Bauhn ACRWC-0423-W User manual

1. : press to turn the light on/off and adjust the
brightness
2. DC PORT (rear of product) : plug in the supplied
power adaptor to the DC port and the other end
to a power socket with a power source to power
on the unit
3. LCD DISPLAY SCREEN
4. Backup Battery (underside of product) : use a
screwdriver to remove the screw and insert a
CR2032 battery (not included)
5. 5W WIRELESS CHARGING LED INDICATOR
6. 5W WIRELESS CHARGING PAD
7. FM ANTENNA
8. TEMPERATURE SENSOR
9. 10W WIRELESS CHARGING LED INDICATOR
10. 10W WIRELESS CHARGING PAD
Have you got everything?
Operation
Product Overview
User Guide
Model: ACRWC-0423-W, ACRWC-0423-M
Clock Radio With Dual Wireless Charging
Unpack the box (be gentle) and make sure all of these items are there:
A. Clock Radio With Dual Wireless Charging
B. Power Adaptor
Connect the supplied power adaptor to the DC port on the unit and the other end to a power socket with a
power source. The LCD display screen will light up and a beep sound will be heard.
To set the time, press and hold the button. The hour on the LCD display screen will ash. Use the Settings
button to set the hour. Press the button again and the minutes on the LCD display screen will ash. Use the
Settings button to set the minutes. Press the button again and the year on the LCD display screen will ash.
Use the Settings button to set the year. Press the button again and the month on the LCD display screen
will ash. Use the Settings button to set the month. Press the button again and the day on the LCD display
screen will ash. Use the Settings button to set the day. Press the button again to save the above settings
(the setting will automatically exit after 1 minute of no operation). Once set, press the button to switch
between 12 hour/24hour display mode.
To set the 1st alarm, press the button to enter alarm mode. Press and hold the button and the hour on
the LCD display screen will ash. Use the Settings button to set the hour. Press the button again and the
minutes on the LCD display screen will ash. Use the Settings buttons to set the minutes. Press the button to
store the alarm setting (the alarm setting will automatically exit after 1 minute of no operation).
Press the button to display the 1st alarm. The icon on the LCD display screen will ash. Use the Settings
button to turn the alarm on and the icon will light up solid.
Press the button to display the 2nd alarm. The icon on the LCD display screen will ash. Use the Settings
button to turn the alarm on and the icon will light up solid.
Press the button to save the settings and go back to clock mode.
To set the 2nd alarm, repeat the above steps.
When an alarm rings, press the SNOOZE button to enter snooze mode. Press the SNOOZE button again to
cancel snooze. When an alarm rings, press any of the / / / Settings buttons to turn off the alarm. The
alarm will automatically stop ringing after 10 minutes of no operation.
Press the button repeatedly to adjust the brightness of the LCD display screen (high/medium/low/off).
FM Operation:
Press the button to enter FM radio mode.
Use the Volume control button to decrease/increase the volume.
Use the Settings button to switch between the previous and next radio station.
Press the button again to switch back to clock mode.
Setting Preset Stations:
Press the button to show the frequency.
Press and hold the Settings buttons to the right to scan the available radio stations.
Press and hold the button to store the radio station (up to 8 stations can be stored).
Use the Settings button to switch between previous and next radio station.
To use the dual wireless chargers, place your smart phone facing up on the 5W/10W wireless charging pads.
The 5W/10W wireless charging LED indicator will light up red when charging. If the smart phone doesn’t start
charging, adjust the position and/or remove your smart phone case. Also ensure that there are no metal or
other objects between the smart phone and the wireless charging pad.
Notes:
The wireless charging function works only on wireless charging compatible smart phones.
Note: this unit uses a button or coin cell battery (not included) as a backup system. Using a screwdriver, remove
the battery compartment cover on the underside of the unit and insert the battery, ensuring the positive (+) is
facing up.
When replacing the battery, do not disconnect the power adaptor otherwise the clock/alarm settings/preset
stations will be lost.
C. User Guide
D. Warranty Certicate
Your new product is ready to enjoy!
Well done, you made it.
Now sit back and relax... your new product is automatically covered
by a 1-year warranty. How nice!
11. Volume control : scroll left to decrease volume
level. Scroll right to increase volume level
12. : enter alarm settings
13. : enter clock settings
14. SNOOZE: press to enter snooze mode.
15. : press to adjust the LCD display screen
brightness
16. : press to enter FM radio mode
17. Settings button : press left or right to set time/
day/month/year/alarm time/play previous or
next FM station.
CD
Top base
Bottom base
3
4
1
6
5
10
11
7
12 14 15 16 17 13
9
8
2

GENERAL SAFETY WARNINGS
General Safety Warnings
For the safety of yourself and others, follow all instructions and take notice of all the warnings. When
adhered to, these safety precautions can reduce the risk of fire, electric shock and injury.
This product complies with Australian Safety standard AS/NZS 62368.1 to ensure the safety of the
product.
The RCM is a visible indication of a product’s compliance with all applicable ACMA
regulatory arrangements, including all technical and record-keeping requirements.
Power adaptor input AC 100-240V, 50/60Hz 0.8A Max.
Power adaptor output 12VDC, 2.5A
Radio frequency range 87-108MHz
Power consumption 30W
Top base wireless charging 5W
Bottom base wireless charging 10W
Dimensions (W x H x D) 225 x 191 x 111 mm
Weight 850g (approx.)
Troubleshooting
Wireless chargers not
working
• Check that your smart phone supports wireless charging.
• Adjust the position of your smart phone to the centre of the
wireless charging pad.
• Remove the smart phone case.
• Check and remove any metal or other objects between the
mobile phone and wireless charging pad (the LED indicator
will ash red).
LCD display screen not
showing
• Check that the power adaptor is plugged into the DC port
and the other end to a power socket with a power source.
• Press the button to check whether the screen is on lowest
brightness setting.
Specications
IMPORTANT
Plastic wrapping can be a suffocation hazard for
babies and young children, so ensure all packaging
materials are out of their reach.
To prevent environmental factors (dampness, dust,
food, liquid etc.) harming the product, only use it in a
well-ventilated, clean and dry environment, away from
excessive heat or moisture.
Keep the product away from direct sunlight or heat
sources.
In case of damage, do not disassemble, repair or
modify the product yourself. Contact After Sales
Support for advice on repair or replacement, or refer
servicing to qualified personnel only.
This product is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the product by a
person responsible for their safety.
Children should be supervised to ensure they do not
play with the product.
This product is not suitable for use in locations where
children are likely to be present.
Do not put any object on top of the product
Do not place or store appliance where it can fall or be
pulled into a bath or sink.
Do not place the product into water or any other
liquids.
Do not expose the product to microwaves.
Do not place speakers too close to ears. Damage may
occur to ear drums, especially in young children.
Do not dispose the battery into a fire or hot oven,
and mechanically crush or cut the battery as this can
lead to an explosion.
Do not place the product in a high temperature
surrounding environment that can that can result in
an explosion or the leakage of flammable liquid/gas.
Do not use the product at a low air pressure
environment at high altitude as battery subjected
to low air pressure can result in an explosion or the
leakage of flammable liquid/gas.
Clean using a dry cloth only - do not use water or
chemicals.
Keep the product away from oils, chemicals or any
other organic liquids.
Use this appliance only for its intended purpose as
described in this guide.
Responsible disposal of the packaging
The packaging of your product has been selected
from environmentally friendly materials and can
usually be recycled. Please ensure these are disposed
of correctly. Plastic wrapping can be a suffocation
hazard for babies and young children, please ensure
all packaging materials are out of reach and are safely
disposed of. Please recycle these materials rather
than throwing them away.
Responsible disposal of the product
At the end of its working life, do not throw this
product out with your household rubbish. An
environmentally friendly method of disposal will
ensure that valuable raw materials can be recycled.
Electrical and electronic items contain materials
and substances which, if handled or disposed of
incorrectly, could potentially be hazardous to the
environment and human health.
Give us a call
What? You mean this User Guide didn’t have ALL the answers? Speak to us!
We’d love to help you get up and running as quickly as possible.
Call our After Sales Support on 1300 002 534.
Operating hours: Monday-Friday, 8:30am-6pm; Saturday, 9am-6pm AEST
WARNING: Uses button
or coin cell battery as
backup (not included).
Hazardous if swallowed.
WARNING!
This product contains a coin/button cell battery
inside. Keep batteries out of reach of children.
Swallowing may lead to serious injury or death in
as little as 2 hours due to internal burns.
This product has been designed so that the coin/button cell
battery is not accessible to young children, as the battery
compartment cover is secured with a screw or mechanical
fastener. Always ensure that the compartment is secured
before use.
If swallowed, immediately call the 24-hour Poisions
Information Centre on 13 11 26 for fast expert advice.
Dispose of used batteries immediately.
KEEP BATTERIES OUT OF REACH OF CHILDREN.
Swallowing may lead to serious injury or death in
as little as 2 hours due to internal burns.
Batteries must not be exposed to
sources of excessive heat such as
direct sunlight.
WARNING
WARNING!
