Battery Fighter BFP-012 User manual

BFP-012 12V 5A charger and BFP-024 24V 3A lead battery charger
The BFP is a Microprocessor controlled fully automatic 4 stage charger that charges more efficiently plus
extending battery life compared to other similar output chargers. Featuring a lightweight mountable chassis the
BFP series is also vibration resistant, dust proof & water resistant to IP65. Other features include spark proof
connection, reverse polarity protection on the PCB & an auto reset program. Available in two models, suitable for
12 volt batteries with a 5 amp output & suitable for 24 volt batteries with a 3 amp output.
GENERAL DESCRIPTION: The lightweight, mountable battery charger is a high frequency switching power converter
that has a true DC output at a maximum power level of approximately 70 watts.
SUITABILITY: Lead Acid Battery types - Standard; Flooded, Sealed, VRLA, GRT, AGM and GEL.
OUTPUT CABLE CONNECTIONS: The battery charger is equipped with an Constar type interchangeable
non-reversible connection output. Included in the package are a BFL2 leads fitted with permanent connect ring terminals:-
positive 3/8" diameter ring terminal with a red molded polymer insulation cylinder, negative 5/16" diameter ring terminal with
a black molded polymer insulation cylinder. BFL1 Alligator clips are the second connection type also included.
Charger Specification Summary
420-PFB210-PFB:rebmuNtraP
stloV42stloV21:egatloVtuptuOlanimoN
spmA3spmA5:tnerruCtuptuOlanimoN
Input Voltage: 230 to 240 VAC
Input Frequency: 47 to 62 Hz
Maximum Input Current: 0.81 Arms @ 180 VAC
Nominal Efficiency: 80%
6.0:rotcaFrewoPlanimoN
Charger Output:
Maximum Power: @ 25 °C: 70 Watts (+2, -5) Watts
Maximum Current During Bulk Charge: 5.0 Amps (+/- 10%) 3.0 Amps (+/- 10%)
Absorption Voltage: 14.4 VDC = (2.42 vpc) 28.8 VDC = (2.4 vpc)
Absorption to Float Transition: Charge Current drops: below 2.5 Amps. Charge Current drops: below 1.0 Amp.
Float Voltage: 13.2 VDC = (2.2 vpc) 26.4 VDC = (2.2 vpc)
Charge Reset: Battery Voltage Threshold: 11.5 to 12.0 VDC (2 to 2.08 vpc) 23.5 to 24.0 VDC (2 to 2.04 vpc)
Output Regulation: Line (Typical): 1%
Electrical Isolation: Input / Output: 2500 VAC
Electrical Isolation: Input / Chassis: 2500 VAC
Electrical Isolation: Output / Chassis: 500 VAC
Operating Temp: -20°C to 50°C
Dimensions & Weight: 5 in (127mm)L x4.9 in (125mm)W x2 in (51mm)H, 800 grams
Enclosure: Powder Coated Aluminum Chassis
SEY:noitcetorPtiucriCtrohS
SEY:noitcetorPytiraloPesreveR

Stage 1) Qualification: Ensure the battery is in good condition and safely able to be charged.
The following symptoms are incurred if the Red light continuously flashes:-
•The battery voltage is detected too low, that is the battery voltage is lower than 4.0V (BFP-024), 2.0V (BFP-012),
the charging will not be commenced.
•The battery is not being connected properly, please check the connection of battery is clean & good.
•Reverse polarity connected.
Stage 2) Bulk Charge: Red Light On, Green Light Off, Constant Current = 5.0 Amps, Transition to Stage
3, Absorption Charge when battery voltage reaches 14.4 VDC.
Stage 3) Absorption Charge: Red Light On, Absorption Voltage = 14.4 VDC Transition to Float Charge
(Stage 4) when battery charging current drops below 2.5 amps.
Stage 4) Float Charge: Red Light Off, Green Light On. Float Voltage = 13.2 VDC. If an external load is
applied to the battery while the charger is in stage 3, Float Charge, and if the battery voltage drops below a
range between 11.5 to 12.0 VDC, then the charge cycle restarts.
Figure 1 Charging Graph: Float Maintain Charger ‘Fighter’ 12Vdc 5A
12 Volt 5 Amp DC Output
Float Maintain Charger Charging Algorithm
Con sta nt= 2.42 vp c
(14.4 V)
(13.2 V)
Flo a t = 2.20 vp c
Transition:
Battery Voltage=14.4 Volts
Transition:
Battery Current=2.5 Amp
Recharge Times shown to
Fully Recharge a 16 Ah Battery Pack
Charging Time (Hours)
Em p ty
Charging
80% Full
Full
Light Weight Mounted
LightWeightOn-Board(PowerTender)
ChargingTime(Hours)
4.0
Constant
Voltage
ABSORPTION
11
BULK
RechargeTimesshownto
FullyRechargea16AhBatteryPack
6
00.5 1.0
9
7
8
10
(6 A)
Current
Limit
2.51.5 2.0 3.53.0
12 Volt 6 Amp DC Output
13
12
15
14
17
16
Battery
Terminal
Voltage
(VOLTS )
Constant=2.42vpc
Transition:
BatteryVoltage=14.5Volts
(14.5V)
12.5
FLOAT
(50 to 100 mA)
4.5 5.0 5.5 6.0 6.5
Constant
Voltage
(3 A)
8.07.0 7.5
0
2.5
5.0
7.5
10.0
Charging
A
lgorithm
Transition:
BatteryCurrent=3Amp
(13.2
V
)
Float = 2.20 vpc
STANDARD
17.5
15.0
22.5
20.0
Batt ery
Charging
Current
(AMPS)
27.5
25.0
12 Volt 5 Amp DC Output
Float Maintain Charger Charging Algorithm
Co nsta nt= 2.42 vp c
(14.4 V)
(13.2 V)
Flo a t = 2.20 vp c
Transition:
Battery Voltage=14.4 Volts
Transition:
Battery Current=2.5 Amp
Recharge Times shown to
Fully Recharge a 16 Ah Battery Pack
Charging Time (Hours)
Em p ty
Charging
80% Full
Full
Light Weight Mounted
(5 A )
( 2.5 A )
