Bauknecht GSF 7396 User manual

Further indications are given in the pages to follow and in the user instructions.
Water supply indicator
Check the appliance fills with water.
Lower spray arm blockindicator
Release the spray arm.
"Water stop” device indicator
"Water stop” device not working.
Switch off the dishwasher and shut off the
water tap.
Rinse aid level indicator
Add rinse aid.
Salt level indicator
Add regeneration salt; only add regeneration
salt immediately before starting a wash
programme.
Programme progress indicator Delayed start buttons
The wash cycle can be programmed to start after 1-24
hours. Then press the Start button. The dishwasher will
start at the set time.
Time and failure display
Indicates in hours the time remaining until the start of the
wash cycle. Switches off when the programme has started.
Toward the end of the programme, during the drying cycle,
the display will indicate the time remaining in minutes.
“F1-F9” Identification of faults for service technician.
Start button
Indicator lamp lit while the dishwasher is operating. Flashes
when a fault occurs.
Switches off at the end of the programme.
On / Off Button
Pre-rinse /
Pre-wash
Washing
Drying
Programme
end
Options
Eco-Dry button
Dry cycle without using fans.
Half Load button
This function can be used with any
programme. The indicator lamp switches on:
The wash cycle is activated for the upper or
lower rack only.
Programme Symbol
and Temperature Programme selection and recommended load type
Place the detergent in the:
small compartment large compartment Consumption 1) Normal load / (Half load)
Water
(Litres) Energy (kWh) Time (Min.)
Eco Normal 40 - 55° C Recommended programme for routine washes, for
crockery with little or no dried-on food. X X
(13.5)
(11.5)
(1.3)
(0.9)
(80)
(60)
Intensive 60 - 70° C Recommended programme for heavily soiled
crockery. with dried-on food. Especially suitable for
pans and saucepans. X X
(19.5)
(11.5)
(1.7)
(1.3)
(98)
(90)
Pre-wash Crockery to be washed later. - - 5.0 (4.2) 0.02 (0.02) 9(9)
Rapid 40° C Lightly soiled crockery with no dried-on food. - X 13.0 (13.0) 0.85 (0.75) 30 (30)
Glasses 40° C Light soiling, especially glasses. - X 12.5 (10.0) 0.82 (0.78) 60 (59)
Bio 50° C 2) Normally or heavily soiled crockery with dried-on food. X X 16.0 (14.5) 1.05 (0.90) 120 (117)
DYNAMIC SENSE: Energy savings and optimum wash results
The two sensor-controlled “DYNAMIC SENSE” wash options are
recommended for routine washes. They use double-sensor
technology. Separate sensors gauge turbidity and particles in
order to determine the degree of soiling of the wash water. In
accordance with values measured, a microprocessor establishes
optimum water, energy and time consumption. Optimum wash
results are thus achieved using only those resources strictly
required.
Quick Reference Guide
GB
5019 100 90216
(We reserve the right to make technical modifications)
1) Values may vary in relation to usage, e.g.: different loads, water temperatures - above or below 15° C -
as well as water hardness and power supply voltage.
2) Reference programme for Test Institute and energy-label.
GSF 7396

1. After loading the dishwasher, close the
door properly and open the water
supply tap.
2. Press the On/Off button to switch the
dishwasheron.Oneoftheprogramme
indicator lamps will switch on.
3. Select the desired programme by
pressing the corresponding button. The
corresponding indicator lamp lights
up. If required,selectoptions(ifsupplied).
4. Press the Start button to start the
selected programme. The Start
indicatorlampwilllightup.Onceset,
the programmed data cannot be
altered by pressing the programme
selector buttons.
Note: Once the Start button has been
pressed, the dishwasher memorises the
last programme selected. This
information remains in the memory even
during interruption of the power supply.
To change the selected
programme, press the Start
button for about 5 seconds,until
the Start indicator lamp
switches off. Select a new
programme using the
programme selector knob and
press the Start button.
Note: If the dishwasher is switched off
during a wash programme, when
switched on again it will resume the wash
cycle from where it was interrupted.
Only open the dishwasher door if
strictly necessary during a wash
cycle and exercise maximum
caution. Danger of scalding from
steam.
5. To indicate the end of the programme,
the Start indicator lamp switches off
and the End indicator lamp (if fitted)
switches on (for about 30 min.).
6. Once the Start indicator lamp has
switched off press the On/Off button to
switch the dishwasher off. All the
indicator lamps switch off.
7. Open the door (warning: beware of hot
steam). Unload the lower rack before
the upper one. Close the water tap.
Upper rack
Half Load:
If only the upper rack is to be loaded remove
the cutlery basket from the lower rack and
place it in the upper one.
Rack height adjustment:
(The dishwasher is delivered with the upper
rack in the top position).
The rack height can also be changed
when loaded.
•To lower: pull out the two side
handles and gently lower the rack.
•To raise: pull up the two side handles
until the rack clicks into place.
•The rack must be level on both
sides.
Crockery Holders:
•Down: cups and long-stemmed glasses.
•Up: plates.
"Vario Organizer”multi-purpose
support:
•To be used, for example, for long-
handled utensils (arrange knives
with the blade facing downwards),
cups and glasses.
•May be used in three different
positions (see also “Dishwasher
loading instructions”on Page 4).
1. Upon the left-hand side of the rack.
2. Upside-down, towards the centre of
the rack.
3. Upside-down, towards the left side.
Glass holder:
Lower rack
Half Load:
Loading the lower rack only gives
greater washing power, especially for
plates and saucepans.
Plate holders:
•May be lowered to increase
available space (A).
•May be removed to increase available
space(B). To remove: pull the handle
up.
Cutlery basket:
The cutlery basket can be removed to
increase (C) available space.
B
A
C
B
A
C
How to use the dishwasher
Please read the user instructions carefully.
Upper and lower rack

Tips and advice
•Arrange crockery so that items do not
touch each other. Arrange large
crockery in the lower rack and smaller
crockery in the upper rack.
•Load cups at an angle to facilitate
water drainage.
•Generally speaking, place cutlery in the
basket with the handles positioned
downwards, but ensure that any sharp
knives and forks that might cause
injury are placed in the basket with the
handles positioned upwards.
•Make sure the water jet can reach all
loaded items and that the spray arms
turn freely. Important
•Fill the detergent dispenser and check
the salt and rinse aid level.
•Do not use the appliance for items not
suitable for washing in a dishwasher,
for example: wooden items, aluminium,
plastic utensils, tin, hand-decorated
crockery (unglazed), silver cutlery.
•Do not put liquid fat in the dishwasher
(e.g. oil used for frying) or candle wax.
•If a fault occurs or you wish to change
the current programme,
press the “START”button for about 5
seconds until the Start indicator lamp
switches off.
•If regeneration salt is to be added,
immediatelystart a wash programme in
order to eliminate any residual salt
(rinsing alone is not sufficient).
•Sometimes
even though the regeneration salt
container has been filled, the
corresponding indicator lamp (if fitted)
will light up during the first wash cycle
after filling with salt.
•Before starting a wash programme,
make sure that the spray arms can turn
freely and are not impeded by crockery
or cutlery.
•Only switch off the dishwasher once the
“Start”indicator lamp has switched off.
If the dishwasher is switched off during
a wash cycle, when switched on again it
will resume the cycle from where it was
interrupted without having to start it
again.
If a fault occurs, before contacting our
After-Sales Service, make the following
checks to try and remedy the problem:
The dishwasher is not working:
•Is the plug properly inserted in the wall
socket?
•Is there a power failure?
•Is the dishwasher switched on?
•Has the Start button been pressed?
•Has the delayed start timer been set (if
fitted)?
•Is the water supply tap on?
•Is the flow of water obstructed by
impurities? If so, close the water supply
tap, detach the water hose and clean the
filter. Then re-connect the water hose to
the tap and open the water tap once again.
•Are the filters clogged? (See “Care and
maintenance”chapter in the user
instructions).
•Is the door closed properly?
•Is a fault indicated?
(The Start indicator lamp flashes).
Start the programme again from the
beginning: Press the Start button for
about 5 seconds, until the Start indicator
lamp switches off.
Select a new programme and press the
Start button.
Crockery still dirty after washing:
•Was the crockery loaded properly?
•Crockery must be loaded facing
downwards; this is important, especially
for large items of crockery.
•The water jets must spray the entire
surface of all items.
•Make sure that crockery and cutlery are
arranged properly.
•Have you selected the correct programme?
•Did you use too much or too little
detergent? (The use of poor quality
detergents may result in less effective
washing).
•Are the filters clogged or incorrectly
assembled? (See “Care and
Maintenance”chapter in the user
instructions).
•Arethesprayarmsblockedorthenozzles
clogged? (See “Care and Maintenance”
chapter in the user instructions).
•Is the lower spray arm correctly fitted?
•Is the salt container cap (water softening
system) screwed down?
Marked crockery:
•Is the water hardness level selector not
properly adjusted? See ("Filling the salt
container”in the user instructions).
•Is the salt container empty? (See “Filling
the salt container”in the user
instructions).
•Was insufficient detergent used? (See
“Filling the detergent dispenser”in the
user instructions).
Marked glasses and cutlery:
•Was too much rinse aid used? (See
“Filling the rinse aid dispenser”in the user
instructions).
Note: With some models, when the Start
button is pressed a pre-wash cycle precedes
the actual wash programme; this regenerates
the water softening system.
If, after carrying out the above checks the
malfunction persists or appears again,
turn the appliance off and turn off the
water supply tap, then call our After-Sales
Service (see guarantee). Please specify:
•The nature of the fault.
•The appliance type and model.
•The service code (the number after the
wordServiceontheadhesiveratingplate)
inside the door on the right-hand side.
•Your full address and telephone number.
AFTER-SALES
SERVICE
Troubleshooting Guide
Please read the user instructions carefully.

LOWER RACK
UPPER RACK
Half Load
Dishwasher loading instructions
Depending on the model, rack features may vary (see “Upper and lower rack”description).
