Bauhn AACBL-415 User manual

INSTRUCTION MANUAL
Model Number: AACBL-415
Alarm Clock Radio
with Lightning Dock
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
*iPhone not included

1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
i
Remote Control
1
2
3
4
5
6 10
11
12
13
79
8
1. : Turn the unit on or o.
2. SOURCE: (FM Radio, Bluetooth / Docking, or Line In).
3. PROG: Preset stations for FM radio.
4. / : Select the next / preset station. Adjust the time.
: In BT/DOCK mode, start or pause play.
/ : In BT/DOCK mode, skip to previous/next track le.
In FM mode, search radio stations manually / automatically.
5. PAIR: In BT mode, activate the pairing function and disconnect the
existing paired Bluetooth device.
6. ALARM 1: Set or view the settings for Alarm 1.
7. SLEEP: Set the sleep timer.
8. Vol+ / Vol-: Increase/decrease the volume level.
9. SNOOZE: Repeat the alarm.
10. ALARM 2: Set or view the settings for Alarm 2.
11. DIMMER: Adjust the brightness.
12. CLOCK: Set or display the clock.
13. MUTE: Mute of resume the sound.

1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
ii
Remote Control (Cont.)
Remote control battery
The remote control comes with a CR2025 3V button cell pre-installed.
First time use
• To activate the battery and use the remote control, pull out the plastic tab
that separates the battery from the contacts inside the compartment.
Battery replacement
• If the remote control unit is no longer working even when it is operated
near the Alarm Clock, you will need to replace the battery with a new
battery of the same type.
• Push in the tab and pull out the battery tray. Remove the old battery.
• Insert a fresh CR2025 battery with the (+) marking facing upwards. Then
push the battery tray with the battery back into the slot.
WARNING!
Keep batteries out of reach of children. Swallowing may
lead to serious injury or death in as little as 2 hours due
to internal burns. If swallowed, go straight to a hospital
emergency room. Dispose of used batteries immediately.

1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
iii
Using the remote control
• The remote control has a range of up to 3 metres from the Alarm Clock.
Point the remote control directly towards the sensor at the front of the
Alarm Clock.
• Make sure no obstacles are blocking its path. The remote control will not
operate if its path is blocked.
• Handle the remote control with care. Do not drop, apply shock or step on
the remote control. Do not spill water on the unit.
• Do not use the remote control while simultaneously operating a remote
control unit of any another unit, which may result in interference.
• If the remote control is operated near other products which generate
infrared rays, or if other remote control devices using infrared rays are
used near the unit, it may operate incorrectly. Conversely, the other
products may operate incorrectly.
• If you do not intend to use the remote control for an extended period of
time (more than a month), remove the battery to prevent possible damage
from battery leakage and corrosion.
Battery precautions
• Do not use any other battery than specified.
• Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type.
• Do not carry or store batteries with other metallic objects. Doing so could
cause batteries to short-circuit, leak or explode.
• Do not expose the battery to excessive direct heat such as sunshine, fire
or the like.
• Do not attempt to short-circuit, disassemble or throw batteries into a fire.
• Never recharge a battery unless it is confirmed to be a rechargeable type.
• Dispose of batteries promptly and properly, observing any local
hazardous waste regulations. Do not burn or bury them.
Remote Control (Cont.)

2
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Warranty Details 3
Welcome 4
General Safety Instructions 5
Product Overview 8
Getting Started 9
Instructions 10
FAQs 16
Other Useful Information 17
Repair and Refurbished Goods or Parts Notice 18
Contents

3
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts
for a period of 12 months from the date of purchase. Defects that occur within
this warranty period, under normal use and care, will be repaired, replaced or
refunded at our discretion, solely at our option with no charge for parts and
labour. The benets conferred by this warranty are in addition to all rights
and remedies in respect of the product that the consumer has under the
Competition and Consumer Act 2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
Alarm Clock Radio with Lightning Dock

4
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Congratulations on choosing to buy a BAUHN® product.
All products brought to you by BAUHN® are manufactured to the highest
standards of performance and safety and, as part of our philosophy of
customer service and satisfaction, are backed by our comprehensive 1 Year
Warranty. We hope you will enjoy using your purchase for many years to
come.
Welcome

5
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
General Safety Instructions
Read this manual thoroughly before rst use, even if you are familiar with this
type of product. The safety precautions enclosed herein reduce the risk of
re, electric shock and injury when correctly adhered to. Keep the manual
in a safe place for future reference, along with the completed warranty card,
purchase receipt and carton. If applicable, pass these instructions on to the
next owner of the appliance.
Always follow basic safety precautions and accident prevention measures
when using an electrical appliance, including the following:
Electrical safety and cord handling
• Voltage: Before plugging in the power adaptor, make sure your outlet
voltage and circuit frequency correspond to the voltage stated on the
product rating label.
• Wall socket: Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of re or electric shock.
When the adaptor is plugged into the power supply, make sure the wall
socket is easily accessible so it can be readily unplugged.
• Do not immerse: To protect against re and electric shock, do not immerse
the cord, plug, power adaptor or the product itself in water or other liquid.
• Protect from moisture: Never subject this product to moisture or extreme
temperatures. Do not expose it to dripping or splashing water. Do not use
the product near water (bathtub, washbowl, kitchen sink, laundry tub,
swimming pool) or in a damp basement.
• Protect the power cord: Do not kink, bend, squash or damage the cord of
the power adaptor and protect it from sharp edges and heat. Ensure nothing
is placed upon or against the cord. It is always best to have a clear area
from where the cord exits the unit to where it is plugged into a wall outlet.
Run the cord in such a way that there will be no risk of anyone pulling it
inadvertently, tripping over it or stepping on it.
• Damaged cord: If the electric cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied personnel. Contact our
after sales support line in order to avoid a hazard.
• Disconnect: To prevent damage to the product due to lightning strikes and
powerline surges, switch the product o and unplug it from the wall outlet
during lightning storms and when the product is not going to be used for an
extended period of time. Grip the plug when disconnecting, do not pull the
cord.

6
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
General Safety Instructions (Cont.)
Usage conditions and restrictions
• Attachments: Do not use attachments that are not recommended by the
product manufacturer or distributor.
• Adjustments: Only use and adjust controls and perform procedures as
specied in this manual. Any other adjustments or procedures may expose
you to danger and void your warranty.
• Installation and use: Improper use or installation may result in the risk of
re, electric shock and/or injury. We assume no liability for any eventual
damages caused by improper use or incorrect handling.
• Usage restriction: This product is not intended for use by persons
(including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the product by a person responsible for
their safety.
• Children: Supervise young children to ensure they do not play with the
product.
Safe usage
• Location: Place the product on a straight, rigid and stable surface, away
from sources of direct sunlight or excessive heat.
• Ventilation: The unit should be situated so that its location or position
does not interfere with its proper ventilation. For example, do not place
it on a bed, sofa, carpet, rug or similar surface that may block the
ventilation openings. Do not cover the ventilation openings with items
such as newspapers, tablecloths, curtains, etc. Do not place it in a built-
in installation, such as a bookcase or cabinet. Do not place anything
underneath the product (for example, CDs or magazines).
• Prevent overheating: Place the product in a suciently aerated place,
allowing at least 10cm clearance at the back and top of the product, and
5cm on both sides, to prevent overheating. Do not place the product on top
of another appliance that may cause overheating (for example, a receiver or
amplier).
• Keep away from heat: Do not place the product near heat sources such as
radiators, heat registers, stoves or other appliances that produce heat.
• Prevent damage: Do not place the product near other items that may
damage it, such as naked ame sources (lit candles) or objects containing
water (a vase or sh bowl).
• Keep openings clear: Take care that no objects fall and no liquids are
spilled into any openings or vents.

7
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
General Safety Instructions (Cont.)
Care and cleaning
• Cleaning: Clean the unit only as recommended in this manual, with a dry,
soft cloth.
• Do not use chemical cleaners: Do not use strong cleaning agents, such
as benzine, thinner or similar substances as these can damage the surface
of the unit.
• Do not open: Do not remove the cover or the back of this product. There
are no user-serviceable parts inside this product.
• Do not repair yourself: Do not attempt to dismantle, open or repair this
product yourself. Do not attempt to service the unit beyond those methods
described in this instruction manual. Service methods not covered in the
operating instructions should be referred to qualied service personnel.
• Service: Contact the after sales support line and arrange a service by
qualied service personnel in the following circumstances:
* The power supply cord or plug of the power adaptor has been damaged.
* Objects have fallen into or liquid has been spilled into the enclosure.
* The unit has been exposed to rain.
* The unit has been dropped or the enclosure damaged.
* The unit exhibits a marked change in performance or does not operate
normally.
• Battery disposal: Dispose of spent or damaged batteries in accordance
with local regulations.
The lightning flash with an arrowhead
symbol within an equilateral triangle is
intended to alert you to the presence
of non-insulated dangerous voltage
within the product’s enclosure that
may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
The exclamation point within an equi-
lateral triangle is intended to alert you
to the presence of important operating
and maintenance (servicing) instruc-
tions in the literature accompanying
the product.
To reduce the risk of electric shock, do not remove
the cover (or back).
This unit contains no user-serviceable parts inside.
Refer all servicing to qualified service personnel only.

8
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Product Overview
1. Dock for iPod/iPhone:
Connect your Lightning Pin
enabled device to pair and
charge.
2. : Press this button to turn
ON or press and hold to enter
Standby mode. When the unit
is on, press to change the
source. The selected mode will
show on the display.
3. : In BT/DOCK mode, start or
pause play
4. / : In BT/DOCK mode,
skip to previous/next track le.
In FM mode, search radio
stations manually by pressing
once and automatically by
holding it for 3 seconds.
5. VOL + / VOL -: Increase/
decrease the volume level.
6. : NFC (Near Field Communication) Sensor
7. Display Panel: Display the Time, FM Station, and other common
notications.
8. DC 5V~ Socket: Connect to the power adapter.
9. LINE IN Socket: Connect to an external audio device
10. FM Antenna Wire

9
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Connecting the Power
• Connect the adapter plug to your power outlet and adapter socket to your
Alarm Clock
Power ON/OFF
• When you rst connect the unit to the main socket, the unit will be in
STANDBY mode.
• Press the button on the remote control or the button on the main unit
to switch the main unit ON.
• Press the button on the remote control or press and hold the button
on the main unit to switch the main unit back to STANDBY mode.
NOTE: Disconnect the adaptor plug from the power outlet if you want to
switch the unit o completely. All settings will be erased.
• If there is no signal under the BT (Bluetooth), DOCK (iPhone/iPod) and LINE
IN mode, the unit will switch o automatically within 15 minutes.
Set the Time
• The built-in clock shows the time in the display.
1. In STANDBY mode, press and hold the CLOCK button on the remote
control until the hour indicator starts ashing.
2. Press the / buttons on the remote control to set the hour. Then press
the CLOCK button to conrm the hour. The minute indicator will start
ashing.
3. Press the / buttons on the remote control to set the minutes. Then press
the CLOCK button to conrm the minutes. Your clock will now be set.
IMPORTANT:
• If no button is pressed for 15 seconds, the settings will be lost and you will
need to start again.
• If you are in BT,DOCK, or LINE IN modes and would like to see the time,
press CLOCK on the remote and the time will be displayed. Press again to
return to the original display.
Getting Started (Cont.)
CAUTION!
Risk of product damage! Ensure
that the power supply voltage
corresponds to the voltage printed
on the rating label on the back or the
underside of the power adapter.

10
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Instructions
Setting the Alarm
You can set two alarms that go o at dierent times.
NOTE: Before setting the alarm, ensure that the clock is set correctly.
1. Press and hold the ALARM [1or 2] button on remote control in standby
mode for a few seconds and the hour digits will ash.
2. Press the / buttons on the remote control to set the required hour. Then
press the ALARM [1or 2] button to conrm the hour. The minute digits will
start ashing.
3. Press the / buttons on the remote control to set the required minute.
Then press the ALARM [1or 2] button to conrm the minute. The alarm
time will now be set.
4. Press the / buttons on the remote control to select an alarm sound
source: iPod/iPhone, FM tuner or buzzer. Then press the ALARM [1or 2]
button to conrm.
NOTE: If FM mode is chosen, the alarm will play the last played station.
5. Press the / buttons on the remote control to select the required volume,
we recommend no less than 5 as a minimum. Then press the ALARM [1or
2] button to conrm.
Your Alarm is now set, and either or will be displayed.
Activate and Deactivate the Alarm
• If an Alarm is set, press the ALARM [1or 2] button twice on the remote to
activate or deactivate the timer.
• If the alarm is activated or is displayed.
• If the alarm is deactivated, the or will disappear from the display
on the front of the unit.
Snooze Alarm
When the alarm sounds, you can stop it temporarily by pressing the SNOOZE
button. The display will show the SNOOZE indicator and the relative alarm
or will be ashing.
• The alarm will be delayed for 9 minutes and then start again.
• This manual snooze operation can be repeated again and again.
• If the alarm is set in FM mode, snoozing will reactivate FM after 9 minutes

11
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Instructions (Cont.)
• If the alarm is set in Docking mode, snoozing will reactivate playing music
from the device after 9 minutes.
Stop Alarm Ring
When the alarm rings, press the corresponding ALARM [1or 2] button. The
alarm will stop, but the settings will remain activated so you do not need to
keep setting every day.
View the Alarm Settings
Press the ALARM [1or 2] button to view the alarm settings. The display will
scroll through the date, mode and volume of the set alarm.
Setting the Sleep Timer
This unit can switch to standby automatically after a set period of time.
• To activate the Sleep Timer, press the SLEEP button on remote control
repeatedly to select a set period of time (in minutes).
90 60 30 15 00
When the sleep timer is activated, the display will show “ “ and the
volume will gradually decrease before the unit powers o.
• To deactivate the Sleep Timer, press the SLEEP button on remote control
repeatedly until [00] is displayed.
When the sleep timer is deactivated, “ “ disappears from the display.
Adjust the Display Brightness
Press the DIMMER button on remote control repeatedly to select dierent
levels of display brightness.
Adjust the Volume
During play, press the VOL+/- buttons on the remote control or on the main
unit to increase or decrease the volume level.
If you wish to turn the sound o, press the MUTE button on the remote
control. Press the MUTE button again, or press the VOL+/- buttons on the
remote control or main unit to resume normal listening.

12
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Instructions (Cont.)
Radio (FM) Operation
Auto Scanning and saving a Preset Station
• Press the button on the main unit or the FM button on the remote
control to select the FM mode.
• Press and hold the PROG button on the remote control or the button
on the unit for a few seconds to activate automatic programming. All
available stations are programmed in the order of waveband reception
strength.
• The rst programmed radio station is played automatically after the unit
has nished scanning for radio stations.
• Press the / buttons on the remote control to select the preset station
you would like to listen to.
Tuning in a Station manually
• Press and hold the / button on the remote control, the frequency
will change down or up automatically until a station is found. Continue to
press the / button on the remote control until you nd the station
you want.
Storing Stations Manually
You can store up to 20 FM stations.
1. Following the steps above, tune in the desired station, then press the
PROG button on the remote control.
2. Press the / buttons on the remote control to select the preset number
you would like to save to.
3. Press the PROG button on the remote control to store the station.
4. Repeat steps 1 to 3 for each station you would like to store in the preset
stations.

13
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Instructions (Cont.)
iPod/iPhone Operation
You can enjoy audio from iPod/iPhone through
this unit.
Listen to the iPod/iPhone
NOTE: This unit only supports products with a
Lightning Connector.
1. Press the button on the main unit or
the BT/DOCK button on the remote control to select the DOCK (iPhone/
iPod) mode.
2. Carefully place your iPhone/iPod into the docking bay by placing the
connecting port on the bottom of the iPhone/iPod onto the connector in
the docking bay.
NOTE: Remember to remove any bumper case before inserting your
device onto the docking connector.
3. Follow below instructions to operate this unit:
• To pause/resume play, press the button on the remote control or on
the main unit.
• To skip to a track, press the / buttons.
• To fast forward/backward during play, press and hold the /
buttons, then release to resume normal play.
Charging the iPod/iPhone
Your iPod/iPhone will automatically charge the battery when docked.
Bluetooth®Operation
You can listen to music from a Bluetooth enabled device via this player.
1. Press the button on the main unit or the BT/DOCK button on the
remote control to select the BT (Bluetooth) mode. “NO BT” will show on
the display if the unit is not paired to any Bluetooth device, the system
has entered pairing mode.
Alternately, you can press the PAIR button on the remote control to
activate Bluetooth pairing. The word PAIRING will sound from the unit,
and PAIR will be shown on the display.

14
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Instructions (Cont.)
2. Activate Bluetooth on your device, and select the search mode.
“BAUHN AACBL-415” will appear. Tap on this to establish the Bluetooth
conection.
3. When pairing is successful, the unit will sound “PAIRED”.
TIPS:
• Before you connect a Bluetooth device to this unit, familiarize yourself with
the Bluetooth capabilities of your device. Not all devices and functions are
compatible with this unit.
• Enter “0000” for the password if necessary.
• If a connection already exists, once in BT mode, press the PAIR button
on the remote control once to re-activate the pairing. The unit will sound
“PAIRED” indicating a successful pairing.
• In Pairing Mode, if no Bluetooth device is paired within 2 minutes, the
player will recover the previous connection.
• The operational range between this player and a Bluetooth device
is approximately 9 meters. The connection will be disconnected
automatically when the device is out of this range and the display will
ash NO BT once. To reconnect, place it back within the operational
range. the unit will sound “PAIRED”
• Any obstacle between this unit and Bluetooth device can reduce the
operational range.
• Keep this player away from any other electronic device that may cause
interference.
NFC (Near Field Communication) Operation
Pair your NFC-enabled mobile device directly with this unit by just a single
tap.
1. Activate NFC on your mobile
device.
2. Tap and hold your mobile
device on the icon of the
unit. The rst time you are
pairing your devices, your
mobile device will vibrate
or a message will pop up,
prompting you to pair the unit
with your device. Your mobile
NFC sensing area

15
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Instructions (Cont.)
device will then switch to Bluetooth mode. The unit will sound PAIRED
and BT will ash once on the display.
3. You can operate playback features via your mobile device.
4. To disconnect your mobile device, tap and hold again on the icon of
the unit. The unit will sound “DISCONNECTED” and “NO BT” will ash
once on the display.
NOTE:
• The NFC function only works with mobile devices that support NFC
technology.
• You may need to remove your mobile device case to connect using NFC.
Line in Operation
You can listen to an external audio device through this unit.
1. Ensure that the unit is connected to the external or audio device.
Connect the 3.5mm audio cable (supplied) to the LINE IN socket on the
rear of unit and to the headphone socket on your audio device.
2. Press the button on the main unit or the LINE IN button on the
remote control to select the LINE mode.
3. The music playing on your device will automatically start playing on the unit.
4. Press the VOL +/– button on remote control or on main unit to adjust the
volume to your desired level.
NOTE: Only the volume can be adjusted via the remote control, other
functions must be controlled via the settings on your device.

16
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Symptom Possible Problem and Solution
No power Ensure that the adaptor is connected properly.
Ensure that there is power at the AC outlet.
Remote control does not
work
Ensure the correct source is selected.
Reduce the distance between the remote
control and the unit.
Insert the battery with its polarities (+/-) aligned
as indicated.
Replace the battery.
Aim the remote control directly at the sensor on
the front of the unit.
Poor radio reception
Increase the distance between the unit and
your TV or VCR.
Fully extend the FM antenna.
Set FM antenna close to windows if you are
using it indoors.
Sleep timer does not work
Ensure the clock is set correctly.
Ensure the timer is set correctly and is
activated.
Clock setting erased
Power has been interrupted or the power cord
has been disconnected.
Reset the clock.
I can’t nd the Bluetooth
name of this unit on my
Bluetooth device for
Bluetooth pairing
Ensure that the unit is switch on.
Ensure that the Bluetooth function is activated
on your Bluetooth device.
NFC-enabled mobile
device will not pair
directly via NFC
Download and Install the App “Tap-and-Pair”
from the Google Play Store (https://play.google.
com).
Pair with the unit manually rst, then touch and
hold again on the NFC sensing area.
FAQs

17
1300 886 649 Model: AACBL-415 Product Code: 49737 04/2015
www.tempo.org
AUS
Specications
AC Power Adaptor
Input 100-240V ~ 50/60Hz, 0.5A
Output DC5.0V 2.0A
Speaker Output Power 3W x 2
Audio Input Sensitivity 500mV
Frequency Response 40Hz - 20kHz
Tuning Range 87.5-108MHz
Unit Dimensions (w x h x d) 191.6 x 57 x 191.6mm
Speaker Impedance 2Ω
Other Useful Information (Cont.)
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.,
and any use of such marks by Hands (IP) Holdings Pty Ltd is under license. Other trademarks
and trade names are those of their respective owners.
The N Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and
in other countries.
Lightning, iPod and iPhone are a trademark of Apple Inc.
