Bauknecht GSU 5536 User manual

5019 496 90412
GB
GSU 5536 Quick Reference Guide
Before using the dishwasher, read the user instructions!
(We reserve the right to make technical modifications)
Add regeneration salt
Only add regeneration salt immediately
before starting a wash programme.
Add rinse aid
“Delayed start” button
The wash cycle can be programmed to start after
3-6-9 hours. Then press the Start button.
The wash programme will start at the set time
“Half load” button
The half load cycle can be used for the upper and
lower rack. Select the required programme then
press the “Half Load” button. The light comes on
and goes off at the end of the programme.
The “Half Load” function can be used with
programmes marked with an *.
Antibacterial rinse 4)
This function adds an antibacterial rinse at the end
of the wash cycle, thereby guaranteeing a perfectly
clean and sanitized load. The lamp will light up
when the function is activated. If the temperature is
notmaintainedduringtheantibacterialcycle(e.g.if
the door is opened and remains open for a long
time), the lamp will start blinking to indicate that
sanitation is not guaranteed.
1) Reference programme for energy label EN 50242
2) Refer to “User instructions”;
3) Program data obtained in conformity with European
standard EN 50242. Values may vary in relation to
usage, e.g.: different loads, water temperatures -
above or below 15°C - as well as water hardness and
power supply voltage, etc.
4) The bacteria removal efficiency has been tested by
the Institut Pasteur de Lille (France), based on the NF
EN 13697 standard of November 2001.
5) These programmes can be used with the Antibacterial
rinse option.
Programme selector knob
On / Off button
Start button
Switches “on” when the dishwasher is
operating. Flashes when a fault occurs.
Switches off at the end of the programme.
Indicators
Programme cycle
Pre-Rinse Washing Drying End
Options
Programme chart Detergent 2) Consumption 3)
Programmes Loading instructions A B Litres kWh Minutes
Pre-Rinse cold Crockery to be washed later. - - 5.0 0.02 10
Rapid 30 min 40°C Lightly soiled crockery with no
dried-on food. X - 13.0 0.70 30
Standard 1) 5) (*) 50°C Normally soiled crockery. X X 16.0 1.05 140
Normal 5) (*) 65°C Normally or heavily soiled crockery. X X 16.0 1.65 100
Intensive 5) 70°C Recommended programme for
heavily soiled crockery, especially
suitable for pans and saucepans. X X 17.0 1.90 135
Important information for Test Laboratories:
For detailed information on the EN comparison test and other tests, contact the following address:
“[email protected]”.

How to use the appliance
Further indications are given in the single chapters and in the user instructions.
Press the ON / OFF button.
Large compartment A:
With each wash cycle.
Small compartment B:
For programmes with pre-wash only.
Mechanical indicator C.
Electric indicator on control panel (if provided).
On models with water softener system only.
Mechanical indicator D.
Electric indicator on control panel (if provided).
Refer to the dishwasher loading instructions.
The last programme selected will light up.
Select the desired programme (using the specific button or
knob). The corresponding indicator lamp lights up.
If necessary (and if provided) the corresponding indicator
lamp lights up.
The selected programme
is then memorised (even
in the event of power
failure).
- Only open the dishwasher if necessary
(Warning: beware of hotsteam).
- Iftheapplianceis switchedoffduring
a wash cycle, when switched on
again it will resume the cycle from
where it was interrupted.
Only after the START button has switched off: Press the
ON / OFF button. All the indicator lamps switch off.
Warning: when the door is opened steam comes out!
Unload the appliance, starting from the lower rack.
Switch on the appliance
How to fill the
detergent dispenser
CBA
Check the
rinse aid level
Check the regeneration
salt level
Load the racks
Close the door,
turn on the water tap
Select a programme
Select additional
options
Press the START button
“Change programme”
Press the START button for 2 sec. until
the Start indicator lamp switches off;
Select another programme and
press the START button again.
Wash cycle
Switch off the appliance
Shut off the water tap,
unload the racks

Dishwasher loading instructions and racks provided
Upper rack: depending on the model
Multi-purpose support (A) 1):
Depending on the position, for
long-handles utensils, cups and
glasses. May be used in three
different positions.
Crockery holders (B):
Depending on the position, for
example plates, cups and
long-stemmed glasses.
Revolving glass support (C) 2):
Depending on the position, for
example small or long-stemmed
glasses.
Long-handled utensils (e.g.
carving forks, knives) must be
arranged with the sharp end
facing in towards the appliance.
Half Load:
Load the upper rack only.
Place the cutlery basket (D) in the
upper rack.
Rack height adjustment (also
when loaded):
•Lower adjustment: pull out
the two rack handles outwards
(E) and lower the rack.
•Upper adjustment: pullthetwo
handles (E) upwards until the rack
clicks into place (Factory setting).
The rack must be level on both
sides.
Removing the top rack to
provide clearance for large
items of crockery in the
bottom rack:
Open the rack guide retainers (F)
on the right and left and remove
the top rack.
When the upper rack is in place the
retainers must always be closed.
Lower rack:
Depending on the model with fixed
or tilting plate holders (G).
Half Load:
Load the lower rack only.
Greater washing power,
particularly for plates and
saucepans.
Cutlery basket (J) or (H):
Somemodelsareprovided with a grid
(I) that can be fitted onto the cutlery
basket to keep items separated.
Cutlery basket (D), if provided, for
appliances with half load only.
Sharp knives and forks that
might cause injury must be
placed in the cutlery basket with
the sharp end facing downwards.
Only use dishwasher-proof crockery and dishes. Do not use the appliance for items not suitable for washing in
a dishwasher, for example wooden items, aluminium, plastic utensils, tin, hand-decorated crockery (unglazed),
silver cutlery.
Spare parts which are sold separately:
1) Multi-purpose support (A) - N. AMH 369.
2) Revolving glass support (C) - N. WGH 1000.
FF
Retainer
closed Retainer
open

What to do if...
If a fault occurs, before contacting our After-Sales Service, make the following checks to try and remedy the
problem (* see also the corresponding chapter in the user instructions).
Problem Cause Remedy
The appliance is not
working • No water supply. • Open the tap.
• The appliance does not load
sufficient water. • Clean the water supply tap filter. Ensure there are no kinks in the water hose.
• There is a power failure. • Insert the plug into the mains socket.
• Press the Start button.
• Close the door.
• Check the domestic circuit fuse.
• Starting the selected programme. • The programme can be set to “0” to start.
If crockery is not
perfectly dry • Insufficient rinse aid. • Increase dosage *.
• Residual water in cavities. • Load crockery at an angle.
If crockery is not
perfectly clean • The water jet does not reach the
crockery. • Arrange crockery so that items do not touch each other. Load crockery upside down.
• Insufficient detergent. • Follow recommended detergent dosage.
• Unsuitable programme. • Select a more intense wash cycle.
• Spray arms blocked. • The spray arms must be able to turn freely.
• Spray arm nozzles clogged. • Remove any impurities obstructing the water
flow *.
• Incorrect detergent/detergent too
old. • Use a good quality detergent.
Sandy or grainy
residues • Clogged filters. • Check filters regularly/if necessary clean *.
• Filters incorrectly assembled. • Insert the filter correctly *.
Colour of plastic
parts faded • Tomato/carrot juice... • Depending on the material, if necessary use a
detergent with a greater whitening power.
Deposits on crockery
• removable • Streaks on the crockery/glasses. • Increase the rinse aid dosage *.
• Streaks on glasses. • Reduce the rinse aid dosage *.
• Layer of salt on crockery/glasses. • Close the salt container lid properly*.
• not removable • Insufficient water softening,
calcium deposits. • Change water hardness setting, if necessary add salt *.
Opaque glasses/
glasses not sparkling • Cannot be washed in the
dishwasher. • Use suitable glasses.
Rust on cutlery • Not made of stainless steel. • Use suitable cutlery.
Identifying
appliance faults • The START indicator lamp flashes.
• Indicator F... (if provided). • Ensure the filter assembly is not clogged and that there is no interruption to the water
supply (if necessary, clean the filters *).
Start the programme again. Press the START
button for 2 seconds, until the START indicator
lamp switches off. Select a new programme
and press the Start button again.
If after carrying out the above checks the malfunction persists or appears again, turn the appliance off
and turn off the water supply tap, then call our After-Sales Service (see guarantee).
Before contacting our After-Sales Service, take note of the following:
• The nature of the fault.
• The appliance type and model.
• The service code (the number indicated on the adhesive rating
plate) inside the door on the right-hand side.
