Baxton Studio 257C User manual

ASSEMBLY INSTRUCTION MODEL : 257C
Read this instruction carefully. Remove all wrapping material, staples and straps
from the carton. See hardware and furniture part list for guidance. Be sure you
have all wooden furniture parts on a clean and flat soft surface, such as a carpet or
rug, to prevent from being scratched.Follow the figure to start assembling.
CAUTION :
1. Do not FULLY - TIGHTEN the nut or screw untill all is ready to assemble.
2. Do not OVER - TIGHTEN the nut or screw to avoid causing damages to the thread.
3. Keep all hardware part out reach of children.
COMPLETE
ASSEMBLE
STEP 4
PART LIST
NO QTY
ABACK REST
BFRONT LEG
CSIDE RAIL 2 PCS
DWOODEN SEAT 1 PC
1 PC
1 PC
DESCRIPTION
NO QTY
1
JCBC SCREW M6 X 50MM 2 PCS
2
3
4
SPRING WASHER 6 PCS
M4 ALLEN KEY 1 PC
CSK SCREW M4 x 30MM
WOOD DOWEL Ø8 x 30MM 4 PCS
55
6
E
JCBC SCREW M6 X 70MM 4 PCS
F
CENTER SUPPORT 1 PC
WOOD BUTTON 4 PCS
4 PCS
STEP 1.1
Firstly, stick E to C for both left and
right side.
C
E
STEP 1.2
Then, attached STEP 1.1 to B
according to the hole and tighten it
using hardware number 2,3,4 and 6.
2
3
4
C
6
C
B
STEP 2
Continued with combine the whole
part from STEP1.2 to A . Tighten the
part of C and A using hardware
number 3,1 and 6 . Then cover the
hole with F.
C
A
31
6
C
STEP 3
Stick the whole assemble part to D
according to the marked and
fully-tighten it with hardware number 5 .
WOODEN
SEAT
5 X 4PCS
F
D
A

STEP 1
Attached B to A according to the hole and tighten it
using hardware number 1,2,3, and 4 .
MODEL : 7006T
ASSEMBLY INSTRUCTION
Read this instruction carefully. Remove all wrapping material, staples and straps from the carton. See
hardware and furniture part list for guidance. Be sure you have all wooden furniture parts on a clean and
flat soft surface, such as a carpet or rug, to prevent from being scratched.Follow the figure to start
assembling.
CAUTION :
1. Do not FULLY - TIGHTEN the nut or screw untill all is ready to assemble.
2. Do not OVER - TIGHTEN the nut or screw to avoid causing damages to the thread.
3. Keep all hardware part out reach of children.
PART LISTNO QTY
ATABLE TOP
BTABLE LEG 4 PCS
1 PC
DESCRIPTIONNO QTY
1
2
3
4
COMPLETE ASSEMBLE
8 PCS
1 PC
8 PCS
8 PCS
JCBC M6 x 70mm
FLAT WASHER 6 / 19"
SPRING WASHER 6 / 13"
M4 ALLEN KEY
4
B
A
1
2
3
B
B
A
B
B
