20V Cordless Angle Grinder AG2

Safety

Read and understand all safety warnings before using the tool.

•Avoid dangerous environments. Do not operate power tools in explosive atmospheres, such as in the

presence of flammable liquids, gases or dust. Power tools create sparks which may ignite dust or fumes.

•Do not use this product if it is not completely assembled or if any parts appear to be missing or

damaged. Use of a product that is not properly and completely assembled could result in serious

personal injury.

•Inspect the tool carefully to make sure no breakage or damaged occurred during shipping.

•If any parts are damaged or missing do not operate this tool until the missing parts are replaced. Use of

this product with damaged or missing parts could result in serious personal injury.

•Do not attempt to modify this tool or create accessories not recommended for use with this tool. Any

alteration or modification is misuse that will void product warranty and could result in a hazardous

condition leading to possible serious personal injury.

•To prevent accidental starting that could cause injury, always remove the battery pack from the tool

when assembling parts.

•Keep the tool and all components away from children.

•Keep children and bystanders away while operating power tools.

•Keep the work area clean and well lit

•Keep the tool pointed away from yourself and others at all times. Keep hands and body parts away from

moving parts and use safety guards.

•Do not allow persons unfamiliar with the tool or its operation to use the tool.

•Use safety equipment. Always wear eye and ear protection. Safety equipment such as dust mask, non-

skid safety shoes and hard hat should be used in appropriate conditions.

•Only use parts and accessories recommended by manufacturer.

•Do not modify any part of the tool or its safety mechanisms.

•Do not use in ambient temperatures above 40°C (104°F).

•Do not use the tool outside of its operating parameters. For example, polishing.

•Cutting discs may become hot during use – wear suitable protective gloves when handling discs.

•Always use the correct type of grinding / cutting disc for the material and the rotational speed (7000RPM)

of the tool –discs designed for slower operating speeds may become over-stressed and fracture or break

apart if used at higher than rated speeds.

•Do not grind using cut-off discs, or cut using grinding discs. Always use the correct type and size (that is,

outside diameter and bore diameter) of disc for the type of work to be performed. Do not use toothed

saw blades etc or discs that are not designed for a tool of this type.

•Do not start the tool with the disc inside a cut or against any object. Always allow the disc to be running

at full speed before contacting it to the work-piece.

•Position yourself to not be in the path of sparks or debris created by the tool. Always be aware of the

direction in which sparks / debris may be ejected from the tool.

20V Cordless Angle Grinder AG2

•Kick-back – "Kick-back" is a sudden reaction to a pinched, bound or misaligned cutting disc. If the

rotating disc becomes pinched or digs into in the work-piece, the disc may stall and the motor reaction

can drive the tool rapidly back toward the operator – this is highly dangerous. To help avoid kick-back:

•Always maintain a firm grip with both hands on the tool and position your arms to resist kick-back

forces.

•If the disc is binding, or when stopping a cut before completing it for any reason, release the trigger

and hold the tool motionless in the blade comes to a complete stop. Never attempt to remove the

cutting disc from the work-piece or pull the tool backward while the disc is in motion. If binding

occurs, investigate and take corrective actions to eliminate the cause of binding.

•When restarting the tool with the disc in the work-piece, centre the disc in the cut and check that it is

not engaging the material.

•Support large work-pieces to minimize the risk of pinching and kick-back. Supports must be placed

under the work-piece on both sides of the cut, near the line of cut and near the edge of the work-

piece.

•Do not use excessively worn or damaged cutting / grinding discs.

•Use extra caution when making “plunge cuts”.

•Keep hands away from the cutting area and disc – always use both hands to hold the tool when cutting.

•Never hold the work-piece being cut in your hands or across your legs, body etc. Always secure the

work-piece to a stable platform. It is important to support the work-piece properly to minimize body

exposure, disc binding, or loss of control.

•Hold the tool by the insulated handles only when cutting to help reduce the possibility of electrical shock

should the tool make contact with "live" wires.

•Always use cutting discs of the correct size and arbour size. Discs that do not match the mounting

hardware will run eccentrically, causing loss of control.

•Never use a damaged or non-original disc collar. Use of substitutes may present a safety hazard.

•Check that the disc guard is secure before each use. Do not operate the tool if the disc guard is loose or

not installed.

•Do not use on magnesium.

•Use extra caution when using the tool on sharp corners or edges and avoid bouncing the disc, chatter,

vibration and kick-back.

•Always observe that the cutting disc has stopped rotating completely before placing the tool down.

Battery and Charging Safety

•Use only with the batteries and battery charger specified by the manufacturer.

•Do not open the battery – danger of short-circuiting.

•Do not attempt to destroy or disassemble battery pack or remove any of its components.

•Do not touch the battery terminals with metal objects and/or body parts as short-circuit and/or personal

injury may result.

•Explosion hazard – protect the battery against heat; for example, direct sunlight and fire.

•Explosion hazard – do not short-circuit the battery.

20V Cordless Angle Grinder AG2

•Poison hazard – battery leakage (liquid ejection) may cause irritation or burns. Under extreme

conditions, liquid may be ejected from the battery – avoid contact. If contact occurs, flush with water. If

eye contact occurs, flush with clean water for at least 10 minutes and seek medical attention.

•Care when charging. Make sure cord for the battery charger is located so that it will not be stepped on,

tripped over, or otherwise subjected to damage or stress. Do not operate the battery charger if it has a

damaged cord or plug.

•Dispose of non-serviceable batteries in an environmentally responsible manner.

Servicing

•Have your power tool serviced by a qualified repair person using only identical replacement parts. This

will ensure that safety of the tool is maintained.

Intended Use

•Cutting / grinding suitable materials (metal etc).

20V Cordless Angle Grinder AG2

Table of Contents

Safety...................................................................................................................................................2

Parts Identification.............................................................................................................................6

Batteries and Battery Charging........................................................................................................7

Charging ....................................................................................................................................................7

Inserting and Removing the Battery Pack..................................................................................................7

Assembly ............................................................................................................................................8

Operation ............................................................................................................................................9

Cutting and Grinding ..................................................................................................................................9

Guidelines for Use......................................................................................................................................9

Maintenance and Troubleshooting ................................................................................................10

Changing the Disc.................................................................................................................................... 10

Troubleshooting .......................................................................................................................................11

Specifications...................................................................................................................................11

20V Cordless Angle Grinder AG2

Parts Identification

Note that some cutting discs / accessories may come supplied with the tool.

No. Name No. Name

1 Tool Body / Main Handle 7 Disc Collar

2 Disc Guard 8 Typical Disc

3 Secondary Handle (shown installed) 9 Battery

4 Spindle Lock 10 Pin Spanner

5 Trigger 11 Battery Charger

6 Trigger Safety Switch

2

3

10

1

6

9 5 8

7

4

11
