Racking Solutions WD002 User manual

Chrome 3-Tier Wardrobe
WD002
PACKAGE CONTENTS
Please inspect box contents to ensure you have received all components.
Note: the black circular plastic tops in between the shelves are used only for
packaging purposes. They are NOT NEEDED. Please discard responsibly
Total weight capacity of is 80 kg on casters.
& keep away from small children.
DX24+2
AX3 BX4 CX4
Shelf Bottom Pole (with threaded
insert pre-installed)
Top Pole (with end cap and
pole connector pre-installed)
extra Slip sleeve
EX4 FX2
GX2 HX1
Casters
(2 locking; 2 non-locking) Screw
Hanging Rod Bracket Hanging Rod
HELP LINE
01977 555007
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED
Never climb or stand on the shelves.
Informaon
if in doubt contact the supplier
Allow adequate working space and be
aware of others working around you
Inspect all packages for damage and
check that all components have been
supplied
Cauon
During Assembly
!
Warning
Rules for safe use of shelving
!
ENSURE THAT THE MAXIMUM LOAD
CARRYING CAPACITIES ARE NOT
EXCEEDED
Dispose of packaging materials
responsibly
Wear appropriate clothing -protecve
gloves and footwear are
recommended
Make sure the floor is level
Take care when handling heavy items
parcularly when liing or stretching
Please read these instrucons
throughly before commencing
assembly.
Assembly should be undertaken by
at least two people
Not suitable for use in damp or wet
environments.
Shelves must be loaded evenly, and load
heavier items on the boom shelves
Rubber Mallet

ASSEMBLY INSTRUCTIONS
STEP 2: SLIP SLEEVES
STEP 1: ASSEMBLING THE CASTERS
On the Bottom Pole (B), place 1 pair of slip sleeves (D) at the desired level.
Screw each Caster (E) into the bottom of each Bottom Pole (B). Turn
clock-wise to screw in place. Screw in tightly.
Please make sure the arrow faces up and that the word “top” is right side
up. Do this for each Bottom Pole (B) and make sure that the heights are
identical for Bottom Pole (B).
Slide the pair of Slip Sleeves (D) until you hear a click to confirm the pair is
locked onto the Bottom Pole (B).Do not place more than one pair
on each Pole (B) at a time.
*For safety and stability, the lowest SHELF (A) should be lower than the 3rd
notch from the bottom.
**Note: There will be a very small gap in-between the Slip Sleeves (D)-this
is normal.
STEP 3 : INSTALLING THE SHELF
STEP 4 : INSTALLING TOP POLES
Place The Shelf (A) on its side and slide the Bottom Pole (B) through the
holes in the Shelf (A). Make sure that the shelf (A) corner cylinders are
positioned over the Slip sleeves (D).
Stand the unit upright.
Repeat step 2 & 3 for the other shelf.
*Note : The level side of the Shelf (A) is the Top side(the logo on the
corner cylinders should be right-side up.)
**Use a rubber mallet, if needed, to secure the Shelf (A).
Screw the Top Pole (C) into the Bottom Pole (B). The tops of these poles .
are indicated by the black end up.
STEP 5: INSTALLING TOP SHELF
On Pole (B+C), place 1 pair of slip sleeves (D) at the highest position.
Slide shelf (A) onto the Slip Sleeves (E)
STEP 6: INSTALLING HANGING ROD
Hang the Hanging Rod Bracket (G) on both ends of the top Shelf as shown.
Fasten the screws (F) through Hanging Rod Bracket (G) to Hanging Rod
(H). Do this for both Hanging Rods (H).
STEP 7: FINISH
AND ENJOY YOUR QUALITY
RACKING SOLUTION PRODUCT
