Baylan BT.11 User manual

IMPORTANT POINTS AND SAFETY
• Wiring the meter up to the network must be done by the person who has
knowledge about both technical and safety warnings.
• The meter parts which are carrying voltage must not be touched for any reasons,
electricity must be cut off while both wiring on and wiring off to the network.
• The outer surface of the meter must not be cleaned with cleaning agents
containing abrasives.
• The suitability of the meter type to be installed should be checked by authorised
personnel. Otherwise, your meter will be damaged due to incorrect meter selection
and connection. The meters in this case are out of guarantee.
• Calibration and programming of the meter are done during manufacturing.
Marketing is provided after each meter quality check. There is no maintenance or
programming that the user can do.
• BAYLAN Electronic Electricity Meters is a superior technology product in
compliance with world standards. All technical information and documents are in
the company's own Intellectual properties and copyright’s.
TECHNICAL SPECIFICATIONS
Model Name BT.10
Meter Type 3-Phase, 4-Wire
Accuracy Class B
Connection Type Direct
Nominal Voltage (Un) 3x230/400 V
Operating Voltage Range 0,8 Un and 1,15Un
Reference Frequency 50 Hz ±%5
Starting Current (Ist) 20mA (0,04.Itr)
Minimum Current (Imin) 0,25 A
Transitional Current (Itr) 0,5 A
Nominal Current (In) 5 A
Maximum Current (Imax) 100 A
IP Rating IP54 (Outside)
Protective Class Two (2)
Humidity Ratio Max. %95
Operating Temperature -40 °C, +70 °C (3K7)
Mechanical Environment Class M1
Electromagnetic Environment Class E2
Voltage Circuit Power Consumption < 2W, 10 VA
Current Circuit Power Consumption < 4 VA
Electrostatic Discharges Contact discharge 8kV, air discharge 15kV
Impulse Voltage 6 kV
Meter Constant 1000 imp/kWh
LCD Display 6+3
Communication Optical 300-19200 Baud (EN 62056-21)
Battery Life ≥ 10 year / 4 year
RTC Accuracy < 0,5sec/day (EN 62054-21)
Standards EN 50470-1, EN 50470-3
GENERAL FEATURES
• Eight different time zones can be set during the day and saved in one of four
different tariffs. It is possible to create different time zones and different tariffs for
4 different day types (weekdays, saturday, sunday and public holidays).
• Automatic daylight save implementation.
• Tariff informations, meter date and time, daylight saving time can be changed by
authorized personnel.
• If the top cover is opened, it records the opening date and time.
• If the terminal cover is opened, it records the first opening date for each month
and the total number of openings in that month. The last 12 months are stored in
memory.
• In the case of magnetic tampering, it records the start and end times.
• The meter records the consumed energy for each tariff in the last 12 months, the
maximum demand in the last 12 months and the date and time of the demand.
• Meter can record 8 channel load profile for period of 15 minutes for last 180
days. (Optional)
• The meter records the last 10 of voltage connection faults and current connection
faults.
• The meter records the start and end dates of the last 99 of short and long power
cuts.
LCD INFORMATION
Main menu
Information
Date information
Time information
Total energy consumption
Energy consumption during 1st Tariff
Energy consumption during 2nd Tariff
Energy consumption during 3rd Tariff
SPECIAL Energy consumption in the 4th Tariff *
Max. demand information
Max. demand date information
Max. demand time information
Obis code
0.9.2
0.9.1
1.8.0
1.8.1
1.8.2
1.8.3
1.8.4
1.6.0
1.6.0
1.6.0
Unit
day:month:year
hour:minute:second
kWh
kWh
kWh
kWh
kWh
kW
day:month:year
hour:minute
READING THE INFORMATION ON THE METER
• When the meter is powered, the main informations of the meter displayed
sequentally with 5 second periods. By pressing the button, the next information can be
switched quickly. If the button is pressed for 5 seconds, the meter screen switches to the
sub menu. Waits for the button to be pressed again to display the next information. If
the button is not pressed for 30 seconds or the button preesed for 5 seconds, meter
display returns to the main menu.
• When during power cuts, it is necessary to press the button to see the information on
the screen. Each press displays the next information.
• All the datas that the meter records and the datas which display on LCD can be read
from the meter with the communication interfaces. When during power cuts, the button
must be pressed to wake up the meter to read.
RTC Error
Low battery.
If the top cover is opened, it will flash on the screen and it will not be lost
under any circumstances.
If the terminal cover is open, it will be displayed continuously on the
screen. If it is flashing, it indicates that the terminal cover has already
been switched on and off.
Indicates the tariff slice.
T1 T2
T3 T4
The display shows which tariff consumption information is available.
RTC battery low.
Blinks during magnetic intervention. Continuous display on the screen
indicates that a magnetic interference has been made before.
It is visible during communication.
It shows the energized phases and current directions.
Indicates that information about the demand is displayed.
P
L1 L2 L3
Units
HzVAkWh
BT.11
Three Phase Active Electronic Electricity Meter
User Manual
BAYLAN
ELECTRICITY METERS
BAYLAN ÖLÇÜ ALETLERİ SAN. ve TİC. LTD. ŞTİ.
Headquarters: A.O.S.B. 10032 Sk. No:16 Cigli - IZMIR / TURKEY
Production: A.O.S.B. 10053 Sk. No: 6 Cigli - IZMIR / TURKEY
Tel: [phone] •Fax: [phone]
e-mail: [email protected] •web: www.baylanelektrik.com
YÖNETİM SİSTEMİ
BELGELERİMİZ
1783
Test
TS EN ISO/IEC 17025
AB-0177-T
Management
System
ISO 9001:2015
www.tuv.com
ID 9000004716

LCD INFORMATION
Sub Menu
Information
Serial no
Program version
Top cover opening date
Top cover opening time
Terminal cover opening date
Terminal cover opening time
Instant voltage of the first phase
Instant voltage of the second phase
Instant voltage of the third phase
Instant current of the first phase
Instant current of the second phase
Instant current of the third phase
Instant Frequency
Instant Active Power
Obis code
0.0.0
0.2.0
96.70
96.70
96.71
96.71
32.7.0
52.7.0
72.7.0
31.7.0
51.7.0
71.7.0
14.7.0
16.7.0
Unit
day:month:year
hour:minute
day:month:year
hour:minute
V
V
V
A
A
A
Hz
kW
NOTICE
This guarantee which is provided by Baylan Ölçü Aletleri San ve. Tic. Ltd Şti. does
not cover the remedies that may arise from normal or unintended use of the device
as well as,
1- Damages and failures due to misusage,
2- Damages and failures occurring, after delivery to the user, during transportation,
loading and unloading,
3- Failure to make the installation according to the installation and operating
instructions and faulty connections,
4- Products for which the warranty label is torn or seals are broken,
5- Fire, lightning, flood and earthquake (natural disasters), malfunctions and
damages due to improper environment and accidents,
6- In the event of unauthorized intervention of the device for reparing,
7- In case of the warranty label is damaged.
The repair cost is charged to customer. The warranty is valid only for the product
failure within warranty period specified below. Warranty is invalid; when the original
serial number on the device is removed, destroyed or tampered with, or warranty
certificate is damaged
8) The consumer may apply to the Consumer Arbitration court or the Consumer
Court where the settlement is located or where the consumer transaction is made
during the disputes that may arise in connection with the exercise of the rights arising
from the guarantee.
9) In case of Warranty Certificate is not issued by the seller, the consumer may apply
to the General Directorate of Protection of the Consumer and the Market
Surveillance of the Ministry of Customs and Trade.
WARRANTY CONDITIONS
1) Warranty period starts after delivery date of the product, and valid for 5 years.
2) Products and all spare parts are under the guarantee of our company.
3) In case the meter is defective, the consumer shall be deemed to have the right to
inspect the goods within the scope of Article 11 of the Act on the Protection of
Consumer No 6502;
a- Withdraw the contract
b- Request reduction from sales price
c- Request free repair
d- Right to request that the sold product be replaced with a indefective duplicate.
4) If the consumer chooses the right of free repair from these rights; the manufacturer
must bear the cost of labour, the cost of replacing parts without any charge to the
make repair. The consumer can also use the free repair right against the manufacturer.
The seller and producer are jointly responsible for using this right of the consumer.
5) In case the customer uses the right for free repair;
* Another failure during warranty period
* Exceeding the target time to get repair;
* If repairs are not possible, by a report by an authorized service station, dealer,
manufacturer or importer. Consumer may request to replace the meter with the one
which freed from defects, discount the price regarding the defect ratio or refund the
meter price from the seller. The seller can not refuse the consumer's request. If this
request is not fulfilled, the seller and producer are jointly liable.
6) The repair period of the goods can not exceed 20 business days. This period starts
from the delivery date of the goods to the authorized service station on the date of
notification to the authorized service station or vendor within the warranty period, and
to the authorized service station if the goods are out of guarantee period. If the
malfunction can not be fixed within 10 working days, until the completion of the repair
of the goods, has to allocate another product with similar characteristics to the use of
customer. In case of malfunction within the warranty period, the period of repair will be
added to the warranty period.
7) Defects arising from unauthorized use of the goods are not covered by the
guarantee.
INSTALLATION INSTRUCTION:
1. Energy must be cut off when assembling and disassembling the meter.
2. Phase connection and neutral connection must be done according to the connections
diagram. (When making connections, it is necessary to make sure that the ends of the
cables are properly opened, the screws in the connection terminals are tight enough so
that they do not damage the conductors, and there is no faulty connection).
3. Make sure that the meter terminal cover closes without tension.
4. Meter starts working only when installed and energized, thus the screen starts
displaying informations.
5. If L1L2L3 symbols are flashing on the display, there is a phase sequence fault in the
connections.
6. If lock symbol 2 appears on the display, the terminal cover is not installed correctly.
WIRING DIAGRAM:
The inner diameter of the phase and neutral terminals of the BT.11 is 7,5 mm.
NN
1
R R
3
S S
4 6
T T
7 9 10 11 12 13
Optical
Port
LCD Display
Button
Terminals
cover
seal
Top cover
seal
BAYLAN
146
155
BAYLAN BAYLAN
The use of this document was authorized by Republic Of Turkey Ministry of Customs and Trade, Directorate General of Consumer Protection and Market Surveillance according to The Law on Consumer Proteciton No. 4077, and Application of the Guarantee Certificate communique based on this law. It is valid for all models in production. * The serial number will be the same as the number written on the meter and will be filled by the vendor.
MANUFACTURER COMPANY Brand :
BAYLAN ÖLÇÜ ALETLERİ San. ve Tic. Ltd. Şti.
Addres :
AOSB, 10053 Sk. No:6
Cigli-IZMIR
Tel : [phone] Fax : [phone] E-mail : [email protected] Date : Signature : Stamp : Type : Electronic Electricity Meter Brand : BAYLAN Model : BT.11
SELLER COMPANY Brand : Addres : Tel : Fax : E-mail : Invoice Date and No : Date : Signature : Stamp : Warranty Period : 5 Years Max. Time To Repair : 20 day Serial No :
BAYLAN
WARRANTY CERTIFICATE
PRODUCT
BAYLAN
1783
Management System ISO 9001:2015
www.tuv.com ID 9000004716
RS485
A B
216
56,3
