Bass Habit SPL Elite SE45T User manual

SPL Elite 45mm Bullet Tweeter User Manual
SE45T

SE45T

SAFETY & WARRANTY INFORMATION
Thank you for purchasing this Bass Habit tweeter. Please read this manual in order to fully understand how to
get the best result from this product and ensure that the advices on how to look after the product and the
safety precautions are followed. We hope you enjoy using the product as much as we enjoyed creating it.
DO NOT EXPOSE THIS PRODUCT TO EXCESSIVE DAMP OR MOISTURE
- Doing so may damage the product.
BEFORE WIRING, DISCONNECT THE CABLE FROM THE POSITIVE BATTERY TERMINAL
- Failure to do so may result in electric shock or injury.
ENSURE GOOD AND CORRECT CONNECTIONS
- Failure to make the correct connections may result in permanent damage to the product.
KEEP THE VOLUME AT A LEVEL SO YOU CAN STILL HEAR OUTSIDE NOISE
- Failure to do this may result in an accident. Bass Habit equipment is capable of producing sound levels
that can permanently damage your hearing. Bass Habit recommends caution when listening at a high
volume. For safety and enjoyable listening, the sound should be clear without distortion.
CAUTION
Never connect any speaker lead to the car chassi. This can cause severe damage to your car audio set up.
Before drilling or cutting any holes, investigate the layout of your vehicle thoroughly.
Use caution when working near the fuel/hydraulic lines and electrical wiring.
Observe the correct polarity when wiring. Improper phasing may cause a loss of bass response.
Ensure that no moving parts catch on the speaker or grill (e.g. door handles or window glass inside the door).
WARRANTY
All Bass Habit products carry a full warranty depending on the conditions in the country where it is sold. The
warrany is valid from the date of the original receipt as proof of purchase (warranty period differs depending
on local warranty laws and policies). Contact your international Bass Habit dealer or distributor concerning
specific procedure for your country’s warranty policies.
WHAT IS NOT COVERED
• Damage to product due to improper installation.
• Subsequent damage to other components.
• Damage caused by exposure to moisture, excessive heat, chemical cleaners and/or UV radiation.
• Damage through negligence, missuse, accident or abuse. Repeated returns for the same fault may be
considered as abuse.
• Any cost or expense related to the removal and/or abuse. Repeated returns for the same fault may be
considered as abuse.
• Damage caused by amplifier clipping or distortion.
• Items repaired or modified by any unauthorised repair facility.
• Return shipping on non-defective items.
• Products returned without a return authorisation number.
• Damage to product due to use of sealant.
WARNING
Bass Habit equipment is capable of sound pressure levels that can cause permanent damage to your hearing
and those around you. Please use common sense when listening to your audio system and practice safe
sound.
INTERNATIONAL TECHNICAL ENQUIRIES
For international technical support please contact the distribution agent for your country.

Component
Size
Frame Material
Cone Material
RMS Power
MAX Power
Nominal Impedance
Freq. Response
Sensitivity
Magnet
Voice Coil Diameter
Voice Coil Wire
Crossover
Bullet Tweeter
45mm (1,75”)
Die Cast Aluminium
Titanium
200W Rms
400W Max
4 ohm
2,5Khz - 20Khz
106 dB
Ferrite
45mm (1,75”)
Aluminium
6000Hz /6db
(3,3 uF capacitor included)
SPECIFICATION
Outer Dimension
Total Height
Weight (pcs)
100x100mm
71,5mm
1,35 KG
4xΦ4.5mm
106,5mm
Φ100,5mm
Φ100,5mm
71.5mm
64mm
92mm

INSTRUCTIONS
capacitor
included
3,3
INSTALLATION EXPERIENCE
Installation of Bass Habit tweeters may require experience with a variety of mechanical procedures including
enclosure construction. This manual only provides general installation and operation instructions. If you have
any reservations about your installation skills, please contact your local authorized Bass Habit dealer for help.
CHOOSING TWEETER MOUNTING LOCATIONS
Choosing the correct tweeter mounting location will have the greatest effect of the sound quality of the
system. There are many different considerations needed when choosing the location(s) that best meet your
needs. The location(s) must be large enough for the tweeter to fit. Care is needed to ensure that the desired
location will not affect either the mechanical or electrical operation of the vehicle.
WARNING! The use of silicone rubber to seal in a tweeter will void the warranty. If any sealing is needed in
addition to the tweeter’s gasket, use caulking cord or vinyl weather strip.
INSTALLING THE TWEETER
1) Determine where the tweeter will be mounted. Make sure there is a flat area large enough for the
speaker to fit properly. An uneven mounting surface can damage the tweeter.
2) Check to make sure the space you have selected for the tweeter will not interfere with vehicle operation.
3) If a template is included in the packaging, use the template and mark the hole with a pen.
4) Cut the hole for the tweeter. A hole can be cut either with a pair of metal tin snips, a saber or jig saw.
5) Run speaker wire (not included) to the tweeter. Make sure to keep wires away from sharp metal or other
rough edges. When passing through metal, use a grommet to protect the wires from sharp edges.
6) Pre drill the mounting holes using a 1/8” (3mm) drill bit.
7) Pull the wire through the tweeter opening and connect to the tweeter. Be sure to observe proper polarity.
8) Mount the tweeter using good quality screws.
9) Always use the inline crossover capacitor when included. Failure in using crossover(s) may cause
damage to the tweeter(s).

The crossed-out wheelie bin symbol means that the product, literature and packaging included must be taken to
separate collection at the end of their working life. Do not dispose of these products as unsorted municipal waste:
dispose of them at a recycling point. For info on your nearest recycling point, check with your local waste
authority.
Winn Scandinavia reserves for possible typos, factual or numeric errors that may have been printed on any
products, package designs, user manuals and/or other included accessories.
Products marked with the RoHS symbol complies with the relevant provisions of the RoHS Directive for the
European Union. In common with all Electrical and Electronic Equipment (EEE) the product should not be
disposed of as household waste. Alsternative arrangements may apply in other jurisdictions.
The product with the CE mark indicates that it has passed the correspondning conformity assessment procedure
and the manufacturer’s declaration of conformity, and it complies with the relevant EU directives, and is used as
a pass for the product to be allowed to enter the European Community market. Relevant directives require
industrial products to be affixed with the CE mark. Those that do not have the CE mark shall not be marketed.
Winn Scandinavia AB
Elementvägen 15, 702 27 Örebro
Sweden
www.winnscandinavia.com
