Bauhn HE315032 User manual

Digital Indoor Antenna
Model Number: HE315032
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
INSTRUCTION MANUAL

Warranty Note
If you experience any issues with this product, or it’s
performance is not what you had expected, please contact
us at Winplus before returning the item to the store.
It is likely that we can resolve any problems for you via
phone or email.
We can be reached on:
Phone: [phone] (Mon - Fri; 8:30am - 6:00pm EST)
Email: customercar[email protected]om.au
Web: www.winplus.com.au
Scan the QR Code
to find out
Will this antenna improve reception where you live?
This antenna is suitable for
“Good Coverage” areas.
See reverse for more details
Check your reception coverage in your area by
scanning the QR code or visiting
http://myswitch.digitalready.gov.au/ and entering your
address. This antenna is suitable for areas with Good
Coverage. If your address does not have Good
Coverage you may not be able to pick up all digital
channels with this antenna and a rooftop antenna
may be necessary.
Coverage Remarks

Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for a period
of 12 monthsfrom the date of purchase. Defects that occur within this warranty period,
under normal use and care, will be repaired, replaced or refunded at our discretion.
The benefits conferred by this warranty are in addition to all rights and remedies in respect
of the product that the consumer has under the Competition and Consumer Act 2010 and
similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage.You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
AFTER SALES SUPPORT
YEAR WARRANTY
1
MODEL: HE315032 PRODUCT CODE: 38558 10/2015
[e-mail]
1300 663 907
AUS
DIGITAL INDOOR ANTENNA

5
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for a period
of 12 monthsfrom the date of purchase. Defects that occur within this warranty period,
under normal use and care, will be repaired, replaced or refunded at our discretion.
The benefits conferred by this warranty are in addition to all rights and remedies in respect
of the product that the consumer has under the Competition and Consumer Act 2010 and
similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage.You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
AFTER SALES SUPPORT
YEAR WARRANTY
1
MODEL: HE315032 PRODUCT CODE: 38558 10/2015
[e-mail]
1300 663 907
AUS
DIGITAL INDOOR ANTENNA
Safety Instructions
Read this manual thoroughly before rst use and keep it in a safe place for future reference, along
with the warranty card, purchase receipt and carton. The safety precautions enclosed herein reduce
the risk of re, electric shock and injury when correctly adhered to. Follow all instructions and take
notice of all warnings to reduce the risk of re or electric shock.
• Do not expose this product to water, rain, moisture or dust. Electronic products of this kind
should never be subjected to moisture or extreme temperatures.
• Do not attempt to open the product housing. There are no user-serviceable parts inside this
product.
• Do not repair the unit yourself. If your device is not functioning correctly, disconnect the
product from power, and contact after sales support.
• Supervise young children to ensure they do not play with the product.
• Do not expose to water, dust, moisture, chemicals, oils, or other liquids.
• Do not expose to naked ames or other heat sources.
• Do not drop or subject the device to undue shock.
• Keep device away from magnets at all times.
• Keep away from direct sunlight. Indoor use only.
• Unplug this device during lightning storms or when unused for long periods of time.

6
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Contents
Warranty Details 4
Safety Instructions 5
Parts List 7
Technical Specications 7
Features 7
Instructions 8
Antenna Basics 8
Congure For Best Signal 8
Connecting 9
Mounting (Optional) 11
FAQs and Other Useful Information 12
Tips and Troubleshooting 13
Repair and Refurbished Goods or Parts Notice 14

7
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Parts List
Technical Specications
Features
1 x Digital Indoor Antenna
1 x Power Adaptor
1 x Instruction Manual
1 x Getting Started Guide
1 x Warranty Card
Frequency: VHF(174-230MHz) UHF(470-694MHz)
Gain: VHF: 14dB; UHF: 18dB
Output level: Max 87dBμV
Impedance: 75
Input voltage: AC230-240V
Operating Power: DC 6V / 50mA
Connector: IEC-connector (male)
Reception
• Receive local free-to-air 1080P Full HD TV (depending on broadcaster), digital TV and analogue
TV signals
• Receive DAB digital radio signals
• UHF and VHF signal amplication
• Extremely low noise circuitry helps enhance weak signals
• Wide band amplier for best picture and sound reception
• Adjustable gain for clear television reception
Power
• Operate with or without power depending on strength of signal
Design
• Sleek design compliments any home theatre
• Eliminates the need for traditional rabbit ear antennas
• Wall mountable with mounting holes provided on the back of the unit
Note: Check reception signals prior to permanently mounting the antenna

8
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Instructions
Antenna Basics
Variables unrelated to product performance can aect reception. These include obstacles and
terrain between the transmitter and your antenna, radiated energy from electronic components
and building materials such as concrete or aluminium panelling. Consider these factors during
installation. For best results, test the antenna in multiple locations until you nd a position that
provides the best reception.
Congure For Best Signal
Use the following guide to ensure that the best reception signal can be achieved.
Coverage
Check your reception coverage in your area by visiting http://myswitch.digitalready.gov.au/ and
entering your address. This antenna is suitable for areas with Good Coverage. If your address does
not have Good Coverage, you may not be able to pick up all digital channels with this antenna.
A rooftop antenna may be necessary.
Angle
Position the front or back of the Bauhn
Digital Indoor Antenna to face the strongest
transmission tower.
(Indicated on http://myswitch.digitalready.
gov.au/ by the green line)

9
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Instructions
Location
Placing the Bauhn Digital Indoor Antenna near a window will
also increase the signal strength.
Amplication
Adjust the amplication dial until a strong signal is
achieved. To increase amplication, turn the dial to the
left. Some areas won’t require amplication, meaning the
power adaptor is not required.
Try dierent angles, locations and amplication levels until
the strongest signal is achieved for all channels.
Connecting
1. Connecting the antenna directly to a digital or
analogue TV
a. Connect the antenna cable to the Antenna IN socket on your TV
b. Connect the power adaptor to the DC 6V socket on the back of the antenna
c. Plug in the power adaptor to an available mains power point
d. Follow the guide in ‘CONFIGURE FOR BEST SIGNAL’ to achieve the best possible signal for
your antenna. Depending on your signal strength, it may take a few attempts to nd an
ideal conguration
e. Using your TV’s Remote Control, nd the auto tune option in your channel menu to scan
for available channels (Please refer to your television manual for further details)

10
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
2. Connecting the antenna to a digital set top box
a. Connect the antenna cable to the Antenna IN socket on your set top box
b. Connect the power adaptor to the DC 6V socket on the back of the antenna
c. Plug in the power adaptor to an available mains power point
d. Follow the guide in ‘CONFIGURE FOR BEST SIGNAL’ to achieve the best possible signal for
your antenna. Depending on your signal strength, it may take a few attempts to nd an
ideal conguration
e. Using your Set Top Box’s Remote Control, nd the auto tune option in the channel menu
to scan for available channels (Refer to set top box manual for further details)
3. Connecting the antenna to a Computer
a. Connect the antenna cable to the USB dongle (not included) or antenna port if available
b. Connect the power adaptor to the DC 6V socket on the back of the antenna
c. Plug in the power adaptor to an available mains power point
d. Turn the dial on top of the antenna to the left
e. Tune channels as per your software’s instructions
SET-TOP BOX
Instructions

11
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Mounting (Optional)
If you would like to mount the Digital Indoor Antenna onto a wall (Optional), follow the steps
below.
Note: Screws are not included
a. Find a suitable position to mount on the wall or cabinet
b. Test the reception on all channels
c. Line up screws with mounting holes and screw into the wall, leaving enough distance
(approx. 25mm) for the screw to reach the mounting hole
d. Hang antenna on the wall and admire your handy work
WARNING: Ensure there are no cables, wiring or pipes in the wall you are screwing into
Instructions

12
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
FAQs and Other
Useful Information
Can I mount the antenna on a wall or on my TV cabinet?
Yes, you can mount the antenna using the mounting holes on the back of the unit. Always check
for suitable reception before permanently mounting.
Do I have to use the power adaptor?
The power adaptor can improve the signal in some cases. If you are already receiving a good signal
you do not need to use the power adaptor.
What can I do to improve my reception?
You need to nd the best signal for the antenna. This can often be achieved by moving the
antenna to face dierent directions, or dierent locations. Follow the guide in ‘CONFIGURE FOR
BEST SIGNAL’ to maximise the signal received by the antenna. To check your signal strength,
please visit http://myswitch.digitalready.gov.au/
Why are some channels not appearing on my TV or set top box?
After connecting the antenna, make sure you scan for new channels in your TV or set top box’s
channel menu, otherwise they may not appear when you try to change channels.
Can I use this antenna outdoors?
This antenna is designed for indoor use only.
Will the 4G network interfere with my signal?
No, a built-in 4G lter prevents interference from the 4G mobile network.

13
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Tips and Troubleshooting
• Move the antenna around to nd the best place for reception in your room.
• Never mount the antenna until you have tested the antenna in that location.
• Some locations are not suitable for indoor antennas. If you are still having diculty producing
an adequate signal after all steps in this manual have been attempted, a rooftop antenna may
be required.
• In regions with very strong reception signals, too much amplication can result in a poor
picture. Turn the amplication dial to the “OFF” position to improve the reception.

Repair and Refurbished Goods
or Parts Notice
Unfortunately, from time to time, faulty products are manufactured which need to be returned
to the Supplier for repair.
Please be aware that if your product iscapable of retaining user-generated data (such as files
stored on a computer hard drive, telephone numbers stored onamobile telephone, songs
stored on a portable media player, games saved onagames console or files stored ona USB
memory stick) during the process of repair, some or all of your stored data may be lost.
We recommend you save this data elsewhere prior to sending theproduct for repair.
You should also be aware that rather than repairing goods, we may replace them with
refurbished goods of the same type or use refurbished parts in the repair process.
Please be assured though, refurbished parts or replacements are only used where they
meet ALDI’s stringent quality specifications.
If at any time you feel your repair is being handled unsatisfactorily, you may escalate your
complaint. Please telephone us on 1300 663 907 or write to us at:
Winplus Australasia
PO BOX 537
Bayswater Business Centre
Bayswater, VIC 3153
Winplus Help Desk 1300 663 907
(Operating Hours: Mon-Fri 08:30AM to 6:00PM)
[email protected]
www.winplus.com.au
AFTER SALES SUPPORT
1300 663 907
AUSYEAR WARRANTY
1
MODEL: HE315032 PRODUCT CODE: 38558 10/2015
[e-mail]
DIGITAL INDOOR ANTENNA

Repair and Refurbished Goods
or Parts Notice
Unfortunately, from time to time, faulty products are manufactured which need to be returned
to the Supplier for repair.
Please be aware that if your product iscapable of retaining user-generated data (such as files
stored on a computer hard drive, telephone numbers stored onamobile telephone, songs
stored on a portable media player, games saved onagames console or files stored ona USB
memory stick) during the process of repair, some or all of your stored data may be lost.
We recommend you save this data elsewhere prior to sending theproduct for repair.
You should also be aware that rather than repairing goods, we may replace them with
refurbished goods of the same type or use refurbished parts in the repair process.
Please be assured though, refurbished parts or replacements are only used where they
meet ALDI’s stringent quality specifications.
If at any time you feel your repair is being handled unsatisfactorily, you may escalate your
complaint. Please telephone us on 1300 663 907 or write to us at:
Winplus Australasia
PO BOX 537
Bayswater Business Centre
Bayswater, VIC 3153
Winplus Help Desk 1300 663 907
(Operating Hours: Mon-Fri 08:30AM to 6:00PM)
[email protected]
www.winplus.com.au
AFTER SALES SUPPORT
1300 663 907
AUSYEAR WARRANTY
1
MODEL: HE315032 PRODUCT CODE: 38558 10/2015
[e-mail]
DIGITAL INDOOR ANTENNA
