BASYX CONFERENCE TABLE WITH SLAB BASE User manual

60181252B
SIDE 1 OF 2 (2/07)
CONFERENCE TABLE WITH SLAB BASE
ASSEMBLY
INSTRUCTIONS
To prevent the possibility of serious eye
injury, always wear eye protection when
using power tools.
Heavy panels can pinch or crush fingers.
Do not place fingers between or under pan-
els during assembly.
Read all instructions and review illustrations
before installing.
Tools required for assembly:
Rubber mallet
24" long level
3/16" Allen wrench (provided)
This assembly includes:
(1) Top
(2) Slab base panels
(8) 1/2" bolt
(8) 3/8" washer
(1) 3/16" Allen wrench
(4) Glide insert
(4) Glide
Illustration 1
Illustration 2 Installation:
1. Refer to Illustration 1. Lay top, with stretchers
facing up, onto cardboard or a carpeted sur-
face.
2. Refer to Illustration 1. Position base panels
against stretchers and align pre-drilled holes
in base panel with holes in ends of each
stretcher.
3. Refer to Illustration 1. Place a washer (from
hardware pack) onto each 1/2" bolt (from
hardware pack)
Install a bolt (with washer) through each hole
in base panel (four per panel) and into ends
of stretcher. Use the 3/16" Allen wrench to fully
tighten bolts.
4. Refer to Illustration 2. Thread a glide (from
hardware pack) into each glide insert (from
hardware pack) by turning glide clockwise
until glide is flat against insert.
Locate two holes in bottom of each base
panel. Use the rubber mallet to install a
glide/glide insert assembly into each hole.
5. Use two or more people to set table upright
and to position table were desired.
Adjust glides until table is level from front-to-
rear and side-to-side. Use the 24" long level
to verify table is level.
1/2" bolt
Washer
Stretcher
Top
Slab base panel
Slab base
panel
Slab base
panel
End of stretcher
Glide insert
Glide
Top
~
WARNING

CONFERENCE TABLE WITH CURVED BASE
60181252B
SIDE 2 OF 2 (2/07)
ASSEMBLY
INSTRUCTIONS
To prevent the possibility of serious eye
injury, always wear eye protection when
using power tools.
Heavy panels can pinch or crush fingers.
Do not place fingers between or under
panels during assembly.
Read all instructions and review illustrations
before installing.
Tools required for assembly:
1/2" socket Rubber mallet
Socket wrench 24" long level
This assembly includes:
(1) Top
(2) Curved base panels
(8) 1/2" bolt
(8) 3/8" washer
(8) Wedge washer
(4) Glide insert
(4) Glide
Illustration 2
Installation:
1. Refer to Illustration 1. Lay top, with stretchers
facing up, on cardboard or a carpeted sur-
face.
2. Refer to Illustration 1. Position curve panels
against stretchers and align pre-drilled holes
in base panel with holes in ends of each
stretcher.
3. Place a washer (from hardware pack) and
wedge washer (from hardware pack) onto
each 1/2" bolt (from hardware pack). I
Install a bolt (with washer and wedge wash-
er) through each hole in base panel (four per
panel) and into ends of stretcher. Use the 1/2"
socket and wrench to fully tighten bolts.
4. Refer to Illustration 2. Thread a glide (from
hardware pack) into each glide insert (from
hardware pack) by turning glide clockwise
until glide is flat against insert.
Locate two holes in bottom of each base
panel. Use the rubber mallet to install a
glide/glide insert assembly into each hole.
5. Use two or more people to set table upright
and to position table were desired.
Adjust glides until table is level from front-to-
rear and side-to-side. Use the 24" long level
to verify table is level.
1/2" bolt
Washer
Wedge washer
Stretcher
Top
Curved base panel
Curved base
panel
End of stretcher
~
WARNING
Illustration 2
Glide insert
Glide
Top
Curved base
panel
