Bauhn ASPP8-0723-W User manual

Product Overview
Troubleshooting
Have you got everything?
Unpack the box and make sure all
of these items are there:
Note: only one power board
(white/black) is supplied.
User Guide
Model: ASPP8-0723-W, ASPP8-0723-B
8-Way Surge Protection Power Board
with USB A & C
A. 8-Way Surge Protection
Power Board with USB A & C
B. User Guide
C. Warranty Certicate
Active Power LED Indicator
When lit, the green light indicates that the
power board is active and ready for use.
Surge Protected LED Indicator
When lit, the green light indicates that all
connected devices are surge protected.
USB-C and USB Charging Ports
For charging phones, tablets or other devices.
Overload Circuit Breaker (Resettable)
Protects against current overload at 10 amps.
AC Sockets
All 8 sockets are the same protected sockets
and can be used interchangeably.
TV Line Protection
Protects the TV line against power surges.
Power On/Off Switches
Press to supply/cut off power to the outlets.
Give us a call
What? You mean this User Guide didn’t have ALL the answers? Speak to us!
We’d love to help you get up and running as quickly as possible.
Call our After Sales Support on 1300 002 534.
Operating hours: Monday-Friday, 8:30am-6pm; Saturday, 9am-6pm AEST
No power
output from
one of the
sockets
• Try other sockets. If the other sockets have power output, it’s probably
the contact of one faulty socket that is loose or not connected; avoid
using that socket.
No power
output from
any of the
sockets
• Check that the power switch is turned on (you can try to turn it on and off
a few times to make sure it’s switched on) and that the Active Power LED
Indicator is lit green.
• Check the overload circuit breaker button to see whether it’s tripping,
push it down to reset the circuit breaker.
• Make sure the input socket for the power board has power output.
No output
from the USB
ports
• Check that the USB cable is connected securely to the USB port and/or
try a different USB port.
• The total output current for the USB ports are 2.1A. Remove devices
using the other USB ports.
• Use another USB cable.
Power board
is not turning
on
• Check that there is no visible damage to the plug or cord.
• Ensure that the devices connected do not exceed the total maximum
load (2400W, 10A). If exceeded, unplug the devices and press the
overload reset button.
The TV cable
signal is weak,
or there is no
signal at all
• Check the two cable connectors are rmly connected to the ANT-IN
and ANT-OUT ports (located on underside of power board) ; you can try
unplugging them and then plugging them back in; also turn the cable
connector clockwise or counterclockwise to help make better contact for
the connectors.
• Disconnect the cable and connect your TV directly to the wall ANT
socket to make sure its not an issue with the source signal.
Well done, you made it.
Now sit back and relax... your power board is automatically
covered by a 1-year warranty.
How nice!
1
1
2
2
3
4
4
5
Enjoy using your power board!
3
6
6
7
7

Specications
Input AC 240V, 50Hz, 10A
Total Loading Max 10A 2400W
Maximum Energy 1050J
Surge Protection Limit 30,000A
USB Output DC 5V, 4A Total
Power Cable 1.1m
Mass 568g
Dimensions (W x H x D) 310 x 120 x 33 mm
GENERAL SAFETY WARNINGS
General Safety Warnings
For the safety of yourself and others, follow all instructions and take notice of all the warnings.
When adhered to, these safety precautions can reduce the risk of fire, electric shock and injury.
This product complies with Australian Safety standard AS/NZS 3105, AS/NZS 62368.1 to ensure
the safety of the product.
The RCM is a visible indication of a product’s compliance with all applicable ACMA
regulatory arrangements, including all technical and record-keeping requirements.
IMPORTANT
• Damage: If the power board or
cord is damaged, contact the After
Sales Support line for advice. Do not
attempt to open the board or replace
the cord. The cord must be replaced
by appropriately qualied personnel.
• Repair: If the power board requires
repair, contact the After Sales Support
line; never disassemble or modify the
power board or attempt to service it
yourself.
• Run the power supply cord in such
a way that there will be no risk of
anyone pulling it inadvertently or
tripping over it.
• If power supply cord is damaged, it
must be replaced by an authorised
service agent or similarly qualied
person to avoid a hazard.
• The power board is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision or
instruction by a person responsible
for their safety.
• Young children should be supervised
to ensure they do not play with the
power board. Close supervision is
always necessary when any appliance
is used by or near children.
• The product is not suitable for use in
locations where children are likely to
be present.
• The surge power board is designed
for indoor use in dry places only.
• Do not exceed a maximum loading of
2400 watts.
• For safety reasons, always use earth
connections.
• Only use the power board with the
power supply cord fully unwound.
• Before installing the power board,
make sure to place it away from: heat
sources, radiators or other products
that produce heat; areas with high
temperatures, high humidity or direct
sunlight; excess dirt and dust; open
windows and any place where water
may get to the unit.
• Do not immerse the cord, plug or
the surge power board in water or
other liquid, or expose the electrical
connections to water or other liquid.
• Unpack the power board and keep
the original packaging carton and
materials in a safe place. It will help
prevent any damage if the power
board needs to be transported in the
future, and you can use it to store the
power board when it is not in use.
• The power board should always be
repacked in its original packaging
whenever transporting to prevent any
possible damage to the product.
• When not in use: Disconnect from
the power source and store in a cool,
dry and well ventilated location out
of direct sunlight, and not subject to
humidity.
• Warning: The socket outlet should
be located near the equipment and
should be easily accessible.
Responsible disposal of the product
At the end of its working life, do not throw
this product out with your household
rubbish. An environmentally friendly
method of disposal will ensure that
valuable raw materials can be recycled.
Contact your local authority for your
nearest recycling centre. Electrical and
electronic items contain materials and
substances which, if handled or disposed
of incorrectly, could potentially be
hazardous to the environment and human
health.
Responsible disposal of the packaging
The packaging of the product has been
selected from environmentally friendly
materials and can usually be recycled.
Please ensure these are disposed of
correctly. Plastic wrapping can be a
suffocation hazard for babies and young
children, please ensure all packaging
materials are out of reach and are safely
disposed of. Please ensure they are
offered for recycling rather than throwing
these materials away.
Cleaning the product
Only use a soft, dry cloth for cleaning the
product; do not use a damp cloth. Never
clean with industrial strength polish, wax,
benzene, paint thinner, air freshener,
lubricant, detergent or other chemicals.
Wipe off any moisture, dirt or dust on the
power sockets and plug pins with a clean,
dry cloth.
