UFM CoolPoint CP2-V8 User manual

CPBatMan080212
CoolPoint
®
Installation and Operation Manual
Vortex Shedding Flowmeters
Series:
CP-V8 Battery operated
UNIVERSAL FLOW MONITORS, INC.
1755 East Nine Mile Road PO Box 249
Hazel
Park, MI 48030-0249
TEL [phone] FAX [phone]
Website: http://www.flowmeters.com

1 CPBatMan080212
UNIVERSAL FLOW MONITORS, INC.
TABLE OF CONTENTS
CONTENTS
TABLE OF CONTENTS....................................................................................................................................... 1
PROPRIETARY NOTICE.................................................................................................................................. 2
USING THIS MANUAL...................................................................................................................................... 2
QUICK SET UP............................................................................................................................................................ 3
INSTALLATION..................................................................................................................................................... 4
GENERAL SPECIFICATIONS....................................................................................................................... 5
OPERATION............................................................................................................................................................ 6
APPLICATIONS .................................................................................................................................................... 6
MODEL CODES........................................................................................................................................................... 7
PRESSURE DROP CHARTS.................................................................................................................................... 7
DIMENSIONS.............................................................................................................................................................. 8
RMA NOTICE RETURN MERCHANDISE AUTHORIZATION................................................ 9
RMA FORM............................................................................................................................................................ 11
WARRANTY INFORMATION.................................................................................................................... 12

2 CPBatMan080212
UNIVERSAL FLOW MONITORS, INC.
PROPRIETARY NOTICE
The information contained in this publication is derived in part from proprietary and patented data
and has been prepared for the express purpose of assisting in installation, operation, and
maintenance of the instruments described herein. Publication of this information does not convey
any rights of use or reproduction other than in connection with the installation, operation and
maintenance of the equipment described herein. Universal Flow Monitors, Inc. reserves the right
to change the information contained in this publication at any time and without prior notice.
USING THIS MANUAL
In order to use this manual, you will need the model code that can be found on the nameplate of
the flowmeter, as shown on the example below (see MODEL CODES). The Model Code allows you
to determine minimum and maximum flow capabilities, as well as pressure drop for various sizes.
NAMEPLATE EXAMPLE – CP6-V8

3 CPBatMan080212
UNIVERSAL FLOW MONITORS, INC.
QUICK SET UP
PIPING
Install in pipe making sure to orient IN port to flow supply.
10 pipe diameters distance is required upstream and 5 down for best accuracy.
Use proportional spacing if this much space is not available.
50 pipe diameters are required upstream as distance from a valve.
No use of Teflon tape please. (See detailed piping instructions.)
CONFIGURATION OF METER
At start up , display shows 1.888.8.8 showing that its digits are all functional
18888.8.8
Then model is shown
CP6 1.0
Example
Run mode achieved. Flow rate displayed at 0 flow is 0.
0.00
Note that if no adjustments are made, GPM displays.
SELECTING GPM, LPM OR CMH
Depress MENU button to display flow in GPM, LPM or CMH.
TOTALIZER FUNCTION
Depress SELECT button to display total flow. To change between total in GPM, LPM or CMH,
depress MENU button after entering totalizer mode.
Resetting total: Depress and hold both MENU and SELECT buttons to reset the totalizer. TOTAL
will blink 3 times.

4 CPBatMan080212
UNIVERSAL FLOW MONITORS, INC.
INSTALLATION
For best results, the meters may be installed in any position as long as proper piping installation
requirements are observed. This includes sufficient support of adjacent piping to minimize the
system’s inherent vibration. Unions of the same pipe size and full port isolation ball valves may be
installed for ease of removal and servicing of equipment, if necessary. Meters should be placed in
horizontal, slightly ascending runs or vertical runs to prevent trapped air from accumulating in the
meter. Furthermore, the meters should not be placed at the highest point in the piping. The
piping system should be filled slowly to prevent water hammer from damaging the flow sensor.
Please note that reverse flow can also damage the flow sensor.
In order to achieve the stated accuracy, a straight pipe run of 10 pipe-diameters (minimum) is
required upstream of the meter, as well as 5 pipe-diameters downstream. Isolation ball valves,
when used, should be in the full open position. Throttling valves should always be placed
downstream of the meter. A minimum straight run of 50 pipe-diameters is required between an
upstream valve and the flowmeter.
If Teflon® tape or pipe sealant is used, the user must ensure that no loose parts become
wrapped around the bluff or the flow sensor when flow starts.
Use of diaphragm or piston pumps affects the meter’s performance unless they are installed with
a properly sized pulsation dampener and pressure control. The piping system must create some
backpressure on the meter to allow vortex formation and to prevent cavitation, especially at full
flow. Minimum required backpressure is 10 PSIG at maximum flow and at 70 °F (21 °C). Higher
backpressures are required at elevated temperatures and occasional surges to 125% of maximum
flow.
In rare situations, the user may notice an intermittent flow display that drops off while the flow is
held steady. In this case, please contact UFM to discuss the backpressure requirements.

5 CPBatMan080212
UNIVERSAL FLOW MONITORS, INC.
GENERAL SPECIFICATIONS
Maximum Operating Pressure: 300 PSIG (20.4 Bar)
Minimum Operating Pressure: 10 PSI of back pressure is required for the formation of
vortices. See INSTALLATION and PRESSURE DROP CHARTS
Maximum Operating Temperature: 130 °F (54 ºC). Rating applies to both fluid & ambient temp.
Minimum Operating Temperature: 35 °F (2 ºC). Rating applies to both fluid & ambient temp.
Maximum Flow: Meters may occasionally be over-ranged up to 125% of
capacity without damaging the meter (display reads up to
125% of max flow)..
Flow Capacities: 3/4" = 25 GPM (95 LPM)
1" = 50 GPM (190 LPM)
1 1/2" = 100 GPM (380 LPM)
2" = 200 GPM (750 LPM)
Turndown Ratio (max to min flow): 10:1 standard.
Process Connections: Female NPT with BSPP and BSPT optional
Wetted Parts: Body is brass or 316 Stainless Steel. Sensor is PVDF or PEEK.
Seals are Viton®
Display: 3-digit LCD
6-digit LCD (Totalizer mode only)
Displays in GPM, LPM and CMH
Digit height = 0.3"
Power: 3 AA Alkaline batteries. Provides 45 days of continuous
operation (longer if flow measurement is intermittent – up to 1
year)
Low Battery: “Mode” LED blinks red.
Enclosure rating: Designed to meet the requirements of IP67
Accuracy: 2% Full scale
Response Time: 450 ms.
Repeatability: .25% of indicated
*Viton®is a registered trademark for DuPont Performance Elastomers.

6 CPBatMan080212
UNIVERSAL FLOW MONITORS, INC.
OPERATION
CoolPoint is an inline flowmeter that utilizes the vortex shedding principle. The fluid strikes a
bluff body, generating vortices (eddies) that move downstream. The vortices form alternately,
from one side to the other. A piezoelectric sensor housed in a sensor tube directly downstream of
the bluff senses the pressure zones created by the vortices. The sensor generates a frequency
directly proportional to the vortices (flow). The pulses are then amplified by the circuit board and
converted to an output, which is also linear with flow. Flow is displayed on the LEDs in either GPM,
LPM or CMH. Selection of the preferred units of measure is made by using the MENU pushbutton.
APPLICATIONS
CoolPoint can be used on low viscosity, clean or dirty water-like liquids that are compatible with
brass, PVDF and Viton. Metered fluids should not include long fibers or a significant level of
abrasive solids. Should abrasive wear occur over time, bluffs as well as the sensors are
replaceable. Typical applications include cooling loops using water, 50% solutions of glycol, and
water-soluble machine coolant (up to 10%). These applications are found in most process
industries, including rubber, steel, fabrication, manufacturing, refining, paper, chemical, food,
petrochemical and power. They cannot be used on gases (including air), or on flammable liquids.
Note: If used outside the parameters specified in this manual, the proper operation of the
flowmeter cannot be guaranteed.
Cleaning: These meters do not require any special cleaning of the external surfaces. If cleaning is
deemed necessary, strong solvents, detergents, or chemicals should not be used. A damp cloth
may be used to wipe off dirt or debris.

7 CPBatMan080212
