Baumr-ag Trn600 User manual

TRN600 Trencher

User Manual

[Revision 2.0 December 2017]

READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY

DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by

this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.

The product is NOT supplied with engine oil, although traces of oil from the manufacturing

process may be present. It is essential to add adequate engine oil of the correct type to the

engine before use – see Checking and Changing Engine Oil. Failure to add engine oil will void the

product warranty.

TRN600 Trencher

Safety

Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or

equipment or property damage if not understood or followed. Safety messages have the following symbols:

You WILL be KILLED or

SERIOUSLY INJURED if you

do not follow instructions.

You CAN be KILLED or

SERIOUSLY INJURED if you

do not follow instructions.

You CAN be INJURED if you

do not follow instructions or

equipment damage may occur.

It is vital that you read and understand

this user manual before using the product,

including safety warnings, and any

assembly and operating instructions.

Keep the manual for future reference.

Safety precautions and recommendations

detailed here must be fully understood

and followed to reduce the risk of injury,

fire, explosion, electrical hazard, and/or

property damage.

Safety information presented here is

generic in nature – some advice may not

be applicable to every product. The term

"equipment" refers to the product, be it

electrical mains powered, battery powered

or combustion engine powered.

•Before Use - If you are not familiar with

the safe operation/handling of the

equipment, or are in any way unsure of

any aspect of suitability or correct use

for your application, you should

complete training conducted by a

person or organization qualified in safe

use and operation of this equipment,

including fuel/electrical handling and

safety.

•Do NOT operate the equipment in

flammable or explosive environments,

such as in the presence of flammable

liquids, gases or dust. The equipment

may create sparks or heat that may

ignite flammable substances.

•Keep clear of moving parts.

•Equipment may be a potential source of

electric shock or injury if misused.

•Do NOT operate the equipment if it is

damaged, malfunctioning or is in an

excessively worn state.

•Do NOT allow others to use the

equipment unless they have read this

manual and are adequately trained.

•Keep packaging away from children -

risk of suffocation! Operators must use

the equipment correctly. When using

the equipment, consider conditions and

pay due care to persons and property.

General Work Area Safety

•Work areas should be clean and well it.

•Do not operate the equipment if

bystanders, animals etc are within

operating range of the equipment or the

general work area.

•If devices are provided for connecting

dust extraction / collection facilities,

ensure these are connected and used

General Personal Safety

•Wear appropriate protective equipment

when operating, servicing, or when in

the operating area of the equipment to

help protect from eye and ear injury,

poisoning, burns, cutting and crush

injuries. Protective equipment such as

safety goggles, respirators, non-slip

safety footwear, hard hat, hearing

protection etc should be used for

appropriate equipment / conditions.

Other people nearby should also wear

appropriate personal protective

equipment. Do not wear loose clothing

or jewellery, which can be caught in

moving parts. Keep hair and clothing

away from the equipment.

•Stay alert and use common sense

when operating the equipment. Do not

over-reach. Always maintain secure

footing and balance.

•Do not use the equipment if tired or

under the influence of drugs, alcohol or

medication.

•This equipment is not intended for use

by persons with reduced physical,

sensory or mental capabilities.

General Fuel Safety

•Petrol/fuel/gasoline is extremely

flammable – keep clear of naked flames

or other ignition sources.

•Do not spill fuel. If you spill fuel, wipe it

off the equipment immediately – if fuel

gets on your clothing, change clothing.

•Do NOT smoke near fuel or when

refuelling.

•Always shut off the engine before

refuelling.

•Do NOT refuel a hot engine.

•Open the fuel cap carefully to allow any

pressure build-up in the tank to release

slowly.

•Always refuel inwell ventilated areas.

•Always check for fuel leakage. If fuel

leakage is found, do not start or run the

engine until all leaks are fixed.

General Carbon-Monoxide Safety

•Using a combustion engine indoors

CAN KILL IN MINUTES. Engine

exhaust contains carbon-monoxide – a

poison you cannot smell or see.

General Equipment Use and Care

•The equipment is designed for

domestic use only.

•Handle the equipment safely and

carefully.

•Before use, inspect the equipment for

misalignment or binding of moving

parts, loose components, damage or

any other condition that may affect its

operation. If damaged, have the

equipment repaired by an authorised

service centre or technician before use.

•Prevent unintentional starting of the

equipment - ensure equipment and

power switches are in the OFF position

before connecting or moving

equipment. Do not carry equipment

with hands or fingers touching any

controls. Remove any tools or other

items that are not a part of the

equipment from it before starting or

switching on.

•Do not force the equipment. Use the

correct equipment for your application.

Equipment will perform better and be

safer when used within its design and

usage parameters.

•Use the equipment and accessories

etc. in accordance with these

instructions, considering working

conditions and the work to be

performed. Using the equipment for

operations different from those

intended could result in hazardous

situations.

•Always keep equipment components

(engines, hoses, handles, controls,

frames, housings, guards etc) and

accessories (cutting tools, nozzles, bits

etc) properly maintained. Keep the

equipment clean and, where

applicable, properly lubricated.

•Store the equipment out of reach of

children or untrained persons. To avoid

burns or fire hazards, let the equipment

cool completely before transporting or

storing. Never place or store the

equipment near flammable materials,

combustible gases or liquids etc.

•The equipment is not weather-proof,

and should not be stored in direct

sunlight, at high ambient temperatures

or locations that are damp or humid.

•Do not clean equipment with solvents,

flammable liquids or harsh abrasives.

TRN600 Trencher

properly. Dust collection can reduce

dust-related hazards. •Use combustion engines OUTSIDE

only, and far away from windows, doors

and vents.

•For specific equipment safety use and

care, see Equipment Safety.

General Electrical Safety

•Inspect electrical equipment, extension

cords, power bars, and electrical fittings

for damage or wear before each use.

Repair or replace damaged equipment

immediately.

•Ensure all power sources conform to

equipment voltage requirements and

are disconnected before connecting or

disconnecting equipment.

•When wiring electrically powered

equipment, follow all electrical and

safety codes.

•Wherever possible, use a residual

current device (RCD).

•High voltage / high current power lines

may be present. Use extreme caution

to avoid contact or interference with

power lines. Electrical shock can be

fatal.

General Electrical Safety

•Electrically grounded equipment must

have an approved cord and plug and be

connected to a grounded electrical

outlet.

•Do NOT bypass the ON/OFF switch

and operate equipment by connecting

and disconnecting the electrical cord.

•Do NOT use equipment that has

exposed wiring, damaged switches,

covers or guards.

•Do NOT use electrical equipment in wet

conditions or in damp locations.

•Do NOT use electrical cords to lift,

move or carry equipment.

•Do NOT coil or knot electrical cords,

and ensure electrical cords are not trip

hazards.

General Service Information

•The equipment must be serviced or

repaired at authorised service centres

by qualified personnel only.

•Replacement parts must be original

equipment manufacturer (OEM) to

ensure equipment safety is maintained.

•Do NOT attempt any maintenance or

repair work not described in this

manual.

•After use, the equipment and

components may still be hot – allow the

equipment to cool and disconnect

spark plugsand/or electrical power

sources and/or batteries from it before

making adjustments, changing

accessories or performing repair or

maintenance.

•Do NOT make adjustments while the

equipment is running.

•Perform service related activities in

suitable conditions, such as a

workshop.

•Replace worn, damaged or missing

warning/safety labels immediately.

TRN600 Trencher

Safety Symbols

The product may have safety warning labels attached to it, explained below. Understand the symbols on

your product and their meanings. If any stickers become unreadable, unattached etc, replace them.

Flammable Material Hazard

Flammable liquids, gases or

substances etc may present.

Avoid ignition sources and

open flames. Danger of fire.

Read User Manual

Read and fully understand

product safety warnings,

operation, procedures etc

before using the product.

Use Hand Protection

Wear appropriate hand

protection and take due care

as the product or use of the

product may present hand

hazards.

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be

fatal.

Electrocution / Electrical

Shock Hazard

High voltage or high current

electricity may be present or

required by the product. Take

Toxic Fumes / Dust Hazard

Using the product or by-

products from use may

produce fumes, smoke or

particles that could be harmful

Explosive Material Hazard

Combustible liquids, gases or

substances etc may be

present. Avoid ignition sources

Cutting / Amputation Hazard

The product may have blades,

edges or mechanical devices

that can cause severe cut

injury to fingers, limbs etc.

TRN600 Trencher

due care when handling

electrical products, cables,

plugs and leads. Electrical

shock can be fatal.

if inhaled. Wear appropriate

breathing protection and have

adequate ventilation.

and open flames. Danger of

explosion.

Take due care when handling

and using the product.

Crush Hazard

The product may have blades,

edges or mechanical devices

that can cause severe crush

injury to fingers, limbs etc.

Take due care when handling

and using the product.

Single Operator Only

The product must be operated

by a single person only. More

than one person operating the

product may introduce

additional hazards.

Use Face Protection

Wear appropriate full-face

protection and take due care

as the product or use of the

product may present face and

eye hazards.

Use Foot Protection

Wear appropriate foot

protection and take due care

as the product or use of the

product may present foot

hazards.

Use Eye / Ear / Head

Protection

Wear appropriate eye and / or

ear and / or head protection

and take due care as the

product or use of the product

may present eye, hearing and

head hazards.

Running Hazard

Do not run on or near the

product as doing so may

present a fall hazard.

Diving Hazard

Do not dive into the product as

doing so may present a neck /

head injury hazard.

Adult Supervision Required

Always supervise children and

other users of a product to

prevent drowning or injury.

Skin Penetration / Puncture

Hazard

The product may produce

pressure, emit liquids or

objects that can cause severe

injury to fingers, limbs, blood

etc. Take due care when

handling and using the

product.

Hot Surface Hazard

Be aware that the product may

produce high temperatures

and hot surfaces that can

cause burn injuries.

Flying Debris Hazard

Be aware that the product or

use of the product may

present hazards produced by

flying debris. Wear appropriate

clothing and protectiove

devices.

Moving Parts Hazard

Be aware that the product

contains or uses mechanical

devices that move or rotate.

Always wait for moving parts

to stop fully before handling

the product, adjusting,

maintenence etc.

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be

fatal.

Pull Hazard

Be aware that the product

contains or uses mechanical

devices that can pull in objects

and can cause severe injury to

fingers, limbs etc. Take due

care when handling and using

the product.

Slope / Fall Injury Hazard

Be aware that using the

product on sloping surfaces or

in slippery conditions may

present additional dangers

from falls and contact with

blades, moving parts, hot

surfaces etc.

"Slam Dunk" Warning

Do NOT attempt "slam dunk"

maneouvres as this may result

in severe injury due to falling,

product breakage or collapse

etc.

Electrocution / Electrical

Shock Hazard - Outdoor

High voltage or high current

electricity may be present or

required by the product. Do

NOT use in rain, damp or wet

conditions. Electrical shock

can be fatal.

Electrocution / Electrical

Shock Hazard - Disconnect

High voltage or high current

electricity may be present or

required by the product.

Always disconnect the product

from the electrical supply

before handling the product,

adjusting, maintenence etc.

Power Line Electrocution

Hazard

High voltage / high current

power lines may be present.

Use extreme caution to avoid

contact or interference with

power lines. Electrical shock

can be fatal.

"Kick-Back" Hazard

High level of "kick-back"

hazard that can cause the

machine to suddenly rotate

towards operator. Kick-back

injury can be fatal.

TRN600 Trencher

Winch Operator Position

Hazard

Do NOT stand between winch

and load. Do NOT use winch

to move people.

Winch Lift Hazard

Do NOT LIFT load vertically.

Use machine to PULL only.

Cable Hazard

Ensure that load bearing cable

is not kinked or knotted.

Winch Cable Hazard

Ensure that there is a

minimum number of cable

coils on winching mechanism.

Winch Hook Hazard

Carry hook to load – do NOT

throw or run.

TRN600 Trencher

Equipment Safety

Trenchers are high-speed, fast-cutting equipment with exposed teeth that can cause serious

injury if not used correctly or without taking proper safety precautions. It is extremely

important that you read and fully understand the information in this section and all other safety

warnings / recommendations and usage instructions before using the equipment.

Operator

•If you are untrained in the use of a motorised trencher, it is highly recommended that you be

trained/instructed by a suitably qualified or experienced person before using the machine.

•Fully understand how to safely operate the machine and the trenching process. See Operation.

•You must be in good physical condition to use a motorised trencher. NEVER operate the machine when

tired, or under the influence of any substance (medication, alcohol, drugs etc) that may impair your

judgement, alertness, physical strength, vision or dexterity.

•Maintain sure-footing and balance always when using or handling the machine and have full awareness

of your surroundings and any possible hazards.

•Prolonged machine use may lead to health complications, such as carpal tunnel syndrome, due to

vibration. To help reduce the possibility of such conditions, wear gloves, take breaks frequently, keep

fingers and hands warm, and maintain the equipment for optimal operation and minimal vibration. It is

recommended to seek medical advice if you feel numbness or burning sensations in fingers/hands.

Clothing and Protective Equipment – All Operators and Assistants

•Wear approved safety goggles, or safety glasses with adequate top and side protection..

•Wear suitable hearing protection.

•Wear heavy-duty, non-slip leather or protective gloves.

•Wear approved heavy-duty safety boots, with steel toe-caps and non-slip soles.

•Wear suitable overalls or work clothing that fits snugly, but does not restrict movement. Avoid loose

fitting clothing, scarves, jewellery etc and keep long hair contained to avoid getting caught or pulled by

the chainsaw or by tree branches etc.

Work Area Safety

•Use EXTREME CAUTION to avoid power cables – contact can be fatal. Also be aware of plumbing,

water and gas pipes etc. If in any doubt, do NOT dig – contact the appropriate organisation or authority

for information before digging.

•Inspect the work area and remove any objects that may get caught up or obstruct the machine, or may

get thrown by it.

•Be aware of fire risks resulting from machine use. Ensure that the machine exhaust and spark arrestor (if

equipped) is well maintained and that engine is tuned correctly.

•Refuel outdoors only. Avoid fuel spillage. Start the machine at least 3m (10') away from the fuelling

location.

Operational Safety

•Do NOT use the machine if the throttle or any safety guard or mechanism is not installed or is not

operating correctly – have the machine inspected and repaired at an authorised service centre before

using it again.

•Always hold the machine firmly with both hands during operation. Always use the machine handles.

•Use EXTREME CAUTION when using the machine on sloping surfaces.

•Use EXTREME CAUTION when changing machine direction, reversing etc.

•Do NOT use any trenching attachment that is cracked or damaged in any way – replace it.

TRN600 Trencher

•Ensure the trenching teeth are not obstructed before digging.

•Ensure that all trenching teeth are fully secured before digging.

•If the trencher jams, stop the engine immediately.

•Do NOT use the equipment for purposes it is not designed for, such as cutting concrete.

•Do not attach the machine to fixed supports.

Transportation Safety

•Always STOP the engine before transporting or working on it (refuelling, adjusting etc).

•When transporting the machine in a vehicle, ensure the engine is OFF, and the machine is secured in an

upright position to prevent tip-over, machine damage or fuel spills.

TRN600 Trencher

Table of Contents

Safety...................................................................................................................................................2

Safety Symbols..........................................................................................................................................4

Equipment Safety...............................................................................................................................7

Parts Identification...........................................................................................................................10

Engine and Machine Components...........................................................................................................11

Before Use Checklist.......................................................................................................................12

Assembly .................................................................................................................................................12

Engine Oil ................................................................................................................................................15

Air Filter....................................................................................................................................................15

Fuel..........................................................................................................................................................15

Engine Starting and Stopping........................................................................................................16

Engine Starting ........................................................................................................................................16

Stopping the Engine.................................................................................................................................16

Emergency Stopping.........................................................................................................................17

Environmental Considerations.................................................................................................................17

Trencher Operation..........................................................................................................................18

Adjusting Handlebar Position.............................................................................................................19

Adjusting Trench Depth.....................................................................................................................19

Using the Wheel Locks......................................................................................................................19

Using the Throttle..............................................................................................................................20

Maintenance .....................................................................................................................................21

Maintenance Schedule – Petrol Engines / Machines...............................................................................22

Engine Oil ................................................................................................................................................23

Air Filter....................................................................................................................................................25

Inspection and Cleaning....................................................................................................................25

Removal/Installation – Petrol Engines...............................................................................................25

Spark Plug ...............................................................................................................................................26

Cleaning and Gap Checking..............................................................................................................26

Removal/Installation..........................................................................................................................26

Greasing Drive Shafts..............................................................................................................................27

Transportation and Storage............................................................................................................28

Troubleshooting...............................................................................................................................29

Specifications...................................................................................................................................31

Engine Service and Maintenance Record.....................................................................................32

TRN600 Trencher

Parts Identification

No. Name No. Name

1

Engine / Gearbox / Frame / Handle Assembly 8 Tools / Fasteners / Accessories:

Note that all necessary fasteners are installed in

position.

10 / 13 (2) / 17 / 19mm Spanner

Spark Plug Tool

M6x20 Bolt (4)

M8x25 Bolt (5)

M10x50 Bolt (2)

M6 Washer (4)

M8 Washer (7)

M10 Washer (2)

M6 Spring Washer (4)

M8 Spring Washer (4)

M6 Nut (4)

M8 Nut (2)

Fuel Bottle

2

Chain Arm

3 Front Guard

4 Guide Wheel

5 Chain / Cutting Teeth Assembly

6 Side Guard

7 Depth Adjustment Handle

4

8

1

2

3

6

7

5

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

TRN600 Trencher

Engine and Machine Components

No. Name No. Name

1

Engine ON / OFF Switch

14

Engine Safety Switch

2

Throttle Control

15

Drive Cover (drive system inside)

3 Choke Lever 16 Guide Wheel

4 Starter Cord 17 Oil Filler Cap

5 Fuel Tank 18 Oil Drain Plug

6 Fuel Tap 19 Chain Arm

7

Exhaust

20

Idler Gear

8

Air Filter Assembly (air filter inside)

21

Chain

9

Spark Plug (obscured)

22

Cutting Tooth / Mounting Plate (27)

10 Handlebar 23 Front Guard

11 Handlebar Lock Lever 24 Side Guard

12 Wheel Lock Lever 25 Wheel

13 Depth Adjustment Handle 26 Emergency Stop Button (obscured)

1

2

7

3

5

12

9

6

8

4

10

11

13

14

15

16

17

18

21

26

23

20

19

22

24

25

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

TRN600 Trencher

Before Use Checklist

Ensure that you carry out all procedures below before starting the engine or operating the

equipment. All procedures described are generic in nature and slight variations between

different models may exist. Failure to follow the checklist and carry out the procedures correctly may

result in making the product warranty void. The product is NOT supplied with engine oil, although traces

of oil from the manufacturing process may be present. It is essential to add adequate engine oil of the correct

type to the engine before use – see Engine Oil. Failure to add engine oil will void the product warranty.

Assembly

2 or more persons are required for assembly. • Suitable tools are required for correct

assembly. • Check all parts have been supplied and are in good condition before

commencing assembly. • Firmly secure all fasteners. • Occasionally, additional fasteners may come

supplied, however, these are not used for this machine configuration.

1. Place the depth adjustment handle (A) over the depth adjustment shaft (B). Ensure that the spring (C) is

facing outward.

2. Place a M8 washer (D) in position, and insert a M8x25 bolt (E) through the slot in the handle and screw it

in (rotate right) to the depth adjustment shaft approximately 10mm. Pull the end of the spring over the

bolt, then screw the bolt in further (there is no need to "tighten" the bolt as the spring tension should

prevent it from loosening).

3. Slide the end of the chain arm (F) onto the bar (G) at the front of the machine. Using a suitable spanner

and Allen key, back-off (rotate left) the chain tensioning bolts (F1) on either side of the chain arm so they

are as far back as possible.

F

F1

G

A

B

C

D

E

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

TRN600 Trencher

4. The chain and cutting teeth assembly (H) needs to be "split' in order to be installed. Find the removable

link (H1) in the chain – it has split pins (H2) to retain the link pins (H3). Remove both split pins (do not

damage or discard them), then using a suitable pin punch and hammer, drive 1 link pin through the chain

link from the split pin side. Remove 1 nut, spring washer and bolt (H4) from the split pin side of the tooth

plate (H5), then remove the link plate (H6) from the split pin side – the chain is now split.

5. Pull the chain around the drive shaft housing underneath the machine (at this stage run the chain next to

the drive gear, and ensure that the cutting teeth are facing forward) so the free end of the chain will lie

along the top of the chain arm. Lift the chain onto the drive gear so the links engage with the drive gear

teeth. Rest the chain on the ridge running the length of the chain arm.

6. Hold the chain in position so it does not roll back around the drive gear, then pull the free end of the

chain over the idler gear at the front end of the chain arm. Bring the two ends of the chain together, then

drive the previously removed link pin through the chain link so the chain is again joined. Place the link

plate over the two link pins, then re-insert the split pins through the link pins. Bend the legs of the split

pins around so the pins cannot fall out. Re-insert the previously removed bolt through the tooth plate and

link plate, then secure it using a spring washer and nut. Use the spanners to firmly tighten (rotate right)

the nut.

7. Using a suitable spanner and Allen key, advance (rotate right)

the chain tensioning bolts (F1) on either side of the chain arm

to increase tension on the chain. Tension the chain so there is

approximately 10 to 20mm of slack in it when you pull it down

from the underside of the chain arm at its centre. When tension

is correct, tighten the nut (F2) against the welded nut (F3) on

both sides.

8. Bring the guide wheel assembly (I) into position next to the

chain arm (left side of the machine when standing behind it).

Attach the guide wheel assembly to the plate on the chain arm

side using 2 M8x25 bolts (E), 4 washers (D), 2 spring washers

(J) and 2 nuts (K). The bolts should pass through a washer,

plate, guide wheel assembly, washer, spring washer, then nut.

Note that it may be necessary to change the chain arm depth

position in order to have access to the bolt holes.

H5

H1

H2

H3

H4

H6

H

F1

F2

F3

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

TRN600 Trencher

9. On the drive cover side, attach the guide wheel assembly using 2 M8x25 bolts (E), 2 washers (D) and 2

spring washers (J). The bolts should pass through a spring washer, washer, guide wheel assembly, then

into the plate. Firmly tighten (rotate right) all fasteners using the spanners.

10. Attach the front guard (L) to the mounting plate (M) above the chain arm using 2 M10x50 bolts (N),

washers (O) and spring washers (P). The bolts should pass through a spring washer, washer, front

guard, then into the plate. Firmly tighten (rotate right) the fasteners using the spanner.

11. Attach the side guard (Q) to the inside of the

soil ejection chute (R) using 4 M6x20 bolts (S),

washers (T), spring washers (U) and nuts (V). The

bolts should pass through a washer, chute, guard,

spring washer, then nut. Firmly tighten (rotate right)

the fasteners using the spanners.

When assembly is complete, the machine should look

similar to below.

L

M

I

D

E(2)

J

K

D

E

J

N

O

P

S

T

U

Q

V

R

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

TRN600 Trencher

Engine Oil

Four-stroke engines require engine oil in the crankcase for lubrication of internal components. Severe or

irreparable damage may occur if the engine is allowed to run without engine oil. The engine oil level requires

regular maintenance. Check the engine oil level and ensure that the oil level is at or just under the maximum

level indicator.

Always check the engine oil level before starting the engine. See Engine Oil.

Air Filter

The air filter is used to prevent dirt and other particles from possibly entering the engine and causing internal

damage to it. The air filter requires regular maintenance.

Always check the air filter before starting the engine. See Air Filter.

Fuel

Petrol/fuel/gasoline is extremely flammable – keep clear of naked flames or other ignition

sources. • The engine must be cool before refuelling.

Adequately fill the fuel tank with the correct fuel type.

•Use non-ethanol unleaded petrol (higher RON values will provide best engine performance). Do not use

old or contaminated fuel.

To fill or top up fuel:

1. Place the machine on a flat and level surface.

2. Clean the machine around the fuel filler so that no dirt or other material enters the engine when the cap

is removed.

3. Remove (rotate left) the fuel filler cap.

4. Using a funnel, carefully fill the tank with fuel. Do not fill above the top of the strainer (if equipped) or

otherwise overfill the tank.

5. When finished, reinstall (rotate right) the fuel filler cap until firm. Wipe away any residual fuel from the

machine. If fuel has been spilt, move the pump away from the spillage before starting the engine.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

TRN600 Trencher

Engine Starting and Stopping

Engine Starting

1. FUEL – Place the fuel

tap (A) in the "ON"

position (to the right).

2. CHOKE – If the engine

is cold, place the choke

(B) in the "COLD"

position (to the left). If the

engine is warm or ambient

temperature is high, place in

the "HOT" position (to the

right).

3. IGNITION – Place the

engine ON/OFF switch (C)

in the "ON" ("I") position, and

secondary ON/OFF switch in

the "ON" position.

4. THROTTLE – Place the throttle

control (D) just off the "SLOW"

position. To move

the throttle, press

and hold the

button at the top

of the lever, move

it to the required

position, then

release the

button.

5. START – Slowly

pull out the starter

cord (E) until you

feel it engage with

the engine, then

pull it out rapidly (use both hands if necessary).

The engine should start. Allow the starter cord to

rewind slowly – do not let it "snap" back.

6. WARM-UP – Allow the engine to warm-up and

run smoothly. If choke is being applied, place the

choke (B) in the "HOT" position.

7. THROTTLE – Adjust the throttle control (D) for

the required engine speed.

If the engine does not start, repeat step 5 onward. If

the engine fails to start after several attempts, refer

to Troubleshooting.

Stopping the Engine

To stop the engine, release the throttle and place the engine ON/OFF switch in the "OFF" position.

A

B

1

2

5

4

6

7

3

D

E

C

Video Tutorial:

Starting Petrol Engines

Note that there is a secondary engine ON/OFF switch

located on the left handlebar. To place it in the ON

position, pull the lever and hold in this position, then

rotate the metal clip over so it is between the lever and

switch housing. Release the lever – the clip should

remain in the ON position.

3

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

TRN600 Trencher

Emergency Stopping

To stop the engine in an emergency, pull the secondary ON/OFF switch lever (A), or push the emergency

stop button (B) on the end of the handlebar. After using the button, rotate it right (clockwise) until it "pops" up.

Environmental Considerations

Altitude – If the engine is being used in altitudes at or above 1500m (approximately 5000'), adjustments to

the carburettor may be required. This is because there is less oxygen in the air as altitude increases, which

effectively "enriches" the ratio of fuel to air going into the engine and the higher the altitude, the richer the

fuel mixture becomes. If the engine is being permanently operated at high altitude, it is recommended to

have an authorized service centre make the necessary carburettor adjustments. If the engine is used

occasionally at altitude (not extreme altitudes), no adjustments should be required, however, a slight

decrease in engine performance can be expected.

Temperature – If the engine is being used in extremely cold or

hot environments; for example, desert or snow conditions, the

type of engine oil may need to be changed to suit environmental

temperatures. Oil thickens as the temperature decreases and

thins as temperature increases, which means that if the engine

oil is not suited to the temperature its ability to properly lubricate

the engine may be affected. Use the chart to determine the

correct engine oil.

A

B

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

TRN600 Trencher

Trencher Operation

Trenchers are high-speed, fast-cutting equipment with exposed teeth that can cause

serious or fatal injury if not used correctly or without taking proper safety

precautions. It is extremely important that you read and fully understand the information in this

section and all other safety warnings / recommendations and usage instructions before using the

equipment. • Before use, ensure that there are no electrical cables, gas or water pipes etc or other buried or

unseen hazards in the work area. Contact the applicable utility providers for assistance. • The machine

should be operated on ground that is suitable for trenching by machine. • Do not attempt to trench through

concrete, rock, tree roots, heavy clay or other hard or problematic surfaces. If you come across material that

cannot be trenched by the machine, use some other method to remove the material before continuing

trenching (for example, a jackhammer etc) • Do not use attachments or accessories beyond those supplied

with the machine. • Augers and auger tips are consumable parts, and are not covered under warranty.

The machine is used for digging and clearing narrow trenches, up to 600mm deep, in suitable ground

material. The machine is designed for manual operation, where the operator both holds and controls it. Note

the following:

•Adjust the throttle, which engages the trenching chain and controls its speed, only when ready to begin

trenching.

•Guide the machine as straight as possible when in use to ensure straight trenches.

•Depending on the softness of the ground material and the depth of trench, it may require several passes

at greater depths each time to complete the trench.

•Always check the trenching chain and cutting teeth before trenching. Replace any worn or damaged

components. Do not use if damaged in any way.

•If the machine is getting "stuck" during trenching, reduce depth and/or investigate other resons such as

suitablility of the ground material, obstacles etc.

•When moving the machine, disengage the wheel locks, then push down on the handlebars to raise the

trenching arm, then move the machine.

To trench:

1. Position the machine in the required location, with the front of the machine at the end of the trench – that

is, trenching is performed by moving the machine backwards.

2. Start the machine and allow it to warm up.

3. Set the trenching arm to the required depth. It may be necessary to hold the trenching arm up by putting

weight on the handlebar.

4. Engage the wheel locks.

5. Use the throttle to increase engine speed and drive the trenching chain.

6. Holding the handlebar firmly with both hands, carefully lower the trenching arm into the ground, Allow the

cutting teeth to "dig in" to the ground material.

7. When the guide wheel contacts the ground the trench is at full depth. Put weight on the handlebar to

raise the trenching arm, then disengage the wheel locks and move the machine backwards 100 to

150mm (4 to 6").

8. Repeat steps 4 to 7 as necessary to cut the trench.

9. When finished, stop the engine and raise the trenching arm.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

TRN600 Trencher

Adjusting Handlebar Position

1. Rotate the locking handle (A) left (anti-clockwise)

until the top section of the handle (B) can be

rotated.

2. Move the handle to the required position – where it

is comfortable for you to hold, and to raise the front

of the machine. Generally, waist height is a good

starting point.

3. Rotate the locking handle right (clockwise) until the

handlebar assembly is firmly held.

Adjusting Trench Depth

1. Pull the depth adjustment handle (C) upward so it disengages from the setting plate (D).

2. Move the handle forward to increase trench depth, or backward to reduce depth as required. Note that it

may be necessary to raise the front of the machine off the ground to allow the trenching arm to drop.

3. Release the depth adjustment handle, ensuring that the tab at its bottom is fully engaged in a slot in the

setting plate.

Using the Wheel Locks

The wheels use spring-loaded pins to lock them in position while

trenching. This is to help reduce forward "creep" caused by the digging

action of the cutting teeth.

1. Pull and hold the lever on the right handlebar (E) to disengage the

wheel locking pins.

2. Move the machine as required.

3. Release the lever. Note that there may be a small amount of

movement before the locking pins fully engage.

The wheel lock mechanism comes factory set, however, can be

adjusted, if required (for example, if the locking pins are not fully

disengaging). Before adjusting, visually inspect the wheel lock on each side of the machine – whilst looking

at the mechanism, pull the wheel lock lever (E) and check if the locking pin (F) is retracting fully from the

A

B

C

D

0mm

150mm

340mm

450mm

600mm

E

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

TRN600 Trencher

holes in the wheel hub (G). Release the lever – the

locking pin should enter the hole in the hub sufficiently

to prevent the wheel from rotating. If the cables require

adjustment:

•If adjustment is required for one wheel only,

loosen the lock nut (H). Rotate the adjusting

screw (I) "IN" (right / clockwise) to reduce how

much the locking pin retracts when the lever is

pulled; rotate "OUT" (left / anti-clockwise) to

increase locking pin retraction. When adjustment

is complete, tighten the lock nut.

•If adjustment is required equally for both wheels,

use spanners to loosen lock nuts (J) at the rear of

the machine – there is a second on the inside of

the plate (K). Rotate the adjusting screw (L) "IN"

(right / clockwise) to reduce how much the locking

pins retracts when the lever is pulled; rotate

"OUT" (left / anti-clockwise) to increase locking

pin retraction. When adjustment is complete,

tighten the lock nuts.

Using the Throttle

The throttle lever (F), located on the

handlebar column, is used to adjust the

engine speed, which in turn engages the

trenching chain. To adjust the throttle,

press and hold the button at the top of

the lever, rotate the lever to the required

position, then release the button.

F

G

L

J

K

I

H

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Baumr-AG TRN600 User manual

Popular Construction Equipment manuals by other brands
