440E/440H DROP SPREADER
OPERATOR’S MANUAL

DOCUMENT REVISION: DECEMBER 2018
MODEL:
SERIAL NUMBER:
PURCHASE DATE:
DEALER/WHERE PURCHASED:
3 INDUSTRIAL DRIVE
ELMIRA, ON N3B 2S1
PHONE: [phone]
FAX: [phone]
WWW.BAUMANMFG.COM

1
Contents
INTRODUCTION.......................................................................................................................................................................2
GENERAL INFORMATION ........................................................................................................................................................3
SAFETY INSTRUCTIONS............................................................................................................................................................ 4
SAFETY LABELS ....................................................................................................................................................................5
MAINTENANCE........................................................................................................................................................................ 6
ATTACHMENT OF THE MACHINE ............................................................................................................................................6
SPREADING MATERIAL............................................................................................................................................................7
HYDRAULIC/ELECTRICAL ROUTING INSTRUCTIONS................................................................................................................7
440E/440H, COMMON PARTS LIST .........................................................................................................................................8
440E, ELECTRIC SPECIFIC PARTS LIST ......................................................................................................................................9
440H, HYDRAULIC SPECIFIC PARTS LIST.................................................................................................................................. 9
INSTALLATION LOCATIONS ...................................................................................................................................................10
HYDRAULIC COMPONENTS ASSEMBLY.................................................................................................................................14
ELECTRICAL HOOK-UP DIAGRAM..........................................................................................................................................15
OPTIONAL BRACKETS ............................................................................................................................................................16
ADDITIONAL OPTIONS...........................................................................................................................................................17
WARRANTY INFORMATION...................................................................................................................................................18
NOTES: ..................................................................................................................................................................................19

2
INTRODUCTION
Congratulations on your purchase of a Bauman Drop Spreader! This spreader has been
designed and manufactured to enable operators to carry out their work safely and efficiently.
The Bauman Drop Spreader is capable of spreading sand, salt, grit, or similar materials and
should only be used for this purpose. Correct usage of the machine also includes following the
factory’s preparation, operation and maintenance instructions.
This manual will help you understand the proper maintenance and operation of the spreader
in order to maximize the longevity and effectiveness of the machine. All information,
illustrations and technical specifications in this manual are based on the most recent product
information available at the time of printing.
Bauman Manufacturing reserves the right to change the design and specifications and/or
make additions and improvements to the product without notice.

3
GENERAL INFORMATION
The operator must read and understand the information in this
manual to ensure the correct service and operation of the machine
and avoid unnecessary risk of accidents and breakdowns.
Please Note:
Stop the tractor engine before you adjust, lubricate, or repair the machine. Remember to
remove the ignition key to make sure no one starts the tractor while you are repairing the
machine.
Do not let anyone underneath the machine once it is connected to the tractor. Always
disconnect power when servicing.
Do not let anyone get close to or stay close to the machine while it is in operation. Do not
squeeze between the machine and the tractor as an unintentional maneuver may result in
serious injury.
Make certain that the hydraulic components are not subjected to continuous operating
pressure exceeding 1800 psi or intermittent pressures of 2350 psi. A higher pressure may
cause danger of exploding parts, hot oil exposure, or component failure.
Tractor Requirements:
It is recommended that the tractor operator use hearing protection in case of insufficient
sound insulation in the cab. In order to keep full control of the tractor in all circumstances, at
least 20% of the tractor’s total weight should be on the front axle. It may be necessary to
regulate weight distribution with additional weights.
Do not overload your vehicle beyond the manufacturer’s payload limits. If there are any
questions concerning weight limits, contact vehicle manufacturer.
Material Density Guideline*
Fine Salt (Dry)
85 lbs./cubic foot
Coarse Salt (Dry)
55 lbs./cubic foot
50/50 Sand/Salt Mix
100 lbs./cubic foot
*Material densities are provided for estimation only. Actual material densities may vary.

4
SAFETY INSTRUCTIONS
This machine demands skilled operation therefore, you must read this operator’s manual
before connecting the machine to the tractor. Even though you may have owned or operated
similar equipment, you should read through the safety and maintenance procedures
thoroughly. This concerns your safety.
The Bauman Drop Spreader should only be operated by one person. The operator should
ensure that no one is close to the area where the machine is in use. Do not let others operate
the machine unless you are certain that they have the necessary knowledge to operate the
machine safely and correctly.
The following precautions should be read and understood before operation of the machine:
▪Activate the tractor’s parking brake and stop the tractor’s engine before:
•Unclogging material jams;
•Lubricating the machine;
•Cleaning the machine;
•Disassembling any part of the machine;
•Adjusting, repairing, or maintaining the machine.
▪Lower the machine to the ground when parked.
▪Disconnect power before servicing.
▪Do not work underneath an elevated unit until it has been secured mechanically or with
stop wedges.
▪Do not start or operate the tractor until bystanders are clear of the machine.
▪Check to make sure that all tools have been removed from the machine before starting
the tractor.
▪Check that all safety shields and grills are in place and secured.
▪Do not operate the machine while wearing loose garments.
▪Use statutory vehicle lights and safety markings when operating the spreader on public
roads or when driving in the dark.
▪Hearing protection is recommended, especially if the machine is in use over a long
period of time.
▪Before lifting or lowering the spreader, ensure there is no one in the vicinity of the
machine. Do not stand between the tractor and the spreader during attachment and
detachment.
▪The machine has been manufactured strictly for the intended use as a drop spreader.
Do not use the machine for any other purpose.
▪Be considerate of people, property and animals near the machine. Maintain a distance
of at least 10 meters from obstacles while operating from the machine.

5
▪Use only original components or replacement components received from Bauman
Manufacturing.
▪Sitting, reaching into or climbing on or in the spreader during operation can result in
serious injury or death. Do not ride on the spreader while the vehicle is in motion.
▪All laws and rules relating to public safety in the country of operation must be obeyed.
Follow both the vehicle and spreader manuals to ensure safety and mechanical
efficiency.
It is the operator’s responsibility to ensure the safety of themselves and others
while operating or maintaining a Bauman Drop Spreader.
SAFETY LABELS
The danger labels on Bauman Manufacturing equipment are for the safety of the operator as
well as pedestrians and bystanders. Read and obey warning and danger labels. The operator
must ensure that before operating the machine, all guards and grills are in place and that they
are attached properly. Stay clear of all moving parts and rotating shafts.
Under no circumstances should anyone reach into the
hopper when the spreader is in operation.

6
MAINTENANCE
Warning: When repairing, maintaining and cleaning the machine, it is particularly important
to be aware of the safety precautions. Park the tractor (if connected) as a precautionary
measure and disconnect power when servicing. Do not clean, lubricate or adjust the machine
before the tractor engine has been stopped and the parking brake is activated.
Important: Screws and bolts on your new machine must be tightened up after the first two
hours of operation. All moveable parts must be greased regularly for the best performance.
To extend the durability of the machine, frequent and thorough cleaning is recommended. Set
spring tension to loosest setting for ease of cleaning the machine and use plenty of water
when cleaning to avoid material freezing on the roller or rubber belts.
Remember: Do not spray water directly into bearings or bearing housings. If the machine is
stored for a lengthy period of time, spray it with acid-free oil before use. Remove all foreign
material from the roller. Check and lubricate all chain and bearings regularly.
It is important to properly maintain and service your spreader. Failure to comply
with the manufacturer’s suggested servicing procedures may result in premature
wear and may hinder the machine’s performance.
ATTACHMENT OF THE MACHINE
This spreader can be attached to the tractor using various methods. It is the operator’s
responsibility to make sure that it is connected and fastened properly and safely. Ensure that
the spreader sits horizontally when in operation.
Hydraulic Units: Ensure the hydraulic hoses are properly connected to the tractor’s hydraulic
ports. Improper connection may damage the machine if the oil runs in the wrong direction.
Flow control and hoses to the tractor are included.
Electric Units: Ensure the wiring kit is properly connected to the tractor’s battery. A wiring kit
is included. See page 15 for connection diagram.
Mounting options include 3 Point Hitch bracket, Ventrac bracket, Click-N-Go bracket and
Steiner bracket. See page 16 for an illustration of these brackets.

7
SPREADING MATERIAL
REGULATING SPREAD QUANTITY
The spreading quantity is adjusted with the tension adjustment lever. Correct adjustment is
important. If the adjustment is too tight, unnecessary wear of the rubber belts or rotating parts may
occur. If the adjustment is too slack, distribution of material will be uneven.
Hydraulic Units: All hydraulic units are equipped with hydraulic flow control. To ensure to correct
rate of drop of material, the operator would adjust the tension adjustment lever, hydraulic flow
control, engine RPM, and ground speed. Adjusting engine RPM impacts hydraulic flow.
Electric Units: To ensure the correct rate of drop of material, the operator would adjust the tension
adjustment lever and ground speed. An optional variable power controller may be installed, allowing
for fine-tuning of the motor rotation speed.
STARTING TO SPREAD
Spreading of material starts as soon as the tractor’s PTO, hydraulic, or electrical system is engaged.
HYDRAULIC/ELECTRICAL ROUTING INSTRUCTIONS
Electrical: Bauman Manufacturing electric Drop Spreaders include a wiring kit (see page 15 for
schematic). It is the responsibility of the operator to ensure that the motor is wired correctly. It is
important that the direction the distributor drum rotates matches the rotation arrow in Figure A.A
decal depicting the correct rotation direction has also been positioned near the bearings supporting
these shafts.
Hydraulic: Similarly, the hydraulic spreader models come equipped with the hoses and fittings
already installed in their intended orientation. Ensure the tractor hoses are attached in such a way
that allows for the agitator and distributor drum to rotate in the direction shown in Figure A.
Figure A:
Direction of Drum
Rotation

8
440E/440H, COMMON PARTS LIST
ITEM
#
PART NUMBER
DESCRIPTION
QTY.
1
440 410
#40 ROLLER CHAIN WITH C/LINK - DRIVE
1
2
40B30 100
#40-30 TOOTH 1" BORE
1
3
1040SI 430
BEARING PLATE
1
4
1140 201 SEAL
SHIELD RUBBER SEAL
1
5
1140 201
SHIELD
1
6
1140 301
FINGER BAR ASSEMBLY
1
6.1
1140 301-001
FINGER BAR TUBE 40
1
6.2
220 301 GALV STRIP
FINGER BAR STRIP
2
6.3
220 R-24527
FINGER BAR "RED" 5"x19 3/4"x3/16"
2
7A
1140 302
DISTRIBUTOR DRUM (SAND), SHAFT WITH STUDS
1
(A or B)
7B
1140 302 SALT 01
DISTRIBUTOR DRUM (SALT), SHAFT WITH GROOVES
8
1140 303
AGITATOR
1
9
1140 310
TENSION LEVER BASE 40"
1
10
1140 400
DOUBLE SPROCKET
1
11
1140 411
#40 ROLLER CHAIN WITH C/LINK - DRUM
1
12
440 200
440 GRILL
1
13
440 305
TENSION LEVER FOR 440/1040SI
1
14
440 100
HOPPER WELDMENT
1
15
DECAL BAUMAN LOGO 12"
BAUMAN LOGO 12" WITH WHITE LETTERING
1
16
DECAL CW ROT
CLOCKWISE ROTATION DECAL
1
17
DECALSW404
MOVING PART HAZARD
1
18
DECAL SALT
DECAL SALT (ONLY ON UNITS PURCHASED WITH ITEM 7B)
1
19
DECAL SERIAL #
SERIAL # DECAL
1
20
DECAL WHITE TAPE
2" WIDE, WHITE REFLECTOR TAPE
2
21
DECALW803
KEEP HANDS/FEET AWAY
2
22
1140 SB50-4
RUBBER FLAP FINGER BAR 40
1
23
1140 SB60-4
RUBBER FLAP DISTRIBUTOR DRUM 40
1
24
1140 800
HOOK BRACKET
2
25
CLAMP CHANNEL 40
40" RUBBER FLAP CHANNEL
2
26
BSFL 205-16
BEARING BACKSTOP-NEOPRENE
4
27
UCFL 205-16
TWO BOLT FLANGE BEARING
4
28
440 LID
GALV HINGED LID (OPTIONAL ATTACHMENT)
1

9
440E, ELECTRIC SPECIFIC PARTS LIST
ITEM
#
PART NUMBER
DESCRIPTION
QTY.
29
440 ELECTRIC DRIVE ASM
SEE COMPONENTS BELOW, COMES ASSEMBLED W/ HARDWARE
1
29.1
1801 440 MOTOR
1/4 HP 12VDC MOTOR
1
29.2
1801 440 REDUCER
REDUCER 35.5:1
1
30
DECAL 440E
MODEL # FOR 440E
1
31
40B12 010 EXT
#40-12 TOOTH 5/8" BORE-EXT
1
32
1801 440 ELE
ELECTRICAL TOGGLE KIT
1
32.1
1801 440 WIRE
WIRING HARNESS, FUSE, & QUICK-CONNECTS
1
32.2
1801 440 SWITCH
SWITCH BOX WITH LEAD
1
440H, HYDRAULIC SPECIFIC PARTS LIST
ITEM
#
PART NUMBER
DESCRIPTION
QTY.
33
HYD KIT 440H
HOSES AND FITTINGS FOR 440H
1
33.1
HYD FLOW
FLOW CONTROL VALVE 8GPM
1
33.2
HYD6602-6-6-6
SWIVEL NUT RUN TEE - MJIC x MJIC x FJIC
1
33.3
HYD6801-6-8
STRAIGHT THREAD ELBOW - MJIC x MORB 90°
2
33.4
HYD6400-6-8
STRAIGHT THREAD CONNECTOR - MJIC x MORB
1
33.5
HYD6400-6-10
STRAIGHT THREAD CONNECTOR - MJIC x MORB
1
33.6
HYD6801-6-10
STRAIGHT THREAD ELBOW - MJIC x MORB 90°
1
33.7
HYD440TH52
3/8 3000 PSI 1/2" NPT X 3/8 JIC 90 ELBOW
1
33.8
HYD440MH15
3/8 3000 PSI 3/8 JIC STRAIGHT X 3/8 JIC 90 ELBOW
1
33.9
HYD440MH18
3/8 3000 PSI 3/8 JIC STRAIGHT X 3/8 JIC STRAIGHT
1
33.10
HYD440TH66
TRACTOR HOSE 3/8" JIC 90 x 1/2" NPT
1
34
440 601
FLOW CONTROL MOUNTING BRACKET
1
35
HYD MOTOR 440
50cm^3/rev HYDRAULIC MOTOR
1
36
40B12 100 EXT
#40-12 TOOTH 1" BORE EXT. HUB
1
37
DECAL 440H
MODEL # FOR 440H
1

10
INSTALLATION LOCATIONS

11

12

13

14
HYDRAULIC COMPONENTS ASSEMBLY

15
ELECTRICAL HOOK-UP DIAGRAM

16
OPTIONAL BRACKETS
3 POINT HITCH BRACKET
Part Number: Bracket 3 PT
VENTRAC BRACKET
Part Number: Bracket 4100
CLICK-N-GO BRACKET
Part Number: Bracket CNG
STEINER BRACKET
Part Number: Bracket 440

17
ADDITIONAL OPTIONS
GALVANIZED METAL LID
Part Number: 440 LID
SOFT COVER
Part Number: 440 COVER
CONTROL BLOCK: VARIABLE POWER
Part Number: 1801 440 80A-SC

18
3 INDUSTRIAL DRIVE
ELMIRA, ON N3B 2S1
PHONE: [phone]
FAX: [phone]
WWW.BAUMANMFG.COM
WARRANTY INFORMATION
One Year Limited Warranty
If the unit fails to operate within one year from date of purchase because of defects in
materials or workmanship, Bauman Manufacturing will, at its option, either replace or repair
such components for the original purchaser. This warranty does not cover damage resulting
from accident, misuse or abuse, water, tampering, servicing performed or attempted by
unauthorized agencies, or units that have been modified in any fashion. If the components do
not perform as warranted herein, the original purchaser’s sole remedy will be the repair or
replacement of the components as provided above. Bauman Manufacturing products are not
intended for applications where a failure could result in a costly, dangerous or life-threatening
situation. Bauman Manufacturing will not be held responsible for damages or losses greater
than the cost of the Bauman Manufacturing replacement parts. In no event will Bauman
Manufacturing be liable for damages, lost revenue, lost wages, lost savings or any other
incidental or consequential damages, domestic or international, rising from the purchase and
use or inability to use the components, even if Bauman Manufacturing has been advised of the
possibility of such damages. Except as provided herein, Bauman Manufacturing makes no
warranties, expressed or implied, including without limitation, the implied warranties of
merchantability and fitness for a particular purpose, with respect to the components. All
warranties for the components expressed or implied, are limited to the warranty period set
forth above.
WARRANTY SERVICE
In order to obtain the remedy of repair or replacement parts, contact Bauman Manufacturing.
