2.5 times
or more 174.5 x 76 x 41 300 70 420
Screw-in type
(Rc, NPT, G) 1/4
One-touch fittings
ø6 to ø10
ø1/4" to ø3/8"
S coupler
R1/4
3 times
or more
2.5 times
or more
Occupied
volume
13 % reduction
543 cm3(IBG2)
c
625 cm3(IBG1)
Light
weight
300 g (IBG2)
c
380 g (IBG1)
Air
consumption
30 % reduction
∗1
420 cc (IBG2)
c
600 cc (IBG1)
21 % reduction
1
Air Saving Impact Blow Gun IBG Series

Various Functions
MAdjuster with indicator∗1
MWith S coupler/
One-touch fitting
MOperational force: 10 N or less
MChip guard
Guards against the blown machining
chips and workpiece
Quick and simple peak pressure adjustment is possible.
∗1 IBG1 only MLong nozzle
Nozzle length:
50/100/150/300/
600/1000 mm
MLong nozzle
with a silencer
80 dB(A) or less
∗Based on SMC’s
measurement
conditions
∗ Please order it
separately. It is
possible to use the
guard with a silencer,
but in that case,
mount the guard
before mounting the
silencer.
Related Product
Polyurethane
Coil Tubing
TCU
Peak pressure [MPa]
Number of needle rotations
0
0.1
0.2
0.3
43210
Peak pressure and the number of
needle rotations
(Supply pressure: 0.5 MPa)
M Compliant with OSHA
Standards (U.S. Standards)
Silencer 1910.95: Max. noise level
1910.242B: Max. discharge pressure
Chip guard 1910.242B
M Built-in tank provides a stable discharge
pressure
Tank
As the tank is built into the
air gun, the product is not
affected by pressure drops
on the inlet side.
Indicator
window
Number of
needle rotations
0 0
1 1
2 2
3 3
4 4
∗Based on SMC’s measurement conditions
∗Without silencer
With S coupler With One-touch fitting
Built-in tank
2
Air Saving Impact Blow Gun IBG Series

For the reliable and simple removal of machining
chips, foreign matter, and water droplets
Application Examples
For the quick removal of machining chips coated with oil For the removal of foreign matter with a single shot from a distance
For finishing the removal of water dropletsFor the separation of workpieces stuck together with oil, etc.
For blowing away sticky soil For the removal of dust
CONTENTS
Powerful
blow
Reduced
air
consumption
Reduced
operation
time
High Peak Pressure Type Impact Blow Gun
IBG1 Series
How to Order p. 4
Specifications p. 4
Compact Type Impact Blow Gun
IBG2 Series
How to Order p. 5
Specifications p. 5
Dimensions p. 6
How to Mount a Nozzle p. 8
Specific Product Precautions p. 9
3
Air Saving Impact Blow Gun IBG Series

Adjuster
Symbol Type
0Without adjuster
1With adjuster
Supply port Nozzle (Refer to page 8 for details.)
Symbol Type Nozzle length Nozzle part no.*2
Nil Without nozzle — —
01
Long nozzle*1
50 mm IBG1-12-10-50
02 100 mm IBG1-12-10-100
03 150 mm IBG1-12-10-150
04 300 mm IBG1-12-10-300
05 600 mm IBG1-12-10-600-X1
06 1000 mm IBG1-12-10-1000-X1
11
Long nozzle with a
silencer*1, *3
50 mm IBG1-12-10-50S
12 100 mm IBG1-12-10-100S
13 150 mm IBG1-12-10-150S
14 300 mm IBG1-12-10-300S
15 600 mm IBG1-12-10-600S-X1
16 1000 mm
IBG1-12-10-1000S-X1
*1 A long nozzle and a silencer are included in a package but do
not come mounted. Refer to page 8 for assembly procedures.
*2 This is the part number for the long nozzle and fitting set.
*3 The silencer and long nozzle can be used together. Part number
for ordering a silencer alone is IBG1-12S.
Impact Blow Gun
IBG1 Series
How to Order
Specifications
IBG1 0
Model IBG10
(Without adjuster)
IBG11
(With adjuster)
Fluid Air
Max. operating pressure 0.7 MPa
Proof pressure 1.05 MPa
Fluid and ambient temperature range +5 to +60°C
Operational force 10 N or less
Weight*1380 g 400 g
*1 For the screw-in type
Screw-in type
Symbol Size
Nil Rc3/8
NNPT3/8
FG3/8
With S coupler/One-touch fitting
Symbol Applicable
tubing O.D. Part no. Appearance
S coupler
11 — KK4P-03MS
12 — KK130P-03MS
One-touch fitting
H06 ø6 KQ2H06-03AS
H08 ø8 KQ2H08-03AS
H10 ø10 KQ2H10-03AS
H07 ø1/4" KQ2H07-36AS
H09 ø5/16" KQ2H09-36AS
H11 ø3/8" KQ2H11-36AS
*The S coupler or fitting is shipped together with the product.
*For the S coupler or metric size One-touch fitting (H06, H08,
H10), the port size on the impact blow gun side is Rc3/8.
*For the inch size One-touch fitting (H07, H09, H11), the port
size on the impact blow gun side is NPT3/8.
02
Silencer
High Peak Pressure Type
Chip Guard (Please order it separately.)
Description Part no.
Chip guard IBG1-12C
Guards against the blown machining
chips and workpiece
p. 8
Symbol
Without adjuster
With adjuster
1
(IN)
2
(OUT)
1
(IN)
2
(OUT)
4

Supply port Nozzle (Refer to page 8 for details.)
Symbol Type Nozzle length Nozzle part no.*2
Nil Without nozzle — —
01
Long nozzle*1
50 mm IBG1-12-10-50
02 100 mm IBG1-12-10-100
03 150 mm IBG1-12-10-150
04 300 mm IBG1-12-10-300
05 600 mm IBG1-12-10-600-X1
06 1000 mm IBG1-12-10-1000-X1
11
Long nozzle with a
silencer*1, *3
50 mm IBG1-12-10-50S
12 100 mm IBG1-12-10-100S
13 150 mm IBG1-12-10-150S
14 300 mm IBG1-12-10-300S
15 600 mm IBG1-12-10-600S-X1
16 1000 mm
IBG1-12-10-1000S-X1
*1 A long nozzle and a silencer are included in a package but do
not come mounted. Refer to page 8 for assembly procedures.
*2 This is the part number for the long nozzle and fitting set.
*3 The silencer and long nozzle can be used together. Part number
for ordering a silencer alone is IBG1-12S.
Impact Blow Gun
IBG2 Series
How to Order
Specifications
IBG20
Model IBG20
(Without adjuster)
Fluid Air
Max. operating pressure 0.7 MPa
Proof pressure 1.05 MPa
Fluid and ambient temperature range +5 to +60°C
Operational force 10 N or less
Weight*1300 g
*1 For the screw-in type
Screw-in type
Symbol Size
Nil Rc1/4
NNPT1/4
FG1/4
With S coupler/One-touch fitting
Symbol Applicable
tubing O.D. Part no. Appearance
S coupler
11 — KK4P-02MS
12 — KK130P-02MS
One-touch fitting
H06 ø6 KQ2H06-02AS
H08 ø8 KQ2H08-02AS
H10 ø10 KQ2H10-02AS
H07 ø1/4" KQ2H07-35AS
H09 ø5/16" KQ2H09-35AS
H11 ø3/8" KQ2H11-35AS
*The S coupler or fitting is shipped together with the product.
*For the S coupler or metric size One-touch fitting (H06, H08,
H10), the port size on the impact blow gun side is Rc1/4.
*For the inch size One-touch fitting (H07, H09, H11), the port
size on the impact blow gun side is NPT1/4.
02
Silencer
Compact Type
Chip Guard (Please order it separately.)
Description Part no.
Chip guard IBG1-12C
Guards against the blown machining
chips and workpiece
p. 8
Symbol
Without adjuster
1
(IN)
2
(OUT)
5

With S coupler
plug mounted
KK4P-03MS
With One-touch
fitting mounted
KQ2H-AS
Valve position adjuster
Scale setting range:
0 (Fully closed) to 4 (Fully open)
29
41
14
8.5
37.6
30
11
183.8
138.3
108.3
164.3 14.5
25.5 32
83
55
84.6
B
B
20.5
35
41
29
14
8.5
138.3
37.6
30
11
138.3
183.8
108.3
164.3 14.5
84.6
55
3225.5
Locked: ≈100.3
Unlocked: ≈101.7
20.5
35
Rc3/8, NPT3/8, G3/8
Supply port
Rc3/8, NPT3/8, G3/8
Supply port
Long nozzle Long nozzle
with a silencer
A A
R
c1/4
Discharge port
Rc1/4
Discharge port
With S coupler
plug mounted
KK130P-03MS
B
IBG10/Without adjuster
IBG11/With adjuster
Dimensions
Symbol Type
Nozzle length
[mm]
Nozzle part no. A
[mm]
Weight
[g]
01
Long nozzle
50 IBG1-12-10-50 57 35
02 100 IBG1-12-10-100 107 40
03 150 IBG1-12-10-150 157 45
04 300 IBG1-12-10-300 307 59
05 600 IBG1-12-10-600-X1 607 88
06 1000 IBG1-12-10-1000-X1 1007 126
11
Long nozzle
with a
silencer
50 IBG1-12-10-50S 72 57
12 100 IBG1-12-10-100S 122 62
13 150 IBG1-12-10-150S 172 67
14 300 IBG1-12-10-300S 322 81
15 600 IBG1-12-10-600S-X1 622 110
16 1000
IBG1-12-10-1000S-X1 1022 148
Symbol Type Applicable
tubing O.D. Part no. B [mm]
11 S coupler — KK4P-03MS 35.7
12 — KK130P-03MS 32.5
H06 Metric size
One-touch
fitting
ø6 KQ2H06-03AS 13
H08 ø8 KQ2H08-03AS 13
H10 ø10 KQ2H10-03AS 18.4
H07 Inch size
One-touch
fitting
ø1/4" KQ2H07-36AS 13.4
H09 ø5/16" KQ2H09-36AS 13.4
H11 ø3/8" KQ2H11-36AS 18
6
Impact Blow Gun IBG Series

Long nozzle Long nozzle
with a silencer
With S coupler
plug mounted
KK4P-02MS
With S coupler
plug mounted
KK130P-02MS
With One-touch
fitting mounted
KQ2H-AS
R
c1/4
Discharge port
14
29
41
8
174.5
128
31.8
25
11.7
32
76
19.6
101
154 15.5
75.8
47
A A
B
B
B
30
20.5
Rc1/4, NPT1/4, G1/4
Supply port
IBG20/Without adjuster
Dimensions
Symbol Type
Nozzle length
[mm]
Nozzle part no. A
[mm]
Weight
[g]
01
Long nozzle
50 IBG1-12-10-50 57 35
02 100 IBG1-12-10-100 107 40
03 150 IBG1-12-10-150 157 45
04 300 IBG1-12-10-300 307 59
05 600 IBG1-12-10-600-X1 607 88
06 1000 IBG1-12-10-1000-X1 1007 126
11
Long nozzle
with a
silencer
50 IBG1-12-10-50S 72 57
12 100 IBG1-12-10-100S 122 62
13 150 IBG1-12-10-150S 172 67
14 300 IBG1-12-10-300S 322 81
15 600 IBG1-12-10-600S-X1 622 110
16 1000
IBG1-12-10-1000S-X1 1022 148
Symbol Type Applicable
tubing O.D. Part no. B [mm]
11 S coupler — KK4P-02MS 34.2
12 — KK130P-02MS 32
H06 Metric size
One-touch
fitting
ø6 KQ2H06-02AS 12
H08 ø8 KQ2H08-02AS 17.3
H10 ø10 KQ2H10-02AS 22.6
H07 Inch size
One-touch
fitting
ø1/4" KQ2H07-35AS 12.3
H09 ø5/16" KQ2H09-35AS 17.7
H11 ø3/8" KQ2H11-35AS 20.7
7
IBG Series

R1/4
L
≈L+ 7 ∗Reference dimension after R thread installation
ø10 ø12
Width across flats 19 Width across flats 17
Width across
flats 17
≈L+ 22 ∗Reference dimension after R thread installation
L
Width across flats 19
7
Width across flats 19
Width across flats 17
R1/4
Fitting bodyFerrule
Union nut
Polycarbonate (Transparent)
ø26
øD
11
2
øD
Rubber bushing
(Material: CR)
Tighten the union nut until it
touches the body.
Long nozzle (Option)
Dimensions
[mm]
Part no. Nozzle I.D. Connection thread
L
IBG1-12-10-50
ø10 R1/4
50
IBG1-12-10-100 100
IBG1-12-10-150 150
IBG1-12-10-300 300
IBG1-12-10-600-X1 600
IBG1-12-10-1000-X1 1000
[mm]
Part no. L
IBG1-12-10-50S 50
IBG1-12-10-100S 100
IBG1-12-10-150S 150
IBG1-12-10-300S 300
IBG1-12-10-600S-X1 600
IBG1-12-10-1000S-X1
1000
Long nozzle with a silencer
(Option)
Chip guard
(Please order it separately.)
How to Mount a Nozzle
Preparation
Tightening
zCheck that the ferrule is mounted inside the
fitting as shown in the figure below. Hand-
tighten the union nut. Ensure the ferrule is
aligned properly.
vAfter verifying the dimension, insert the
nozzle into the fitting body again. Confirm
that the nozzle is inserted down to the
marking.
xInsert the nozzle until it touches the fitting
body. Then, mark a line on the nozzle at the
edge of the union nut.
bUsing the tightening tool, tighten the union
nut so that the gap between the fitting body
and the union nut becomes 2 mm or less.
cRemove the nozzle once, and check the
dimension from the end of the nozzle to the
marking. If the dimension is different from the
17 mm, verify the alignment of the nozzle
and adjust.
nPull the nozzle by hand to ensure that the
nozzle is secure.
Before operation, pull the nozzle by hand
again to confirm that the nozzle is securely
attached and will not be ejected during
operation.
Insert the nozzle until it touches the bottom of
the fitting body.
Union nut Fitting body
Ferrule
Nozzle
Marking
Union nut
Gap 2 mm or less
Bottom of the fitting body
Put a mark.
Approx. 17 mm
Marking
Tighten the union nut so that the
clearance is 2 mm or less.
Insert to the marking.
Remove it once, and check the dimension.
[mm]
Part no. øD
IBG1-12C 100
*The rubber bushing is shipped together with the product.
*It is possible to use the guard with a silencer, but in that
case, mount the guard before mounting the silencer.
8
Impact Blow Gun IBG Series

Mounting
Warning
3. Screw-in the nozzle to the torque below by holding
the flat faces on the discharge side or metal holder.
As a guideline, it is equivalent to 2 to 3 additional
turns with a tool after hand-tightening.
Flat face
Metal holder
Nozzle tightening torque range 12 to 14 N·m
Insufficient tightening may cause loosening of the nozzle.
Piping
Caution
1. Check the model, type, and size before installation.
Also, confirm that there are no scratches, gouges, or cracks on the product.
2. Preparation before piping
Before piping is connected, it should be thoroughly blown out with air (flushing)
or washed to remove chips, cutting oil, and other debris from inside the pipe.
3. Winding of sealant tape
When connecting pipes, fittings, etc., be sure that chips from the pipe
threads and sealing material do not enter the blow gun. Furthermore,
when sealant tape is used, leave 1.5 to 2 thread ridges exposed at
the end of the threads.
Winding direction
Sealant tape
Expose approx. 2 threads
4. When tightening the threads, tighten with torque specified
in the table below. As a guideline, it is equivalent to 2 to 3
additional turns with a tool after hand-tightening.
Be careful that tightening with torque beyond the range in the
table below may cause damage to the body.
Male thread Tightening torque [N·m]
R1/4 12 to 14
R3/8 22 to 24
5. Allow extra length when connecting a tube to accom-
modate changes in tube length due to pressure.
6. Confirm that no twisting, turning, or tensile force or
moment load is applied to the port or tube. This may
cause fittings to fracture or tubes to be crushed,
burst, or come loose.
7.
Do not abrade, entangle, or scratch the tube. This may
cause the tube to be crushed, burst, or come loose.
Prior to Use
Warning
As the pressure of the air blow is quite powerful, do
not aim the product at another person during
operation. It may cause danger to personnel.
Additionally, the following precautions should be
taken before use.
1. Before use, make sure that the blow pressure, or
blow, will not cause surrounding objects to scatter
and injure others or damage workpieces, equip-
ment, etc., in the vicinity.
2. Wear protective eyewear when operating the
product to protect your eyes from scattering debris.
3. This product is not a toy. Do not play with the
product or use it as an air gun for fun.
4. Air pressure may cause the nozzle to fly off during
operation if it is not properly tightened. To prevent
this, be sure to check the nozzle for loosening by
pulling on it with your hands before use.
5. The grip may become hot due to repeated operation;
however, this is not abnormal.
Selection
Warning
1. Confirm the specifications.
Products represented in this catalog are designed only for use
in compressed air systems. Do not operate at pressures,
temperatures, etc., beyond the range of specifications, as this
can cause damage or malfunction.
Caution
1. Do not apply the blow gun to flammable, explosive,
or toxic substances such as gas, fuel gas, or
refrigerant. Such substances may exude from inside
the blow gun.
Mounting
Warning
1. Install a stop valve on the supply pressure side of the
blow gun.
It will be emergency shut off in case of unexpected leakage or
damage.
2. When installing a nozzle on the blow gun, wind
sealant tape around the threads of the nozzle.
Be sure to read this before handling the products. Refer to the back cover for safety
instructions. For other precautions, refer to the “Handling Precautions for SMC
Products” and the “Operation Manual” on the SMC website: https://www.smcworld.com
IBG Series
Specific Product Precautions 1
9

Maintenance
Caution
1. In periodical inspections, check the following items
and replace the parts if necessary.
a) Scratches, gouges, abrasion, corrosion
b) Air leakage
c) Twisting, crushing, and turning of connected tubes
d) Hardening, deterioration, and softening of connected tubes
e) Loosening of nozzles
2. When removing the product, first stop the pressure
supply, exhaust compressed air in the piping, and
check the condition of atmospheric release.
3.
Do not disassemble or remodel the body of the product.
Handling
Warning
1. Air pressure may cause the nozzle to fly off during operation if it
is not properly tightened. To prevent this, be sure to check the
nozzle for loosening by pulling on it with your hands before use.
2. Be sure to wear protective eyewear when operating the
product to protect your eyes from scattering debris.
3. Do not direct the tip of the nozzle at the face or other
parts of a human body. It may cause danger to personnel.
4. Do not use the product to clean or remove toxic
substances or chemicals.
5. Do not drop, step on, or hit the product. It may
cause damage to the product.
6. Do not use the product to disturb public order or
public hygiene.
7. This product is not a toy.
8.
After blowing, make sure to hang the product on a hook, etc.
If leaving the product in a dusty place, particles will enter the
product and may result in a malfunction.
Hook
9. When the blow gun is used or stored, confirm that no
twisting, turning, or tensile force or moment load is
applied to the port or tube. This may cause fittings to
fracture or tubes to be crushed, burst, or come loose.
Caution
1. Pressurizing the air blow discharge port may result
in the breakage of the product.
2.
The blow adjusting range 4 provides the maximum blow. Rotating
the adjuster exceeding 4 may result in the breakage of the product.
Lubrication
Warning
1. Do not lubricate the product.
It may contaminate or damage the target object.
Air Supply
Warning
1. Use clean air.
Do not use compressed air that contains chemicals, synthetic
oils that include organic solvents, salt, corrosive gases, etc.,
as it can cause damage or malfunction.
Caution
1. Install an air filter.
Install an air filter upstream near the blow gun. Select an air
filter with a filtration size of 5 μm or smaller.
2. Take measures to ensure air quality, such as by
installing an aftercooler, air dryer, or water separator.
Compressed air that contains a large amount of drainage can
cause the malfunction of the blow gun and contaminate or
damage the target object. Therefore, take appropriate
measures to ensure air quality, such as by providing an
aftercooler, air dryer, or water separator.
Operating Environment
Warning
1. Do not use in an atmosphere where corrosive
gases, chemicals, sea water, water, or water steam
are present. Do not use in cases where there is
direct contact with any of the above.
2. Do not expose the product to direct sunlight for an
extended period of time.
3. Do not use in locations where radiated heat will be
received from nearby heat sources.
4. Do not use in an environment where static electricity
is a problem. It may result in system failure or
malfunction. Please contact SMC for use in such an
environment.
5. Do not use in an environment where spatters are
generated. Spattering may result in a fire hazard.
Please contact SMC for use in such an environment.
6. Do not use in an environment where the product is
exposed to cutting oil, lubricating oil, or coolant oil.
Please contact SMC for use in such an environment.
Be sure to read this before handling the products. Refer to the back cover for safety
instructions. For other precautions, refer to the “Handling Precautions for SMC
Products” and the “Operation Manual” on the SMC website: https://www.smcworld.com
IBG Series
Specific Product Precautions 2
10

∗ The IBG2 series has been added.
∗ The number of pages has been increased from 8 to 12.
BP
Revision History
Edition B
Akihabara UDX 15F,
4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021, JAPAN
Phone: [phone] Fax: [phone]
https://www.smcworld.com
© 2023 SMC Corporation All Rights Reserved
Specifications are subject to change without prior notice
and any obligation on the part of the manufacturer.
D-G
Safety Instructions
Be sure to read the “Handling Precautions for SMC Products” (M-E03-3) and “Operation Manual” before use.
Caution
SMC products are not intended for use as instruments for legal
metrology.
Measurement instruments that SMC manufactures or sells have not been
qualified by type approval tests relevant to the metrology (measurement) laws
of each country. Therefore, SMC products cannot be used for business or
certification ordained by the metrology (measurement) laws of each country.
Compliance Requirements
∗1) ISO 4414: Pneumatic fluid power – General rules relating to systems.
ISO 4413: Hydraulic fluid power – General rules relating to systems.
IEC 60204-1: Safety of machinery – Electrical equipment of machines.
(Part 1: General requirements)
ISO 10218-1: Manipulating industrial robots – Safety.
etc.
Caution indicates a hazard with a low level of risk which,
if not avoided, could result in minor or moderate injury.
Caution:
Warning indicates a hazard with a medium level of risk which,
if not avoided, could result in death or serious injury.
Warning :
Danger :
Danger indicates a hazard with a high level of risk which,
if not avoided, will result in death or serious injury.
Warning Caution
1. The compatibility of the product is the responsibility of the
person who designs the equipment or decides its
specifications.
Since the product specified here is used under various operating conditions,
its compatibility with specific equipment must be decided by the person who
designs the equipment or decides its specifications based on necessary
analysis and test results. The expected performance and safety assurance
of the equipment will be the responsibility of the person who has determined
its compatibility with the product. This person should also continuously
review all specifications of the product referring to its latest catalog
information, with a view to giving due consideration to any possibility of
equipment failure when configuring the equipment.
2. Only personnel with appropriate training should operate
machinery and equipment.
The product specified here may become unsafe if handled incorrectly. The
assembly, operation and maintenance of machines or equipment including
our products must be performed by an operator who is appropriately trained
and experienced.
3. Do not service or attempt to remove product and machinery/
equipment until safety is confirmed.
1. The inspection and maintenance of machinery/equipment should only be
performed after measures to prevent falling or runaway of the driven
objects have been confirmed.
2. When the product is to be removed, confirm that the safety measures as
mentioned above are implemented and the power from any appropriate
source is cut, and read and understand the specific product precautions
of all relevant products carefully.
3. Before machinery/equipment is restarted, take measures to prevent
unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of
safety measures if the product is to be used in any of the
following conditions.
1. Conditions and environments outside of the given specifications, or use
outdoors or in a place exposed to direct sunlight.
2. Installation on equipment in conjunction with atomic energy, railways, air
navigation, space, shipping, vehicles, military, medical treatment,
combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press
applications, safety equipment or other applications unsuitable for the
standard specifications described in the product catalog.
3. An application which could have negative effects on people, property, or
animals requiring special safety analysis.
4. Use in an interlock circuit, which requires the provision of double interlock
for possible failure by using a mechanical protective function, and
periodical checks to confirm proper operation.
1. The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in
manufacturing industries.
If considering using the product in other industries, consult SMC beforehand
and exchange specifications or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/
Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and
“Compliance Requirements”.
Read and accept them before using the product.
Limited warranty and Disclaimer
1. The warranty period of the product is 1 year in service or 1.5 years after
the product is delivered, whichever is first.∗2)
Also, the product may have specified durability, running distance or
replacement parts. Please consult your nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our
responsibility, a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any
other damage incurred due to the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms
and disclaimers noted in the specified catalog for the particular products.
∗2) Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad
or failure due to the deterioration of rubber material are not covered by the limited warranty.
1. The use of SMC products with production equipment for the manufacture of
weapons of mass destruction (WMD) or any other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are
governed by the relevant security laws and regulations of the countries involved
in the transaction. Prior to the shipment of a SMC product to another country,
assure that all local rules governing that export are known and followed.
These safety instructions are intended to prevent hazardous situations and/or
equipment damage. These instructions indicate the level of potential hazard with
the labels of “Caution,” “Warning” or “Danger.”They are all important notes for
safety and must be followed in addition to International Standards (ISO/IEC)∗1),
and other safety regulations.
Safety Instructions
